Nokia HSU-4 User manual

Nokia Car Handset
Installation Guide
User‘s Guide
9232831
Issue 1
CUW-3
HSU-4

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the product HSU-4 in
conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the
Declaration of Conformity can be found at:
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2004 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents of this document
in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are trademarks or registered trademarks of Nokia
Corporation. Other products and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products and services may vary by region. Please check with the
Nokia dealer nearest to you.
9232831/ Issue 1

3 Copyright © 2004 Nokia. All rights reserved.
For your safety
ROAD SAFETY COMES FIRST
Remember that the safety of operating a motor vehicle in traffic
requires the full attention of all motorists. Only use / operate your
handset if allowed by local laws / restrictions and traffic conditions
permit safe use.
Observe the safety and care and maintenance guidelines set out in the Nokia 610
car kit phone user's guide.
1. Important information
The Nokia Car Handset HSU-4 replaces the CUW-3 input device supplied
with the Nokia 610 car kit phone.
This user's and installation guide supplements the user's guide
belonging to the scope of supply of the Nokia 610 car kit phone.
2. Mounting the handset
The handset comes with a mount that is to be fixed in a suitable location
where it is easily accessible for the user.
Remember that all equipment must be mounted so that it does not
interfere with the operation of the vehicle. Check to make sure that
deployment of the airbag is not blocked or impaired in any way.
With ignition off, remove the cable connection from the CUW-3 input
device to the radio unit and insert the handset cable in the appropriate
socket in the radio unit (see diagram title page).
The best location to mount the handset is horizontally on the console
between the driver's and front passenger's seats.
Contact your service technician for further detailed information on
alternatives for mounting the handset suitably in your vehicle.

4 Copyright © 2004 Nokia. All rights reserved.
3. Functions of the handset
The handset consists of the function selectors including four keys and a
NaviTM wheel, the alphanumeric keypad, the microphone, and the
earpiece. As the function selectors at the upper part of the handset are
identical to the components on CUW-3 input device supplied with the
Nokia 610 car kit phone, please refer to the car kit phone user's guide for
the relevant information on their use.
■Alphanumeric keypad
Use these keys to enter numbers 0-9, letters, and other characters.
Several characters have been assigned to each key. To enter a character,
repeatedly press the related key until you have reached the desired
character.
Entering numbers and characters:
• To enter a number, press and hold the number key for approximately
one second.
• To call up characters, repeatedly press .
• To enter a blank space, press .
• To switch between upper- and lower-case characters, press .
• Use to move the cursor in the entered text.
For example, if you wish to enter the letter "C", press three times.
When the flashing cursor appears to the right of the letter entered, you
can select the next character to be entered. Repeat these steps until you
have completed your entry.
The procedure set out above applies only for entering text.
When you have finished using the handset, make sure that it
is placed securely in the cradle. A loose handset may cause
bodily injury if you have to brake sharply or should have an
accident.

5 Copyright © 2004 Nokia. All rights reserved.
■Making a call using the keypad
You can also make a call by keying in a phone number:
• In the standby display, key in the desired phone number by pressing
the number keys to .
• If you have keyed in the number incorrectly, press to delete it.
• To call the number shown on the display, press .
■Searching for names and numbers
You can access the list of names and phone numbers quickly from the
standby display:
• Scroll with to the first letter of the desired name and press
to select it.
You can now view all the names stored in your contacts list which
start with the letter selected. They are listed in alphabetical order.
• Scroll with to the desired name in the list.
• To make a call to this person, press .
• To end the call, press .
■Adding a name and a phone number
Names and phone numbers are stored in the phone book. You can add a
name and the related number to the contacts entries starting from the
standby display:
• Select the Contacts menu and press to open the list of
contacts.
• Scroll with to Add contact and press to select this
option.
• Key in the name with the alphanumeric keys and press to save
it.
• Key in the corresponding number and press to save it.
• To erase a character incorrectly selected, press .

6 Copyright © 2004 Nokia. All rights reserved.
■Editing names and phone numbers
You can edit names and phone numbers in the Contacts starting from
the standby display:
• Select the Contacts menu and press to open the list of
contacts.
• Scroll with to Edit contact and press to select this
option.
• Scroll with to the first letter of the desired name and press
to view the list of entries starting with this letter.
• Scroll with to the desired name in the contacts and press
to select it.
• Scroll with to the letter or number to be changed and make
the desired changes.
• To save any changes made, press .
■Saving multiple numbers and text items per
name
You can add as many as four additional phone numbers to an entry in
the contacts. The first number saved under a name is automatically set
as the default number and is indicated with (General). Symbols can
be added for other number types, i.e. (Mobile), (Home),
(Office), and (Fax).
Starting from the standby display:
• Select the Contacts menu and press to open the list of
contacts.
• Scroll with to Add number and press to select this
option.
• Scroll with to the desired name and press to select it.
• Scroll with to the symbol you wish to assign to the number
you are adding and press to select it.
• Key in the number and press to save it.

7 Copyright © 2004 Nokia. All rights reserved.
■Speed dialling
The speed dialling option is a convenient shortcut function that lets you
dial a phone number assigned to a number key quickly and easily. You
can activate (On) or deactivate (Off) this feature in the menu Settings -
Call settings - Speed dialling.
Assigning a phone number to a speed dialling key
You can assign any phone number in your phone book to a speed dialling
key ( to ). Note that the key is reserved for speed dialling
your voice mailbox. The following options are available for each of the
dialling keys: show number, edit or erase.
Starting from the standby display:
• Select the Contacts menu and press to open it.
• Scroll with to Speed dialling and press to select this
option.
You can now view the list of speed dialling keys and the phone
numbers that have been assigned to them.
• Scroll with to the desired entry in the contacts and press
to select it.
The options Show number, Edit, and Erase will be displayed.
• Scroll with to the desired option and press to select it.
• Follow the instructions shown on the display.
Speed dialling a number
• Press and hold the speed dialling key assigned to the number until
the call is started.
