Laser Corporation Pty SPK-TT820 User manual

SPK-TT820 Portable Turntable QUICK START GUIDE
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- The following willdamage this product: any liquid such as wateror moisture, extreme heat; cold;
humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached cables are secure and will not
cause the device to fall.
- There are no user serviceable parts in this product.
-Un-authorized attempts to dismantle orrepair this product will void product warranty
- Using this device near other electronic devices may cause interference.
Operation - Front Panel
1
Dust cover latch
2
Dust cover
3
Powerlight
4
Volume control
5
Headphone jack
6
Micro SD Card Slot
7
USB Socket
8
Speaker
9
Tone arm
10
Stylus
11
Carry handle
12
Turn
table plate
13
Mode/REC/USB/SD/BT
selection button
14
Next track
15
Play / Pause /Delete
16
Previous Track
17
AUX In (3.5mm jack)
18/19
Line output (RCA)
20
Powerin

Accessories Included
Poweradaptor,User manual
Playing A Record
1) Place yourrecord on the turntable.
2) Select the correct playing speed (33.3, 45 or 78 rpm)
(Note: this speed needs to match the speed rating of your record)
3) Turn the power on
4) Release the arm lock.
5) Engage the arm raising lever, position the needle over the record and using the arm lever, lowerthe
needle onto the record.
Record your record to external storage
1) Begin playing your record as per the steps above
2) Insert aUSB Drive or Micro SD Card then press and hold the REC button.
3) A confirmation tone will sound when recording has begun.
4) Recording will stop when either the REC button is pressed again or the tone-arm is raised.
(Anotherconfirmation tone will sound when this occurs)
Playing files via a USB drive or Micro SD Card
1) Turn yourturntable on and insert your USB Drive or Micro SD Card.
2) Playback from your external storage device should begin straight away.
* Files which have been recorded to your external storage using your turntable (only) can be deleted
during playback. Simply press the DEL button to delete the current file which is on playback.
Note:
Record playback just be stopped for this external storage file playback to function correctly.
Select USB using the MODE button if playback has not begun automatically.
Bluetooth
1) Press the MODE button until BLUETOOTH mode is announced.
2) Turn the BLUETOOTH feature on, on your portable device and pairwith the turntable.
3) You can now playback music through the turntable from your portable device.
Connect your Turntable toan External speaker system(via RCA output)
You can use the LINE OUTsocket (Red and white RCA sockets) at the back of the turntable to connect
your turntable to an external speaker system. (Cable not supplied)

Rechargeable Battery
This portable turn table has a built in battery so you can use it on thego. To charge the battery simply
plug in the poweradapter. When fully charged the LED power indicator will turn GREEN.
MAINTENANCE
REPLACING THE STYLUS
HINTS AND TIPS
-Keep yourrecords clean by occasionally wiping them with an anti-static cloth
-Pick off any dust which may occasionally accumulate on thestylus.
-A very soft brush dipped in alcohol can beused to clean the stylus by wiping in from back to the front.
- When transporting your record player do not forget to replace the protective cap on the stylus and
engage the tone-arm clip.
Unlock the tone
-
arm
Unlock the tone
-
arm
Lift the front tab to
removeStylus Carefully remove cables
Connectthe cables for
the new Stylus Position the stylus correctly to insert Position the Stylus from the back first Then push the front to click into place

Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your newproduct to be freefrom defects in materials and
workmanship for 12 months, from the date of purchase,provided thatthe product is used in accordance with
accompanying recommendations or instructions where provided. The benefitof this warranty is in addition to
your rights underthe Australian Consumer Law and to other rights and remedies of the consumer under alaw in
relation to the goods or services to which the warranty relates.
Through anetwork of retailers and resellers,Laserwill provide you with yourchoiceof a repair,exchange (where
possible) or refund (within Dead on Arrival period) forthis product if itbecomesdefective within the warranty
period.This warranty willno longer apply where the defect is a result of alteration, accident, misuse,abuse,
normal wear and tear, neglect or improperstorage. Please retain your receipt as proof of purchase
How to make a productwarranty claim:
Step 1: Find your receiptwhich proves the date of purchase. Where the date of purchase cannot be verified,
your place of purchase or Laserwill make an assessment based on the dateof manufacture,the condition of the
Laser Product and the type of defect.
Step 2a): Contactyour place of purchase. They will assess the nature ofthe fault and repair, replace or fund the
product as per their store refund or warranty policy.Step 2b): If your place of purchasecannot becontacted,
then you can contact Laser. Customer Service with details of your defective Laser Product: Phone: [phone];
or Email: [e-mail] or online www.laserco.com.au/warranty (click on “Consumers (End Users)”).
Our business address isat 1/6-8 Byfield Street, North Ryde, NSW 2113.Step 3: Laser willissue you with aReturn
Authorisation (RA) numberwithin 48 hours. Whenrequested, send us the defectiveProductand a copy ofyour
receipt. Laserwill cover the cost of the return delivery. Step 4: Wait for us to contact you. Once we have
received your defective Laser Product forinspection, we willinform you of our assessment of your claim within 7
days. When we contact you, we will firstly let you know whether you have a valid claim under this Warranty, and
if so, we will inform you whether your defective Laser Productwill be replaced or repaired, together with the
numberof days you can expect to wait to receive your replaced or repaired Laser Product.Step 5: For
further details on warranty cover and returns, please check Terms and Conditions for Warranty Returns section
on http://www.laserco.com.au/warranty
Our goods come with guarantees that cannotbe excluded under the Australian ConsumerLaw. Youareentitled
to a replacement or refund for amajor failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
