LAON TECHNOLOGY LT150 MOBILE User manual

ⓒ2019 LaON Technology Co., Ltd. All rights reserved.
LT150 Mobile Digital Wireless Intercom
User Manual (Version V2.0 191215)
(This manual applies to MS150 Version V112)
LaON Technology

ⓒ2019 LaON Technology Co., Ltd. All rights reserved.
Contents
Section 1. Introduction
4
System usage example
6
Section 2. Product overview
8
Mobile Station MS150 equipment
8
Beltpack equipment
8
Battery chargers
9
Headsets
9
Mobile Station overview
10
Beltpack overview
11
LT150 Mobile system menus
12
Section3. System setup and connections
14
Mobile Station setup
14
Beltpack setup and pairing
15
Beltpack setup
15
Pair Beltpacks
15
Battery charger BATCHG-125, BATCHG-225
16
BRK150 Mount kit installation
16
Section 4. System operation
17
Operating the Mobile Station MS150
17
Auxiliary device setup
24
Beltpack operation
25
Section 5. FAQ and trouble shooting
32
Mobile Station
32
Beltpack
33
Section 6. Appendix
34
Factoty default setting
34
6-PIN headset cable connector
34
Section 7. Specifications
35
Mobile Station MS150
35
Beltpack BP150
36
Battery charger BATCHG125
37
Battery charger BATCHG225
37
Rechargeable battery pack
37
Headsets
38

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 2
Important Safety Information
1. For LT150 systems, to reduce the risk of electric shock, explosion or fire;
⚫Use only the supplied AC power adapter
⚫Do not disassemble the product
⚫Avoid contact with liquids besides the permitted certain equipments
⚫Use only the proper type of battery and rechargeable battery supplied by the manufacturer
2. Battery Safety and Cautions
⚫Do not charge with any other AC power adapter or charger.
⚫Do not burn, disassemble, bend or short-circuit the battery.
⚫Dispose of used up battery promptly and safely according to local regulations.
⚫Keep battery away from children.
⚫Do not short the metal contacts with electrically conducting material such as bracelets, keys, and etc.
⚫Recommended battery storage temperature is -20 °C to 30°C for less than 1 year, -20°C to 40°C for less
than 90 days, -20 °C to 50°C for Less than 30 days.
⚫Recommended Battery charging temperature is 0°C to 40°C
⚫Do not burn or expose batteries to excessive heat such as sunshine or other heat sources
⚫When using alkaline or other maker’s rechargeable batteries other than LAON provided rechargeable
batteries, LTWI-BAT50 and LTWI-BAT150, use the same batteries as packaged by the makers for the
same specifications, related current and voltage. In case of using non-LAON provided rechargeable
batteries, use the maker designated battery charger. Two or Four batteries to be used together by
putting into the Battery Sled of LAON products should be managed to have the same residual time, life
and recharged with same cycles. Using batteries together with different specifications and natures may
cause damages on inner parts of the applicable LAON product and affect battery operating time.
3. Antenna Safety and Cautions
⚫Use only manufacturer supplied antennas.
⚫Antenna shall be mounted in such a manner to minimize the potential for human contact during normal
operation. The antenna of the Mobile Station should not be contacted during operation. The minimum
separation distance of 7.9 inches (20 cm) from the antenna to the body of user required.

