Lancaster CBF054_037P User manual

MODEL: CBF054_037P
VM Innovations
ASSEMBLY INSTRUCTIONS
ATTENTION
Contact
MD Sports
Customer Service
DO NOT RETURN
TO THE STORE
* For additional resources and Frequently
Asked Questions, please visit us at
themdsports.com

www.themdsports.com
CBF054_037P 1
(Continued on the next page.)
NOTICE!
This product is covered by a limited warranty that is effective for 90 days from the date of purchase. If, during the limited
warranty period, a part is found to be defective or breaks, we will offer replacement parts at no cost to you, the customer. The
only exceptions to the warranty include mainframes, table tops, playing surfaces, batteries or tools.
The above warranty will not apply in cases of damages due to improper usage, alteration, misuse, abuse, accidental damage
or neglect.
This Limited Warranty gives you specific legal rights and you may also have other rights which vary from one State (province)
to another.
A PURCHASE RECEIPT (or other proof of purchase) will be required before any warranty service is initiated. For all
requests for warranty service, please feel free to contact our
Consumer Service Department at :
WEBSITE: www.themdsports.com
Please be aware of your product’s Limited Warranty for the return/refund policy from the store, We, at Medal Sports, can not
handle the product which is out of product’s limited warranty since we only provide available parts. Thank you!
PLEASE CONTACT US BEFORE RETURNING
THE PRODUCT TO THE STORE.
LIMITED 90 DAYS WARRANTY
STAPLE YOUR RECEIPT HERE
1 - Please leave your name, address, phone number, model number, parts needed on the answering machine if there is no
attendant. Failure to do so will result in a delay in shipping parts to you.
2 - Please review the replacement parts list and make sure that you have all of your parts before beginning assembly.
For questions that may arise or for missing/damaged parts, please contact us.
3 - Since you build all tables upside down, please inspect tabletops or playing surfaces right away before putting together, all
damaged table tops/playing surfaces need to be returned to the store. Please contact with retailer for their return policy.

www.themdsports.com
CBF054_037P 2
(Continued on the next page.)
Phillips Screwdriver - Not Included
Standard (Flat Head Screwdriver) - Not Included
Wrench - Included
Allen Key - Included
CAUTION!
Electric Screwdrivers may be helpful during assembly; however, please set a low torque and use
extreme caution.
1 - This product is intended for INDOOR use only.
2 - Please do not sit, climb or lean on the product.
3 - Please do not drag the product when moving it in order to avoid damaging the legs.
4 - Please only use spray furniture polish to clean the exterior surfaces of the product.
5 - This is not a child's toy, adult supervision is required for children playing this game.
Power Tools
- Set Low Torque
High Torque
over tightened
WARNING:
Adult Assembly Required.
WARNING:
CHOKING HAZARD 
TOOLS REQUIRED
ASSEMBLY TIPS
IMPORTANT NOTICE!
Strong Adults Needed No Children in
Assembly Area Keep away from pets
Do not use or keep product
outdoors. For indoor use only.
No wet/humid conditions.
X2
1 - Please read the instructions carefully, and follow all assembly, operation and safety instructions properly in order to avoid
damage or injury. For the assembly, at least two adults are required.
2 - Some figures or drawings may not look exactly like your product. Please read and understand the text before beginning each
assembly step.

