Lantech IES-5416DF Series User manual

IPES/IES-5416DF
IPES/IES-5216DF
Series
16 10/100TX + 4 or 2 100/1000FX Dual Speed Fiber L2+(w/ PoE
at/af) EN50155 Managed Ethernet Switch
User Manual (Hardware)
IP-67
IP-54
Apr 2019

Recommendation for Shielded network cables
STP cables have additional shielding material that is used to reduce external interference.
The shield also reduces the emission at any point in the path of the cable. Our
recommendation is to deploy an STP network cable in demanding electrical environments.
Examples of demanding indoor environments are where the network cable is located in
parallel with electrical mains supply cables or where large inductive loads such as motors
or contactors are in close vicinity to the camera or its cable. It is also mandatory to use an
STP cable where the power device (like IP camera) is used outdoors or where the network
cable is routed outdoors.

Important Notice
Lantech Communications Global, Inc. reserves the right to modify the
equipment, its specification or this manual without prior notice, in the interest
of improving performance, reliability, or servicing. At the time of publication
all data is correct for the operation of the equipment at the voltage and/or
temperature referred to. Performance data indicates typical values related to
the particular product.
No part of this documentation or information supplied may be divulged to any
third party without the express written consent of Lantech Communications
Global Inc. Products offered may contain software which is proprietary to
Lantech Communications Global Inc. The offer or supply of these products
and services does not include or infer any transfer of ownership.
Interference Issues
This Equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
commercial or industrial installation. This equipment generates, uses, and
can radiate radio frequency energy. It may cause harmful interference to
radio communications if the equipment is not installed and used in
accordance with the instructions.

FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy. It may cause harmful interference to radio
communications if the equipment is not installed and used in accordance
with the instructions. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.

Content
Chapter 1 Introduction ........................................... 5
Chapter 2 Hardware Description............................ 6
2.1 Physical Dimension....................................... 6
2.2 IP Protection................................................12
2.3 LED Indicators .............................................15
Chapter 3 Hardware Installation .......................... 17
Chapter 4 Network Application............................ 22
4.1 ITU G.8032 Scheme......................................22
4.2 Ring Coupling ...............................................22
4.3 Multiple Rings ...............................................23
4.4 Dual Homing.................................................24
4.5 Chain ............................................................24
Chapter 5 Console Management.......................... 26
5.1 Connecting to the Console Port....................26
5.2 Login in the Console Interface......................26

5
Chapter 1 Introduction
Model Description
IPES-5416DF series
16 10/100TX PoE at/af + 4 Dual Speed Fiber L2+EN50155
Managed IP67/IP54 Ethernet Switch w/ 8 or 16 PoE at/af
IPES-5216DF series
16 10/100TX PoE at/af + 2 Dual Speed Fiber L2+EN50155
Managed IP67/IP54 Ethernet Switch w/ 8 or 16 PoE at/af
IES-5416DF series
16 10/100TX PoE at/af + 4 Dual Speed Fiber L2+EN50155
Managed IP67/IP54 Ethernet Switch
IES-5216DF series
16 10/100TX PoE at/af + 2 Dual Speed Fiber L2+EN50155
Managed IP67/IP54 Ethernet Switch

6
Chapter 2 Hardware Description
In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling
information, and wiring installation.
2.1 Physical Dimension
IPES-5416DF
Aluminum case. IP-67,
285 (W) x 193 (D) x 91.2 (H) mm
Aluminum case. IP-54,
252 (W) x 179.5 (D) x 91 (H) mm

7
IES-5416DF
Aluminum case. IP-67,
285 (W) x 193 (D) x 91.2 (H) mm

8
Aluminum case. IP-54,
252 (W) x 179.5 (D) x 91 (H) mm

9
IPES-5216DF
Aluminum case. IP-67,
285 (W) x 201.4 (D) x 84.4 (H) mm
Aluminum case. IP-54,
285 (W) x 201.4 (D) x 84.4 (H) mm

10
IES-5216DF
Aluminum case. IP-67,
285 (W) x 201.4 (D) x 84.4 (H) mm

11
Aluminum case. IP-54,
285 (W) x 201.4 (D) x 84.4 (H) mm

12
Front panel of IPES-5416DF
2.2 IP Protection
The IP Code, Ingress Protection Rating, sometimes also interpreted as International
Protection Rating, classifies and rates the degree of protection provided against the
intrusion (including body parts such as hands and fingers), dust, accidental contact, and
water in mechanical casings and with electrical enclosures. It is published by the
International Electrotechnical Commission (IEC)
Solid particle protection

13
The first digit indicates the level of protection that the enclosure provides against access
to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid
foreign objects.
Level
Object size
protected against
Effective against
0
—
No protection against contact and ingress of objects
1
>50 mm
Any large surface of the body, such as the back of a
hand, but no protection against deliberate contact
with a body part
2
>12.5 mm
Fingers or similar objects
3
>2.5 mm
Tools, thick wires, etc.
4
>1 mm
Most wires, screws, etc.
5
Dust protected
Ingress of dust is not entirely prevented, but it must
not enter in sufficient quantity to interfere with the
satisfactory operation of the equipment; complete
protection against contact
6
Dust tight
No ingress of dust; complete protection against
contact
Liquid ingress protection
The second digit indicates the level of protection that the enclosure provides against
harmful ingress of water.
Level
Protected
against
Testing for
Details
0
Not
protected
—
—

