Lanoptik MC Series User manual

MC Series USB Camera
User’s Manual
www.lanoptik.com

Content
www.lanoptik.com
CHAPTER 1 NOTES AND SAFETY REQUIREMENTS
1.1 CAUTIONS AND NOTES
CHAPTER 2 SOFTWARE SYSTEM REQUIREMENTS
2.1 SYSTEM REQUIREMENTS UNDER USB WORK MODE
CHAPTER 3 PACKING LIST
CHAPTER 4 FUNCTION INTRODUCTION OF EACH PART
- 1 -
- 1 -
- 2 -
- 2 -
- 3 -
- 4 -
4.1 NAME AND FUNCTION FOR EACH PART OF THE CAMERA - 4 -
CHAPTER 5 PRODUCT ASSEMBLY GUIDE
5.1 CAMERA ASSEMBLY
5.1.1 Assembly with microscope
5.1.2 Disassembly the Camera
CHAPTER 6 INSTRUCTIONS
6.1 SOFTWARE INSTALLATION
6.2 DEVICE CONNECTION
6.3 OPEN SOFTWARE
6.4 START TO USE
CHAPTER 7 DISCLAIMER
- 6 -
- 6 -
- 6 -
- 7 -
- 8 -
- 8 -
- 8 -
- 8 -
- 8 -
- 9 -
4.2 OPTIONAL ACCESSORY - 5 -

To avoid danger or damage incurred to the lens, do not touch the lens or sensor directly with your
fingers.
Chapter 1 Notes and Safety Requirements
1.1 Cautions and Notes
User's Manual | MC Series USB Microscope Camera
To avoid failure or electric shock hazard and so on, do not disassemble or modify the internal
structure of the device.
Do not plug in or unplug the Power connection port when hands are wet.
Do not use alcohol and other organic solvents to clean.
If the lens or sensor is dirty or damp, you should better use dry and non-linen fabric or professional
lens tissue to wipe them. To avoid scratches on the surface, do not touch the lens with your fingers.
Wipe the lens or sensor lightly.
The products are not specifically designed for an outdoor use. Do not expose it to outdoor
environment without any protection. Excessive temperature and humidity will damage the lens.
Please avoid using the product under the following environment: high temperature or high humidity
environment, places with direct sunlight, dirt or vibration and places near heat source.
Please use and store in the following environment:
Operating temperature ： 0℃~ 40℃
Storage temperature ： -20℃~ 60℃
Operating Humidity ： 30~60%RH
Storage Humidity ： 10~80%RH
If any foreign matter, water or liquid enter into the device by accident, disconnect the Power line
immediately. Please send it to the maintenance center and do not use the hair dryer to dry it by
yourself.
To prevent microscope from being tripped over or dropped, please put away the device’s connect
cable in use or standby.
To avoid electric shock by accident, please power off microscope before you move your computer or
laptop.
The cleanliness of the device lens will directly affect clarity degree of contents from the computer
screen during preview. Problems like various circles or spots on the screen may mostly be incurred
by dirt on the lens. When cleaning, please use professional lens tissue or other professional detergent
to clear the dirt on the lens.
Registered trademark and copyright: Copyright ownership of this produc belongs to Lanoptik
Technologies Ltd. Without written authorization of this company, any organizations or individuals
shall not photocopy, print, or translation to another language to any part of this document.
www.lanoptik.com
- 1 -

Windows 7 (64bit), Windows 8 (64bit), Windows 8.1 (64bit), Windows 10 (64bit) , Windows 11 (64bit)
2.1 System Requirements under USB Work Mode
Chapter 2 Software System Requirements
User's Manual | MC Series USB Microscope Camera
Dual core 3GHz or higher CPU
USB 2.0 high-speed interface or USB2.0 compatible interface
At least 10 GB available hard-disk space
8G or more memory
DVD-ROM driver (only needed when installing software)
www.lanoptik.com
- 2 -

User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 3 -
Installation DiskCamera
Chapter 3 Packing List
Adapter (optional accessory)Eyepiece (optional accessory)

User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 4 -
4.1 Name and Function for Each Part of the Camera
Chapter 4 Function Introduction of Each Part
USB Cable:Used for connecting camera to PC.
C-mount thread: make our camera can install to a standard C-mount microscope or spotting scope;
or can install to a different interface microscope with adapter (optional accessory). (For detailed
specifications, please refer to Chapter 5)
Dustproof Cover: screw it out before use for dust prevention and chip protection.

