Lanier JP1030 Manual

your document management partner
Operator Guide
LDD030
Digital Duplicator

Introduction
This manual contains detailed instructions on the operation and maintenance of this machine. To get
maximum versatility from this machine all operators should carefully read and follow the instructions in
this manual. Please keep this manual in a handy place near the machine.
Please read the Safety Information before using this machine. It contains important information related
to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
Notes:
Some illustrations in this manual might be slightly different from the machine.
Certain options might not be available in some countries. For details, please contact your local dealer.
Two kinds of size notation are employed in this manual. With this machine refer to the inch version.
For good copy quality, Standard recommends that you use genuine Standard masters and inks.
Standard shall not be responsible for any damage or expense that might result from the use of parts
other than genuine Standard parts in your Standard office product.
Power Source
120V, 60Hz, 5.0A or more
Please be sure to connect the power cord to a power source as above. For details about power source,
see p.102 “Power Connection”.
For safety, please read this manual carefully before you use this product and keep it handy for future
reference.
PinkGold-F_V4_FM.book Page 1 Friday, September 14, 2001 3:26 PM

Note to users in the United States of America
Notice:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursu-
ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television re-
ception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio /TV technician for help.
Warning
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Note to users in Canada
Note:
This Class B digital apparatus complies with Canadian ICES-003.
Remarque concernant les utilisateurs au Canada
Avertissement:
Cet appareil numérique de la classe B est conforme àla norme NMB-003 du Canada.
In accordance with IEC 60417, this machine uses the following symbols for the main switch:
a
aa
ameans POWER ON.
b
bb
bmeans POWER OFF.
PinkGold-F_V4_FM.book Page 1 Tuesday, September 11, 2001 6:31 PM

i
Safety Information
When using this machine, the following safety precautions should always be fol-
lowed.
Safety During Operation
In this manual, the following important symbols are used:
Safety During Operation
In this manual, the following important symbols are used:
RWARNING:
R
WARNING:
Indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
Indicates a potentially hazardous situation which, if instructions are not
followed, may result in minor or moderate injury or damage to property.
R
WARNING:
Indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
Indicates a potentially hazardous situation which, if instructions are not
followed, may result in minor or moderate injury or damage to property.
•Connect the power cord directly into a wall outlet and never use an ex-
tension cord.
•Disconnect the power plug (by pulling the plug, not the cable) if the
power cable or plug becomes frayed or otherwise damaged.
•To avoid hazardous electric shock, do not remove any covers or
screws other than those specified in this manual.
•Turn off the power and disconnect the power plug (by pulling the plug,
not the cable) if any of the following occurs:
•You spill something into the machine.
•You suspect that your machine needs service or repair.
•The external housing of your machine has been damaged.
PinkGold-F_V4_FM.book Page i Tuesday, September 11, 2001 6:31 PM

ii
RCAUTION:
•Protect the machine from dampness or wet weather, such as rain, snow.
•Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, you should take care that the power cord will not
be damaged under the machine.
•When you disconnect the power plug from the wall outlet, always pull the
plug (not the cable).
•Do not allow paper clips, staples, or other small metallic objects to fall inside
the machine.
•For environmental reasons, do not dispose of the machine or expended
supply waste at household waste collection points. Disposal can take place
at an authorized dealer.
•Be careful not to cut yourself on any sharp edges when you reach inside the
machine to remove misfed sheets of paper or masters.
•Our products are engineered to meet high standards of quality and function-
ality, and we recommend that you use only the expendable supplies avail-
able at an authorized dealer.
PinkGold-F_V4_FM.book Page ii Tuesday, September 11, 2001 6:31 PM

iii
How to Read this Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation that might result in
death or serious injury when you misuse the machine without following the in-
structions under this symbol. Be sure to read the instructions, all of which are de-
scribed in the Safety Information section.
R
CAUTION:
This symbol indicates a potentially hazardous situation that might result in mi-
nor or moderate injury or property damage that does not involve personal injury
when you misuse the machine without following the instructions under this
symbol. Be sure to read the instructions, all of which are described in the Safety
Information section.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before op-
erating.
Note
This symbol indicates precautions for operation, or actions to take after misop-
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
{}
Keys built into the machine's operation panel.
PinkGold-F_V4_FM.book Page iii Tuesday, September 11, 2001 6:31 PM

