Landworks GUO021-FBA User manual

Instruction Manual
REV 06/11/19
Gas Powered Earth Auger
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.

IMPORTANT SAFEGUARDS
For your own safety, always follow these basic precautions when using
this appliance.
1. Read the user Manual carefully for operating instructions. Read all instruc-
tions in this manual before use.
2. DO NOT use this product for anything other than its intended purpose.
3. DO NOT use attachments other than those available from the manufacturer.
4. DO NOT alter this product in any manner; doing so is dangerous and will void
all warranties.
5. DO NOT allow children or adults weighing under 100 lbs. to operate this unit.
6. DO NOT allow your body, loose clothing, drawstrings, scarves, hats or other
materials to touch the power head, or auger (drill) unit at any time.
7. DO NOT operate under the influence of drugs or alcohol.
8. DO NOT continue to use this product in the event of mechanical or electrical
failure.
9. The blades are very sharp. Use extreme caution when drilling a hole or
replacing the blades. Put the blade guard on after each use.
10. This product produces considerable cutting force that is felt by the operator.
Make sure your feet are firmly planted and the handles are firmly held while
operating this product.
11. During operation, the auger unit could possibly stop. Be prepared at any
time to release the buttons.
12. Check cutting blades and auger shaft screws before and after each use to
make sure they are tight.
13. The battery must be removed before any repairs.
14. When drilling the holes, do not push down on the unit. If auger begins to drill
slowly, blades may need to be sharpened or replaced.
15. When drilling, do not push down too hard. It may bring great load to the unit
and the overload protector will work to stop the unit.
16. In case of getting stuck during the drilling, it may hit big rocks or roots. Do
not continue drilling. Take out rocks or roots, or drill in another place.
17. DO NOT discard the battery into trash can. Discard the battery according to
your local, state, federal or country's regulations.

TECHNICAL DETAILS
Technical changes excepted.
IMPORTANT SAFETY INFORMATION
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey
all safety messages that follow this symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTI0N used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
CAUTION without the safety alert symbol, is used to address practices not
related to personal injury.
WARNING! Read all instructions. Failure to follow all instructions listed below
may result in fire, serious injury and/or DEAT DEATH.
The warnings and precautions discussed in this manual cannot cover all possible conditions
and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the
operator.
SET UP PRECAUTIONS
1. Gasoline fuel and fumes are flammable, and potentially explosive. Use proper fuel storage
and handling procedures. Do not store fuel or other flammable materials nearby.
2. Have multiple ABC class fire extinguishers nearby.
3. Operation of this equipment may create sparks that can start fires around dry vegetation. A
spark arrestor may be required. The operator should contact local fire agencies for laws or
regulations relating to fire prevention requirements.
4. Wear ANSI-approved safety goggles, heavy-duty work gloves, and dust mask/respirator
during set up.
5. Use only oil and fuel recommended in the "Specifications" section of this manual.
E1
Engine type
Displacement
Engine power
Starter
Ignition system
Fuel tank capacity
Mixing ratio gasoline:oil
Drill length
Drill diameters
Reduction gear ratio
weight (without drill)
2-stroke
51,7cc
1.3kw/7000rpm
hand pull
electronic
1L
30:1
760mm
200mm
30:1
8.5 kg

OPERATING PRECAUTIONS
1. Engine exhaust contains carbon monoxide. This is a poison you cannot see or smell. Never
use inside a home or garage, even if doors and windows are open.
2. Do not lock trigger on. Always use with both hands on handles.
3. Buried utility lines may be unmarked; contact utility companies before drilling. Strikir utility
lines may cause severe personal injury or death.
4. To prevent severe personal injury or dismemberment from rotating bit: Stand on flat, level,
solid surface and brace against torque during use. Keep hands and feet away from auger bit
and hole when engine is running.
5. Disconnect and insulate spark plug wire before maintenance and/or changing bits.
6. Never disable safety switches or components.
7. Do not carry between holes with engine running.
8. Carry by handle only; not by bit.
9. Gasoline fumes are explosive. Never smoke or refill with engine running.
10. Keep bystanders away during use.
11. Keep children away from the equipment, especially while it is operating.
12. IMPORTANT! Your Warranty is voided if:
a. You do not operate the Auger Drill with the proper 30:1 fuel mix in its fuel
tank. Do not run the Engine with an improper fuel mix, low or no fuel mix. Running the
engine with an improper fuel mix, low or no fuel mix, will permanently damage the unit.
b. You do not operate the Auger Drill with the proper amount of SAE 80-90
gear oil in its Gearbox. Do not run the Auger Drill with low or no gear oil. Running the
Auger Drill with low or no gear oil will permanently damage the unit.
13. Do not leave the equipment unattended when it is running. Turn off the equipment (and
remove safety keys, if available) before leaving the work area.
14. Wear ANSI-approved safety goggles, heavy duty work gloves, and steel-toed heavy-duty
work boots during setup and use.
15. Maintain a firm grip on the Auger Drill with both hands and be aware of the strong start-up
torque of the tool.
16. Keep your thumb near the Kill Switch in the event the Auger Drill must be turned off
immediately.
17. Do not use the Auger Drill if the Auger is dull, bent, or damaged.
18. Drill with the Engine running at full speed. Fully squeeze the Speed Control Lever to
maintain a steady drilling speed.
19. Keep the Auger clean and undamaged.
20. Keep all guards and safety devices in proper working order and properly adjusted.
21. Before starting the Engine, make sure the Auger is not contacting any object.
22. When shutting off the Engine, make sure the Auger has stopped before setting the tool
down.
23. People with pacemakers should consult their physician(s) before use. Electromagnetic
fields in close proximity to a heart pacemaker could cause pacemaker interference or
pacemaker failure. Caution is necessary when near the engine's magneto or recoil starter.
Engine should be off during distributor adjustment.
24. Use only accessories that are commended by Harbor Freight Tools for your model.
Accessories that may be suitable for one piece of equipment may become hazardous when
used on another piece of equipment.
25. Do not operate in explosive atmospheres, such as in the presence of flammable liquids,
gases, or dust. Gasoline-powered engines may ignite the dust or fumes.
26. Stay alert, watch what you are doing and use common sense when operating this piece of
equipment. Do not use this piece of equipment while tired or under the influence of drugs,
alcohol or medication.
27. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the equipment in unexpected situations.
E2

