xPort Pro
Embedded Device Server
Integration Guide

xPort® Pro Embedded Device Server Integration Guide 2
Copyright and Trademark
© 2017 Lantronix, Inc. All rights reserved. No part of the contents of this publication
may be transmitted or reproduced in any form or by any means without the written
permission of Lantronix.
Lantronix and xPort are registered trademarks of Lantronix, Inc. in the United States
and other countries. Evolution OS is registered trademark of Lantronix, Inc. in the
United States. DeviceInstaller is a trademark of Lantronix, Inc.
Windows and Internet Explorer are registered trademarks of Microsoft Corporation.
Mozilla and Firefox are registered trademarks of the Mozilla Foundation. Chrome is a
trademark of Google. Opera is a trademark of Opera Software ASA. Freescale is a
registered trademark of Freescale Semiconductor, Inc. Broadcom is a registered
trademark of Broadcom Corporation. All other trademarks and trade names are the
property of their respective holders.
Warranty
For details on the Lantronix warranty policy, please go to our Web site at
www.lantronix.com/support/warranty.
Contacts
Lantronix, Inc. Corporate Headquarters
7535 Irvine Center Drive
Suite 100
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix
web site at www.lantronix.com/about/contact.
Disclaimer and Revisions
Operation of this equipment in a residential area is likely to cause interference, in
which case the user, at his or her own expense, will be required to take whatever
measures may be required to correct the interference.
Note: This product has been designed to comply with the limits for a Class B digital
device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with this guide, may cause harmful interference to
radio communications.
Changes or modifications to this device not explicitly approved by Lantronix will void
the user's authority to operate this device.
Note: With the purchase of Lantronix® xPort® Pro embedded device server, the
OEM agrees to an OEM firmware license agreement that grants the OEM a non-
exclusive, royalty-free firmware license to use and distribute the binary firmware

xPort® Pro Embedded Device Server Integration Guide 3
image provided, only to the extent necessary to use the xPort Pro hardware. For
further details, please see the xPort Pro OEM firmware license agreement.
Revision History
Date
Rev.
Comments
September 2009
A
Initial Draft
December 2010
B
Updated Lantronix address/contact information.
March 2011
C
Updated SDRAM number information.
April 2011
D
Updated part number information.
September 2011
E
Updated compliance information.
April 2012
F
Updated Pin 4 state and part number information.
August 2012
G
Updated recommended operating condition and part number
information.
June 2016
H
Updated to include the xPort Pro Lx6 part number and unit of
measurement information.
August 2017
J
Updated part number SKU information.

xPort® Pro Embedded Device Server Integration Guide 4
Table of Contents
Copyright and Trademark______________________________________________ 2
Disclaimer and Revisions ______________________________________________ 2
Revision History _____________________________________________________ 3
List of Figures _______________________________________________________ 5
List of Tables _______________________________________________________ 5
1. Introduction 6
About the Integration Guide ____________________________________________ 6
Additional Documentation______________________________________________ 6
2. Description and Specifications 7
The xPort Pro Features _______________________________________________ 7
xPort Pro Block Diagram ______________________________________________ 8
PCB Interface _______________________________________________________ 9
Ethernet Interface ___________________________________________________ 10
LEDs _____________________________________________________________ 10
Dimensions________________________________________________________ 11
Recommended PCB Layout___________________________________________ 12
Product Information Label ____________________________________________ 13
Electrical Specifications ______________________________________________ 13
Functional Specifications _____________________________________________ 14
A: xPort Pro 485 Connection Diagram 16
B: Compliance Information 17
RoHS, REACH and WEEE Compliance Statement _________________________ 17

xPort® Pro Embedded Device Server Integration Guide 5
List of Figures
Figure 2-1. Side View of the xPort Pro ____________________________________ 8
Figure 2-2. xPort Pro Block Diagram _____________________________________ 8
Figure 2-3. xPort Pro LEDs ___________________________________________ 10
Figure 2-4. Front View _______________________________________________ 11
Figure 2-5. Bottom View ______________________________________________ 11
Figure 2-6. Side View ________________________________________________ 11
Figure 2-7. PCB Layout ______________________________________________ 12
Figure 2-8. Product Label _____________________________________________ 13
List of Tables
Table 2-1 xPort Pro Part Numbers ______________________________________ 7
Table 2-2 PCB Interface Signals ________________________________________ 9
Table 2-3 Ethernet Interface Signals (Industry Standards) ___________________ 10
Table 2-4 Absolute Maximum Ratings __________________________________ 13
Table 2-5 Recommended Operating Conditions ___________________________ 13
Table 2-6 Technical Specifications _____________________________________ 14