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 3
LT150 system operates in the 5GHz UNII band frequency range. LT150 system is approved for license free use
in most countries. There may be restrictions on the use of some bands or RF spectrum operations in some
countries. Therefore, it is your responsibility to confirm with the designated authorizer in your local area whether
the equipment of the LT150 system approved to use in your country or not.
Copyright © 2019 Laon Technology Co., Ltd.
All rights reserved.
Theproductsdescribedinthisdocumentare distributedunderlicensesthatlimitusage,copying,and deployment.
The Software described in this document is furnished under a license agreement and does not provide any rights other
thanrestrictedlicenses.Only usabledepending onthe termsof thecontract.
No partofthisdocumentmay be reproducedwithoutprior written approvalofLaonTechnology.
NOTICE
Illustrations, figures and images of this publication are only for explaining equipment’s operations and
functions and may roughly reflect the actual equipment.
Contact the designated distributors or retailers to avoid erroneous interpretations or language translations
that may cause equipment malfunctioning.
The information herein, including but not limited to, illustrations, figures and images subject to change
without prior notice and shall not be interpreted as an expressed or implied commitment on LaON
Technology’s part.
With due respect, LaON Technology, the manufacturer of the equipment does not provide any expressed
or implied warranty to anything included in this operating instruction and shall have no legal responsibility
for any implied warranties of suitableness for a specific application or for any special, indirect, or
consequential damages. LaON Technology may update this publication at its own discretion.

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 4
Section 1: Introduction
LaON Technology(‘LaON’)’s patent-technology base digital wireless intercom system offers the best audio
quality with an excellent clarity by using 5GHz UNII band, triple diversity - frequency, time and antenna, and
frequency interference avoidance technologies. It guarantees the system stability even in the large congested
site environments where various A/V and wireless equipment are co-located. With LT150 system’s Mobile
Station ‘MS150’, users can install the Station at the fixed place or use in mobile with a battery. In addition,
external devices such as a speaker and microphone can be connected with the Mobile Station through Auxiliary
In/Out interface. The Mobile Station can be operated in a Beltpack mode for the LT750’s Base Station ‘BS750
and the Auxiliary In/Out activation mode is still available when it is staying in a Beltpack mode. LT150 Mobile
System provides the equivalent audio quality and performance to the highest range system, LT750 Expert
System that is used for professional applications.
Main features
⚫License-free 5GHz UNII BAND
5GHz UNII Band, the worldwide license-free frequency band provides approximately up to 29 RF channels
depending on the regions as opposed to few RF channels on 2.4GHz ISM band. Therefore, users can enjoy
pleasant wireless communications with even less traffics or interferences. With the advantages of high
frequency band, the system is also hardly affected by high-power digital equipment such as amplifiers and
speakers.
⚫Industry-top level audio quality
23ms low latency, 7.2KHz audio bandwidth, ensures high-quality audio performance. GENIE hasacomplete
hybrid wiredandwireless intercom system for usein large,loud,and diversesite environments.
⚫Two Communication groups
Up to two Communication groups can be allocated for both of Mobile Station and each Beltpack.
⚫Five full-duplex audio channels (1 MS + 4 Beltpacks)
Five full-duplex audio channels are offered with one Mobile Station.
⚫Up to 128 wireless Beltpacks (BP850,BP750,BP150) connection
128 wireless Beltpacks can be connected freely to a Mobile Station.
⚫Mobile Station
The Mobile Station is compact and can be operated either by a rechargeable battery pack or AA type alkaline
battery (x 6) with a LaON provided battery sled.
⚫Wireless Beltpack in Master mode
The wireless Beltpack provides the Master function of the Mobile Station in a location without a Mobile Station. The
MasterBeltpack can serveas aMasterin aspaceindependentof theMobileStation RF space.
⚫Auxiliary I/O interfaces
Auxiliary Input / Output ports are provided to secure seamless connections with wired intercom systems,
external audio devices and etc.
⚫Various options on battery
Either LaON provided rechargeable battery pack or AA type Alkaline battery with LaON designated battery
Sled can be used for supplying power to the Beltpack. Also, commercial rechargeable battery may be used
with the battery Sled.
⚫Monitoring functions
Beltpack provides various monitoring functions such as the link status, RSSI (Received Signal Strength
Indication), battery status and etc.
⚫Top security with AES 256 bits level 3 encryption
Secure confidential communications with AES 256-bit level 3, highest encryption technology.
⚫Efficient 7 or 8 ports chargers
The charger has five bays that can charge the Beltpack with the battery pack inserted. Additionally, there are 2
baysforchargingthe batterypack.Two bays of these are used to charge the Mobile station battery.
There is another type of the charger that can charge 8 battery packs.
⚫Compact design
A compact Beltpack with internal antennas supports high levels of mobility and wearables, along with a
comfortable headset during harsh broadcasts and events.
⚫LaON In-house technologies and solutions
LaON has developed from the wireless SoC built in the systems to the wireless intercom systems in-company
by applying its own patent base technologies. Base on the know-how and comprehensive experiences in
wireless technology, LaON offers timely and prompt service with full flexibilities for customer satisfactions with
top priority.