iv
What You Can Do with this Machine
Below is a quick summary of this ma-
chine's features and where to look in
for more information.
❖
❖❖
❖Standard Printing
See p.13 “Standard Printing”.
❖
❖❖
❖Adjusting the Print Image Position
See p.18 “Adjusting the Print Im-
age Position”.
* Paper feed direction
❖
❖❖
❖Adjusting the Print Image Density
See p.20 “Adjusting the Print Im-
age Density”.
❖
❖❖
❖Tint Mode
See p.21 “Tint Mode”.
❖
❖❖
❖Fine Mode
See p.22 “Fine Mode”.
❖
❖❖
❖Changing the Print Speed
See p.23 “Changing the Printing
Speed”.
❖
❖❖
❖Preset Reduce/Enlarge
See p.25 “Preset Reduce/Enlarge”.
❖
❖❖
❖Zoom
See p.27 “Zoom”.
❖
❖❖
❖Edge Erase
See p.28 “Edge Erase”.
❖
❖❖
❖Printing on Thick or Thin Paper
See p.30 “Printing on Thick or Thin
Paper”.
❖
❖❖
❖Selecting Original Type
See p.31 “Selecting Original Type”.
❖
❖❖
❖Economy Mode
See p.33 “Economy Mode”.
GRRATI0E
GRZOOM0E
GRERAS0E
AB AB
PinkGold-F_V4_FM.book Page iv Tuesday, September 11, 2001 6:31 PM

v
❖
❖❖
❖Class Mode
See p.34 “Class Mode”.
❖
❖❖
❖Memory Mode
See p.36 “Memory Mode”.
❖
❖❖
❖Combining Originals
See p.39 “Combining Originals”.
❖
❖❖
❖Skip Feed Printing
See p.41 “Skip Feed Printing”.
❖
❖❖
❖Program
See p.42 “Program”.
❖
❖❖
❖Security Mode
See p.44 “Security Mode”.
❖
❖❖
❖Making Color Prints
See p.50 “Making Color Prints”.
❖
❖❖
❖Printing in Two Colors
See p.52 “Printing in Two Colors”.
GRCLAS0E
R
RR R
RRR
D
C
B
GRCLAS1E
AAB
C D
ZCTX040E
BA AB
GRCOLO0E
R
P
R
P
PinkGold-F_V4_FM.book Page v Tuesday, September 11, 2001 6:31 PM

vi
TABLE OF CONTENTS
Machine Exterior......................................................................................... 1
Machine Interior.......................................................................................... 2
Options........................................................................................................ 3
Operation Panel .......................................................................................... 4
Keys ............................................................................................................... 4
Indicators........................................................................................................ 6
1.Operation
Print Paper .................................................................................................. 7
Originals...................................................................................................... 9
Preparation for Printing ........................................................................... 10
Loading Paper.............................................................................................. 10
Setting Up the Paper Delivery Tray.............................................................. 11
Standard Printing ..................................................................................... 13
Restoring Paper Feed and Paper Delivery Trays .................................. 16
Energy Saver Mode .................................................................................. 17
Adjusting the Print Image Position......................................................... 18
Forward or Backward ................................................................................... 18
Right or Left.................................................................................................. 19
Adjusting the Print Image Density .......................................................... 20
Before Making a Master ............................................................................... 20
After Making a Master .................................................................................. 20
Tint Mode................................................................................................... 21
Fine Mode.................................................................................................. 22
Changing the Printing Speed .................................................................. 23
Stopping a Multi-print Run ...................................................................... 24
Stopping a Multi-print Run to Print Another Original .................................... 24
Changing the Number of Prints Entered and Check the Completed Prints ... 24
Preset Reduce/Enlarge ............................................................................ 25
Zoom.......................................................................................................... 27
Edge Erase................................................................................................ 28
Printing on Thick or Thin Paper .............................................................. 30
Pressure Lever Position ............................................................................... 30
Selecting Original Type............................................................................ 31
Economy Mode ......................................................................................... 33
Class Mode................................................................................................ 34
Memory Mode ........................................................................................... 36
PinkGold-F_V4_FM.book Page vi Tuesday, September 11, 2001 6:31 PM