CBF054_037P PARTS LIST
www.themdsports.com
CBF054_037P 3
(Continued on the next page.)
x1
FOR FIG. 1
1
Hockey Mainframe
x1
FOR FIG. 2
2
Billiards Playfield
x2
FOR FIG. 14
3
Top Rail
x2
FOR FIG. 5
4
End Apron - A
x2
FOR FIG. 6
5
Ball Shelf
x2
FOR FIG. 6
6
End Apron - B
x2
FOR FIG. 11
7
Side Leg Panel
x2
FOR FIG. 4
8
Left Leg
x2
FOR FIG. 4
9
Right Leg
x4
FOR FIG. 11
10
Side Leg Brace
x2
FOR FIG. 9
11
Apron Corner - Left
x2
FOR FIG. 9
12
Apron Corner - Right
x2
FOR FIG. 3
13
Side Pocket Cap
x4
FOR FIG. 3
14
Corner Pocket Cap
x4
FOR FIG. 4
15
Leg Leveler
x2
FOR FIG. 9
16
End Apron - C
x2
FOR FIG. 14
17
Felt Pad
x1
FOR FIG. 18
18
Hover Puck
x2
FOR FIG. 14
19
Pusher
x1
20
Billiard Ball Set
x1
21
Triangle
x2
22
Cue
x1
23
Brush
x2
24
Chalk
x2
25
Table Tennis Ball
x2
26
Table Tennis Paddle
x1
FOR FIG. 16
27
Table Tennis Net
x2
FOR FIG. 16
28
Table Tennis Post
x1
FOR FIG. 15
29
Bowling Set
x1
30
Wrench
x1
31
Allen key
x4
FOR FIG. 5
32
Locking Pin

CBF054_037P PARTS LIST
www.themdsports.com
CBF054_037P 4
(Continued on the next page.)
CBF054_037P PRE-INSTALLED PARTS
x4
FOR FIG. 1
33
Corner Pocket
x2
FOR FIG. 1
34
Side Pocket
x4
FOR FIG. 1
35
Plastic Strip
x2
FOR FIG. 13
36
Hockey Goal
x8
FOR FIG. 12
37
5x28mm Zinc Bolt
x12
FOR FIG. 11
38
5x28mm Bolt
x8
FOR FIG. 12
39
5mm Zinc Washer
x12
FOR FIG. 11
40
5mm Washer
x20
FOR FIG. 3, 5
41
3x12mm Flat Head Screw
x8
FOR FIG. 14
42
4x32mm Zinc Screw
x8
FOR FIG. 1
43
3x18mm Screw
x26
FOR FIG. 2, 6, 10
44
3.5x25mm Screw
x16
FOR FIG. 1, 7
45
4x12mm Screw
x12
FOR FIG. 8
46
3.5x38mm Zinc Screw
x2
FOR FIG. 1
47
10x45mm Bolt
x4
FOR FIG. 1
48
10mm Washer
x16
FOR FIG. 9, 10
49
3x12mm Round Head Screw
x2
FOR FIG. 1
50
Bushing
x1
FOR FIG. 18
51
USB Power Cord
x4
FOR FIG. 13
52
5x38mm Butterfly Bolt
x4
FOR FIG. 1
P1
Locking Seat
x4
FOR FIG. 4
P2
8mm T - Nut
x20
FOR FIG. 11, 12
P3
5mm T - Nut
x2
FOR FIG. 1
P4
Square Nut with Screws
x8
FOR FIG. 12
P5
Barrel Nut

www.themdsports.com
CBF054_037P 5
(Continued on the next page.)
FIG. 1
X 1
1
X 4
33
X 2
34
X 4
35
X 8
43
X 12
45
ASSEMBLY INSTRUCTIONS:
1. Find a clean, level place to begin the assembly of your Product.
2. Remove all the parts from the box and verify that you have all of the listed parts as shown on the Parts list pages.
Carefully cut or tear the four corners of the box so that the bottom of the box can be used as your work surface.
35
43
P1
35
1
50
47
48
P4
FIG. 1B
FIG. 1C
45
34
FIG. 1A
33
45
Note: DO NOT insert Bolt (#47)
all the way. See FIG. 13B for details.
X 2
47
X 4
48
X 2
50
X 4
P1
X 2
P4
X 1
30

www.themdsports.com
CBF054_037P 6
(Continued on the next page.)
FIG. 2
X 1
2
X 18
44
FIG. 3
X 2
13
X 4
14
X 12
41
2
44
1
44
2
1
14
14
14
13
FIG. 3A
14
41
13
41
FIG. 3B

