LAUER EPC PM 2100 User manual

CiS-Nr.:360.610.0110
Reg10508/0605
Version2/09.05
© Elektronik-Systeme LAUER GmbH & Co.KG
User manual
EPC PM 1200
EPC PM 1500
EPC PM 1700
EPC PM 2100
EPC PM Box

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
0-2
Elektronik Systeme LAUER GmbH & Co.KG
P.O Box 1465
D-72604Nürtingen
Operatinginstructions: Embedded PCPentiumMobile
issue: 01.September2005
editor: Jung
Operatinginstructions, manuals and software are copyrighted. Allrights
are reserved. Copying, duplicating, translating, transcribing en bloc or
partially is prohibited.An exception is the making of a software back up
copy for private use.
• We reserve the right to make amendments to the manual without
priornotice.
• We can not guarantee the accuracy and correctness of the
programmesand data storedon the CD-ROM.
• Helpful suggestions, improvements as well as references to errors
are welcome at any time.
• Thestipulationsarealsovalid for any specialannexestothismanual.
Microsoft,Windows2000,WindowsXP andtheWindowsLogo are either
registered trademarks or trademarks of the Microsoft Corporation in the
USAand/or other countries.
The above terms in this documentation can be brands, whose use by
third parties can breach the rights of the proprietor.

© Elektronik-Systeme LAUER GmbH & Co.KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
User tips
Please read the manual prior to using for the first time and keep it in a
safe place for future use.
Targetgroup Thedocumentedinformationinthis manual refersto the appliance,place
of use, transport, storage, assembly, use and maintenance.
This manual is directed to the following target groups:
• User
• Servicetechnicians/maintenance technicians
Especially observe the chapter „safety instructions and general
instructions“.
Knowledgeof PCand Microsoft-operating systems are assumed. Gene-
ralknowledge in the area of automation technology isrecommended.
Diagramconvention [Key] Key entries by the user are shown in squared brackets, for
example[CTRL] or[DEL]
italic Names of pushbuttons to be used, menus or other screen
elements as well as brand names are shown in italic letters.
Necessarybasic knowledge A solid Knowledge of the personal computer and Microsoft-operating
systems is assumed and a general knowledge in the area of automation
technologyis recommended.
Approbation’s&standards Youwillfind information intheannex,chapter„certificateand guide lines“.
Safety instructions Anywhereintheautomationequipment,wheredangerouserrorsmayoccur,
i.e.thatanoccurring error maycausemajormaterial or personaldamage,
additionalexternal precautions orfacilities haveto be made(for example
bymeansofindependentlimitswitches,mechanicalinterlocksetc.),which
incase of an error guarantee or enforce a secure operating condition.
The test and aptitude of the intended usage by the user res. the usage
under operational conditions is the responsibility of the user.Therefore
Elektronik-Systeme LAUER does not assume liability.

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
0-4
UserTips
Icons The following icons are used in the manual to mark certain paragraphs:
Danger
Means that death or severe injury will occur when the relevant
precautionarymeasures arenot taken
Caution
Means that death or severe injury may occur when the relevant
precautionarymeasures arenot taken.
Warning
With warning triangle means that a light injury may occur when the rele-
vant precautionary measures are not taken
Precaution
Without warning triangle means that material damage may occur when
therelevant precautionary measures are nottaken
Attention
Meansthat an undesirable effect or situation mayoccur ifthe respective
advise is ignored.
The warning advise for the highest level is used if various danger levels
occur. When awarning advisewithawarningtrianglewarns aboutperso-
naldamagethenanadditionalwarningformaterialdamagecanbeadded.
Qualifiedpersonnel Thedescribedappliancemayonlybeinstalledand operated inaccordance
withthisdocumentation.Onlyqualified personnel may putitintooperation
and operate this appliance. Qualified personnel are persons, who in
accordance with the safety regulations contained in this documentation,
areauthorised to put intooperation,earthandstamp appliances,systems
and circuits.
Intended use Theappliancecanonlybe used for thedesignatedpurposesasdescribed
in the catalogue and the technical write up and only in conjunction with
externaldevises i.e. componentsrecommended and authorisedby Elek-
tronik-SystemeLAUERGmbH & Co.KG.Theefficient and safeoperation
of the appliance presupposes appropriate transport, storage, assembly
andinstallation aswell as accurate handling andmaintenance.