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 5
System usage example
Communication group allocations
⚫For Mobile Station, up to two Communication groups can be allocated and either one group can be selected
at once
⚫On Beltpack, communication in each individual Communication group or two Communication groups is
available.
⚫On Mobile Station, the group channel setup and volume control will be applied the same to the device which
is connected through auxiliary In/Out interface.
IC/ISO communications in one system
Group 1 & 2
Group 1
Auxiliary or
4-Wire device
Group 1
BP1
BP2
BP10
BP17
BP28
BP127
BP128
…
…
…
Group 1: IC
Group 2 : ISO
MS150
Mobile Station
BP1
BP2
BP4
BP3
BP5
BP10
BP28
BP17
BP127
BP128
Group 1 or 2
Group 1 or 2
Group 1 or 2
Auxiliary Device
Headset
…
…
MS150
Mobile Station
…
…

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 6
System usage of the stand-alone operation
System usage with BS750 Base Station
System usage with intercom devices (MS150 in ‘MS’ mode)
Intercom
GENIE Panel’s Line
…
MS150
Mobile Station
…
…
BP1 BP128
BP1 BP128
BP1 BP128
BP1 BP128
…
MS150
Mobile Station
MS150
Mobile Station
MS150
Mobile Station
BP1
BP2
BP4
BP3
BP127
……..
MS150 Mobile Station
in Beltpack mode
4Wire Line devices
(Intercom etc.)
BS750 Base Station
BP128
BP1
BP2
BP4
BP3
BP127
BP128
……..
MS150 Mobile Station

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 7
Master Beltpack (MB) mode
⚫A Beltpack can be set in Master Mode to replace the Mobile Station.
⚫In the Master Beltpack Mode, the system provides a single communication group channel with five (5)
full-duplex audio channels (1 MB + 4 Beltpacks).
⚫Automatic handoff is available between the Mobile Station and Master Beltpack if they are located in
independent separate area respectively. All Beltpacks to be connected to the Master Beltpack are
automatically set to Communication group one (1).
Stand-alone operation in each independent RF space
NOTE: Do not use Mobile Station and Master Beltpack(MB) in a same coverage. Otherwise, the Beltpacks
will be automatically linked to either one with stronger signal which will cause confusion and wrong
operation on the wireless communication.
……..
BP1
BP2
BP3
BP4
BP127
BP128
BP150 Beltpack
……..
BP1
BP2
BP3
BP4
BP127
BP128
BP150 Beltpack
Master Beltpack (MB)
The Beltpack is connected to the Mobile Station of Communication group 1 and allows automatic or manual
roamingbetween theMobileStation andMaster Beltpack
MS150 Mobile Station (MS)

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 8
Section 2: Product overview
Mobile Station MS150 equipment
⚫Mount kit ‘BRK150’ enables to fixed install the Mobile Station onto the wall or camera tripod.
Beltpack equipment
BAT50: 2450mAH, ~500 cycles
BAT50R: 2000mAH, ~2000 cycles
Rechargeable Battery Pack (Optional)
Battery sled
BP150 or BP750 or BP850 Beltpack
BPPCH100
Beltpack Pouch (Optional)
Mount kit, BRK150
BAT150 Rechargeable battery (optional)
Battery sled
MS150 Mobile Station
Mobile Station Antenna

