Laser NAVC-RCMS-999 User manual

Wireless Solar Parking Camera and Monitor
NAVC-RCMS-999
User Manual

WHAT’S IN THE BOX
•Wireless camera with solar panels
•Monitor
•Mounting arm
•Cigarette lighter power adapter
•USB charging cable (for the camera)
•Screws (to install the camera)
•User manual

CONTROLS BUTTONS
2 4
3 5
BUTTONS
1
7 7
89
10 11
13
5
12
66
1Indicator light
2Button - Press to change the parameter
value on the menu setting interface.
3
Menu/OK - Press to conrm the chosen item
in the menu setting interface. Long Press
(press and hold for 3 seconds) to enter the
screen’s menu setting.
4Button - Press to change the parameter
value at the menu setting interface.
5Power button -Press to turn ON/OFF.
6Camera mounting holes
7Solar panels
8Charging socket
9Charging indicator
10 Mounting holes
11 Antenna
12 Power cable
13 USB-A port

INSTALLATION
Before installing the camera in your car:
1. Charge the camera battery by leaving it
in the sun for an hour.
Alternatively, remove the dust cover from
Power socket on the underside of the
camera. Plug in the round end of the
USB charging cable (supplied) to the
camera and USB-A end to the car power
adaptor (supplied). Or you may use a 5V
indoor USB power adaptor to charge.
WARNING: Using a USB adaptor rated
higher than 5V will damage the camera.
2. The camera indicator light will blink while
charging and turn steady red when the
battery is fully charged.

INSTALLATION
TEST THE CAMERA AND THE MONITOR
PAIRING
1. Connect the car adaptor (supplied) to
the monitor and the car’s cigarette
lighter socket.
2. Turn the ignition switch to ACC or ON
position.
3. Press the Power button on the screen or
car adaptor to turn the screen on.
4. Give the fully charged camera a quick
shake to wake it up. The camera and
monitor will pair automatically, and the
camera’s image will appear on the
screen. You’re now ready to install the kit
in your car.
continued...

INSTALLATION
continued...
INSTALLING THE CAMERA
Good to know:
•The camera should be attached to the
pre-drilled holes at the bottom of the
standard Australian license plate.
•If the license plate doesn’t have holes at
the bottom, refer to state laws to see if it’s
allowed to drill holes in the plate. Use the
diagram for correct positioning.
1. Remove the license plate and any frames
from the vehicle.
2. Insert the license plate into the space
between the solar panels and the camera
mount.
3. Use the screws provided to attach the
license plate to the camera mount.
You may require dierent sized screws
depending on your license plate.
4. Attach the license plate assembly to the
vehicle.

INSTALLATION
continued...

INSTALLATION
INSTALLING THE MONITOR
1. Mount the screen to the windscreen.
2. Connect the car adaptor (supplied) to
the power cord attached to the monitor.
3. Plug in the car adaptor to the cigarette
lighter socket in the car.
continued...
Cigarette lighter slot in car

OPERATION
1. Turn the vehicle ignition switch to ACC or
ON position.
2. Press the Power button on the screen or
car adaptor to turn the screen on.
3. Wake up the camera by giving it a slight
vibration, such as closing a car door or
the lurch when the car comes to a full
stop.
NOTE: If no signal is transmitted for
45 seconds, the camera will enter Standby
mode. After two minutes, it will enter Sleep
mode.
4. Once the camera image appears on the
screen, you can adjust the angle of the
camera.
NOTE: Hold the camera mounting bracket
with one hand when rotating the camera,
and use the other hand to move it up or
down.

OPERATION
5. To select a realistic parking guidance
lines position, see instructions for Parking
Guideline Position Adjustment on page
11. To turn o parking guidance lines,
press the button while the camera
image is on the screen.
6. To mirror the image, see instructions for
Mirror Image setting on page 11.
continued...

MENU SETTINGS
•Press the Menu button on the screen to
open the menu settings.
•Use /buttons to navigate through the
menu, and select settings.
•Press and hold the Menu button for 3
seconds to enter the chosen menu
setting.
•Press the Menu button to exist.
•If there is no operation for 8 seconds,
the menu will automatically exit.
1. Pairing - Default pairing settings.
No need to update.
2. Image Parameter
a. Brightness - Change the screen brightness.
b. Contrast - Change the dierence between darkest
and brightest shades.
c. Colour - Change the colour saturation.
3. Image Mirror - Set the image Upwards/
Downwards/ Original/Mirror Image.

MENU SETTINGS
4. Parking Guideline Position Adjustment -
Change the position of Parking
Guidance lines.
5. Time Settings - Adjust the time.
continued...

1. Clean the camera lens and solar panels
using a soft cloth moistened with
water or environmentally friendly and
chemical-free soap if dust or stains have
built-up. Do not use solvents or chemical
materials. Wipe away the moisture with a
dry soft cloth or chamois to avoid
leaving residue behind.
2. Replacing the car adaptor’s fuse
a. Turn the cap on the top of the car adaptor
counterclockwise (no tools needed).
b. Remove the cap, centre pin and the fuse.
c. Replace the faulty fuse with a 3amp fuse.
d. Install the centre pin and cap.
e. Turn the cap clockwise.
CARE & MAINTENANCE

IF THE SCREEN DOESN’T TURN ON WHEN
POWER IS APPLIED:
1. Ensure the screen is getting power (the
ignition switch must be in the ACC or the
ON position, or the engine is running).
2. Check to ensure the power cord is not
damaged.
3. Check the fuse in the car adaptor is not
blown.
THE SCREEN DOESN’T DISPLAY AN IMAGE:
1. The camera battery may have depleted.
Recharge the camera battery.
2. Manually re-pair the camera and screen
by going to Menu (short press the Menu
button) > select Pairing option > press
and hold the Menu button for 3 seconds.
THE CAMERA BATTERY DOESN’T
CHARGE WELL:
1. Clean the solar panels as per instructions
on the Care and Maintenance page.
TROUBLESHOOTING

SPECIFICATIONS
View Angle 135°
Charging Power 1.5w
Camera Waterproof Rating IP67
Battery Capacity 2600mAh
Power (Input) 5V, 2.1A
Screen size 4.3”
Power (input) 5V, 1A
Power (Input) 12-24V
Power (Output) 5V, 2.1A
Frequency 2400-2485.5 MHz
CAMERA
MONITOR
CAR ADAPTOR
TRANSMITTER
