Larson Electronics EXPLED-SOL12-M-SW.M10C User manual

Ver.1018-1
EXPLED-SOL12-M-SW.M-10C Larson Electronics LLC 1
DEUTSCH
CONNECTOR
Thank you for purchasing the Larson Electronics EXPLED-SOL12-M-SW.M-
10C solar powered Explosion Proof light. Follow the steps below for
installing and maintaining your unit.
IMPORTANT
READ CAREFULLY BEFORE OPERATING THIS LIGHT. SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
THIS FIXTURE SHOULD BE INSTALLED BY QUALIFIED TECHNICIANS IN STRICT
ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ANY LOCAL
REQUIREMENTS.
STANDARD PLUGS AND SOLAR PANEL MUST ONLY BE INSTALLED AND
LOCATED OUTSIDE THE HAZARDOUS AREA!
IMPROPER USE OF THIS LIGHT, ASSOCIATED PLUG, RECEPTACLE, AND CORD CAN
LEAD TO SERIOUS INJURIES OR DEATH TO PERSONNEL.
PERIODIC INSPECTION OF THE LAMP AND CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE
ABRASIONS, AND IF ANY ARE FOUND, THE CORD MUST BE REPLACED BEFORE
RESUMING USE OF THE HANDLAMP.
THE GLOBE IS MADE OF TEMPERED GLASS. IF THIS GLASS BECOMES SCRATCHED
OR CHIPPED IT SHOULD BE REPLACED IMMEDIATELY.
PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.
ELECTROMAGNETIC FIELDS IN CLOSE PROXIMITY TO HEART PACEMAKER COULD
CAUSE PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.
KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING AS INJURY COULD OCCUR.
HOW SOLAR LIGHT WORKS
Solar light must be placed outdoors. The solar panel collects and converts sunlight
into DC power while the pre-installed rechargeable batteries store the energy to
power the light at night.
Solar light illumination time
It depends on the seasonal sunlight availability in your geographical area under
certain weather conditions. Stronger or longer sunlight hours enable batteries to
store more energy which provides more lighting hours. On the contrary, weaker or
shorter sunlight hours reduce the lighting hours and its brightness as well.
Solar panel mounting locations
Solar panel must be placed outdoor at a location with its solar panel receiving direct
sunlight at least five hours each day. Shadowed locations will not allow batteries to
be fully charged and will reduce both the brightness of the light and the lighting
hours. Precautions (prior to first time use)
1. To maximize battery capacity, the solar panel should be fully charged by
direct sunlight for five hours before initial use.
2. Under extremely cold temperatures, the batteries may not charge fully. In
such cases, the Solar Lights may not stay illuminated as long.
MOUNTING SOLAR PANEL
This solar panel includes a permanent mounting system that allows for mounting to
square/round poles or flat surfaces such as a wall or post shown in figure 1.
Position the solar panel in a location that receives the maximum amount of
sunlight throughout the day. This may need adjusted depending on the season.
With pole mounting, loosen the adjustment bolts to fit solar panel onto pole. Once
mounted, tighten bolts snug to secure panel to pole. For surface mounting,
remove additional plate and use the existing mounting holes to mount directly to
surface.
MOUNTING
WARNING: ONLY LAMP
AND INLINE SWITCH ARE
RATED FOR HAZARDOUS
AREAS. MOUNT THE
SOLAR PANEL OUTSIDE
THE HAZARDOUS
ENVIRONMNT.
The light is connected to the
panel by cord. Be sure the beacon is connected to the solar panel and that the
connections are tight (if detachable). Run the cord and mount the beacon nearby.
Lamp: Mount the beacon to a ferrous metallic surface capable of holding the weight
of the lamp. Route cable in a safe manner to prevent snags and/or potential injury to
personnel.
Inline Switch: Route the switch to a ferrous metallic surface capable of holding its
weight. Route cable in a safe manner to prevent snags and/or potential injury to
personnel.
RE-LAMP
To re-lamp loosen the locking screw and remove the globe support assembly.
The globe support assembly disengages after approximately 3 turns. *Replace the
lamp with one of the correct size and type. Refer to the fixture nameplate for this
information. When re-lamping be careful not to damage the threaded areas of the
fixture, as they maintain the fixture’s explosion proof properties. Clean the threads
and apply a thin coating of lubricant before reassembling.
ON/OFF SWITCH
The on/off switch powers the beacon on or off with the flip of a switch. The power
switch is attached to the solar panel for operating the beacon at a moment’s notice.
After the batteries have been fully charged, the beacon will illuminate with configured
panel operation listed.
The solar panel surface must be kept clean to collect sunlight effectively.
SOLAR CHARGING
With up to 5 hours of daily sunlight, this beacon is designed to function 12 hours. Ensure there
are no obstructions that could result in little to no sun reaching the panels.
Operation Guide

Ver.1018-1
EXPLED-SOL12-M-SW.M-10C Larson Electronics LLC 2
MAINTENANCE
LAMP MAINTENANCE
CAUTION - Turn OFF the supplying circuit before opening fixture for
relamping. To relamp loosen the locking screw and remove the globe
support assembly.
NOTE: The globe support assembly disengages after approximately 3 turns.
* Replace the lamp with one of the correct size and type. Refer to the fixture
nameplate for this information. When relamping be careful not to damage
the threaded areas of the fixture, as they maintain the fixture’s explosion-
proof properties. Clean the threads and apply a thin coating of lubricant
before reassembling.
CLEANING: To maintain maximum light output, the fixture should be
cleaned periodically. Maintenance procedures sometimes require fixtures to
be hosed down for good housekeeping. NOTE: The supply circuit must be
turned OFF and the fixture globe must be allowed to cool to the ambient
room temperature before cleaning. Only mild, non-abrasive cleaning agents
should be used. These periodic cleaning procedures are important to
prevent the accumulation of dust and dirt which will impair the light output of
the fixture. The glass globe should be regularly inspected for scratches and
chips and, if damaged, the entire globe support assembly must be replaced.
SOLAR MAINTENANCE
If the lens or solar panel becomes dirty, wipe down with a mild soap and
water solution.
Keep snow and debris clear of the solar panel so the batteries can charge. If
the panels are covered by snow or debris for an extended period of time,
allow the battery to charge in full direct sunlight for at least 5 hours for the
battery to reach its full capacity.
It is recommended to occasionally inspect the unit for any defects.
TROUBLESHOOTING
If for any reason the LED beacon does not power on:
Batteries not fully charged: Make sure the fixture is placed in an area where
the solar panel gets the maximum amount of full, direct sunlight every day. If
the solar panel does not receive enough sunlight during the day (e.g. due to
cloudy or overcast weather conditions), it will be recharged on the next sunny
day and resume operation.
Other light sources: (For units equipped with a day/night sensor.) If your
solar light is located too close to street lights, porch lights or other lights, the
solar panel may turn off the fixture. Relocate the solar panel or eliminate
those other light sources.
Not enough direct sunlight: Ensure that the fixtures are not installed in a
shady area, for example, in the shadow of a tree or a house. If necessary,
move the fixtures to an area that gets full direct sunlight.
Switch is in the OFF position: (For units equipped with a power switch.)
Cycle power button in a dark room. The light(s) should come on when the
switch is in the on position if the unit is fully charged.
