lanry TF1100-EH Manual

TF1100-EH
Transit Time Ultrasonic Flow Meter
Handheld
Operation & Maintenance
Manual
REV 4/2017

TF1100-EH transit-time handheld flowmeter manual
CONTENTS
PART-1 INTRODUCTION ................................................................................................................................1
1.1 GENERAL.................................................................................................................................................. 1
1.2APPLICATIONVERSATILITY............................................................................................................... 1
1.3 USER SAFETY........................................................................................................................................... 1
1.4 DATAINTEGRITY.................................................................................................................................... 1
1.5 USER FRIENDLY...................................................................................................................................... 2
1.6 PRINCIPLE OFMEASUREMENT......................................................................................................... 2
1.7 PRODUCTIDENTIFICATION................................................................................................................ 3
1.8 SPECIFICATIONS .................................................................................................................................... 3
PART-2 START OPERATING INSTRUCTIONS............................................................................................4
2.1 POWER ON................................................................................................................................................ 4
2.2 KEYPAD ..................................................................................................................................................... 4
2.3 MENUWINDOWS .................................................................................................................................... 5
2.4 MENUWINDOWSARRANGEMENT.................................................................................................... 6
2.5 STEPSTO CONFIGURETHE PARAMETERS..................................................................................... 7
2.6TRANSDUCERS MOUNTINGLOCATING........................................................................................... 8
2.7TRANSDUCERS MOUNTING................................................................................................................. 9
2.7.2TRANSDUCER MOUNTINGMODE................................................................................................... 9
2.8 INSTALLATION CHECKUP ................................................................................................................. 10
2.8.1 SIGNALSTRENGTH........................................................................................................................... 10
2.8.2 SIGNALQUALITY(M90) ................................................................................................................... 10
2.8.3TOTALTRANSITTIMEAND DELTATIME.................................................................................... 11
2.8.4TIME RATIO BETWEENTHE MEASURED TOTALTRANSITTIMEANDTHE
CALCULATED TIME (M91)........................................................................................................................ 11
PART-3 HOW TO USE MENU OPERATION...............................................................................................12
3.1 HOWTO JUDGEWHETHERTHE INSTRUMENTWORKS PROPERLY .................................... 12
3.2 HOWTO JUDGETHELIQUID FLOWINGDIRECTION................................................................. 12
3.3 HOWTO CHANGETHE UNITS SYSTEMS........................................................................................ 12
3.4 HOWTO SELECTAREQUIRED FLOW RATE UNIT ...................................................................... 12
3.5 HOWTO USETHETOTALIZER MULTIPLIER................................................................................ 12
3.6 HOWTO OPEN OR SHUTTHE TOTALIZERS.................................................................................. 12
3.7 HOWTO RESETTHETOTALIZERS .................................................................................................. 13
3.8 HOWTO RESETTHE DEFAULTSETUPS.......................................................................................... 13
3.9 HOWTO USETHE DAMPING ............................................................................................................. 13
3.10 HOWTO USETHE ZERO-CUTOFFFUNCTION............................................................................ 13
3.11 HOWTO SETUPAZERO POINT........................................................................................................ 13
3.12 HOWTO GETASCALE FACTOR FOR CALIBRATION................................................................ 14
3.13 HOWTO USETHE OPERATION LOCKER..................................................................................... 14
3.14 HOWTO USETHE BUILT-IN DATAMEMORY............................................................................... 14
3.15 HOWTO USETHE FREQUENCYOUTPUT..................................................................................... 14

