Lantech IES-5416T Series User manual

IPES/IES-5416T Series
16 10/100TX + 4 1000T L2+(w/8 or 16 PoE at/af)
EN50155 Managed Ethernet Switch
User Manual (Hardware)
IP-67
IP-54
Aug. 2023

Recommendation for Shielded network cables
STP cables have additional shielding material that is used to reduce external interference.
The shield also reduces the emission at any point in the path of the cable. Our
recommendation is to deploy an STP network cable in demanding electrical environments.
Examples of demanding indoor environments are where the network cable is located in
parallel with electrical mains supply cables or where large inductive loads such as motors
or contactors are in close vicinity to the camera or its cable. It is also mandatory to use an
STP cable where the power device (like IP camera) is used outdoors or where the network
cable is routed outdoors.

Important Notice
Lantech Communications Global, Inc. reserves the right to modify the
equipment, its specification or this manual without prior notice, in the interest
of improving performance, reliability, or servicing. At the time of publication
all data is correct for the operation of the equipment at the voltage and/or
temperature referred to. Performance data indicates typical values related to
the particular product.
No part of this documentation or information supplied may be divulged to any
third party without the express written consent of Lantech Communications
Global Inc. Products offered may contain software which is proprietary to
Lantech Communications Global Inc. The offer or supply of these products
and services does not include or infer any transfer of ownership.
Interference Issues
This Equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
commercial or industrial installation. This equipment generates, uses, and
can radiate radio frequency energy. It may cause harmful interference to
radio communications if the equipment is not installed and used in
accordance with the instructions.

FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy. It may cause harmful interference to radio
communications if the equipment is not installed and used in accordance
with the instructions. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.

Content
Chapter 1 Introduction.............................................5
Chapter 2 Hardware Description ............................6
2.1 Physical Dimension........................................ 6
2.2 Front Panel..................................................... 7
2.3 Package Content:........................................... 8
2.4 IP Protection................................................... 9
2.5 LED Indicators.............................................. 12
Chapter 3 Hardware Installation...........................14
Chapter 4 Console Management ..........................22
4.1. Connecting to the Console Port................... 22
4.2. Login in the Console Interface ..................... 22

5
Chapter 1 Introduction
Lantech IES-5416T & IPES-5416T-8/16 (IP67/IP54) series is a high performance L2+
IP67/IP54 industrial Gigabit uplink switch with 8x10/100TX + 4 10/100/1000T (w/8 or 16
PoE at/af injectors: IPES models) by M12 connectors which provides L2 wire speed and
advanced security function for connecting PD network.

6
Chapter 2 Hardware Description
In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling
information, and wiring installation.
A battery is inside the device to maintain the RTC function with estimated battery life of
10 years. The lost of battery power will only effect the RTC function. *Unless otherwise
specified.
2.1 Physical Dimension
Aluminum case. IP-67,
285 (W) x 201.4 (D) x 84.4 (H) mm
Aluminum case. IP-54,
250mm(W)x179.5mm(H)x76.5mm(D)

7
2.2 Front Panel
PoE model

8
Non-PoE model
2.3 Package Content:
Ethernet switch
Console cable
Manual CD (by request)

9
2.4 IP Protection
The IP Code, Ingress Protection Rating, sometimes also interpreted as International
Protection Rating, classifies and rates the degree of protection provided against the
intrusion (including body parts such as hands and fingers), dust, accidental contact, and
water in mechanical casings and with electrical enclosures. It is published by the
International Electrotechnical Commission (IEC)
Solid particle protection
The first digit indicates the level of protection that the enclosure provides against access
to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid
foreign objects.
Level
Object size
protected against
Effective against
0
—
No protection against contact and ingress of objects
1
>50 mm
Any large surface of the body, such as the back of a
hand, but no protection against deliberate contact
with a body part
2
>12.5 mm
Fingers or similar objects
3
>2.5 mm
Tools, thick wires, etc.
4
>1 mm
Most wires, screws, etc.
5
Dust protected
Ingress of dust is not entirely prevented, but it must
not enter in sufficient quantity to interfere with the
satisfactory operation of the equipment; complete
protection against contact
6
Dust tight
No ingress of dust; complete protection against
contact

10
Liquid ingress protection
The second digit indicates the level of protection that the enclosure provides against
harmful ingress of water.
Level
Protected
against
Testing for
Details
0
Not
protected
—
—
1
Dripping
water
Dripping water (vertically
falling drops) shall have no
harmful effect.
Test duration: 10 minutes
Water equivalent to 1 mm
rainfall per minute
2
Dripping
water when
tilted up to
15°
Vertically dripping water
shall have no harmful effect
when the enclosure is tilted
at an angle up to 15°from
its normal position.
Test duration: 10 minutes
Water equivalent to 3 mm
rainfall per minute
3
Spraying
water
Water falling as a spray at
any angle up to 60°from
the vertical shall have no
harmful effect.
Test duration: 5 minutes
Water volume: 0.7 litres per
minute
Pressure: 80–100 kPa
4
Splashing
of water
Water splashing against
the enclosure from any
direction shall have no
harmful effect.
Test duration: 5 minutes
Water volume: 10 litres per
minute
Pressure: 80–100 kPa
5
Water jets
Water projected by a
nozzle (6.3 mm) against
enclosure from any
direction shall have no
harmful effects.
Test duration: at least
15 minutes
Water volume: 12.5 litres per
minute
Pressure: 30 kPa at distance
of 3 m