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 9
Battery chargers
Headsets
LMH-10 (Dynamic)
LSH-S125D (Dynamic)
LMH-125D (Dynamic)
LNH-20D (Neckband, Dynamic)
PTE-850 (Electret)
15VDC 8A Power Supply
BATCHG225 Battery Charger
BATCHG125 Battery Charger

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 10
Mobile Station overview
1. Antenna connector
10. Battery cover
2. Antenna connector
11. AUX Input Line / Mic. level selection switch
3. OLED Display
12. AUX Input connector
4. Talk button with indicator light
13 .AUX Output connector
5. Power (PWR) button (press 3 sec)
14. 12V DC Power connector
6. Communication group (GRP) button
15. Power switch
7. Volume up /Menu scroll button
16. Headset cable connector (Receptacle)
8. Menu Set button
9. Volume down / Menu scroll button
17. Mount kit hole
Figure 2-1. Panels of the Mobile Station
2
4
3
5
9
8
10
7
6
1
12
13
14
15
11
17
16

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 11
Beltpack overview
Beltpack is moisture resistant which is excellent in using under humid environment.
1. Headset cable connector (Receptacle)
7. Menu/Set button
2. OLED display
8. Volume down / Menu scroll button
3. Talk button with indicator light
9. Beltpack clip
4. Power (PWR) button, Manual roaming (press twice)
10. Battery cover
5. Communication group (GRP) button/
Talk button in Two groups mode
11. Charging pinout (Bottom of the Beltpack)
6. Volume up /Menu scroll button
➢Beltpack pairing setup key: ‘PWR + Set’
➢Manual handoff key: ‘PWR + PWR’ (Double click of PWR)
Beltpack charging pinout
NOTE: Do not stand the Beltpack direct on electric conductors such as iron plate, etc. and do not short the
metal contacts on the bottom of the Beltpack with those electrically conducting material.
NOTE: It is necessary to store the battery after fully charged and separating from the Beltpack. Turn off the
Beltpack before charging
1
2
1. –
2. Temperature sensor
3. +
3
Figure 2-2. Panels of the Beltpack
9
10
11
1
4
2
7
3
5
6
8

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 12
LT150 Mobile system menus
➢Pressing Set button on the Normal menu will lead you to Main menu.
➢On Main menu, press Up/Down direction key to move to the next menus.
➢Pressing Power button once on any menu screen will lead you to the Normal menu.
MS150 Mobile Station menu (‘MS’ mode)
Below is the menu operation with the Mobile Station
Beltpack BP150 menu
MS150 Mobile Station menu in Beltpack (‘BP’) mode
Below is the menu operation for connecting BS750 Base Station and Mobile station in Beltpack mode.
MS-BP
Mobile Station’s menus in Beltpack mode shown sequentially
MS
<Normal menu>
<Main menu>
TX Power
0dB +3dB +6dB
Beltpack menus shown sequentially
MS-BP V112
MS
MB
<Normal menu>
<Main menu>
<Main menu>
<Normal menu>
MS150 V112
MS
MS150
CH:11
Menus in Mobile Station (MS) mode shown sequentially
TX Power
0dB +3dB +6dB
Select RF CH ID
00
Select RF CH
INdoor OUTdoor

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 13
Beltpack BP150 menu in Master Beltpack (‘MB’) mode
The following is how the menu works when the Beltpack BP150 is in Master Beltpack mode.
MB
MB
MB
CH:11
<Normal menu (Master Beltpack)>
<Main menu>
Master Beltpack menus shown sequentially

