LawnMaster FD2401 Quick start guide

FD2401
540304
FAST SHREDDER
Original Operation Manual
GB
WARNING! Read the instructions before using the product
Before initial start-up, please read through these operating instructions carefully
prior to using the machine. Keep the instructions safe and pass them on
to any subsequent user so that the information is always available.
Serial Number:

A12
7
5
11
3
8
6
9
4
10

5 12
13
14 15
BC
6
6
D
16 18 19
9
20
17
6.1

5
GB
Intended Purpose
The shredder is intended for shredding fibrous
and wood-related materials such as hedge and
tree cuttings, branches, bark and pine cones.
Any use not expressly permitted in this manual
may damage the shredder and pose a serious
danger to the user.
Do not put stones, glass, metal, bones,
plastics or fabrics into the shredder.
The operator or user is responsible for accidents
and injury or damage to third parties.
The manufacturer will not be held responsible
for any damage caused by improper operation
or use outside of intended usage.
This shredder may cause serious injuries
if improperly used. Before using the
shredder, read the user manual carefully
and familiarise yourself with all of the
controls.
In cases of uncertainty, ask an expert for
advice. Keep the manual in a safe place
and pass it on to any subsequent owner
to ensure that the information contained
therein is available at all times.
Safety Precautions
Symbols used in the instructions
Hazard symbols with information on
prevention of personal injury and
property damage.
Precaution symbol (other symbol may be
used instead of exclamation mark) with
information on prevention of harm / damage.
Notice symbol with information on how to
handle the device properly.
Content
Intended Purpose .................................................. 5
Safety Precautions ................................................ 5
Symbols Used In The Instructions..................... 5
Symbols On The Shredder ................................ 6
Important .................................................................. 6
Training ................................................................. 6
Preparation ........................................................... 6
Operation .............................................................. 7
Maintenance And Storage ................................. 7
Additional Safety Instructions For Units With
Bagging Attachments .................................... 7
Electrical Safety....................................................... 8
General Description ........................................ 9
Technical Specifications ............................... 9
Summary ................................................ 9
Technical Specifications ..................................... 9
Assembling The Shredder ................................ 10
Unpacking ............................................. 10
Box Contents ......................................... 10
Attach The Collection Bag ..................... 10
Start - up ................................................ 10
Switching The Shredder On And Off ........ 10
Emptying The Collection Bag ................ 10
Overload Protection ............................... 10
Restart Prevention ................................ 10
Working Methods ................................... 10
Freeing Up A Jam ................................. 11
Sharpening, Turning Or Replacing The
Blades ................................................... 11
Maintenance And Cleaning ...................11
General Cleaning And Servicing ...........11
Replacement Parts .............................................. 12
Waste Disposal And Environmental Protection
................................................................................... 12
Trouble Shooting ................................................. 13
Warranty ................................................................. 13
Exploded Drawing ............................................... 15
EC Declaration Of Conformity ................ 16

6
GB
Symbols on the shredder
Warning! Beware of hazards. Take
special care to avoid injury or damage.
Read the manual.
The equipment is intended only for use
in premises in which the current bearing
capacity of the network is >=100 A per
phase and which are supplied by a
distribution grid with a nominal voltage
of 230V-240V.
Do not dispose of electrical equipment
in the domestic waste.
Protection against contact with the
fingers and solid foreign bodies with
Ø > 12 mm as well as protection
against splashed water from all
directions.
The product complies with the
applicable European directives and
an evaluation method of conformity
for these directives was done.
Wear ear and eye protection.
Wear hand protection.
Do not expose the unit to rain.
Caution! Switch off the motor and
disconnect from the mains before
adjustment or cleaning work, or if
the cable is caught or has been
damaged.
Warning! Danger of injury from
rotating blade .
Danger-Rotating blades.
Keep hands and feet out of openings
while machine is running.
Warning! Danger from thrown objects.
Keep your distance from the feeder and
ejection area, and keep others away
from the danger area.
Caution! Moving blade
Warning! Electric shock hazard.
Always unplug the shredder before
working on it.
Guaranteed noise power level.
Safety class II
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP
FOR FUTURE REFERENCE
Training
Become familiar with the owner's manual before
attempting to operate this equipment.
Preparation
1) do not allow children to operate this equipment;
2) do not operate this equipment in the vicinity
of bystanders;
3) wear ear protection and safety glasses at all
times while operating the machine;
4) avoid wearing clothing that is loose fitting or
that has hanging cords or ties;
5) only operate the machine in open space
(e.g. not close to a wall or other fixed object)
and on a firm, level surface;
6) do not operate the machine on a paved or
gravel surface where ejected material could
cause injury;
7) before starting the machine, check that all
screws, nuts, bolts, and other fasteners are

