Lantech IGS-0208GSFP User manual

Lantech
I(P)GS-0208GSFP
8 10/100/1000T + 2 1G SFP (w/8 PoE at/af)
Industrial Unmanaged Switch
User Manual
Aug 2021

Recommendation for Shielded network cables
STP cables have additional shielding material that is used to reduce external interference. The
shield also reduces the emission at any point in the path of the cable. Our recommendation is
to deploy an STP network cable in demanding electrical environments. Examples of
demanding indoor environments are where the network cable is located in parallel with
electrical mains supply cables or where large inductive loads such as motors or contactors are
in close vicinity to the camera or its cable. It is also mandatory to use an STP cable where the
power device (like IP camera) is used outdoors or where the network cable is routed outdoors.

Content
Overview............................................................3
Introduction .............................................................. 3
Packing List.............................................................. 3
Safety Precaution.....................................................3
Hardware Description.........................................4
Front Panel...............................................................4
Top View .................................................................. 5
Dimensions .............................................................. 5
Wiring the Power Inputs...........................................6
LED Indicators..........................................................8
RJ-45 Pin Assignments............................................9
Cabling...................................................................11
Mounting Installation........................................15
DIN-Rail Mounting.................................................. 15
Wall-Mount Plate Mounting....................................17
Hardware Installation .......................................18
Installation Steps.................................................... 19

Troubleshooting ...............................................20

3
Overview
Introduction
Lantech I(P)GS-0208GSFP is a high performance all Gigabit switch
with 8 10/100/1000T + 2x 1G SFP (w/8 PoE 802.3af/at Injectors.)
For latest product specifications, please refer to Lantech official site.
Packing List
1 x Industrial Ethernet Switch
1 x Terminal Block
1 x Quick Installation Guide
Safety Precaution
Attention
If DC voltage is supplied by an external circuit, please use a
protection device on the power supply input.

4
Hardware Description
In this paragraph, we will introduce the Industrial switch’s dimensions,
port, cabling information, and wiring installation.
Front Panel
The Front Panel of the switch is shown as below.
Front Panel of the Industrial Switch

5
Top View
The top panel of the Industrial Switch is equipped one terminal block
connector of two DC power inputs.
Top panel of the Industrial Switch Converter
Dimensions
. The dimensions are 74 x 152 x 105 mm (W x H x D). The figure below
gives the dimensions and views of each side of the Industrial Switch.

6
Wiring the Power Inputs
Voltage of Power Input
IPGS-0208GSFP-12V
12V model:
The power input voltage can
be from 9.5V to 56VDC to
feed power on both the
802.3af and 802.3at
standardized devices.
IPGS-0208GSFP-48V
48V model:
The power input voltage can
be from 45V to 56VDC to feed
power on both 802.3af/at
standardized devices.
IGS-0208GSFP
The power input voltage can
be from 9.5V to 60VDC
Please make sure that the external power supply unit you use
to provide the PoE voltage meet the following criteria: The
power consumption can satisfy the total power request from all
PD devices required.
Please follow the steps below to insert the power wire.
1. Insert the positive and negative wires into the V+ and V- contacts on the
terminal block connector.

7
2. To tighten the wire-clamp screws for preventing the DC wires to loose.
Note
The wire gauge for the terminal block should be in the range
between 12~ 24 AWG.

8
LED Indicators
The LED indicators located on the front panel display the power status
and network status of the Industrial switch; each has their own specific
meaning as the table shown below.
LED
Color
Description
P1
Green
On
Power input 1 is active
Off
Power input 1 is inactive
P2
Green
On
Power input 2 is active
Off
Power input 2 is inactive
Fault
Red
On
Power input 1 or 2 is inactive
Off
Power input 1 and 2 are both functional, or no power
inputs
1 ~ 8
LNK/ACT
(Upper LED)
Green
On
Connected to network
Flashing
Networking is active
Off
Not connected to network
1 ~ 8
Speed
(Lower LED)
Yellow
On
Connected to network at speed of 1000Mbps
Off
Not connected to network or not working at speed of
1000Mbps
9 ~ 10
LNK/ACT
Green
On
A network device is detected.
Blinking
The port is transmitting or receiving packets from
the TX device.
PoE
(IPGC only)
Green
On
Link to PD(PoE device)
Off
Link to none PoE device