vii
Combining Originals ................................................................................ 39
Skip Feed Printing .................................................................................... 41
Program..................................................................................................... 42
Storing Your Settings ................................................................................... 42
Recalling a Program..................................................................................... 42
Security Mode ........................................................................................... 44
2.Optional Functions
Optional Document Feeder...................................................................... 45
Originals ....................................................................................................... 45
Placing Originals in the Document Feeder................................................... 46
Combining Originals Using the Document Feeder....................................... 47
Memory Mode Using the Document Feeder ................................................ 48
Color Printing Using the Optional Color Drum...................................... 50
Making Color Prints...................................................................................... 50
Changing the Color Drum Unit ..................................................................... 50
Printing in Two Colors .................................................................................. 52
3.User Tools
Accessing the User Tools........................................................................ 55
User Tools Menu....................................................................................... 57
4.Replenishing Supplies
Loading Paper on the Paper Feed Tray.................................................. 63
Replenishing Paper...................................................................................... 63
Changing the Paper Size ............................................................................. 64
When the Add Ink Indicator (j
jj
j) Lights.................................................. 65
Master Roll Replacement......................................................................... 68
Placing a New Roll of Tape in the Tape Dispenser (Option) ................ 70
PinkGold-F_V4_FM.book Page vii Tuesday, September 11, 2001 6:31 PM

viii
5.Troubleshooting
Machine Operation Problems.................................................................. 71
Printing Problems..................................................................................... 73
Combining Originals Mode........................................................................... 73
x
xx
xClearing Misfeeds................................................................................ 74
When “x” and “P” light ................................................................................ 75
When “x” and “A” light ................................................................................ 77
When “x” and “B” light ................................................................................ 77
When “x” and “C” light................................................................................ 78
When “x” and “D” light................................................................................ 81
When “x” and “E” light ................................................................................ 82
When the Open Cover/Unit Indicator (M
MM
M) Lights................................... 85
When the Master Eject Indicator (k
kk
k) Lights.......................................... 88
When Other Indicators Light ................................................................... 89
When the Prints are Thrown Over the Paper Delivery Tray.................. 90
Poor Printing............................................................................................. 91
Dirt on the Back Side of Paper..................................................................... 91
Dirt on the Front Side of Paper (Black Line/Stain) ....................................... 94
White Prints or Incomplete Prints................................................................. 94
6.Remarks
Operation Notes........................................................................................ 97
General Cautions ......................................................................................... 97
Print Paper ................................................................................................... 99
Originals ....................................................................................................... 99
Where to Put the Machine...................................................................... 101
Environmental Conditions .......................................................................... 101
Power Connection...................................................................................... 102
Access to Machine ..................................................................................... 102
Maintaining the Machine........................................................................ 103
Main Frame ................................................................................................ 103
Optional Document Feeder ........................................................................ 104
Combination Chart ................................................................................. 105
7.Specification
Main Frame.............................................................................................. 107
Document Feeder (Option) .................................................................... 110
Consumables .......................................................................................... 111
INDEX....................................................................................................... 112
PinkGold-F_V4_FM.book Page viii Tuesday, September 11, 2001 6:31 PM

1
Machine Exterior
1. Front door
Open for access to the inside of the ma-
chine.
2. Operation panel
Operator controls and indicators are lo-
cated here. See p.4 “Operation Panel”.
3. Exposure glass cover or document
feeder (option)
Lower this cover over an original before
printing.
4. Master tray
Pull out this unit when installing the
master.
5. Feed roller pressure lever
Use to adjust the contact pressure of the
paper feed roller according to paper
thickness.
6. Paper feed side plates
Use to prevent paper skew.
7. Paper feed tray
Set paper on this tray for printing.
8. Paper feed side plate lock lever
Use to lock or unlock the paper feed side
plates.
9. Side tray fine adjusting dial
Use to shift the paper feed tray sideways.
10. Paper feed tray down key
Press to lower the paper feed tray.
11. Behind cover
Flip up when you use the keys under-
neath.
PinkGold-F_V4_FM.book Page 1 Tuesday, September 11, 2001 6:31 PM