User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 5 -
4.2 Optional Accessory
Digital Camera can be attached to microscopes of different
calibers through adapter ring and eyepiece. The Digital
Camera body is of Standard C Port; 0.5X eyepiece is of
23.2mm; adapter ring is of 23.2/30mm, 23.2/30.5mm.
According to different assembly methods, the equipment can
be connected to eyepieces of different ports.
Adapter Ring and Eyepiece (Optional)
4.2.1 Connection Methods and Types
1. Install to a standard C-mount interface microscope.
2. Install to a 23.2mm interface microscope.
3. Install to a 30mm interface microscope.
4. Install to a 30.5mm interface microscope

Chapter 5 Product Assembly Guide
5.1 Camera Assembly
5.1.1 Assembly with microscope
Unscrew the plastic dustproof cover at the bottom of the Digital Camera, take the protective film on
the filter of the cavity (See Figure 1).
Screw the Digital Camera to other microscopes (Standard C Port) (See Figure 2).
Connect the eyepiece to the computer and start the program.
1 ． Connection of Microscope for Standard C Port
User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 6 -
Figure1 Figure2
Unscrew the dustproof cover of the Digital Camera, take the protective film on the filter of the cavity.
Connect the eyepiece to additional eyepiece (See Figure 1 and Figure 2).
Narrow the eyepiece cover (or empty sleeve) into 23.2/30mm adapter ring (or 23.2/30.5mm adapter
ring).
Set the adapter ring with Digital Camera to stereo microscope (See Figure 3).
2 ． Connection of Microscope for Standard C Port
Figure1
Figure2 Figure3

5.1.2 Disassembly the Camera
User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 7 -
1 ． Disassembly with Standard C Port Digital Camera
（ 1 ） Turn off the software and unplug the USD cable.
（ 2 ） Screw out the Digital Camera from the microscope.
（ 3 ） Screw the plastic dustproof cover on.
（ 4 ） Put the Digital Camera in place in case of falling down.
1 ． Disassembly with Stereo microscope
（ 1 ） Take the product and adapter ring out from the stereo microscope.
（ 2 ） Disassemble the adapter ring and eyepiece from the product.
（ 3 ） Screw the plastic dustproof cover on.
（ 4 ） Put the Digital Camera in place in case of falling down.

Chapter 6 Instructions
User's Manual | MC Series USB Microscope Camera
6.1 Install Pixit Pro Software
Through the download links provided with the packing box, please download Pixit Pro software.
For the specific operation of software, please refer to the "User Manual of Pixit Pro_English"
6.2 Device Connection
(1) Connect the USB-A port of the USB cable to the USB port of the computer.
(2) Turn the Digital Camera work mode switch to USB work mode. It may appear the reminder for
installing device’s driver when you first use the Digital Camera and then system will finish installation
automatically.
6.3 Open Software
(1) Place the Digital Camera soundly and align the lens to the observation object.
(2) Execute the Pixit Pro software in your computer to observe your needed image.
6.4 Start to Use
(1) Connect the microscope to Digital Camera when required.
(2) Turn on the Digital Camera and connect to the device.
(3) Adjust the microscope or Digital Camera button to view required objects.
(4) For more detailed instructions, please refer to User Manual of Pixit Pro software.
www.lanoptik.com
- 8 -

Please do not use wet hands to plug and unplug the power supply of the equipment.
Please be sure to use a regular brand power socket, and make sure the grounding is well grounded to
prevent electric shock.
Please be sure to make regular safety checks on sockets and plugs to avoid potential electrical
safety hazards caused by aging and short circuit.
Please be sure not to use the product in a humid or hot environment to ensure the safety of the
product.
Please be sure to loosen bundle cords of the power cable before using, to avoid electromagnetic
induction and heating, thus increasing the heat dissipation speed.
Please be sure not to use the product equipment or socket or other places in high or easy to fall, so
as to avoid damage.
Before opening the socket power supply, please be sure to turn off the load power switch of the
product equipment.
The company reserves the rights to improve product, upgrade technology and change parameters
without prior notice.
1. In order to protect the legitimate rights and interests of users, please carefully read the
instructions, disclaimers and safety instructions provided with this product before using it. The company
reserves the right to update the above documents. Please operate the product
according to the instructions and safety instructions.
2. Once you begin to use the product, you shall be deemed to have read, understood,
recognized and accepted all terms and contents of the product's instructions, disclaimers and
safety instructions. Users undertake to be responsible for their actions and all consequences.
User undertakes to use the product only for legitimate purposes and agrees to these terms and
any relevant policies or guidelines that the company may establish.
3. In the process of using this product, please strictly abide by and execute the requirements
including but not limited to the instructions and safety instructions. All personal injuries,
accidents, property losses, legal disputes and other adverse events that cause conflicts of
interest caused by violation of the safety instructions or irresistible factors shall be borne by
users themselves, and the company shall not assume any responsibility.
4. Safety instructions:
Chapter 7 Disclaimer
User's Manual | MC Series USB Microscope Camera
www.lanoptik.com
- 9 -

LANOPTIK TECHNOLOGIES LTD
No. 72 Hongjing Street, Lejia Road, Baiyun District, Guangzhou, China. 510400
Phone: [phone] | Fax: [phone]
Website: http://www.lanoptik.com | Email: [e-mail]
Specifications are subject to change without any obligation on the part of the manufacturer.
