Lathem LX100 User manual

The LX100 is a keyless proximity
door lock that fits standard interior
doors. Simply replace your existing
cylindrical style door handle with
the LX100 for an economical access
control system in your business or
home. The locks feature stand
alone operation and do not require
the use of a computer or external
device for programming. They are
powered by standard alkaline batteries
eliminating the need for wiring. The LX100
uses radio frequency technology to instantly
identify proximity badges and key fobs. ®
Replaces Existing Door Handles
PROXIMITY BADGE DOOR LOCK

®
L AT HEM
Extra Employee
Badges
Keychain FobsBadge Reels
Security Made Simple
Remove existing handle
Replace with LX100
Present proximity badges
Open secured door
F E AT U RE S
- Economical door access control for up to 120 users per lock
- User installable on most existing interior wood or metal doors
- Uses credit card size proximity badges (included) or optional key fobs
- 5 proximity badges included (additional badges sold separately)
- Badges can be assigned to additional locks for multi-door systems
- Eliminates locksmith costs and hassles of re-keying
- Heavy duty stainless steel construction
- Stand-alone operation - no computer required
- 2 mechanical backup keys
- Operates for 1 year or 4,000 uses on 4 AA batteries (not included)
- LED and audio tone alerts for badge authorization
- Fits door thickness from 1 3/8” to 2” and a standard 2 1/8” hole cutout
- Adjustable latch fits standard 2 3/8” or 2 5/8” backsets
- One year warranty
SPECIFICATIONS
Dimensions: 5 1/4”W w/ lever x 6”H x 1 5/8”D
Operating temperature: 32-140º F
Operating humidity: 15-95% RH
Weight: 4.3 lbs.
Door Requirements
- Door thickness - from 1 3/8” to 2”
- Hole cutout - standard 2 1/8”
- Backset - standard 2 3/8” or 2 5/8”
- Clear Space - see diagram to the right
Which lock do I need?
Handing for an LX100 is determined by
standing on the outside facing the door.
If the hinges are on the left hand side,
you need a left hand LX100 (LX100-L).
If the hinges are on the right hand side,
you need a right hand LX100 (LX100-R).
See diagram to the right
ACCESSORIES
This information is subject to change without notice. Copyright © 2009 Lathem Time Corporation. Printed in USA.
Lathem and the Lathem logo are registered trademarks of Lathem Time Corporation.
TIME • LABOR • SECURITY
Atlanta, Georgia USA • www.lathem.com
FORM# BRLX1-0209