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 14
Section 3: System setup and connections
Mobile Station setup
Antenna installation
Put two enclosed antennas to the antenna connectors (#1 and #2) on the upper panel of the Mobile Station. Turn
the sleeve on each of the antenna connectors clockwise to tighten them and ensure that the antennas are
connected firmly.
NOTE: The Mobile Station should be away from any metal obstructions, walls, and electronic equipment that
can create radio interference. It is highly recommended to place the antenna as high as possible in the
center of the coverage and away from obstructions.
NOTE: Mobile Station must be used after its antenna connection. If the antenna is not connected and
operated, then RF related circuits may be damaged.
Supply the power to the Mobile Station.
⚫When you use the wall-adapter power supply:
Plug the DC cable from the enclosed wall-adapter power supply into the 12VDC Power connector (#14) on
the bottom of the Mobile Station. Plug the large female connector at the end of the AC power cord into the
power supply and plug the other end of the AC power cord into a standard wall outlet.
⚫When you use the battery:
Pull the cover up to open the battery cover (#10) and put a fully charged rechargeable battery pack (BAT150)
or battery sled with six freshAA 1.5v alkaline batteries. Make sure the position of polarity (+, -) is correct.
When both options are used at the same time, power adapter will automatically be used.
The headset is with ‘Push-Pull Lock’ type connector. Connect the headset to the headset connector (#16) on the
bottom panel of the Mobile Station. To disconnect the headset, hold the plug on the headset connector and pull
out slightly turning.
Press the Power switch (#15) on the bottom panel of the Mobile Station and press Power button (#5) longer than
3 seconds to turn on the Mobile Station. A voice message ‘Power on’will be heard from the headset, and the red
Talk LED adjacent to the Talk button will go on. In MS mode, ‘DFS detecting’ message will be indicated on the
Mobile Station’s upper panel screen for one minute and once the detecting is completed, Normal menu with an
indication ‘MS150’ will pop up as shown in Figure 3-2: After a few seconds, Talk LED will be changed to green
slow flashing, indicating the Mobile Station is ready to use
See the MS150 Mobile Station operation in Section 4 for details about the Normal menu.
Figure 3-2. Normal menu (‘MS’ mode)
MS150
Figure 3-1. Panels of the Mobile Station
2
4
3
5
9
8
10
7
6
1
12
13
14
15
11
17
16

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 15
Beltpack setup and pairing
When you operate each Beltpack for the first time with the Mobile Station, you must pair up the Beltpack with a
Mobile Station. This pairing process allows a Mobile Station and a Beltpack to recognize each other and an own
cryptic code will be given for the corresponding system. The Mobile Station will identify all the paired up
Beltpacks and recognize the difference between the Beltpacks. If a Beltpack is added or replaced later, the new
one is necessarily to be paired up with the Mobile Station.
Each Mobile Station allows up to one hundred twenty eight(128) Beltpack connections.
Beltpack setup
Before pairing up the Beltpack with the Mobile Station, set up all Beltpacks as following steps:
Slide the cover down to open the battery cover (#10), and put a fully charged rechargeable battery pack (BAT50
or BAT50R) or battery sled with two fresh AA 1.5V alkaline batteries. Make sure the position of polarity (+, -) is
correct. Close the battery cover.
Pair Beltpacks
Check out the power status of the each Beltpack’s, which will be paired up with Mobile Station. To execute a
paring process, the Mobile Station and Beltpacks should be turned on. Beltpacks should not go further than 3
feet (1 meter) from the Mobile Station while they are being paired.
NOTE: Once paring is completed, the Mobile Station and each Beltpack should go further than 6.5 feet (2
meters) to operate otherwise, there could be audio breakups.
Ready to pair with Beltpack
Turn on the Beltpack by pressing PWR button for 2 seconds and confirm the Normal menu is displayed. When a
Beltpack is not paired up yet, the LED adjacent to the Talk button will be flash red.
Pair Beltpack to Mobile Station
⚫Confirm the Normal screen of the Mobile Station is displayed on the OLED screen. If the screen is in a sleep
mode, press Set to wake it up. On Mobile Station, press and hold the Set button on the front panel just after
pressing and holding the Power (PWR) button. By doing this, the Mobile Station will be in ‘pairing waiting
mode’ and the message, ‘Pairing…’ will appears shortly on the Mobile Station display and then you can
release both buttons. In the Pairing wait mode, Mobile Station waits a pairing requirement from the Beltpack
for 20 seconds, and during this time all communications between Beltpacks will be halted.
⚫Make sure that the Beltpack to pair is displayed on the Normal screen. Otherwise press Set to wake it up
from the sleep mode and stay not further than 3 feet (1 meter) from the Mobile Station. Press and hold the
Set button on the front panel just after pressing and holding the Power (PWR) button. By doing this, the
Beltpack will also be in ‘pairing processing mode’ and the message, ‘Pairing…’ will shortly appears on the
Beltpack display and then you can release both buttons.
The first time each Beltpack is paired to a Mobile Station, each ID number of the Beltpack is generated
sequentially.
9
10
11
1
4
2
7
3
5
6
8