TF1100-EH transit-time handheld flowmeter manual
3.16 HOWTO PRODUCEANALARM SIGNAL....................................................................................... 16
3.17 HOWTO USETHE BUILT-IN BUZZER ............................................................................................ 16
3.18 HOWTO MODIFYTHE BUILT-IN CALENDAR.............................................................................. 16
3.19 HOWTOADJUSTTHE LCD CONTRAST........................................................................................ 16
3.20 HOWTO USETHE RS232 SERIALINTERFACE............................................................................. 16
3.21 HOWTO VIEWTHE DATETOTALIZERS....................................................................................... 16
3.22 HOWTO USETHE WORKINGTIMER ............................................................................................ 17
3.23 HOWTO USETHE MANUALTOTALIZER ..................................................................................... 17
3.24 HOWTO CHECKTHE ESNAND OTHERS...................................................................................... 17
3.25 HOWTO KNOWHOW LONGTHE BATTERYWILLLASTAND HOWTO CHARGETHE
BUILT-IN BATTERY..................................................................................................................................... 17
PART-4 MENU WINDOW DETAILS.............................................................................................................18
PART-5 TROUBLESHOOTING .....................................................................................................................24
5.1 POWER-ON ERROR DISPLAYSAND COUNTER-MEASURES..................................................... 24
5.2 ERROR CODEAND COUNTER-MEASURES.................................................................................... 24
5.3 OTHER PROBLEMSAND SOLUTIONS............................................................................................. 26
5.4 USEMENUWINDOWS FORTRANSDUCER MOUNTINGINSPECTION.................................... 26
PART-6 COMMUNICATION PROTOCOL..................................................................................................28
6. 1THE PROTOCOL................................................................................................................................... 28
6.2 PROTOCOLPREFIX USAGE ............................................................................................................... 29
6.3 CODES FOR THE KEYPAD................................................................................................................... 30
PART-7 WARRANTYAND SERVICE...........................................................................................................31
7.1WARRANTY ............................................................................................................................................ 31
7.2 SERVICE.................................................................................................................................................. 31
APPENDIX 1 TRANSDUCER GUIDE RAIL INSTALLATION.............................................................32
APPENDIX 2 DATA LOGGER USEGE......................................................................................................35
APPENDIX 3 FUILD CHARACTERISTIC (SOUND SPEED)...............................................................37
1. FLUID PROPERTIES .................................................................................................................................. 37
2. WATE R SOUND SPEED ............................................................................................................................. 39
3. PIPE MATERIAL SOUND SPEED TABLE ................................................................................................ 39

TF1100-EH transit-time handheld flowmeter manual
1
PART-1 INTRODUCTION
1.1 GENERAL
Series TF1100-EH ultrasonic flow meters feature advanced Transit-Time measuring
technology, providing accurate and reliable flow rate and total flow display, The TF1100-EH
utilizes a non-invasive transducer which is hand-held or strapped to the outside of a pipe,
which will provide benefits of non-fouling operation and ease of installation.
TF1100-EH transit time flow meters utilize two transducers that function as both ultrasonic
transmitters and receivers.
The transducers are clamped on the outside of a closed pipe at a specific distance from each
other. The transducers can be mounted in V-mode where the sound transverses the pipe two
times, W-mode where the sound transverses the pipe four times, or in Z mode where the
transducers are mounted on opposite sides of the pipe and the sound crosses the pipe once. This
selection is based on pipe and liquid characteristics. The flow meter operates by alternately
transmitting and receiving a frequency modulated burst of sound energy between the two
transducers and measuring the time interval that it takes for sound to travel between the two
transducers. The difference in the time interval measured is directly related to the velocity of the
liquid in the pipe.
1.2 APPLICATION VERSATILITY
The TF1100-EH flow meter can be successfully applied on a wide range of metering
applications. The simple to program transmitter allows the standard product to be used on pipe
sizes ranging from 20mm -6000mm internal diameters. A variety of liquid applications can be
accommodated: ultra-pure liquids, potable water, chemicals, raw sewage, reclaimed water,
cooling water, river water, plant effluent, etc. Because the transducers are non-contacting and
have no moving parts, the flow meter is not affected by system pressure, fouling or wear. Standard
transducers are rated to 85°C.
1.3 USER SAFETY
The TF1100-EH employs modular construction and provides electrical safety for the operator.
The display face contains voltages no greater than 5Vdc. All user connections are made
through sealed bulk-head plugs located on the side of the TF1100-EH enclosure.
1.4 DATAINTEGRITY
Non-volatile flash memory retains all user-entered configuration values in memory for several
years, even if power is lost or the unit is turned off. Data Logger values are stored in flash memory in
the logger. Password protection is provided as part of the Security menu and prevents
inadvertent configuration changes or totalizer resets. A time-keeper is integrated in the flow
meter for the index of date totalizing and works as the time base of flow accumulation. It
keeps operating as long as the battery’s terminal voltage is over 1.5V. In case of battery
failure, the time-keeper will not keep running and it will lose proper time values. The user
must re-enter proper time values in case the battery becomes totally exhausted. An improper
time value affects no other functions but the date totalizer.

