Lang CLGPB-48A-E Operating instructions

Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203
Phone: [phone] Fax: [phone]
WWW.LANGWORLD.COM © Copyright 2002
Installation, Operation, Maintenance, & Troubleshooting
Model: CLGPB-48A-E Electric Cruise Line Griddle, Pickle Barrel
Serial:

2
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY
OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS
EQUIPMENT.
DANGER POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH.
WARNING POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY.
CAUTION POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY.
NOTICE Helpful operation and installation instructions and tips are
present.

3
TABLE OF CONTENTS
CHAPTER PAGE
1. TABLE OF CONTENTS............................................................................... 3
2. READ FIRST................................................................................................. 4
3. UNPACKING ................................................................................................ 5
4. INSTALLATION........................................................................................... 6
5. INITIAL START-UP ..................................................................................... 7
6. OPERATION ................................................................................................. 8
7. CLEANING.................................................................................................... 9
8. TROUBLESHOOTING................................................................................. 10
9. PARTS LIST.................................................................................................. 11
10. EXPLODED VIEWS ..................................................................................... 12
11. WIRING DIAGRAM..................................................................................... 15

4
IMPORTANT READ FIRST IMPORTANT
CAUTION GRIDDLE WEIGHS 515 lbs (234 kg). FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR
PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO
THE PLACE OF INSTALLATION.
CAUTION ANY STAND, COUNTER OR OTHER DEVICE ON WHICH GRIDDLE WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE
GRIDDLE.
CAUTION SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.
DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN
ELECTROCUTION AND DEATH.
WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN CAUSE
INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT MUST BE
INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE The data plate is located behind the access panel in the back of the griddle.
The griddle voltage, wattage, serial number, wire size, and clearance
specifications are on the data plate. This information should be carefully
read and understood before proceeding with the installation.
NOTICE The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.
WARNING KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
NOTICE Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your authorized service station directory
or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM
for the service station nearest you.
WARNING BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE
WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
CAUTION USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL
VOID ALL WARRANTIES.

5
UNPACKING
3.1 Receiving the Griddle
Upon receipt, check for freight damage, both visible and concealed. Visible
damage should be noted on the freight bill at the time of delivery and signed by the
carrier's agent. Concealed loss or damage means loss or damage which does not
become apparent until the merchandise has been unpacked. If concealed loss or
damage is discovered upon unpacking, make a written request for inspection by the
carrier's agent within 15 days of delivery. All packing material should be kept for
inspection. Do not return damaged merchandise to Lang Manufacturing Company.
File your claim with the carrier.
3.2 Location
Prior to un-crating, move the griddle as near its intended location as practical. The
crating will help protect the unit from the physical damage normally associated
with moving it through hallways and doorways.
3.3 Un-crating
The griddle will arrive completely assembled inside a wood frame covered by
cardboard box and strapped to a skid. Remove the cardboard cover, cut the
straps and remove the wood frame.
Remove griddle from skid and place in intended location.
CAUTION GRIDDLE WEIGHS 515 lbs (234 kg). FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR
PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO
THE PLACE OF INSTALLATION.
CAUTION ANY STAND, COUNTER OR OTHER DEVICE ON WHICH GRIDDLE WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE
GRIDDLE.
CAUTION SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.

6
INSTALLATION
DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN
ELECTROCUTION AND DEATH.
WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN CAUSE
INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT MUST BE
INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE The data plate is located behind the access panel in the back of the griddle.
The griddle voltage, wattage, serial number, wire size, and clearance
specifications are on the data plate. This information should be carefully
read and understood before proceeding with the installation.
NOTICE The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
4.1 Electrical Connection
There is one power supply connection on the griddle. Refer to the power supply
chart on the bottom of this page for proper power supply size.
The installer will provide a knockout location in the rear or the bottom of the
griddle.
Use a supply wire suitable for at least 90°C.
4.2 Griddle Voltage
The model CLGPB-48A-E griddle is shipped from the factory wired for 220 volts.
4.3 Phasing
All griddles are shipped from the factory set up for a three-phase service.
GRIDDLE SPECIFICATIONS
NOMINAL AMPS PER LINE WEIGHT
THREE PHASE
220 VOLT
MODEL
NUMBER TOTAL kW
LINE 1 LINE 2 LINE 3
CLGPB-48A-E 29.6 89.0 58.0 89.0 515 lbs.

7
INITIAL START UP
5.1 Initial Start Up
Before starting the griddle for the first time, clean the griddle body and cooking
surface with a mild soap and water solution then rinse with clear water and dry.
Set the temperature dials to 200 degrees.
Heat the griddle at 200 degrees for 2 hours to evaporate any moisture that may be in
the elements.
After 2 hours at 200 degrees, proceed with "SEASON THE GRILL SURFACE".
5.2 Season the Grill
The cooking surface must be "seasoned" in order to reduce product sticking.
To season, heat the griddle to 250 degrees.
Once at 250 degrees, coat the cooking surface with a non-salted vegetable oil.
Allow the griddle to stand at 250 degrees until the cooking surface looks dry then
coat it again.
Heat the griddle to 350 degrees and repeat the procedure.
The griddle may emit a small amount of smoke as the cooking surface passes the
350°point. Do not be alarmed as oils associated with the manufacturing process
may cause smoke and will stop when the griddle reaches 350 degrees.