xPort® Pro Embedded Device Server Integration Guide 6
1. Introduction
About the Integration Guide
This guide provides the information needed to integrate the Lantronix Port® Pro
embedded device server into a customer printed circuit board. This manual is
intended for engineers responsible for integrating the xPort Pro into their product.
Note: This document covers xPort Pro Embedded Device Server versions
XPP1004000-02R, XPP1002000-01R, XPP100200S-01R, XPP1002000-02R,
XPP100200S-02R, XPP1003000-01R, XPP100300S-01R, XPP1003000-04R and
XPP100300S-04R.
Additional Documentation
Visit the Lantronix web site at www.lantronix.com/support/documentation for the
latest documentation and the following additional documentation.
Document
Description
xPort Pro Embedded
Device Server User Guide
Provides information needed to configure, use,
and update the xPort Pro firmware.
xPort Pro Lx6 Embedded
Device Server User Guide
Provides information needed to configure, use,
and update the xPort Pro Lx6 firmware.
xPort Embedded Device
Server Universal Demo
Board Quick Start
Provides the steps for getting the xPort Pro up
and running.
xPort Embedded Device
Server Universal Demo
Board User Guide
Provides information needed to use the xPort Pro
on the demo board.
DeviceInstaller User
Guide
Provides instructions for using the Windows-
based utility to configure the xPort Pro and other
Lantronix device servers.
Com Port Redirector User
Guide
Provides information on using the Windows-
based utility to create a virtual com port.

xPort® Pro Embedded Device Server Integration Guide 7
2. Description and Specifications
The xPort Pro embedded device server is Lantronix’s most powerful, self-contained
embedded networking module. Footprint compatible with the popular xPort product
and running either Linux or the Lantronix Evolution OS® operating systems, the xPort
Pro eliminates the complexity of designing network connectivity into a product and
allows you to deploy advanced applications on the edge device itself. The thumb-
sized xPort Pro provides everything you need in a single embedded solution. It
effortlessly handles demanding applications with the power of a high-speed,
advanced architecture 32-bit processor. The ample built-in memory allows virtually
unlimited flexibility for customization and application enablement.
xPort Pro provides bullet-proof security by offering a variety of robust data encryption
and authentication options. What’s more, the option to run Linux, with IPv6 built in,
enables you to deploy custom applications and take advantage of the large feature
libraries available for Linux developers. Critical agency certification has already been
completed by Lantronix, reducing your test time and speeding time-to-market.
The xPort Pro Features
The xPort Pro contains a 32-bit Freescale® processor, with 8/16 megabytes (MB) of
SDRAM (see Table 2-1), 16 MB of Flash and an integrated Broadcom® 10/100 PHY.
Table 2-1 xPort Pro Part Numbers
Part Numbers
SDRAM
Operating System
XPP1002000-01R
8 MB
Evolution
XPP100200S-01R
8 MB
Evolution
XPPDK1000-EVO-01
8 MB
Evolution
XPP1002000-02R
16 MB
Evolution
XPP100200S-02R
16 MB
Evolution
XPPDK1000-EVO-02
16 MB
Evolution
XPP1003000-01R
8 MB
Linux
XPP100300S-01R
8 MB
Linux
XPPDK1000-LNX-01
8 MB
Linux
XPP1003000-04R
16 MB
Linux
XPP100300S-04R
16 MB
Linux
XPPDK1000-LNX-02
16 MB
Linux
XPP1004000-02R
16 MB
Linux

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 8
The xPort Pro also contains the following:
3.3-volt serial interface
All I/O pins are 3.3V tolerant
Ethernet magnetics
Power supply filters
Reset circuit
+1.5V regulator
Crystals and Ethernet LEDs
The xPort Pro requires +3.3-volt power and is designed to operate in an extended
temperature range (see technical data).
Figure 2-1. Side View of the xPort Pro
xPort Pro Block Diagram
The following drawing is a block diagram of the xPort Pro showing the relationships
of the components.
Figure 2-2. xPort Pro Block Diagram
RJ45
CMOS IO
RESET
+3.3VDC
32-bit CPU
FLASH/SDRAM
MAGNETICS
LEDs
Rx
Tx
PHY