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 16
NOTE: When executing the paring process with a Beltpack, after pressing and holding the PWR button,
quickly press and hold the Set button otherwise, the Beltpack power may be turned off.
NOTE: While the pairing process, all communications will be halted temporarily and recovered upon
completing the pairing.
If pairing completed properly:
The display of the Beltpack shows a Beltpack Label with an ID number that is sequentially generated from ‘1’to
‘128’.If the paring is completed successfully ‘Paring…’ message will be changed to ‘Paring Completed’within
20 seconds as shown from Figure 3-3. And the LED adjacent to the Talk button of the Beltpack is flash green.
Repeat the paring processing for each Beltpack.
After 20 seconds in Pairing wait mode, it automatically returns to the Normal screen.
If pairing is failed:
After the message ‘Pairing...’appears on the Beltpack display, up to 20 seconds will be taken until the message,
‘Pairing Failed’appears on the Beltpack display. Try to process the paring again. If the paring is failed again, try
again after rebooting of the Beltpack. If these processes do still not work, please contact your dealer or
manufacturer for the further supports.
Battery charger BATCHG-125, BATCHG-225
The BATCHG125 is a seven-bay charger for recharging the BAT50 and BAT150 rechargeable battery packs.
The charger has five bays that can charge the Beltpack with the battery pack inserted in the battery
compartment. Additionally, there are 2 bays for charging the battery pack. Two bays of these are used to charge
the Mobile station battery BAT150. Using the Beltpack/LTWI-BAT150 two-way bay, up to two BAT150
rechargeable battery packs can be recharged instead of the Beltpack. It takes approximately 4.5 hours to fully
charge. LEDs indicate the recharging status. There is another type of the charger that can charge 8 BAT50
battery packs. The BATCHG225 is eight-bay charger for recharging the BAT50 battery pack.
See BATCHG125/BATCHG225 User Manual for details.
BRK150 Mount kit installation
Fasten the enclosed two (2) screws on the bottom of the Mobile Station. And with the screw holes on the Mount
Kit, the Mobile Station can be fixed install on a wall or camera tripod.
Section 4: system operation
Figure 3-5. BRK150 Mount Kit
3
2
1
Screw holes on the wall
Screw hole for a camera tripod
Screw holes to fasten with Mobile Station
Pairing …
Pair- ID:000
Pairing Failed
Pairing …
BPK01 ID:001
Pairing Completed
Power Off/On
Figure 3-3: Pairing completed status
Figure 3-4: Pairing failed status

