Lanscape Forms FGP Series User manual

Page 1 of 2
HANDLEWITHCARE! Thefinishcanbescuffedbycontactwithtools,concrete,
orotherabrasivesurfaces.Protectthefinishfromdamageduringinstallation.
FGP Bench
Installation Guide www.landscapeforms.com Ph: 800.521.2546
Date: September 27, 2016
ToolsRequired
•Hammerdrillwithmasonrybits
Forsurfacemountoption:
•(4)zinc‐plateddrop‐inanchorsfor5/8‐11threadsize,forusewithMagni‐coatedbolts
•3mmhexkey
•Slottedscrewdriver
Forembeddedoption:
•Forembeddedmountoption:chemicalanchoringadhesive(HiltiHITRE500or
equivalent)
Backless,70in Backless,120in Backed,70in Backed,120in
INSTALLATIONPROCEDURE:
Benchshipsfullyassembled.Freestandingunitcanbesetinplace.
FOREMBEDDEDMOUNT:
1. Turnbenchupsidedownonprotectivesurface.
2. RemovefourouterscrewsfromglidesasshowninFig.1.Leaveglidesinstalled.
3. InstallfourthreadedrodsasshowninFig.2.
4. Setunitinpositionandmarkholelocations.
5. Moveunitaside.
6. DrillholesaccordingtoFig.3.Clearholesofdebris.
7. Setunitbackinposition,ensuringthatthreadedrodsarenotrestingonthebottom
ofthehole.Ifnecessary,moveunitanddrillholesdeeper.
8. Fillholeswithadhesivetolevelrecommendedbyadhesivemanufacturer.
9. Setunitinposition.Wipeawayexcessadhesivebeforeitcures.
FORSURFACEMOUNT:
1. Turnbenchupsidedownonprotectivesurface.
2. InstallsurfacemountboltsandsetscrewsasshowninFig.4.
3. Setunitinpositionandmarkholelocations.
4. Moveunitaside.Removesurfacemountboltsandsetscrews.
5. Drillholesaccordingtoconcreteanchormanufacturer’srecommendations.
6. Clearholesofdebris.
7. Installconcreteanchors(notincluded).
8. Installsurfacemountboltsintoconcreteanchors.
9. Setbenchinpositionoversurfacemountbolts.
10. InstallsetscrewsasshowninFig.5.
4x–5/8‐11thread
Surfacemt bolt
4x–M8x1.25x100mm
Embeddedthreadedrod
4x–M6‐1x25mm
Setscrew
Includedcomponents(surfacemount) Includedcomponents(embedded)

FGP Bench
Installation Guide www.landscapeforms.com Ph: 800.521.2546
Date: September 27, 2016
Page 2 of 2
Fig.4–Installsurfacemountboltsandsetscrews
Fig.2–Installthreadedrods
Fig.3– Embeddedsectiondetailforholes
[127mm]
5”MIN
Fig.5–Surfacemountboltsectionview
SETSCREW
SURFACE
MOUNT BOLT
DROP‐IN
ANCHOR
(NOTINCLUDED)
MIN
Fig.1–Removescrewsforthreadedrodinstall
