USE AND CARE GUIDE
Sears Peyton Umbrella Base
Product Code: D71 M80908
UPC Code: 7 22938 07959 9
Date of Purchase: __ / __ / __
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2015 La-Z-Boy Incorporated.

2
Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team, We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents
Table of Contents..........................................2
Safety Information ........................................ 3
Warranty ........................................................ 3
What is covered .......................................... 3
What is not covered .................................... 3
Care and Maintenance..................................4
Pre-Assembly................................................ 5
Planning Assembly ..................................... 5
Hardware Included...................................... 5
Package Contents....................................... 6
Assembly Instruction ................................... 7
Customer Service ......................................... 9

3
THIS IS NOT A FREE-STANDING
UMBRELLA BASE. THIS BASE MUST
BE USED UNDER A MATCHING
TABLE.
DANGER: Do not allow children to play with
plastic wraps or small parts to prevent
potential choking hazard..
CAUTION: Read all the instructions before
assembly. Failure to do so may result in
faulty assembly and potential injury!
NOTICE: As a safety precaution, when umbrella is
not in use please crank down and take completely
out of the base and store in a safe location.
Warranty
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
1 YEAR WARRANTY FOR FRAME.
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for 1 year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.
Glass table top breakage and corrosion or rusting of hardware are not covered.
In addition, purchase parts are not covered under this warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
Safety Information

4
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrinking or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and / or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

5
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 5 minutes for one person to
complete all the assembly.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
NOTE: Seek assistance to assemble
bulky or heavy items.
Part Description Quantity
AA M6*30mm hex bolt 2
BB M6 Washer 2
CC Hex wrench 1

6
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Support pole with umbrella
locking knob (pre-assembled)
1
B Umbrella base 1
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 1.
Safety Information

7
Assembly Instruction
1 Attaching the supporting pole
□Attach the support pole (A) to the base (B) using hex bolts (AA) and M6 washer (BB).
□Tighten completely until all bolts are in place.

8
Assembly Instruction
(continued)
2 Using with the umbrella
□Insert the umbrella through table top into the umbrella base and secure the umbrella with
locking knob.
□Umbrella base is ready for your enjoyment.

9
Please refer to part number when reordering
Questions, problems, missing parts? Before returning to the store,
call our Customer Service
8 a.m. - 5 p.m., EST, Monday-Thursday
8 a.m. – 4 p.m., EST, Friday
1-866-391-4868
Made in/ Hecho en CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179
See our extensive assortment of outdoor living products on-line
at www.sears.com and www.kmart.com
Retain this manual for future use.