7
GB
properly secured and that guards and
screens are in place. Replace damaged or
unreadable labels;
Operation
1) before starting the machine, look into the
feeding chamber to make certain that it is
empty;
2) keep your face and body away from the feed
intake opening;
3) do not allow hands or any other part of the
body or clothing inside the feeding chamber,
discharge chute, or near any moving part;
4) keep proper balance and footing at all times.
Do not overreach. Never stand at a higher
level than the base of the machine when
feeding material into it;
5) always stand clear of the discharge zone
when operating this machine;
6) when feeding material into the machine be
extremely careful that pieces of metal, rocks,
bottles, cans or other foreign objects are not
included;
7) if the cutting mechanism strikes any foreign
objects or if the machine should start making
any unusual noise or vibration, switch off
the machine and allow the machine to stop.
Disconnect the plug from supply and take
the following steps:
— inspect for damage;
— check for and tighten any loose parts;
— have any damaged parts replaced or
repaired with parts having equivalent
specifications.
8) do not allow processed material to build up
in the discharge zone; this may prevent
proper discharge and can result in kickback
of material through the feed intake opening;
9) if the machine becomes clogged at the inlet
opening or discharge chute switch off the
machine and disconnect the plug from supply
before clearing debris in the inlet opening or
discharge chute.
10) keep all guards and deflectors in place and
in good working condition;
11) do not transport this machine while the
machine is running;
12) switch off the machine and disconnect the
plug from supply whenever you leave the
work area;
13) do not tilt the machine while the machine is
running.
Maintenance and storage
1) when the machine is stopped for servicing,
inspection, or storage, or to change an
accessory, switch off the machine, disconnect
the plug from the supply, make sure that all
moving parts have come to a complete stop
and, where a key is fitted remove the key.
Allow the machine to cool before making any
inspections, adjustments, etc.
2) Always allow the machine to cool before storing;
Additional safety instructions for units with
bagging attachments
1) switch off the machine before attaching or
removing the bag.
Working with the device:
1) This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should
be supervised to ensure that they do not play
with the appliance.
• Never use the shredder with other persons or
animals nearby.
• Wear appropriate protective clothing such as
protective gloves, firm footwear and long
trousers. Do not wear loosely fitting clothes or
clothes with dangling cords or belts.
• Only use replacement parts and accessories

8
GB
-
CAUTION! The following states how
damage to the trimmer and possible injury
CAUTION!
The following states how to avoid accidents
Electrical Safety
supplied and recommended by the manufacturer.
Using third-party parts will immediately invalidate
the guarantee.
• Do not leave the shredder working unattended
and keep it in a dry place out of children’s reach.
• While being used in the open, connect the
shredder to a residual current device (RCD)
or circuit breaker with a trip current of not more
than 30mA.
• Do not reach into the funnel feeder during
operation. The shredder will continue to run for
a short period after you switch it off.
• Make sure that the material inserted into the
shredder does not contain hard objects made
of metal, stone, glass or similar.
• Do not use the shredder in the rain and in bad
weather. Work in daylight or under good lighting
conditions.
• Do not operate the shredder when you are tired
or distracted, or under the influence of alcohol
or medication. Always take a break when you
need one and be sensible about how you work.
• Switch the shredder off and pull the plug under
the following circumstances:
- when you are not using the device,
- transporting it or leaving it unattended;
- before releasing a jammed blade.
- when you are checking the device, cleaning
it or removing blockages;
- when you are carrying out cleaning or
maintenance work or replacing accessories;
- Before moving or lifting the shredder
- If foreign objects should enter the shredder,
if the shredder is making unfamiliar noises
or vibrations (check the shredder for damage
before starting it up again)
• Do not allow shredded material to accumulate
near the ejection area. This may otherwise
hinder proper ejection and force the material
back up through the feeder.
• Do not transport or tip the shredder with the
motor running.
• Keep hands, other body parts and clothing out
of the filling chamber and ejection channel and
away from other moving parts.
• In the event of blockages in the machine intake
or ejection, switch off the motor and disconnect
the machine from the mains before removing
leftover material in the intake opening or ejection
channel. Ensure that the motor is free of rubbish
and other accumulations in order to safeguard
the motor from damage or possible fire.
to people can be avoided:
• Handle the unit with care. Clean the ventilation
slits regularly; keep to the maintenance instructions.
• Do not overload your device. Work only within
the indicated range of performance.
Do not employ any low power machines for
heavy work. Do not use your device for
purposes for which it has not been designed.
• Only switch the shredder off once the funnel
feeder is completely empty since the shredder
may otherwise clog up and not be able to start
afterwards.
• Do not attempt to repair the shredder yourself
unless you are qualified to do so. Any work not
specified in this manual may only be carried
out by our service centre.
• Damaged cables, coupling and plugs or
connecting leads not corresponding to
specifications, must not be employed. Remove
the plug immediately from the plug socket in
case of damage to the mains cable.
Do not touch the mains power supply cable
under any circumstances until you have pulled
the plug out of the mains socket.
• If the power cable for this equipment is damaged,
it must be replaced by the manufacturer, a
customer service agent of the same or a similarly
qualified person in order to prevent hazards.
• Do not use the appliance if the on/off switch

