Lasertec HV1G User manual

INSTRUCTION MANUAL
HV1G Green Rotary Laser

2
Please read this instruction manual before operating this product.
Please store this instruction manual in the carry case for future reference.
CAUTION: Class 3 Laser Product
Do not stare directly into the laser beam from apertures.
Do not disassemble the instrument or attempt to perform any internal servicing
as this will void your warranty. No user serviceable parts included.
Only approved and authorised service technicians can carry out warranty repairs.
SAFETY

3
Laser glasses
BatteriesCarry case
Laser targetLED Detector and clamp
Lasertec HV1G
Please ensure the following items are included with your laser.
If anything is missing please contact your retailer.
ITEM CHECKLIST
INCHES CM
1
1
2
3
4
5
6
7
2
3

4
Rotating laser port
Protective lighthouse
PRODUCT OVERVIEW
Control panel

5
CONTROL PANEL
Power
Power indicator Tilt alarm indicator
Tilt alarm

6
DETECTOR CONTROL PANEL
Sound on / off
Coarse / fine mode
LED Lights
Laser sensor
Speaker
Power

7
USING YOUR LASER
Power Supply
The Lasertec HV1G is powered by four C cell alkaline batteries.
Horizontal Set Up
Vertical Set Up
‣Select a place as close as practical to the work site.
Ensure the location is clear of traffic.
‣Attach the laser to a tripod and place on a level surface.
Ensure the unit is secured correctly and tightened in position.
‣Select a place as close as practical to the work site.
Ensure the location is clear of traffic.
‣Place the laser onto a level surface with the control panel facing upwards.

8
Tilt alarm
‣Once the unit has been levelled off the tilt alarm can be enabled by pressing
the tilt alarm button. The tilt alarm indicator light will flash for approximately
15 seconds. Once the light is constant the alarm is enabled.
‣If the unit is disturbed while the alarm is active the unit will need to be
powered off and on again to reset its level position.
Operation
‣To turn the unit on press the power switch. Self
levelling will commence and the laser will begin to rotate.
‣If the unit is outside the self levelling range the unit will not
level causing the laser beam to flash continuously.

9
Using Your Detector
‣Switch the detector on by pressing the power button. The speaker will beep
once indicating the unit is operating.
‣To change between coarse and fine mode press the coarse / fine mode button.
‣Move the detector into the path of the laser beam.
‣Hold the detector upright for horizontal beams. Rotate the detector 90°
for vertical beams.
‣The LED lights will indicate the position of the beam alongside the up and down arrows.
The detector will emit a constant beep once the level position has been located.

10
Before doing any precision levelling it is advised to check the calibration of the unit.
‣Set up the laser on a tripod at about 30m facing a wall or staff with a detector.
‣Allow the unit to level.
‣Detect and note laser position on the wall or staff.
‣Without moving the tripod rotate the unit 180°.
‣Detect and note laser position on the wall or staff.
‣Calculate the distance between the two readings.
‣The difference should be within 6mm at 30m.
‣If the unit is out of calibration it is advised to send it in to Spot-on.
(see www.spoton.com.au for details)
CHECKING CALIBRATION

11
TROUBLE SHOOTING
Laser does not turn on
‣Check the batteries. They may be in the wrong way or need replacing.
‣Check the battery compartment for signs of damage. Ensure they are clean and not bent.
Laser turns on but does not rotate
‣Check the batteries. They may be in the wrong way or need replacing.
‣Check the battery compartment for signs of damage. Ensure they are clean and not bent.
Laser does not remain on for long periods of use.
‣Check the batteries. They may be in the wrong way or need replacing.
‣Check the battery compartment for signs of damage. Ensure they are clean and not bent.
Laser does not level off
‣Unit may be outside its self levelling range. Adjust the unit or tripod so it is level.
‣Unit may have low power
‣Unit may have impact damage.

12
Detector does not detect the laser beam
‣Check the batteries. They may be in the wrong way or need replacing.
‣Check that the laser is operating correctly.
Detector speaker is not functioning
‣Check sound is on.
‣Check the laser is operating correctly and producing a beam.

13
CARE AND MAINTENANCE
‣Reflective surfaces such as glass may reflect the beam, causing
two beams to strike the detector at the same time. This may
create inaccurate reference points.
‣This is a precision instrument and should always be transported
within the carry case provided.
‣Whenever possible, store the instrument in a dry, shady location.
‣The HV1G should be calibrated every 6 months, if ongoing
accurate levelling is required or an impact has occurred.
‣The operator should check the HV1G for accuracy before
precision levelling is attempted.
‣Clean the instrument with a dry, soft cloth after use in dusty, damp
or wet conditions before storing.
‣Smudges and fingerprints may be removed with a damp tissue
or a soft, lint-free cloth.

14
WARRANTY
The Lasertec HV1G comes with a 1 year manufacturers warranty.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
Separate to the above Australia Consumer Law, Spot-on oers a global warranty.
Customer Support
To assist you with any queries or technical questions please contact the
customer support line: 1300 658 338
Operates 5 days a week: 8am - 5pm (EST)
30 Day Free Service
If your laser is out of calibration within the rst 30 days of purchase you
are entitled to a free calibration adjustment. For more information please
contact your retailer or Spot-on.

15
SPECIFICATIONS
Specications Lasertec HV1G
Product code 90014
Warranty 1 Year
Accuracy ±3mm at 30m
Range 250m
Levelling range ±9% / ±5°
Laser class 2 Red
Battery life 20 hours
Battery type 4x C
IP rating 65
Weight (kg) 1.95
Dimensions (mm) 185x200x150

www.spoton.com.au