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 17
Operating the Mobile Station MS150
MS150 exceptionally offers a mobile use with either a rechargeable battery pack, BAT150 or AA type alkaline
batteries (x 6) with a LaON provided battery sled.
Power On
Turn on the Power toggle switch (#15) on the bottom panel of the Mobile Station and press Power button longer
than 3 seconds to turn it on. A voice message ‘Power on’will be heard from the headset, and the LED adjacent
to the Talk button will go on. When the Mobile Station is in normal ‘MS’ mode, ‘DFS detecting’ will be indicated
for one minute in the display of the upper panel, and once the detecting is completed, Normal menu will pop up
as shown in Figure 4-2. ‘MS150’ appears on the screen to indicate that it is in Mobile Station mode. After a few
seconds, The LED flash green to indicate that the Mobile Station is ready for use.
Power Off
Turn off with the Power toggle switch (#15) on the bottom panel of the Mobile Station.
When using battery, once the battery level is getting low, the power will be automatically off with the voice prompt
from the headset, ‘Change the battery’.
Normal menu on the Mobile Station’s upper screen
The item ‘A’ indicates the Beltpack’s Received Signal Strength Indication (RSSI) level when Mobile Station is in
the Beltpack mode operation. The RSSI level is presented graphically. This will not be indicated while the
Mobile Station is in the ‘MS’ mode operation.
If ‘BP’ is selected in a Select Mode menu, the Mobile Station can be operated as a Beltpack for the Base
Station BS750. Auxiliary device such as a speaker can still be connected though it is in the ‘BP’ mode.
The item ‘B’ indicates the Communication Group of the Mobile Station’s headset. The numbers ‘1’and ‘2’stand
for the number of the Communication Group channel.
The item ‘C’ indicates the Mobile Station’s battery level. The battery level is presented graphically. When using
power adapter, the graphic will be indicated as full.
The item ‘D’ indicates that the Mobile Station is in the ‘MS’ mode operation. While the Key Lock is set, ‘Lock’
will be indicated here to instead.
While the Mobile Station is in ‘BP’ mode operation, there will be a Beltpack ID indication to instead which has
been set up to be linked to the Base Station BS750.
The item ‘E’ indicates Hands Free On/Off operation mode of the Mobile Station. If the headset of the Mobile
Station is in the hands free on (Latched) mode operation, ‘HF on’will appear in the display. If the headset of
A
B
C
E
D
Figure 4-2. Normal menu
MS150
Figure 4-1. Panels of the Mobile Station
2
4
3
5
9
8
10
7
6
1
12
13
14
15
11
17
16

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 18
Mobile Station is in the push-to-talk (hands free off) mode operation, ‘HF off’will appear in the display
accordingly.
Lock the menu
The Mobile Station keys can be locked to avoid any wrong operation by accident. Press and hold the PWR
button (#5) and quickly press GRP button (#6) within one (1) second and release both. And the keys will be
locked. In this mode, Set (#8) and GRP (#6) button will be inactivated and the Normal menu will show the text
‘Lock’ in the bottom-right of the screen. To unlock, press and hold the PWR button (#5) and quickly press GRP
button (#6) within one second and release both again.
NOTE: Quickly operate to press the two buttons as instructed above otherwise, pressing PWR button longer
than 2 seconds will make the Mobile Station turned off.
NOTE: This settingisvalid regardlessof thebeltpackreboot.
Talk and Communication group buttons
Communication Group Button (#6)
Either Group 1 or Group 2 Communication Group can be selected on the Mobile Station. Mobile Station and
Beltpacks in the same Communication group can talk with others in the designated group. Communication
group of the Mobile Station is initially set to ‘1’(Group 1) by the factory default. To select or change
Communication group on the Mobile Station, press the Communication group button (#6) on the front panel of
the Mobile Station. It will be changed sequentially by each pressing, from ‘1’to ‘2’. Every time you press the
Communication Group button, a voice message will be heard from the headset. The selected Communication
Group is displayed on the Normal menu of the Mobile Station, as following examples.
‘1’: Mobile Station’s Communication group is selected to ‘1’.
‘2’: Mobile Station’s Communication group is selected to ‘2’.
The Communication group set for Mobile Station will be applied the same to the auxiliary input/output. While
the auxiliary input/output is activated, all Beltpacks and the external device that has been connected can
communicate together if they are in the same Communication group.
Talk button (#4)
Push-To-Talk (Hand-free off) mode
You can set a Mobile Station to be in Push-to-talk (PTT) communication mode in the ‘Hands Free’ menu. A
voice message ‘Hands free off’ will be heard from the headset.
NOTE: After selecting the PTT mode, hands-free-on mode is disabled until it is changed to hands-free-on
mode.
Press and hold the Talk button while talking. In PTT operation, audio will be transmitted only while you are
pressing the Talk button.
Hands-Free-On mode
You can set a Mobile Station to be in Hands-free-on (‘HFon’) communication mode in the ‘Hands Free’ Menu.
A voice message ‘Hands free on’ will be heard from the headset.
Press and release the Talk button to latch the transmission. After latching the transmission, talk and listen
work as in normal telephone conversation. Press and release the Talk button again to stop the transmission,
and you can listen only.
Talk LED
When the Mobile Station is transmitting, the LED on top of the Talk button will be solid green. When the
Mobile Station is ready but not transmitting, that is listen only status, the LED on top of the Talk button flash
green.
Talk LED operation
⚫Solid green: Listen and talk mode by pressing Talk button
⚫Green flashing slowly: Listen only mode
⚫Red flashing rapidly: Only while the Mobile Station is in the Beltpack mode, the Beltpack is not paired up
yet or is not linked to any Base Station or Remote Antenna (Out of coverage)
⚫Red: When the battery level is low, a voice message, ‘Change the battery’ will be heard from the headset
and the LED will be changed to red.