8
OPERATION
CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.
6.1 Setting the Temperature
If different temperature settings across the same griddle are to be used, select one
side of the griddle and run that at the lowest temperature. Adjoining sections
should be set at progressively higher temperatures. Do not try to run end sections
hot and center sections cool.
6.2 Loading the Grill
An understanding of how the griddle sections are controlled will be a valuable aid
in loading your griddle.
A thermostat independently controls each 12-inch section. The sensor for each is
mounted under the griddle plate in the center of each cooking section.
If product is loaded directly over the temperature sensor, that section will turn on
and the element will heat the entire cooking section. If the product is loaded to the
side, front or back of the temperature sensor, the controller will react to the
temperature change of the entire section instead of just one product.
During slow periods minimal loads, do not load directly over the temperature
sensors as this will unnecessarily turn the elements on and over heat the reminder of
the section not being utilized.
During busy periods, a systematic approach should be utilized in loading the
griddle. Load the entire section from rear to front and continue cooking to the next
section if necessary.
Turn the product and continue cooking until it has reached its desired degree of
doneness.
Remove the product from the griddle.
When reloading the griddle, first use the griddle surface on which a previous load
was not placed. This will ensure the proper griddle temperature.

9
CLEANING
WARNING KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
7.1 Daily Cleaning (after each meal)
Keep the griddle surface clean. After each cooking load, scrape the griddle surface
with the grooved griddle cleaning tool to remove any carbonized grease.
The griddle surface should be cleaned and re-seasoned. Use a griddle stone, griddle
pad, or liquid cleaner. Rub with the grain of the metal, being careful not to scrape
the splashguard.
Clean the exterior of the appliance with a hot water and chlorine solution to
maintain a gleaming appearance.
Be sure to rinse thoroughly and coat the cooking surface with a thin film of oil to
prevent rusting.
Re-season the griddle plate after each cleaning (refer to page 8).

10
TROUBLESHOOTING
9.1 Symptoms
What follows is a chart of Symptoms and Possible Causes to aid in diagnosing
faults with the oven.
Refer to the Symptoms column to locate the type of failure then to the Possible
Cause for the items to be checked.
To test for a possible cause, refer to the TEST section and locate the Possible Cause
then refer to test to identify test procedures.
SYMPTOM POSSIBLE CAUSE
Griddle will not heat •Failed element
•Failed thermostat
•No power to cord outlet
•Open wire
Product burning •Product is cooked too long
•Failed thermostat
Product under done •Failed thermostat
NOTICE Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your authorized service station directory
or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM
for the service station nearest you.
WARNING BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE
WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
9.2 TESTS
If an item on the list is followed by an asterisk (*), the work should be done by a factory
authorized service representative.
Possible Cause TEST
Product is cooked too long •No test available, operational condition
Failed thermostat •Check thermostat for continuity, or that it is
cycling on & off
Failed element •Remove the wires and check for proper
resistance across the element
CAUTION USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL
VOID ALL WARRANTIES.

11
PARTS LIST
Item # Description Part
Number
1 Bod
y
Assembl
y
, 4 Foot, Pickle Barrel LGCL-219-41
2 Plate Assembly, 4 Foot, Pickle Barrel LGCL-723-41
3 Control Panel Assembly, Pickle Barrel LGCL-725-41
4 Bottom Snout Cover LGCL-416
5 Supply Wire Baffle LGCL-227
6 Rear Cover LGCL-507
7 Knob, Thermostat 70701-28
8 Griddle Stand Assembly LGCL-710-4
9 Screw, 10-32 X .5, S/S Hex Head Cap 20111-09
10 Element, 208/240V, 5991 Watts 11030-29
11 Nut, 10-32, Hex Head 20303-02
12 Element Pan, Zig-Zag LGCL-439
13 Element Pan, Insulation XL-424
14 Element Pan LGCL-434
15 Washer, Stainless Steel, Flat 20203-05
16 Nut, Hex, Stainless Steel, 5/16-18 20303-07
17 Thermostat Holder LGCL-504
18 Thermostat, Griddle, 550°F 30402-07
19 Terminal Block, 2 Pole, 30500-11
20 Wire Harness LGCL-586
21 Ground Harness LGCL-770
22 Hotel Pan, Pickle Barrel 73800-01
23 Element, 208V, 1491 Watts 11030-30
N/A Grooved Griddle Brush 50100-05

12
EXPLODED VIEW

13
EXPLODED VIEW CONT’D

14
EXPLODED VIEW CONT’D
20
21 18 19

15
WIRING DIAGRAM

16
THIS PAGE IS
INTENTIONALLY
LEFT BLANK