9
GB
A
1 Hopper
2 Pusher
3 Bag mount
4 Collection bag
5 Wheel
6 Chassis
7 Mains lead
8 Reset button
9 Housing interlock
10 On/Off switch
11 Handle
Technical Specifications
does not work properly. Always have a damaged
switch repaired by our a qualified technician.
• Only use extension cables that have been
approved for outdoor use and are resistant to
splash water.
The core diameter for extension cables
measuring up to 25 m must be at least 1.5 mm²,
and 2.5 mm² for cables longer than 25m. Always
roll the whole cable off the reel before use.
Check the cable for damage.
• Do not unplug the shredder by the cable. Keep
the cable away from heat, oil and sharp edges.
General Description
Functional description
The shredder has a powerful electric motor with
overload protection. Cutting is performed by a
system of blades. The sturdy chassis ensures a
stable standing position with good mobility.
Refer to the following descriptions for a functional
description of the controls. This appliance is not
intended for use by persons (including children)
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Summary
Blade-type shredder.................................. FD2401
Nominal power intake................................ 2400 W
Nominal voltage........................ 230V-240V~ 50Hz
Safety class.......................................................... II
Degree of protection........................................ IP24
Idling speed........................................... 3940 min-1
Volume of collection bag..............................….60 l
Weight............................................................12 kg
Branch thickness ................................max. 40 mm
Noise pressure level EN ISO 11201(LpA)...............
....................................... 98dB(A); KpA = 3,0dB(A)
Noise performance level EN ISO 3744 (measured)
/(LwA)….......................105dB(A); KwA = 2,0dB(A)
Noise performance level (guaranteed)........ 107dB
*Rated operation duty: P(40)
The machine shall periodically continuous operate
with load for 40s and then without load for 60s.
The max. branch thickness that can be shredded
is dependent on the type of wood and the quality
of the material being cut.
For hard wood (e.g. oak/beech branches), the
max. branch thickness that can be shredded is
less than for soft wood (e.g. pine/spruce wood).
For dry or knotted wood, the cutting thickness
may also be less.
The equipment is intended only for use in premises
in which the current bearing capacity of the
network is >=100 A per phase and which are
supplied by a distribution grid with a nominal
voltage of 230-240V.
To be on the safe side, check with your local
electric utility to verify that the junction point of
the mains has enough continuous current carrying
capacity for the unit.
Noise and vibration values were determined
according to the standards and stipulations
mentioned in the declaration of conformity.
Technical and optical changes can be carried
out in the course of further development without