© Elektronik-Systeme LAUER GmbH & Co.KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
Usertips 3
Contents 5
Preamble 6
Certificates and guide lines 7
1 Preparation 9
1.1 listhof supplied equipment................................................... 9
1 Preparation 10
1.1.1 Organisationdriver-CD ....................................................... 10
1.2 Preparingtheinstallation ofthe appliance .......................... 10
2 Description 11
2.1 Installation ......................................................................... 11
2.2 Display............................................................................... 12
2.3 Ports .................................................................................. 13
2.4 Motherboard–slots, memorymodule ................................ 15
3 Putting in to operation 17
3.1 Powersupply...................................................................... 17
3.2 Earthing system................................................................. 18
3.3 Assembly........................................................................... 19
3.4 operatingsystem ............................................................... 20
3.5 BIOS-settings .................................................................... 21
3.6 Importantitems regardingsoftwareinstallation .................. 23
3.7 Touch installation 6.10 Windows 2000 / XP ........................ 24
3.8 Graphicboardinstallation ................................................... 28
3.9 InstallationLAN-/networkcard............................................ 29
4 Service 31
4.1 Changingthe fan ................................................................ 32
4.2 PCI-boardinstallation ......................................................... 34
4.3 Memoryexpansion,-change .............................................. 38
5 Technical data 41
5.1 Detaileddrawings ............................................................... 43
5.1.1 EPC PM 1200 .......................................................... 43
5.1.2 EPC PM 1500 .......................................................... 45
5.1.2 EPC PM 1700 .......................................................... 47
5.1.3 EPC PM 2100 .......................................................... 49
5.1.4 EPC PM Box ........................................................... 51
Contents

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
0-6
Preamble
Elektronik-Systeme LAUER GmbH & Co.KG
Kelterstraße 59
D-72669Unterensingen
Tel. [phone] / 9660-0
Fax [phone]
http://www.lauer-systeme.net
our philosophy Elektronik-SystemeLAUERisareliableinternationallyorientatedpartner.
From the text display LCA, the high-tech operating console PCS, to the
industrial computer we supply a complete range to:
• operate,observea nd control
Systeme LAUER stands for an almost unlimited product range and
competentservice,underthe umbrellaof AUGUSTATechnologie AG–a
globalgroup of companies.
Through active co-operation with our customers, persuasive concepts
are developed harmonising efficiently man, and interface. Proximity to
customers – the direct dialog – is the basis of our success.
Support contact Telephone: [phone]
eMail: [e-mail]
forsupportinquiriesalwayshavetheserialnumberofyour appliance
athand!
Upto datedriver units, software, driver units,manuals ...andinnovations
canbe foundin ourdownload-forum:
http://forum.systeme-lauer.de/
Sales contact Telephone: [phone] / 9660 -0
eMail: [e-mail]
additionally on offer ... ... courses andtechnical trainingin our modernequipped trainingcentre
or alternatively at your place of business. Please ask your distribution
agent for the latest training course schedule.
...not onlydemo-appliances butalso specialists who will personally ass-
ist you when you first take your appliance into operation.