X 4
P2
www.themdsports.com
CBF054_037P 7
(Continued on the next page.)
FIG. 4
X 2
8
X 2
9
X 4
15
FIG. 5
X 2
4
X 4
32
X 8
41
15
P2
9 & 8
Pin
4
32
41
32
FIG. 5A
Locking Pin
IMPORTANT: Make sure that
the Pin from the Locking Pin
is in the direction that is shown.
Note: Be sure that the holes
are on the outside.

www.themdsports.com
CBF054_037P 8
(Continued on the next page.)
FIG. 6
X 2
X 2
5
6
X 4
44
44
5
5
6
6
FIG. 7
X 4
45
FIG. 6 Assembly
45
FIG. 5 Assembly

www.themdsports.com
CBF054_037P 9
(Continued on the next page.)
FIG. 8
FIG. 9
46
46
9
8
FIG. 7 Assembly
X 12
46
X 2
X 2
11
12
X 2
16
X 8
49
49
16
11
12

www.themdsports.com
CBF054_037P 10
(Continued on the next page.)
FIG. 10
X 4
X 8
44
49
FIG. 9 Assembly
FIG. 8 Assembly
44
49
FIG. 11
X 2
X 4
7
10
X 12
X 1
31
38
X 12
40
X 12
P3
10
7
10
40 38
FIG. 11A
P3
10

X 1
31
www.themdsports.com
CBF054_037P 11
(Continued on the next page.)
FIG. 12
X 8
X 8
37
39
X 8
P3
X 8
P5
FIG. 10 Assembly
FIG. 11 Assembly
P5
P3
39 37
FIG. 12A

www.themdsports.com
CBF054_037P 12
(Continued on the next page.)
FIG. 13
X 2
X 4
36
52
X 1
30
Top View of correct Swivel Bolt
and Washer Placement
52
36 36
1
4
47
48
48
50
32
32
FIG. 13B
FIG. 13A FIG. 13C
FIG. 3 Assembly
FIG. 12 Assembly
Note: Keep the Locking Pins (#32) open. Note: Close the Locking Pins (#32)
to secure the Mainframe (#1).
50
Note: Slide the FIG. 3 Assembly into the
FIG. 12 Assembly, then tighten the Bolts.

www.themdsports.com
CBF054_037P 13
(Continued on the next page.)
FIG. 14
FIG. 15
X 2
X 2
3
17
X 2
19
X 8
42
4
42
3
3
19
17
17
Note: Make sure that the
Locking Pins are closed
to secure the mainframe.
Note: Peel off the felt from the Felt Pads (#17)
and attach to the bottom of the Pushers (#19).
FIG. 14A
FIG. 14B
X 1
29
Bowling Set
Note: Be sure to remove the Hockey
Goal setup before attaching the
Table Tennis Net & Post.
52
36
FIG. 15A

www.themdsports.com
CBF054_037P 14
(Continued on the next page.)
FIG. 16
X 1
X 2
27
28
28
27
Note: Make sure that the
Locking Pins are closed
to secure the mainframe.
FIG. 17
32
Note: Open the Locking Pins.
Note: To complete this step, the billiards
side must be facing upwards. If not,
disengage all 4 Locking Pins (#32), swivel
the table and then re-engage the Locking
Pins.
FIG. 17A
FIG. 17B

FIG. 18
X 1
X 1
18
51
www.themdsports.com
CBF054_037P 15
(The last page)
YOU ARE NOW READY TO PLAY!
CHARGER IN
OFF
MADE
IN OHINA
ON
DC
6V
USB Power
CHARGER IN
OFF
MADE
IN OHINA
ON
DC
6V
Charging in
Switch
18
51
Note: To operate the Hover Puck (#18), just turn on the Switch
on the underside of Hover Puck to the ON position. The Hover
Puck will operate for 20-30 minutes when fully charged.
Note: Make sure that the Hover Puck (#18) is
turned to the OFF position. Plug the USB
Power Cord (#51) into the back of the Hover
Puck (#18) . Allow the Hover Puck to charge
for 60 minutes.
Note: Insert USB Power Cord (#51)
into the USB Power plug.