28. Dress properly. Do not wear loose clothing or jewelry. Keep hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
29. Parts, especially exhaust system components, get very hot during use. Stay clear of hot
parts.
30. Do not cover the engine or equipment during operation.
31. Keep the equipment, engine, and surrounding area clean at all times.
32. Use the equipment, accessories, etc., in accordance with these instructions and in the
manner intended for the particular type of equipment, taking into account the working
conditions and the work to be performed. Use of the equipment for operations different
from those intended could result in a hazardous situation.
33. Do not operate the equipment with known leaks in the engine’s fuel system.
34. When spills of fuel or oil occur, they must be cleaned up immediately. Dispose of fluids and
cleaning materials as per any local, state, or federal codes and regulations. Store oil rags in
a bottom-ventilated, covered, metal container.
35. Before use, check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the equipment’s operation. If damaged, have the equipment
serviced before using. Many accidents are caused by poorly maintained equipment.
36. Use the correct equipment for the application. Do not modify the equipment and do not use
the equipment for a purpose for which it is not intended.
Included in delivery
Unpack the package and check the
machine for any transport damage
and for completeness of delivery.
E3
Fig.A
1
2
3
Engine
Driller bit
Tool kit

Components (Fig. I)
SAFETY INSTRUCTIONS
Our earth auger shall be shall be used only for drilling holes into light/moderate soil at
moderate and non-slippery terrain for works like fencing, planting and forestation.
We can not be held responsible for there was per- formed manipulation or adjustments to the
machine.
1. Do not operate the machine at insufficient lighting conditions.
Do not operate the machine indoors.
Do not operate the machine when you are tired, when your concentration is impaired, and/
or under the influence of drugs, medication or alcohol.
2. Always be focused when working, take care to maintain a safe posture at every time.
Do not use the auger on a slope steeper than 15°.
Use the anti-rotation bar(optional) when working to prevent stalling torque.
Do not work on slippery ground. The operation of the machine on icy or snowy ground is
forbidden! Slipping/stumbling/falling down is a frequent cause of severe injuries.
3. The machine shall be used only by trained persons.
Non authorized persons, especially children, shall be kept away from the work area.
4. Do not wear loose clothing, long hair openly or loose jewellery like necklaces etc. when
operating the machine.They might be catched by rotating parts and cause serious injuries.
E4
I-1
I-2
I-3
I-4
I-5
I-6
I-7
I-8
Bar holder
Spark plug cap
Air filter
Recoil starter
Fuel tank cap
Fuel tank
Operating handle
Drill adapter