ⓒ2019 LaON Technology Co., Ltd. All rights reserved. 19
How to control menus (In ‘MS’ mode)
Main menu
Press any button if the screen is in sleep mode, then the Normal menu appears.
Press Set button under the Normal menu, then the Main menu appears.
The item ‘A’ indicates the frequency ID. The frequency ID map can be found out from the table 4-1 below.
The item ‘B’ indicates the Mobile Station’s model name, software version and ID number.
On the Main menu, press Set to back to Normal menu.
Under the Main menu with Up or Down button, move to each menu sequentially and select a menu by
pressing Set button. The selected menu will be flashing and ready to be edited. Use Up or Down button to
change values. Press Set to save the settings and move to next item. Pressing once the power button will
lead you to Normal menu directly.
Hands free (latched Talk) menu
Move to Hands Free menu, and press Set button to select a mode with Up or Down button.
Speaker volume menu
Move to Speaker volume menu, press Set button to select and adjust headset earphone volume level with Up
or Down button. And press Up or Down button in the Normal menu will also allow you to change the
earphone volume level directly.
If the auxiliary connection is activated, the auxiliary output gain will also be controlled with the speaker
volume level adjustment.
Earphone Volume Up
Every time you press the volume up button, a beep sound will be heard from the headset. When the level is
reached out to a maximum, a voice prompt, ‘maximum’ will be heard from the headset.
Earphone Volume Down
Every time you press the volume down button, a beep sound will be heard from the headset. When the level
is reached out to a minimum, a voice prompt, ‘minimum’ will be heard from the headset.
NOTE: Headset safety
⚫Please note that there could possibly be various root causes of distortion, echo or cut-off of the
microphone sounds of the headset. At the initial set up, for the safe use, it is encouraged to set these
volume levels lower and start to adjust for the best level required by various site environments and
improve matters caused by the relevant headset where applicable.
⚫When the microphone gain, side tone or earphone volume on a specific headset is set too high, It creates
some kind of echo or distortion. Try to these gain or volume down for improving and mitigate the relevant
matter.
Figure 4-6. Speaker volume menu
Figure 4-5. Hands free menu
<Main menu>
<Normal menu>
MS150 V112
MS
MS150
CH:11
Figure 4-4. Menus in Mobile Station (MS) mode shown sequentially
TX Power
0dB +3dB +6dB
Select RF CH
INdoor OUTdoor
Select RF CH ID
00
Figure 4-3. Main menu in the ‘MS’ mode operation
A
B
MS150 V112