TF1100-EH transit-time handheld flowmeter manual
2
1.5 USER FRIENDLY
The TF1100-EH features the ease of operation, high accuracy and outstanding reliability,
while the software provides a very user friendly interface and much more functions. It
employs a patent balanced lower voltage multi-pulse igniting circuit which increases the
anti-interference ability magnificently so that the flow meter will work properly even in
demanding industrial environments such as those with power frequency transmitter working
nearby. The signal receiving circuits feature self-adapting performance so as to ensure that
the user can easily operate the instrument without any adjustment. The built-in rechargeable
Ni-H battery can work continuously for more than 12 hours without recharge.
1.6 PRINCIPLE OF MEASUREMENT
The TF1100-EH ultrasonic flow meter is designed to measure the fluid velocity of liquid
within a closed conduit. The transducers are a non-contacting, clamp-on type, which will
provide benefits of non-fouling operation and easy installation.
The TF1100-EH transit time flow meter utilizes two transducers that function as both
ultrasonic transmitters and receivers. The transducers are clamped on the outside of a closed
pipe at a specific distance from each other. The transducers can be mounted in V-method
where the sound transverses the pipe twice, or W-method where the sound transverses the
pipe four times, or in Z-method where the transducers are mounted on opposite sides of the
pipe and the sound crosses the pipe once. This selection of the mounting method depends on
pipe and liquid characteristics. The flow meter operates by alternately transmitting and
receiving a frequency modulated burst of sound energy between the two transducers and
measuring the transit time that it takes for sound to travel between the two transducers. The
difference between the transit-time is directly and exactly related to the velocity of the liquid
in the pipe, as shown in Figure 1.
Where:
f
VLiquidvelocity
KConstant
dt Difference in time of flight
TL Average Transit Time
/fVKdtTL=
Figure 1

TF1100-EH transit-time handheld flowmeter manual
3
1.7 PRODUCT IDENTIFICATION
Each set of the TF1100-EH Series flow meter has a unique product identification or ESN
written into the software that can only be modified with a special tool by the manufacturer. In
case of any hardware failure, please provide this number which is located on menu window
number M61 when contacting the manufacture.
1.8 SPECIFICATIONS
Transmitter:
Measurement principle Ultrasonic transit-time difference correlation principle
Flow velocity range 0.01 to 12 m/s, bi-directional
Resolution 0.25mm/s
Repeatability 0.2% of reading
Accuracy ±1.0% of reading at rates >0.3 m/s);±0.003 m/s of reading at
rates<0.3 m/s
Response time 0.5s
Sensitivity 0.003m/s
Damping of displayed value 0-99s(selectable by user)
Liquid Types Supported both clean and somewhat dirty liquids with turbidity <10000 ppm
Power Supply AC: 85-265V Up to 14 h with fully charged internal batteries
Enclosure type Handheld
Degree of protection IP65 according to EN60529
Operating temperature -20℃to +60℃
Housing material ABS
Display 4 line×16 English letters LCD graphic display, backlit
Units User Configured (English and Metric)
Rate Rate and Velocity Display
Totalized gallons, ft³, barrels, lbs, liters, m³,kg
Communication OCT, RS232,Data logger
Security Keypad lockout, system lockout
Size Transmitter: 273*125*42mm Case:410*320*80mm
Weight 0.5kg
Transducer:
Degree of protection IP65 according to EN60529.(IP67 or IP68 Upon request)
Suited Liquid Temperature Std. Temp.: -35℃~85℃for short periods up to 120℃
High Temp.: -35℃~200℃for short periods up to 250℃
Pipe diameter range 20-50mm for type S, 40-1000mm for type M, 1000-6000mm for
type L
Transducer Size Type S 48(h)*28(w)*28(d)mm Type M 60(h)*34(w)*32(d)mm
Type L 80(h)*40(w)*42(d)mm
Material of transducer Aluminum for standard temp. sensor, and peek for high temp.
sensor
Cable Length Std: 5m

