LCJ CAPTEURS BaroPlug User manual

Copyright © 2014 LCJ CAPTEURS BaroPlug manual 2014 / English 1
USERS MANUAL
BaroPlug
LCJ CAPTEURS
25 Allée des Cinq Continents
ZA le Chêne Ferré
44120 VERTOU –France
Tel: [phone]
Email: [email protected]
www.lcjcapteurs.com
Reg: 42493307500022 / RCS Nantes
VAT: FR17424933075

2Copyright © 2014 LCJ CAPTEURS
1 GENERAL RECOMMENDATIONS
1.1 INSTALLATION
The LCJ Capteurs BaroPlug is an atmospheric sensor for
NMEA 2000 systems. It features a MICRO male plug to
connect directly to the NMEA 2000 backbone.
This is a Plug and Play device: Install the sensor on your
NMEA systems backbone and read the data on any connected
display which features barometric data!
The BaroPlug must be located in a place protected from water
drops and subject to atmospheric pressure.
Do not attempt any modification to the unit.
Never paint any part of the unit or alter its surface in any way.
Warranty is void in case of non following the instructions
of use, repair or maintenance without written
authorisation.
1.2 MAINTENANCE AND REPAIR
The BaroPlug sensor does not require any maintenance.
Check the connection on a regular basis.
If the pages of your instruments do not display the barometric
data correctly, refer to the manufacturer’s manual and check
the connections before asking for service to your LCJ Capteurs
dealer.
1.3 DISPOSAL
Equipments marked with the recycling symbol should be
processed via a recognized recycling agency. By agreement,
they may be returned to the manufacturer. Do not mix
electronic disposal with domestic or industrial refuse.
1.4 LIMITED WARRANTY
The LCJ Capteurs sensors are guaranteed against
manufacturing defects for a period of 3 years from the
date of purchase. It is limited to the repair and/or
replacement of the product. It does not cover installation
costs and shipping costs of faulty units. A proof of
purchase may be asked when filling the warranty
request which must be received by writing. Once the
warranty request is accepted by LCJ Capteurs, the unit
must be sent to LCJ Capteurs’ address in France. LCJ
Capteurs guarantees that each of their sensors are
tested and calibrated before despatch. Operations not
in compliance with the instructions described in the
present manual may result to damage the unit or alter
its performances. In such cases, the warranty is void.
1.5 RESPONSABILITY
LCJ Capteurs do not accept responsibility for:
Consequential damage to the use of LCJ
Capteurs product
Possible errors in the manuals and their results
2 TECHNICAL SPECIFICATIONS
Dimensions: L 81 mm X Ø17.5 mm
Weight: 35 g
Connector: MICRO male NMEA2000
Power supply: via NMEA2000 network. 8V / 28VDC
Consumption: 1 LEN / 25mA
Operation indicator: 1 flashing LED
Hydrophobic membrane for pressure sensor
Pressure’s measure range: 850 hPa / 1150 hPa
EN 55022 EN55024
Resolution:
1 hPa (mbar) with MEA2000 Version 2 systems
0.1 hPa (mbar) with NMEA2000 Version 3 systems
Relative accuracy: +/- 0.5 hPa @ 20°C
Absolute accuracy : +/- 1.5 hPa @ 20°C
Data:
PGNs TX: 59392; 60928; 126464; 126996; 130311; 130214
PGNs RX: 59392, 59904; 60928
NMEA 2000 manufacturer ID: 499
Product ID: BaroPlug