11
6
Powerful
water jets
Water projected in powerful
jets (12.5 mm nozzle)
against the enclosure from
any direction shall have no
harmful effects.
Test duration: at least
3 minutes
Water volume: 100 litres per
minute
Pressure: 100 kPa at
distance of 3 m
7
Immersion
up to 1 m
Ingress of water in harmful
quantity shall not be
possible when the
enclosure is immersed in
water under defined
conditions of pressure and
time (up to 1 m of
submersion).
Test duration: 30 minutes
Immersion at depth of at
least 1 m measured at
bottom of device, and at least
15 cm measured at top of
device
8
Immersion
beyond 1 m
The equipment is suitable
for continuous immersion in
water under conditions
which shall be specified by
the manufacturer.
Normally, this will mean
that the equipment is
hermetically sealed.
However, with certain types
of equipment, it can mean
that water can enter but
only in such a manner that
it produces no harmful
effects.
Test duration: continuous
immersion in water
Depth specified by
manufacturer
9
Powerful
high
temperature
water jets
Protected against close-
range high pressure, high
temperature spray downs.
—

12
2.5 LED Indicators
The diagnostic LEDs that provide real-time information of system and optional status are
located on the front panel of the industrial switch. The following table provides the
description of the LED status and their meanings for the switch.
LED
Color
Status
Meaning
R.M
Green
On
The switch unit is owner switch of ITU-Ring
Off
The switch is not owner switch
PWR1
Green
On
Power 1 is active
Off
Power 1 is inactive
PWR2
Green
On
Power 2 is active
Off
Power 2 is inactive
FAULT
Red
On
Power or port failure
Off
No failure
P1 ~ P16
Link/Ack
On
A network device is detected.
Blinking
The port is transmitting or receiving packets
from the TX device.
Off
No device attached
PoE(1~8)(IP
ES-5416T-
8)
PoE(1~16)(I
PES-5416T-
16)
On
The port is operating in PoE mode.(IPES)
Off
The port is not operating in PoE
mode.(IPES)
P17 ~ P20
Link/Ack
On
A network device is detected.

13
Blinking
The port is transmitting or receiving packets
from the TX device.
Off
No device attached.

14
Chapter 3 Hardware Installation
For POE models: Do not use units’ POE ports to uplink to another POE switch in vehicle
applications. (May Cause Damage) Lantech strongly advise the installation of a Galvanic isolated
DC/DC converter between the power supply and the Ethernet switch on all Non-Isolated models.
Please contact the sales team for advice on which models support isolated power design.
3.1Hardware installation
3.1.1Unpack switch and check the accessory with packing content list
3.1.2 Mount the switch on desired position. For the best ventilation, it is
suggested to mount the switch on metallic surface.
3.1.3 Connect the M12/M23 connector of power input. The power supply
for the series is connected via a 5-pole M12/M23 male connector. *May
vary by models. Please check the front panel of the switch.
Note: Please check the power connector has been connected to the switch
correctly before you turn on the power resource.
Voltage of Power Input
Non-PoE model
24V model:
9V to 36VDC
24VI model:
9V to 36VDC with galvanic isolation
24TVI model:

15
16.8V to 56VDC with galvanic isolation
WV model:
16.8V to 137.5VDC
WVI model:
16.8V to 137.5VDC with galvanic
isolation
PoE model
24V model:
9V to 36VDC
24VI model:
9V to 36VDC with PoE galvanic
isolation
24TVI model:
16.8V to 56VDC with PoE galvanic
isolation
WV model:
16.8V to 137.5VDC
WVI model:
16.8V to 137.5VDC with PoE galvanic
isolation
Please make sure that the external power supply unit you use to
provide the PoE voltage meet the following criteria:
The power consumption can satisfy the total power request from all
PD devices required.

16
M12 power connector
M23 power connector
Pin assignment of Power input
Dual Power Input
The power input can be supported redundantly. The supply voltage is
electrically isolated from the housing.
Note: With single power supply of the mains voltage, the device will
report a power failure. You can disable this power fail event via web
browser.
Attention: When connecting to 110V DC power sources, the following
scenarios can damage to the switch. Please avoid these scenarios.

17
Pin assignment of alarm relay
A break in contact is reported via the relay contact :
The failure of at least one of the two supply voltages.
The break link status of at least one switch port.
3.1.4 Fitting the device, grounding
Install the system in a dry and clean area to protect the switch to
get exposed with dirt.
Plug the connector to the power supply plug then turn on the power
supply.
Ground –IP67 model
The chassis is grounded via a separate ground nut (M3).
Use toothed locking washers for a good electrical connection.

18
Ground screw of Ethernet switch
Ground –IP54 model
The chassis is grounded via a separate grounding nut (M6).
Use toothed locking washers for a good electrical connection.
*Note: The torque should not be over 14 kilogram-force centimeter (kgf·cm).
Using torque over 14 kgf·cm may cause damage to the grounding parts.
Ground screw of the switch
3.1.5 Connect the M12 connector with RJ-45 data cable, ports are not
used shall be caped that comes with the package to insulate the
surrounding.

19
Pin assignment of M12 10/100Tx network connector