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 9
PCB Interface
The xPort Pro has a serial port compatible with data rates up to 921600 bps. The
serial signals (pins 4–8) are 3.3V CMOS logic level. The serial interface pins include
+3.3V, ground, and reset. The serial signals connect to an internal UART driven at
3.3V. For applications requiring an external cable running with RS-232 or RS422/485
voltage levels, the xPort Pro must interface to a serial transceiver chip. We supply an
RS-232 transceiver on the xPort Universal Demo Board for this purpose.
Note: The standard baud rate of 460800 bps is not supported.
Table 2-2 PCB Interface Signals
Signal Name
xPort Pro
Pin #
Primary Function
GND
1
Circuit ground
3.3V
2
+3.3V power in
Reset
3
External reset in
Data Out
1
4
Serial data out (driven by built-in UART)
Data In
5
Serial data in (input to built-in UART)
CP1/RTS
(Configurable Pin 1)
6 CP1 can be configured as follows:
•Flow control: RTS (Request to Send) output driven
by the built-in UART for connection to CTS of
attached device.
•Programmable input/output: CP1 can be driven or
read through software control, independent of serial
port activity.
•RS485 Transmit Enable: In RS485 mode, CP1 is
driven by the built-in UART for connection to the
transmit enable pin of an RS485 Transceiver.
CP2/DTR
(Configurable Pin 2)
7 CP2 can be configured as follows:
•Modem control: DTR (Data Terminal Ready)
output driven by the built-in UART for connection to
DCD of attached device.
•Programmable input/output: CP2 can be driven or
read through software control, independent of serial
port activity.
CP3/CTS/DCD
(Configurable Pin 3)
8 CP3 can be configured as follows:
•Flow control: CTS (Clear to Send) input read by
the built-in UART for connection to RTS of attached
device.
•Modem control: DCD (Data Carrier Detect) input
read by the built-in UART for connection to DTR of
attached device.
•Programmable input/output: CP3 can be driven or
read through software control, independent of serial
port activity.
1 Data out will float during and immediately after power up or assertion of RESET on Pin 3. Pin 4 can be pulled
up to +3.3V with a 10K ohm or larger resistor to hold the pin high during reset.

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 10
Ethernet Interface
The Ethernet interface magnetics, RJ45 connector, and Ethernet status LEDs are all
in the device server shell. The xPort Pro PHY is Auto MDIX capable allowing
connection to either straight through or cross over Ethernet cables.
Table 2-3 Ethernet Interface Signals (Industry Standards)
Signal Name
DIR
Contact
Primary Function
TX+
Out
1
Differential Ethernet transmit data +
TX-
Out
2
Differential Ethernet transmit data -
RX+
In
3
Differential Ethernet receive data +
RX-
In
6
Differential Ethernet receive data -
Not used
4
Terminated
Not used
5
Terminated
Not used
7
Terminated
Not Used
8
Terminated
SHIELD
Chassis ground
LEDs
The xPort Pro contains the following LEDs:
Link (solid green, left LED)
Activity (blinking amber, right LED)
Figure 2-3. xPort Pro LEDs

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 11
Dimensions
The xPort Pro dimensions are shown in the following drawings.
Figure 2-4. Front View
Figure 2-5. Bottom View
Figure 2-6. Side View
RIGHT
LED
18.25 [0.719]
16.25 [0.640]
11.55 [0.455]
7.15 [0.281]
CONTACT 1
CONTACT 8
5.85 [0.230]
14.50 [0.571] 4.03 [0.158]
13.50 [0.531]
1.85 [0.073]
3.25 [0.128]
3.30 [0.130]
1.27 [0.050]
0.40 [0.016]
FRONT
VIEW
DIMS = mm (in)
LEFT
LED
SHIELD TAB
SHIELD TAB
TOLERANCE
.XX+/-0.20[0.008]
33.90 [1.335]
1.00 [0.039]
0.35 [0.014]
10.84 [0.427]
6.35 [0.250]
2.54 [0.100] 3.20 [0.126]
0.60 [0.024]
FRONT
SHIELD
GROUND
INTERFACE
PINS
DIMS = mm (in)
11.90 [0.468]
SHIELD TAB
TOLERANCE
.XX+/-0.20[0.008]
8
2
7
1