TF1100-EH transit-time handheld flowmeter manual
4
PART-2 START OPERATING INSTRUCTIONS
2.1 POWER ON
Press the ON key to switch on the instrument and press the OFF to turn off the
power.
Once the flow meter is switched on, it will run a self diagnostic program, checking first the
hardware and then the software integrity. If there is any abnormality, corresponding error
messages will display.
Generally, there should be no display of error messages, and the flow meter will go to the
most commonly used Menu Window Number 01 (short for M01) to display the Velocity,
Flow Rate, Positive Totalizer, Signal Strength and Signal Quality, based on the pipe
parameters configured last time by the user or by the initial program.
The flow measurement program always operates in the background of the user interface. This
means the flow measurement will keep on running regardless of any user menu window
browsing or viewing. Only when the user enters new pipe parameters will the flow meter
change measurement to the new parameter changes.
When new pipe parameters have been entered or when the power has been just switched on,
the flow meter will enter an adjusting mode to make the signals magnified with proper
amplification. By this step, the flow meter is going to find the best threshold of receiving
signal. The user will see the progress by the number 1, 2, or 3, which are indicated on the
right lower corner of the LCD display.
When the transducers have been adjusted on the pipe by the user, the flow meter will
re-adjust the signal automatically.
Any user-entered configuration value will be retained into the NVRAM of the flow meter,
until it is modified by the user.
2.2 KEYPAD
The keypad for the operation of the flow meter has 16+2 keys, as shown by the right via
Keys 0 ~ 9 and .are keys to enter numbers, Key ∧/+ is the going UP key, when
the user wants to go to the upper menu window. It also works as + key when
entering numbers
Key ∨/- is the going DOWN key, when the user wants
to go down-sided menu window. It also works as the
‘–‘ key when entering numbers.
Key ◄is backspace key, when the user wants
go left or wants backspace the left character that

TF1100-EH transit-time handheld flowmeter manual
5
is located to the left of the cursor.
Key ENT is the ENTER key for any inputting or selections.
Key MENU is the key for the direct menu window jump over. Whenever the user wants
to proceed to a certain menu window, the user can press this key followed by 2-digit
numbers.
The MENU key is shortened as the ‘M’ key afterward when referring to the menu windows.
The ON key is for the power on.
The OFF key is for the power off.
2.3 MENU WINDOWS
The user interface of this flow meter comprises about 100 different menu windows that are
numbered by M00, M01, M02 … M94 etc.
There are 2 methods to enter certain menu window:
(1) Direct going/entering. The user can press the MENU key followed by two-digit number
keys. For example, the menu window M20 is for the entering of Fluid Type. The display will
go to the M20 menu window after the user presses MENU 2 0 .
(2) Pressing ∧/+ and ∨/- keys. Each time of the ∧/+ key pressing will proceed to the
lower-numbered menu window. For example, if the current window is on M12, the display
will go to the number M11 window after pressing the ∧/+ key or M13 after pressing the ∨
/- key.
There are three different types of menu windows:
(1) Menu windows for number entering, like M11 for the entering of pipe outer diameter.
(2) Menu windows for option selection/selecting options, like M14 for the selection of pipe
materials.
(3) Displaying windows only, like M00 to display Velocity, Flow Rate etc.
For number entering windows, the user can directly press the starting digit key when the user
is going to modify the value. For example, when the current window is on M11, and the user
is going to enter 154.6 as the pipe outer diameter, the user can get the numbers entered by
pressing the following serial keys: 1 5 4 . 6 ENT.
For the option selection windows, the user should first press the ENT key to a selection
modification mode and then select the relevant options by pressing the ∧/+ and ∨/- keys
or the digit keys to select the option with a number antecedent to the option. In the end, the
ENT key must be pressed to make the selection. For example, with menu window M14 for
the selection of pipe material selection, (the MENU 1 4 should be pressed first to