2
Machine Interior
1. Paper alignment wings
Lift or lower the wings depending on the
type of paper being used.
2. Paper delivery side plates
Use to align the prints on the paper deliv-
ery tray.
3. Paper delivery end plate
Use to align the leading edge of prints.
4. Paper delivery tray
Completed prints are delivered here.
5. Main switch
Use to turn the power on or off.
6. Drum unit
The master is wrapped around this unit.
7. Drum unit lock lever
Lift to unlock and pull out the drum unit.
8. Ink holder
Set the ink cartridge in this holder.
9. Exposure glass
Position originals here face down for
printing.
10. Master eject box
Pull out this box to remove the used mas-
ters.
PinkGold-F_V4_FM.book Page 2 Tuesday, September 11, 2001 6:31 PM

3
Options
❖
❖❖
❖Document feeder
1. Document feeder
❖
❖❖
❖Exposure glass cover
1. Exposure glass cover
Note
❒Other options:
•A3, 11" ×17" Color Drum
•A4, 81/2" ×11" Black Drum
•Tape Dispenser
•Key Counter
PinkGold-F_V4_FM.book Page 3 Tuesday, September 11, 2001 6:31 PM

4
Operation Panel
Keys
1. {
{{
{Security}
}}
}key
Press to make prints of confidential doc-
uments. See p.44 “Security Mode”.
2. {
{{
{Tint/Economy}
}}
}key
Press to make halftone prints. See p.21
“Tint Mode”.
Press to save ink. See p.33 “Economy
Mode”.
3. {
{{
{Image Density}
}}
}key
Press to make prints darker or lighter. See
p.20 “Adjusting the Print Image Densi-
ty”.
4. Check Indicator
Lights when you have selected one or
more of the functions, and lets you know
that even if the behind cover is lowered.
5. {
{{
{Program}
}}
}key
Press to input or recall user programs.
See p.42 “Program”.
6. {
{{
{Clear Modes/Energy Saver}
}}
}key
•Clear Modes
Press to clear the previously entered
job settings.
•Energy Saver
Press to switch to and from Energy
Saver mode. See p.17 “Energy Saver
Mode”.
7. {
{{
{Auto Cycle}
}}
}key
Press to process the master and make
prints automatically.
8. {
{{
{Proof}
}}
}key
Press to make proof prints.
9. {
{{
{Skip Feed}
}}
}key
Press to select skip feed printing. See p.41
“Skip Feed Printing”.
10. {
{{
{Edge Erase}
}}
}key
Press to select Edge Erase mode. See p.28
“Edge Erase”.
11. {
{{
{}
}}
}and {
{{
{}
}}
}keys (Scroll keys)
Press to adjust the reproduction ratio. See
p.27 “Zoom”.
Press to select size and direction of paper
or original in Edge Erase. See p.28 “Edge
Erase”.
12. {
{{
{Reduce}
}}
}key
Press to reduce the image. See p.25 “Pre-
set Reduce/Enlarge”.
13. {
{{
{Full Size}
}}
}key
Press to make full size prints.
14. {
{{
{Enlarge}
}}
}key
Press to enlarge the image. See p.25 “Pre-
set Reduce/Enlarge”.
PinkGold-F_V4_FM.book Page 4 Tuesday, September 11, 2001 6:31 PM

5
15. {
{{
{Combine}
}}
}key
Press to combine originals onto 1 print.
See p.39 “Combining Originals”.
16. {
{{
{Type of Original}
}}
}key
Press to select Letter, Photo, or Let-
ter/Photo mode. See p.31 “Selecting
Original Type”.
17. {
{{
{Fine}
}}
}key
Press to select the fine image. See p.22
“Fine Mode”.
18. {
{{
{W
WW
W}
}}
}and {
{{
{V
VV
V}
}}
}keys (Speed keys)
Press to adjust the printing speed. See
p.23 “Changing the Printing Speed”.
19. {
{{
{Memory/Class}
}}
}key
Press to select Memory or Class mode.
See p.34 “Class Mode”, p.36 “Memory
Mode”.
20. {
{{
{Image Position}
}}
}key
Press to shift the image forwards or back-
wards. See p.18 “Adjusting the Print Im-
age Position”.
21. Number keys
Press to enter the desired number of
prints and data for selected modes.
22. {
{{
{q
qq
q}
}}
}key
Press to enter data in selected modes.
23. {
{{
{Clear/Stop}
}}
}key
Press to cancel a number you have en-
tered, or to stop printing.
24. {
{{
{Start}
}}
}key
Press to make a master.
25. {
{{
{Print}
}}
}key
Press to start printing.
PinkGold-F_V4_FM.book Page 5 Tuesday, September 11, 2001 6:31 PM