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 12
Recommended PCB Layout
The hole pattern and mounting dimensions for the xPort Pro device server are shown
in the following drawing. For proper heat dissipation, it is recommended that the PCB
have approximately 1 square inch of copper attached to the shield tabs. The shield
tabs are an important source of heat sinking for the device.
The xPort Pro shield is considered “chassis ground” and should be separate from
“signal ground”. ESD near the xPort Pro at the panel opening will likely jump to the
shield.
We recommend using high voltage (~200V), low ESR, 0.01uF capacitors to connect
chassis ground to both signal ground and 3.3V. This will cause any voltage spike
from ESD to be imparted equally to both signal ground and 3.3V with no net voltage
increase between 3.3V and signal ground. For the highest level of ESD protection of
the xPort Pro, it is recommended that the shield not be directly connected to signal
GND. The metal shield fingers around the xPort Pro’s RJ45 should physically contact
the product housing when the housing is metal, or metallic coated.
The shield is also a heat sink for the internal 32-bit Processor. As in all heat sinking
applications, the more copper connected to the heat sink the better. Adding 1 inch
square inch of copper flood on the PCB is adequate to allow the xPort Pro to work up
to +85°C. If the application does not expect to see temperatures up to +85°C the
heat sink may be smaller than 1 square inch.
Figure 2-7. PCB Layout

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 13
Product Information Label
The product information label contains important information about your specific unit,
such as its product ID (name), bar code, part number, and Ethernet (MAC) address.
Figure 2-8. Product Label
Electrical Specifications
Caution: Stressing the device above the rating listed in this table may
cause permanent damage to the xPort Pro. Exposure to Absolute
Maximum Rating conditions for extended periods may affect the xPort
Pro’s reliability.
Table 2-4 Absolute Maximum Ratings
Parameter
Symbol
Min
Max
Units
Supply Voltage
VCC
0
3.6
Vdc
CPx, Reset, Data In, Data Out Voltage
VCP
-0.3
VCC +0.05
Vdc
Operating Temperature
-40
85
oC
Storage Temperature
-40
85
oC
Table 2-5 Recommended Operating Conditions
Parameter
Symbol
Min
Typical
Max
Units
Supply Voltage
VCC
3.15
3.3
3.46
Vdc
Supply Voltage Ripples
VCC_PP
2
%
100Base-TX Active
(Evolution)
I
CC
225
270
mA
100Base-TX Active (Linux)
ICC
200
270
mA
100Base-TX Idle (Evolution)
ICC
215
mA
100Base-TX Idle (Linux)
ICC
175
mA
10Base-T Active (Evolution)
ICC
145
250
mA
10Base-T Active (Linux)
ICC
130
250
mA