9
RJ-45 Pin Assignments
The UTP/STP ports will automatically sense for Fast Ethernet
(10Base-T/100Base-TX) or Gigabit Ethernet
(10Base-T/100Base-TX/1000Base-T) connection. Auto MDI/MDIX means that
the switch can connect to another switch or workstation without changing
straight through or crossover cabling. See the figures below for straight
through and crossover cable schema.
10/100Base-TX Pinouts
Pin Number
Assignment
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Note
“+” and “-” signs represent the polarity of the wires that make up
each wire pair.
The table below shows the 10Base-T/100Base-TX MDI and MDI-X port
pinouts.
Pin Number
MDI-X Signal Name
MDI Signal Name
1
Receive Data plus (RD+)
Transmit Data plus (TD+)
2
Receive Data minus (RD-)
Transmit Data minus (TD-)
3
Transmit Data plus (TD+)
Receive Data plus (RD+)
6
Transmit Data minus (TD-)
Receive Data minus (RD-)

10
10/100Base-TX Cable Schema
Straight Through Cable Schema
Crossover Cable Schema
10/100/1000Base-T Pinouts
The table below describes the gigabit Ethernet RJ-45 pinouts.
Pin
Signal name
Description
1
BI_DA+
Bi-directional pair A+
2
BI_DA-
Bi-directional pair A-
3
BI_DB+
Bi-directional pair B+
4
BI_DC+
Bi-directional pair C+
5
BI_DC-
Bi-directional pair C-
6
BI_DB-
Bi-directional pair B-
7
BI_DD+
Bi-directional pair D+
8
BI_DD-
Bi-directional pair D-

11
10/100/1000Base-T Cable Schema
The following two figures illustrate the 10/100/1000Base-T cable
schema.
Straight Through Cable Schema
Crossover Cable Schema
Cabling
Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP)
cable for RJ-45 connections: 100Ω Category 3, 4 or 5 cable for
10Mbps connections, 100Ω Category 5 cable for 100Mbps, or 100Ω
Category 5e/above cable for 1000Mbps connections. The cable
between the switch and the link partner (switch, hub, workstation, etc.)
must be less than 100 meters (328 ft.) long.
Fiber segment using single-mode connector type must use9/125 µm
single-mode fiber cable. User can connect two devices in the distance

12
up to 30km.
Fiber segment using multi-mode connector type must use 50 or
62.5/125 µm multi-mode fiber cable. User can connect two devices
up to 2kmdistances.
Gigabit SFP port:
The small form-factor pluggable (SFP) is a compact optical transceiver
used in optical communications for both telecommunication and data
communications. The SFP slots supporting Gigabit speed up to
1000Mbps. They are used for connecting to the network segment with
single or multi-mode fiber. You can choose the appropriate SFP
transceiver to plug into the slots. Then use proper multi-mode or
single-mode fiber according to the transceiver. With fiber optic, it transmits
at speed up to 1000 Mbps and you can prevent noise interference from
the system.
To connect the transceiver and LC cable, please follow the steps shown
below:
First, insert the transceiver into the SFP module. Notice that the triangle
mark is the bottom of the module.
Transceiver to the SFP module

13
Transceiver Inserted
Second, insert the fiber cable of LC connector into the transceiver.
LC connector to the transceiver

14
To remove the LC connector from the transceiver, please follow the steps
shown below:
First, press the upper side of the LC connector to release from the
transceiver and pull it out.
Remove LC connector
Second, push down the metal loop and pull the transceiver out by the
plastic handle.
Pull out from the transceiver

15
Mounting Installation
DIN-Rail Mounting
The DIN-Rail is screwed on the industrial switch when out of factory. If the DIN-Rail is not
screwed on the industrial switch, please see the following pictures to screw the DIN-Rail
on the switch. Follow the steps below to hang the industrial switch.

16
1. First, insert the top of DIN-Rail into the track.
2. Then, lightly push the DIN-Rail into the track.
3. Check if the DIN-Rail is tightened on the track or not.
4. To remove the industrial switch from the track, reverse above steps.

17
Wall-Mount Plate Mounting
*Optional Wall Mount Kit required
Follow the steps below to mount the industrial switch with wall mount
plate.
1. Remove the DIN-Rail from the industrial switch; loose the screws to
remove the DIN-Rail.
2. Place the wall mount plate on the rear panel of the industrial switch.
3. Use the screws to screw the wall mount plate on the industrial switch.
4. Use the hook holes at the corners of the wall mount plate to hang the
industrial switch on the wall.
5. To remove the wall mount plate, reverse the above steps.

18
Hardware Installation
In this paragraph, we will describe how to install the 8-port
10/100/1000Base-TX Industrial Switch and the installation points for the
attention.