© Elektronik-Systeme LAUER GmbH & Co.KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
Certificates and guide lines
The following applies for the products described in this documentation:
EMV-directives Alternating - AC supply
The appliances running on AC supply comply with the EC-directive „89/
336/EEC electromagnetic compatibility“ and are according to the CE-
markingdesigned for followingapplications:
Application Standard
Emittedinterference interference resistant
industrial EN61000-6-4: 2001 EN 61000-6-2: 2001
Directcurrent –DC supply
The appliances running on DC supply comply with the EC-directive „89/
336/EEC electromagnetic compatibility“ and are according to the CE-
markingdesigned for followingapplications:
Application Standard
Emittedinterference interference resistant
industrial EN61000-6-4: 2001 EN 61000-6-2: 2001
lowvoltage directive 230V The appliances running on AC supply comply with the EC-directive 73/
23/EEC,low voltage directive. Compliance with this standardwas tested
inaccordance withEN 60950.
Declarationof conformity The EC-declarationof conformity andtheassociated documentation and
are kept at the disposal of the responsible authorities.Your distribution
agentcan makethese available on demand.
Assembly directives Please note the assembly directives and safety instructions mentioned

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
0-8

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
1 Preparation
1.1 list hof supplied equipment
The transport cardboard box contains the following parts and materials:
CD with operating system.
Driver software CD for all pre-installed components like mother board,
touch, key board etc. Further information will be found in chapter
„installation“.
1standard power cable( Europeanor US standard)length approx. 1,9m
Notice!ThePower-cableisNOTdeliveredatthe DC-Version.
Usermanual
Notice!Separatedocumentationofthird partycomponentsisincludedon
the enclosed CD.This manual only describes specific information about
LAUER products – not about third party components.
The LAUER appliance pass is supplied with every appliance.It contains
important information for the user.Ready to hand are important address
data,serial number,thenthere are thecomponents andtypedesignation
correspondingwith the companyinternal appliance designation.
Also shown are all components contained in the system – therefore the
CPUand hard disktype or theoperation system areeasily identifiablefor
theuser.
Youradvantages:
• all important contact data for a fast and uncomplicated handling for
desiredimprovements, general queries or forservice purposes.
• complete configuration of your system including serial number.
Fixing kit
Varying numbersof screws arecontained inthe parcel depending on the
appliance.
EPC PM 1200 - 8 nuts with toothed washers and plain washers
EPC PM 1500 - 10 nuts with toothed washers and plain washers
EPC PM 1700 - 14 nuts with toothed washers and plain washers
EPC PM 2100 - 14 nuts with toothed washers and plain washers

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
10
1 Preparation
1.1.1Organisation driver-CD
Onthe supplied driverCD you willfind the availabledrivers necessary for
yourinstallation.
• AUDIO (OnboardSound)
• CHIPSET
• Graphic (Graphic cards driver for a resolution up to
1600 x 1200 for a 21" Display)
• LAN (Onboardnetwork)
• Touch (mouse pointer control directly over screen contact of
theEPCPM)
Note:
Key Version of the EPC PM: with keyboard on the front plate, you can
install the program Keyconf under E:\Tools\Keyconf for configuring the
individual keys.The software is self-describing over the menu guidance.
1.2 Preparing the installation of the appliance
Openthe package andcheck, whether thecontents match thelist above.
The cardboard box should be kept for an eventual future safe transport.
After removing the appliance from the parcel, lay the parts on a suitable
clean and open surface (for example a table. Workbench etc.). Follow
exactly the instructions described in the following chapters.

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
2 Description
2.1 Installation
The installation of the PPC is independent of the display size, shown as
follows:
1 Frontunit
2 PC-unit
1
2

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
12
2.2 Display
Display sizes of 12", 15", 17"and 21" are available, alternatively with
Touch orkeyboardandTouch.
PureTouch variants available in 12", 15", 17"and 21"
Touch/key variants available in 10“ and 15“
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
2.3 Ports
24V panel
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
14
230V panel
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
2.4 Motherboard – slots, memory module
Thepanel-PCandthePC-modulehave2DIMMslotsforthemainstorage,
2 PCI-slots.
Further details on the motherboard can be found in the manual with the
suppliedmaterials.
Notice!
Individual slots may be part of the supply depending on configuration
andcustomer requirements!
The quality of the memory module may influence the system stability.
Please only use memory modules cleared by Systeme LAUER.
Memory modules are electrostatic sensitive components. Relevant
protective measures (earth) have to be considered during assembly/
disassembly.
ESD-protective measures to be considered when opening and working
onthe appliance.
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
16
2 Description

