LB-Link BL-MP02 User manual

BL-MP02 User Manual
Compact Wireless Router
1) Portable access point (AP):
Portable access point mode,
BL-MP02 given signal wirelessly over
the air, so other device can access
it.eg: Laptop / smartphone.
2) Wireless Router (RT):
Wireless router mode, BL-MP02
should be connect to ADSL modem,
Other device can connect to
BL-MP02 by WiFi to internet.
A. Set the switch BL-MP02 in the "RT" and
Plug the equipment in accordance with
the diagram 2.
B. The configuration settings of your Wi-Fi
card, select "Obtain an IP address and DNS
automatically."
C. Get wireless BL-MP02 default
The SSID is: BL-MP02-XXXXXX, where "X" is
are the last six characters MAC address.
D. Open IE Browser to automatically log on to
management of the screen (or type in the
address bar any address).
E. Enter the user name and
password provided by your
Internet service provider
3) WiFi Repeater:
Select Repeater mode, BL-MP02
become WLan. Repeats, strengthens
orextends the range of the received
signal Wi-Fi. Useful in areas with an
existing network service area.
A. Set the switch BL-MP02 in the
"Reepeater" and Plug the equipment in
accordance with the diagram 3.
B. The configuration settings of your Wi-Fi
card, select "Obtain an IP address and
DNS automatically."
C. Get wireless BL-MP02. Default The SSID
is: BL-MP02-XXXXXX, where "X" is are
the last six characters MAC address.
D. Open IE Browser to automatically log on
to management of the screen (or type
in the address bar any address).
E. Select the network you want to connect
BL-MP02 and click on the "Connect". If the
network is protected by a password
system will ask you to his application.