10
GB
B
C
Emptying the collection bag
notice. All dimensions, references and information
of this instruction manual are therefore without
guarantee. Legal claims, which are made on the
basis of the instruction manual, cannot thus be
considered as valid.
Assembling The Shredder
Unpacking
Make a loop in the power cord
and fasten it to the cable strain
relief . Connect the plug to the
mains socket.
Make sure that the funnel feeder is empty.
1. Set the On/Off switch (10) to “ON” to turn on
the unit.
Place your chopping material in the fill hopper.
The material is drawn in and shredder.
2. Set the On/Off switch (10) back to “OFF” to
turn off the unit.
The shredder will continue to run immediately
after switching off.
the discharge duct!
1. Turn off the unit.
2. Remove and empty the collection bag (4).
Overload protection
n the event of overload, e.g. due to branches
that are too thick, the equipment automatically
switches off.
To restart the unit, wait a little, press the Reset
button (8), then turn on the unit.
Restart prevention
The unit will not automatically restart when the
power returns after a power cut. To restart the
unit, turn on/off switch “on”.
Working methods
General working instructions
Avoid filling the collection bag too much.
Mind that the bag will fill unevenly under
Slide the two wheels (5) onto the chassis axle (6).
Slip the washers (13) onto the axle and stick the
split pins (14) through the appropriate holes in
the axle.
Box contents
• Operating and safety instructions
• Shredder
• Chassis
• Collection bag
• Two wheels, wheel covers, and mounting materials.
• Allen wrench
• Pusher
• Pressure rod
Switching the shredder on and off
If your shredder is fitted with a long mains cable,
plug it directly into the mains supply, using an
RCD device if necessary.
Connect the extension cable.
Slide the axle (6.1) into the chassis (6).
Mount the two wheels (5) onto the chassis (6).
Clip the wheel covers (12) onto the wheels.
Position the shredder (15) on the hopper (1)
(upside down). Push the wheel chassis (6) into
the 2 holes in the plastic housing of shredder.
Secure with the 2 screws provided.
Attach the collection bag
Before each use, always hang the collection bag
over the bag mount (3), keep the collection bag
cover the discharge chute.
Assembling the shredder
Start- up
Check that the mains voltage matches the
rating on the name plate.
Keep your body at a safe enough distance
from the shredder as long branches may
be spun round while being drawn into the
shredder.
Before starting up，hook two straps of the collection
bag(4) into the bag mounts(3).(figure A)

11
GB
D
Leave all work not described in this
manual to an authorised customer
service centre. Only use original parts.
Wear ear and eye protection
Sharpening, turning or replacing
the blades
Wear hand protection
• When feeding branches into the unit, keep
holding them firmly until they are automatically
drawn in.
• Adapt to the speed of the shredder and avoid
overloading the unit.
• To avoid the unit clogging up, mix freshly cut
branches or leafy material with with drier
materials such as twigs
• To prevent the blades from becoming blunt
quickly, remove mud and stones from the roots
before shredding.
• Do not shred but directly compost all soft and
wet material such as kitchen waste.
• Keep a couple of dry branches to use them for
cleaning the unit at the end.
• Do not turn off the unit until all the material
has passed the blades. Remaining material
may otherwise block the blade when you restart
the unit.
Freeing up a jam
wait until the blade comes to a standstill. Take care.
Risk of injury from electric shock, fire and rotating
blades.
• Check that the power plug ( A 7) is removed
from the mains supply.
• Unscrew the housing interlock (9).
• Tip forward the front part of the shredder housing.
You can remove it completely and put it aside.
• You now have full access to the blade (19).
• Use a screwdriver to block the blade plate (17).
Slot the screwdriver into the access hole (20)
and carefully turn the blade plate (17) until one
of the two blocking apertures appears.
Now block the blade plate (17) by slotting the
screwdriver right through it.
• Use the Allen wrench (16) to unscrew the screw
(18) in the blade plate (17) and remove the
blade (19).
Maintenance and cleaning
Before starting to service or clean the unit,
turn off the unit, pull the power plug, and
Wear hand protection when working on
the blade.
Do not spray water onto the shredder.
Electric shock hazard.
Before starting to service or clean the unit,
turn off the unit, pull the power plug, and
wait until the blade stands still. Risk of injury from
electric shock, fire and rotating blades.
General cleaning and servicing
• Always keep the shredder, wheels and air vents
clean. Use a brush or cloth to clean it, avoid
cleaners and solvents.
• Always check that the shredder and especially
the guards are not worn down or damaged but
firmly attached before use.
Before starting to service or clean the unit,
turn off the unit, pull the power plug, and
wait until the blade comes to a standstill.
Take care. Risk of injury from electric shock, fire
and rotating blades.
• Check that the power plug (7) is removed from
the mains supply.
• Unscrew the housing interlock (9).
• Tip forward the front part of the shredder
housing. You can remove it completely and
put it aside.
• You now have full access to the blades (19).
• Remove the blockage.