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
3 Putting in to operation
3.1 Power supply
TheEmbedded PC PentiumMobileare availableas AC-115/230V-power
system or DC-24V-power system.
Power supply system 24V DC TheEPCPM can beoperatedwith extra-low-voltage in accordance with
EN60950!
The controlling transformer has to comply with EN60742!
Checkthe power supply system withthe relevant data on thetype plate.
All cable connections have to be checked prior to putting the system in
tooperation.
It has to be ensured that all voltages and signals comply with the rele-
vant specifications.
1fuse 6,3 A
1powersupply 24V
3earth screw
The power supply is carried out via a double-pole connector (Phoenix
MST BT 2,5/2).
Supplybuild up
230VAC
+ 24 V
230VAC
0V
24V DC
1
2
3

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
18
Power supply system 230VAC TheEPCPM iscertified forthe connection toprotectivegroundedpower
supplyafter EN60950.
1Supply connection 230VAC
2Earthscrew
3.2 Earthing system
The following items have to be observed to guarantee a safe dissipation
ofelectronic interference:
• Appliance and switch board have to be connected to the nearest
possiblecentralearthing point.
• makesureof a possiblylow inductive connectionbetween appliance
andswitch board.
• All data cables connected to the appliance have to be the screened
type.
• The screens have to be earthed on both sides.There has to exist a
lowohmconnectionbetweentheconnectedsystems.Highequalising
currents through the cable screen due to voltage fluctuations are to
beavoided.
• The earthing connection is to be carried out with min. 4 mm² cross
section.
1
2
3 Putting in to operation

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
3.3 Assembly
Assembly The EPC PM is to be inserted in a HF close housing or switchgear
cabinet made of metal
To dissipate the heat generated in the appliance a free space for air
circulation, of 100 mm has to be provided around the appliance!
Theassemblytakesplacebyhexagonnutsorretainingblocks(depending
upon the version of the EPC PM)
Notice!
Possibility of damage to the appliance!
Protection class IP65 to the front panel is only guaranteed with a perfect
fitting seal.
Pay attention to the torque when fixing the front panel!
3 Putting in to operation

© Elektronik-Systeme LAUER GmbH & Co. KG • Kelterstr. 59 • 72669 Unterensingen • Tel. [phone] • Fax [phone]
20
3.4 operating system
Supply incl. operating system hard disk version:
We offer our appliances with installed operating system software. In this
case we opt for following installation concept.The respective operating
system and other programmes are installed on C: drive. D: drive is a
completefreepartitionandcanforexamplebeusedforyourdata(beneficial
for example for data back up). On E: drive are all the data required for a
newinstallation (driversandoperationsystem).Thispartitionalwaysuses
a FAT 16-data system.
At present the following operating systems are available:
Windows2000 German,English and multi-language pack
(C: and D: NTFS)
WindowsXP professional German and English
(C: and D: NTFS)
depending on the configuration, the respective user interface of the
installed operating system appears, once the EPC has booted from the
hard disk.
CompactFlashCard-Version:
WindowsembeddedXP
Wir stellen kundenspezifische Konfigurationen als Dienstleitung zusam-
men.
Withoutoperating system If no operating system is present, the message „DISK BOAT FAILURE,
INSERT SYSTEM DISK AND PRESS ENTER“ comes at switching on
the EPCPM, because of non formatted Non removable disk and missing
partition. In this case you can install the operating system either over
ownboatdisk,setUPstarting disksordirectly with youroperatingsystem
CD start (consider BIOS settings). The additional installations e.g. the
Touch or display driver can be started over the provided drivers - CD,
(driverfolder).
Furtherdetails to theindividualdriverinstallationsyou will findinfollowing
chapters.
3 Putting in to operation