14
1
Dripping
water
Dripping water (vertically
falling drops) shall have no
harmful effect.
Test duration: 10 minutes
Water equivalent to 1 mm
rainfall per minute
2
Dripping
water when
tilted up to
15°
Vertically dripping water
shall have no harmful effect
when the enclosure is tilted
at an angle up to 15°from
its normal position.
Test duration: 10 minutes
Water equivalent to 3 mm
rainfall per minute
3
Spraying
water
Water falling as a spray at
any angle up to 60°from
the vertical shall have no
harmful effect.
Test duration: 5 minutes
Water volume: 0.7 litres per
minute
Pressure: 80–100 kPa
4
Splashing
of water
Water splashing against
the enclosure from any
direction shall have no
harmful effect.
Test duration: 5 minutes
Water volume: 10 litres per
minute
Pressure: 80–100 kPa
5
Water jets
Water projected by a
nozzle (6.3 mm) against
enclosure from any
direction shall have no
harmful effects.
Test duration: at least
15 minutes
Water volume: 12.5 litres per
minute
Pressure: 30 kPa at distance
of 3 m
6
Powerful
water jets
Water projected in powerful
jets (12.5 mm nozzle)
against the enclosure from
any direction shall have no
harmful effects.
Test duration: at least
3 minutes
Water volume: 100 litres per
minute
Pressure: 100 kPa at
distance of 3 m
7
Immersion
up to 1 m
Ingress of water in harmful
quantity shall not be
possible when the
enclosure is immersed in
Test duration: 30 minutes
Immersion at depth of at
least 1 m measured at
bottom of device, and at least

15
water under defined
conditions of pressure and
time (up to 1 m of
submersion).
15 cm measured at top of
device
8
Immersion
beyond 1 m
The equipment is suitable
for continuous immersion in
water under conditions
which shall be specified by
the manufacturer.
Normally, this will mean
that the equipment is
hermetically sealed.
However, with certain types
of equipment, it can mean
that water can enter but
only in such a manner that
it produces no harmful
effects.
Test duration: continuous
immersion in water
Depth specified by
manufacturer
9
Powerful
high
temperature
water jets
Protected against close-
range high pressure, high
temperature spray downs.
—
2.3 LED Indicators
The diagnostic LEDs that provide real-time information of system and optional status are
located on the front panel of the industrial switch. The following table provides the
description of the LED status and their meanings for the switch.
LED
Color
Status
Meaning
R.M
Green
On
The switch unit is owner switch of ITU-Ring

16
Off
The switch is not owner switch
PWR1
Green
On
Power 1 is active
Off
Power 1 is inactive
PWR2
Green
On
Power 2 is active
Off
Power 2 is inactive
FAULT
Red
On
Power or port failure
Off
No failure
P1 ~ P16
Lnk/Act
On
A network device is detected.
Blinking
The port is transmitting or receiving packets
from the TX device.
Off
No device attached
PoE(1~8)
On
The port is operating in PoE mode.(IPES)
Off
The port is not operating in PoE
mode.(IPES)
P17 ~ P20
(5416DF)
P17 ~ P18
(5216DF)
Lnk/Act
On
A network device is detected.
Blinking
The port is transmitting or receiving packets
from the TX device.
Off
No device attached.

17
Chapter 3 Hardware Installation
3.1Hardware installation
3.1.1Unpack switch and check the accessory with packing list
3.1.2 Mount the switch on desired position
3.1.3 Connect the M23/M12 connector of power input.
Voltage of Power Input
Non-PoE model
(5-pin M12
connector)
12V model:
The power input voltage can be from
9V to 60VDC
72V model:
The power input voltage can be from
50.4V to 90VDC
110V model:
The power input voltage can be from
43V to 137.5VDC
WV model:
The power input voltage can be from
16.8V to 137.5VDC
PoE model
(5-pin M23
connector)
12V model:
The power input voltage can be from
9.5V to 56VDC to feed power on both
the 802.3af and 802.3at standardized
devices.
72V model:
The power input voltage can be from

18
50.4V to 90VDC to feed power on both
802.3af/at standardized devices.
110V model:
The power input voltage can be from
43V to 137.5VDC to feed power on
both 802.3af/at standardized devices.
Make sure that the external power supply unit you use to provide
the PoE voltage fulfils the following basic criteria:
The output voltage of power supply must exceed 48VDC for 802.3af
and 53VDC for 802.3at operation (*with IPES-5416DF-72V, only
72VDC can power both the 802.3af and 802.3at PD. **with IPES-
5416DF-110V, only 110VDC can power both the 802.3af and 802.3at
PD.)
The power consumption can satisfy the total power request from all
PD devices required.
Non-PoE model (M12)
PoE model (M23)
Pin assignment of Power input
Dual Power Input
The power input can be supported redundantly. The supply voltage is
electrically isolated from the housing.
Note: With single power supply of the mains voltage, the device will

19
report a power failure. You can disable this power fail event via web
browser.
Pin assignment of alarm relay
A break in contact is reported via the relay contact :
The failure of at least one of the two supply voltages.
The break link status of at least one switch port.
3.1.4 Fitting the device, grounding
Install the system in a dry and clean area to protect the switch to
get exposed with dirt.
Plug the connector to the power supply plug then turn on the power
supply.
Ground
The chassis is grounded via a separate ground nut (M3).
Use toothed locking washers for a good electrical connection.