12
GB
Replacement parts
Only use original replacement parts.
Waste disposal and environmental
protection
• Check that the nuts, bolts and screws are tight.
• Check the covers and guards for damage and
improper attachment. If necessary, change the
components
• Keep the shredder in a dry place out of children’s
reach. Do not cover the shredder in nylon bags,
as moisture may develop.
Be environmentally friendly. Return the
tool, accessories and packaging to a
recycling centre when you have finished
with them.
Machines do not belong with domestic waste.
Hand over the device at an utilization location.
The plastic and metal parts employed can be
separated out into pure materials and recycling
can be implemented. Ask your Service Center
about this.

13
GB
Problem Possible Cause Remedy
Unit won’t shred
property
Garden waste
is not drawn in
Motor will
not start
No mains power supply
Overload protection tipped
Lid of housing not closed
property
Shredding material is too
soft
Unit blocked
Blades are blunt
Shredding material in
discharge duct
Remove shredding matweial from
discharge duct
Check and tum, sharpen or replace blades
as necessary ( see section “ sharpening,
turning, replacing the blades ”)
See section “ Freeing up a jam ”
Use the pusher or add dry twigs/branches
Tightly screw in the housing interlock.
Check the socket, cable, lead and plug
for damage, and if necessary, have any
damage repaired by qualified repair
personnel.
Wait until the motor has cooled down,
then press the Reset button and restart
the unit.
Trouble Shooting
WARRANTY
The manufacturer guarantees
the machine, including the
motor, for 24 months from date
of purchase against proof
thereof (invoice, receipt).
We recommend you check the
product is in good condition
immediately after purchase and
read the instructions carefully
before use.
The manufacturer provides
replacement for all cases of
defective approved parts due
to manufacturing fault or defect.
In no cases can the guarantee
give rise to a refund or direct or
indirect damages or liabilities of
any sort.
Any request for spare parts
should be accompanied by details

14
GB
of exact model number, year of
manufacture and appliance serial
number.
This guarantee does not cover:
1. Abnormal use not conforming
with instruction manual
2. Inadequate maintenance
3. Poor combination or
inadequatelubrication
4. Use for professional or hiring
purposes
5. Assembly, adjustment and
starting procedures
6. Any damage or loss caused
during transit or transfer
7. Any damage due to impact
or dropping
8. Appliance packing and transit
charges (any transportation
charges will be refused by
after-sales service centre)
9. Stated normal consumable
items such as knives, blades,
spark plugs, tree support for
knives, cables, wheels, hub-
caps and collection sacks.
10. Downtime charges or appliance
hire in case of breakdown.
Guarantee automatically lapses
if:
1. Modifications are made to
machine without
manufacturer’s approval.
2. Non-original or unapproved
parts are installed.
Manufacturer declines any
public liability arising from
improper use not complying
with normal standards and / or
with ruling
regulations and from
inadequate maintenance.
No repairs made or parts
replacedcan possibly lead to an
extension of initial guarantee
validity.
SAVE YOUR RECEIPTS.
THIS WARRANTY IS VOID
WITHOUT THEM.

15
GB
Exploded Drawing

GB
EC declaration of conformity
EC declaration of conformity
We
Suzhou Cleva Electric Appliance Co., Ltd.
No.8, Ting Rong Street, 215122 Suzhou, Jiangsu Province
CHINA
Complies with the essential health and safety requirements of the following directives:
- The Machinery Directive 2006/42/EC
- The EMC Directive 2004/108/EC
- The Outdoor Noise Directive 2000/14/EC & 2005/88/EC
- The RoHS Directive 2011/65/EU
Measured Sound Power Level: 98 dB(A)•
Guaranteed Sound Power Level : 107 dB(A)•
The conformity assessment followed was according to Directive 2000/14/EC, Annex V,
and the Directive 2005/88/EC.
Authorized Signatory and technical file holder
Name: Will Zhou
For and on behalf of Suzhou Cleva Electric Appliance Co., Ltd.
Date: 14/11/2018
All technical information is held at the address detailed above
Declare that the product
SHREDDER
540304
(MODEL: FD2401)