6
Indicators
1. Magnification indicators
Show the preset magnification that is se-
lected. See p.25 “Preset Reduce/En-
large”.
2. Zoom counter
Shows the reproduction ratio in zoom
mode. See p.27 “Zoom”.
3. Error indicators
Light to inform you of the status of the
machine. See p.71 “Troubleshooting”.
4. Memory/Class indicator
Lights when Memory or Class mode is
selected. See p.34 “Class Mode”, p.36
“Memory Mode”.
5. Counter
Shows the number of prints entered.
While printing, it shows the number of
prints remaining.
6. Memory/Class counter
Shows the number entered in Memo-
ry/Class mode or User Tools.
7. Original type indicators
Show the type of original that is selected.
See p.31 “Selecting Original Type”.
8. Machine indicators
Show the jammed area with the xindi-
cator. See p.74 “xClearing Misfeeds”.
Show the opened cover/unit with the M
indicator. See p.85 “When the Open Cov-
er/Unit Indicator (M) Lights”.
9. Speed indicators
Show the printing speed that is selected.
See p.23 “Changing the Printing Speed”.
10. Image position indicators
Show the print image position that is se-
lected. See p.18 “Adjusting the Print Im-
age Position”.
PinkGold-F_V4_FM.book Page 6 Tuesday, September 11, 2001 6:31 PM

7
1. Operation
Print Paper
The following limitations apply:
Non-recommended paper:
•Roughly cut paper
•Paper of different thickness in the same stack
•Envelopes heavier than 85g/m2, 22 lb.
•Folded, curled, creased, or damaged paper
•Damp paper
•Torn paper
•Slippery paper
•Rough paper
•Paper with any kind of coating (such as carbon)
•Short grain paper
•Thin paper that has low stiffness
•Paper that is prone to generate a lot of paper dust
•Grained paper loaded with the direction of the grain perpendicular to the
feed direction
•Certain types of long thin envelopes e.g. international mail envelopes
•The following types of envelopes:
Paper Size Paper
Weight
Metric Inch
Paper feed tray A3 L, B4 L, A4 LK, B5 LK,
A5 L, B6 L, A6 L, Others (Ver-
tical: 70 - 297mm, Horizontal: 148
- 432mm)
11" ×17" L, 81/2" ×14" L,
81/2" ×11" LK, 51/2" ×
81/2" LK, Others (Verti-
cal: 2.76" - 11.7", Horizon-
tal: 5.83" - 17")
47.1 -
209.3g/m2,
12.5 - 55.6 lb
PinkGold-F_V4_FM.book Page 7 Tuesday, September 11, 2001 6:31 PM

Operation
8
1
If you print on rough grained paper, the copy image might be blurred.
You can use A3 (297 ×420mm) or 11" ×17" originals or printing paper. When you
want to print the entire image of an A3, 11" ×17" original, select Reduce mode
because the maximum print areas are as follows:
•Metric version: 290 ×409mm, 11.4" ×16.1"
•Inch version: 290 ×415mm, 11.4" ×16.3"
When you use A3, 11" ×17" and 209.3g/m2, 55.6 lb paper, slow the printing
speed down to setting 1, 2, or 3.
Important
❒Correct curls in the paper before placing it in the machine. When you cannot
correct the paper curl, stack the paper with the curl face down or face up as
shown in the illustration. If paper is curled, it might wrap around the drum
or stains might appear.
PinkGold-F_V4_FM.book Page 8 Tuesday, September 11, 2001 6:31 PM
