xPico® 110 Evaluation Kit Quick Start Guide
WHAT’S
IN THE
BOX
xPico 110
Evaluation Board
Product
Registration Form
PRODUCT
REG FORM
Power Supply
With
Regional Adapters
1. Connect the PC to the numbered device ports (Serial 1/Serial 2) on the xPico 110 evaluation board
using appropriate cables and adapters.
2. Connect the evaluation board to the network via an Ethernet cable using the Ethernet (RJ45) port.
3. Supply power to the evaluation board by using the included power adapter and move the power
switch to ON.
4. Via the computer connected on the same network, you can follow the path to device discovery and
initial network configuration as outlined below.
The Ethernet port on xPico 110 defaults to DHCP assigned IP
address. If your network does not support DHCP, then xPico 110
will fall back to using an automatically generated IP address (Auto
IP) within the 169.254.0.0 subnet.
If you want to assign a different IP address, it must be within a
valid range, unique to your network, and within the same subnet as
your workstation.
To configure the xPico 110, you will need the following:
IP address (if not assigned): _____ . _____ . _____ . _____
Subnet mask (if not assigned): _____ . _____ . _____ . _____
Gateway IP address: _____ . _____ . _____ . _____
DNS Server address: _____ . _____ . _____ . _____
xPico 110 Module
CP Headers
SYSTEM Pins
(RESET/DEFAULTS)
LEDs
Serial 2 Header
Serial 1
Power On/Off Switch
Power Input (USB)
5 VDC
10/100 Ethernet Port
1. HARDWARE OVERVIEW
2. HARDWARE INSTALLATION
3. IP ADDRESSING

Registration
Register the xPico 110 Evaluation Kit to receive notifications for firmware and documentation updates at
www.lantronix.com/product-registration, or scan the QR code.
Technical Support
For technical support queries, visit http://www.lantronix.com/support.
Latest Firmware
For the latest firmware downloads, visit http://www.lantronix.com/support/downloads
4. USING DEVICE INSTALLER
INSTALL DEVICE INSTALLER
1. Download the latest version of DeviceInstaller from
http://www.lantronix.com/downloads. The minimum version
required for DeviceInstaller is 4.4.0.4.
2. Run the executable to start the installation process on the
computer being used to configure the xPico 110.
3. Respond to the installation wizard prompts.
USING DEVICE INSTALLER
Run DeviceInstaller. Click Start > Programs > Lantronix >
DeviceInstaller > DeviceInstaller
1. Click the Search icon.
2. Select the unit from the list of Lantronix products discovered
on the local network.
3. Double click the unit in the list. Details about the unit will be
displayed.
4. Select the Web Configuration tab and click on the green
arrow. You will be prompted for username and password
5. The default USER ID = admin and PASSWORD = PASS (both
are case sensitive)
5. COMPLETE THE CONFIGURATION
Continue with the rest of the unit configuration using the Web
Configuration UI.
The unit can also be configured using the Setup Menu. The menu
is accessible via Telnet or the Serial Port.
For detailed instructions, please refer to the xPico 110 User Guide:
http://www.lantronix.com/support/downloads.
KEEP YOUR DEVICE SECURE. Please change the default administrator password before proceeding further.
From the Server menu in the Web UI, enable enhanced password option and enter a new password. Hit Ok to apply
these new settings and continue with the rest of the configuration.
!
xPico® 110 Evaluation Kit Quick Start Guide
©2023 Lantronix, Inc. All rights reserved. Lantronix, xPico and TruPort are registered trademarks of Lantronix, Inc. All other trademarks are the property of their respective owners. Specification are
subject to change without notice. 900-789-R Rev C