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 14
Parameter
Symbol
Min
Typical
Max
Units
10Base-T Idle (Evolution)
ICC
130
mA
10Base-T Idle (Linux)
ICC
110
mA
Supply Reset Threshold
VRST
2.85
2.93
3.00
Vdc
CP2, CP3 Pull-ups
RPU
100
Kohm
CP1 Pull-up
RPU
10
Kohm
CPx, RX
Input Low Voltage
V
CP_IL
0.8
Vdc
CPx, RX
Input High Voltage
V
CP_IH
2
Vdc
CPx, TX Output Low Voltage
(IOL = 4 mA)
V
CP_OL
0.4
Vdc
CPx, TX Output High Voltage
(IOH = -4 mA)
V
CP_OH
V
CC
-0.4
Vdc
Note: All pins are not 5V tolerant.
Functional Specifications
Table 2-6 Technical Specifications
Category
Description
CPU, Memory
Freescale 32-bit Coldfire, 8/16 MB SDRAM (see Table 2-1), 16 MB flash,
Firmware
Upgradeable via TFTP, FTP, and serial port
Reset Circuit
Internal 140ms minimum power-up reset pulse. Power-drop reset triggered at
2.95V. External reset input causes an internal 140ms minimum reset.
Serial Interface
CMOS (Asynchronous) 3.3V-level signals
Rate is software selectable and customizable: 300 bps to 921600 bps
Note: The standard baud rate of 460800 bps is not supported.
Serial Line Formats
Data bits: 7 or 8
Stop bits: 1 or 2
Parity: odd, even, none
Modem Control
DTR, DCD
Flow Control
XON/XOFF (software), CTS/RTS (hardware), None
Programmable I/O
3 PIO pins (software selectable), sink or source 4mA max.
Network Interface
RJ45 Ethernet 10Base-T or 100Base-TX (auto-sensing)
Compatibility
Ethernet: Version 802.3u
Protocols Supported
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, FTP, Auto IP,
SMTP, HTTPS, and HTTP
LEDs
10Base-T and 100Base-TX Link Activity
Management
Internal web server, SNMP (read only)
Serial login, Telnet login, DeviceInstaller utility, SSH
Security
Password protection, locking features, optional Rijndael 256-bit encryption
Internal Web Server
Serves static web pages and Java applets
Storage capacity: 1MB
Weight
0.34 oz (9.6 grams)
Material
Metal shell, thermoplastic case
Temperature
Operating range: -40°C to +85°C (-40°F to 185°F)
Shock/Vibration
Non-operational shock: 500 g's
Non-operational vibration: 20 g's
Warranty
Two year limited warranty
Included Software
Windows® 98/NT/2000/XP-based Lantronix® DeviceInstaller™ configuration

2: Description and Specifications
xPort® Pro Embedded Device Server Integration Guide 15
Category
Description
software and Windows®-based Com Port Redirector
Compliance
Regulatory Approvals
FCC Part 15, Subpart B, Class B
ICES-003 Issue 4 (2004), Class B
EN55022:2006 and EN55024:1998 + A1:2001 + A2:2003
AS/NZS CISPR22:2006
VCCI V-3/2009.04
EN61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005
EN61000-4-2 (+/-4kV Contact Discharge, +/-8kV Air Discharge)
EN61000-4-3 (3 V/m (Unmodulated R.M.S.), 80 MHz - 1 GHz, 80% AM (1 kHz))
EN61000-4-4 (Ethernet Port: ±0.5 kV (Peak), 5 kHz)
EN61000-4-6 (Signal Port(s):3 V (Unmodulated R.M.S), 0.15 MHz - 80 MHz, 80%
AM (1 kHz)
 EN61000-4-8 (50 Hz, 1.0 A/m (R.M.S.))

xPort® Pro Embedded Device Server Integration Guide 16
A: xPort Pro 485 Connection Diagram
The following example illustrates a connection between the xPort Pro embedded
device server and an external transceiver IC:

xPort® Pro Embedded Device Server Integration Guide 17
B: Compliance Information
(According to ISO/IEC Guide 22 and EN 45014)
Manufacturer’s Name & Contact Information:
Lantronix, Inc.
7535 Irvine Center Drive
Suite 100
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Declares that the following product:
Product Name Models: xPort® Pro Embedded Device Server
xPort® Pro Lx6 Embedded Device Server
Conforms to the following standards or other normative documents:
Electromagnetic Emissions/Immunity:
FCC Part 15, Subpart B, Class B
ICES-003 Issue 4 (2004), Class B
EN55022:2006 and EN55024:1998 + A1:2001 + A2:2003
AS/NZS CISPR22:2006
VCCI V-3/2009.04
EN61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005
EN61000-4-2 (+/-4kV Contact Discharge, +/-8kV Air Discharge)
EN61000-4-3 (3 V/m (Unmodulated R.M.S.), 80 MHz - 1 GHz, 80% AM (1 kHz))
EN61000-4-4 (Ethernet Port: ±0.5 kV (Peak), 5 kHz)
EN61000-4-6 (Signal Port(s):3 V (Unmodulated R.M.S), 0.15 MHz - 80 MHz,
80% AM (1 kHz)
EN61000-4-8 (50 Hz, 1.0 A/m (R.M.S.)
RoHS, REACH and WEEE Compliance Statement
Please visit http://www.lantronix.com/legal/rohs/ for Lantronix’s statement about
RoHS, REACH and WEEE compliance.