TF1100-EH transit-time handheld flowmeter manual
6
enter this menu window if the current menu window is on a different window. The pipe
material is stainless steel which has a number “1” antecedent to “stainless steel” on the
display, the user should first press the ENT key to enter into a selection modification mode,
then either make the selection by pressing the ∧/+ and ∨/- keys to make the cursor on the
line that displays “1. Stainless Steel”, or make the selection by pressing the 1 key directly.
Generally, the ENT key must be pressed to enter a modification mode. If the “Locked M47
Open’ message is indicated on the lowest line of the LCD display, it means the
modification operations is locked out. In such cases, the user should go to M47 to have the
instrument unlocked first before any further modification can be made.
2.4 MENU WINDOWSARRANGEMENT
M00~M09 windows for the display of the flow rate, velocity, date time, totalizers, battery
voltage and estimated working hours for the battery.
M10~M29 windows for entering the pipe parameter.
M30~M38 windows for flow rate unit selections and totalizer unit selections.
M40~M49 windows for response time, zeroing, calibration and modification password
setup.
M50~M53 windows for the built-in logger
M60-M78 windows for time-keeper initialization, version and ESN information viewing
and alarms.
M82 window for viewing date totalizer.
M90~M94 are diagnostic windows for a more accurate measurement.
M+0~M+8 are windows for some additional functions, including a scientific calculator,
viewer on records such as total working hours, turn-on and turn-off times, dates
and times when the flow meter has been turned on or turned off.
Other menu windows such as M88 have no functions, or functions were cancelled because
they are not applied to this version of the software.
The major reason why the menu windows are arranged in this way is that the software
programmer hopes that the menu window arrangement for this version has the most
compatibility with the previous versions of the TF1100-EH dedicated model software. This
will make it easier for the former version users with this flow meter series.

TF1100-EH transit-time handheld flowmeter manual
7
2.5 STEPS TO CONFIGURE THE PARAMETERS
The following parameters need to be configured for a proper measurement:
(1) Pipe outer diameter (O.D.)
(2) Pipe wall thickness
(3) Pipe materials (for non-standard pipe materials*, the sound speed for the material must be
configured too)
*Standard pipe materials and standard liquids refer to those with the sound parameters
that have already been programmed into software of the flow meter; therefore there is no
need to configure them.
(4) Liner material and its sound speed and thickness, if there is any liner.
(5) Liquid type (for non-standard liquids, the sound speed of the liquid is also needed)
(6) Transducer type adapted to the flow meter. Generally the Standard M1 or the Frame
M-sized transducers will be the selected option.
(7) Transducer mounting methods (the V-method or Z-method is the common option)
(8) Check up the Space displayed on M25 and install the transducers accordingly.
For standard pipe materials and standard liquids, the following detailed step-by-step setup is
recommended.
(1) Press keys MENU 1 1 to enter M11 window to input the digits for the pipe outer
diameter, and then press ENT key.
(2) Press key ∨/- to enter M12 window to input the digits for the wall thickness and then
press ENT key.
(3) Press key ∨/- to enter M14 window, and press ENT key to enter the pipe material.
Use keys ∧/+ and ∨/- to scroll up and down to the intended pipe material, and then
press ENT key. If you select “Other”, you must enter Menu15, pipe sound speed.
(4) Press key ∨/- to enter M16 window, press ENT key to enter the option selection
mode, use keys ∧/+ and ∨/- to scroll up and down to the liner material, and then
press ENT key. Select “No Liner”, if there is no liner, If you select “Other”, you must
enter Menu17, liner sound speed.
(5) Enter “Liner Thickness” in Menu18.
(5) Press key ∨/- to enter M20 window, press ENT key to enter Fluid Type, use keys
∧/+ and ∨/- to scroll up and down to the proper liquid, and then press ENT key.
If you select “Other”, you must enter Menu21, Fluid sound speed and Menu 22, Fluid
Viscosity
(6) Press key ∨/- to enter M23 window, press ENT key to enter the Transducer Type,
use keys ∧/+ and ∨/- to scroll up and down to the proper Transducer Type (Standard
S, M, L) you selected, and then press ENT key. Plug Type C and B are for Insertion
transducer, no matter with Clamp-on transducers.
(7) Press key ∨/- to enter M24 window to select Transducer Mounting mode, and then