5. Use proper safety clothing and devices when operating the machine (safety gloves, safety
goggles, ear protectors, safety shoes...)
6. Ensure yourself that there are neither water or gas pipes nor electric lines installed under-
ground in the working area.
Ensure yourself that there are no loose objects lying around in the working area
Eliminate high grass, bushes etc. from the immediate working area. They might be winded
up by the rotating drill and block it.
Take especially care, if the ground contains many stones or roots. An unattended stalling of
the drill might easily cause an accident
To reduce the risk of stalling, always drill holes in 2-3 working steps. After each drilling
sequence, pull out the drill and let get it rid of the ground material
7. Refueling
No open light, fire, sparks or smoking allowed in the surrounding of 10m.
Do not refuel when the engine is running and/or engine parts are still hot.
Refuel only outdoors or in well ventilated areas.
Cleanse spilled gasoline immediately.
OPERATION INSTRUCTIONS
IMPORTANT: The first 10 hours of operation the machine shall not be operated but only
at medium engine speed. Do not operate the engine at max. speed right from the start,
as the engine itself as well as the gearing components need a running-in time. The
engine itself reaches its max. capacity after the first 10 hours of operation. Non-compli-
ance with this instruction reduces your engine lifespan substantially. To reduce the
max. possible engine speed, turn the adjustment knob (h-5), so that the throttle
lever(h-4)cannot be pushed entirely in.
1. Refueling
The machine is run by a gasoline-oil mixture. You need for the 2-stroke engine a fuel mixture
of 30: 1
Ensure yourself that no particles get into the fuel tank when refueling. Use a filter. We
strongly recommend the usage of HQ premixed fuels especially recommended for 2-stroke
motors. Many of them keep their consistency even after long periods of storage. If you prefer
to mix your own fuel please use HQ Synthetic Oil for 2-stroke engines. Synthetic oil reduces
accumulation of soot on the spark plug, cylinder, engine cock and exhaust pipe. This
increases the degree of lubrication and prolongs the engines lifespan.
Note: Shake fuel tank prior to every usage! During storage oil descents slowly in the fuel
tank. If you start the engine under this condition, it has barely any lubrication which would
lead to severe engine damage.
2. Cold starting
● Put the choker into position as shown in(Fig. C) ● Put the switch (H-3)into position START.
● Operate the fuel pump (I-9)3-5 times(Fig. k)
● Press the security lever(H-1)with the heel of your hand. ● Operate the throttle lever(h-4)
● Push the locking lever(h-2)in order to block the throttle lever.
● Now grasp the starter handle(1-4)and pull it out briskly! Repeat if necessary.
● After the engine has started, release the locking lever(h-2).
● Let the engine run in idle speed for 2-3 Minutes
● Put the choker into position as shown in(Fig. D).
3. Warm starting
● Put the switch(h-3)into position START. ● Operate the fuel pump(1-9)3-5 times(Fig. K).
● Press the security lever(h-1) with the heel of your hand.
● Operate the throttle lever(h-4)Push the locking lever(h-2)in order to block the throttle ever.
● Now grasp the starter handle(1-4)and pull it out briskly! Repeat if necessary.
● After the engine has started, release the locking lever(h-2)
Shut the machine off by releasing the throttle lever and put the switch(h-3)into STOP position.
E5

MAINTENANCE
ATTENTION - DANGER!
No cleaning, upkeep, checks or maintenance when machine is running
Be safe: Shut off the machine, let it cool down, disconnect spark plug cap from spark
Plug.
The machine does not require intense maintenance. However, to ensure a long lifespan,
we strongly recommend following the upkeep and maintenance plan.
1. Upkeep and maintenance plan
2. Cleaning
Clean the machine from soil, dirt, grass etc. Clean the machine housing with a wet cloth and a
mild cleaning solution.
IMPORTANT
The usage of solvents, aggressive chemicals or scouring agents damages the machine
solution.
3. Clean the spark plug
Take off the spark plug cap (I-2). Loosen and remove the spark plug. Clean it with a small
brush from soot debris. The contact distance shall account approx. 0, 5mm or credit card
thickness.
4. Grease the gear box
Grease every 25 operation hours the gearing of the earth auger with a grease gun. Use for
this purpose commercial HQ gearing grease.
You will find the lubrication nipple (Fig. J) on the side of the gearbox.
5. Clean the air filter
A clogged air filter reduces the engines power output drastically and causes engine
dis-function.
Furthermore it reduces the engines lifespan!
Loosen with a hex-key the screw fixing the air filter cover (Fig. E).
Take off the cover and remove the filter (Fig. F).
Clean the air filter (Fig G) with water. Wring it out strongly. Let it dry. Drip some drops of oil
onto the filter. Mount the filter back and mount on the cover again.
6. Disposal
DO NOT dispose your earth auger in the residual waste! Contact your local authorities for
information about best available disposal possibilities in your area. Drain fuel from the fuel
tank completely before disposing the earth
auger. Disaggregate the auger into its components before disposing its components.
7. Storage
When you store the machine longer than 30 days:
● Drain fuel from fuel tank
● Remove the spark plug, pour into the cylinder some drops of motor oil. Now pull the starter
cable out slowly so that the engine revolutes several
times in order to distribute the oil in the whole
combustion chamber
● Clean the spark plug as described in 1.6.3 and
mount it back.
● Cover the machine with a cloth sheet and store
it at a dry place.
Great Circle USA
Support Line: 1-866-493-0524
[email protected]
www.greatcircleus.com
Loose or lost screws, nuts, bolts
Damage of any part of the machine
Machine cleaning
Clean spark plug
Grease gearbox
Clean air filter
Regularly prior to each operation
Regularly prior to each operation
Regularly after operation
Every 25 working hours
Every 25 working hours
Every 20-30 working hours
Size: 145x210mm REV 06/11/19157克铜版纸
