LDI Spaces Safco Computer Desk 1930 User manual

Modesty Panel: 1930 1 193004
1931 1 193104
1934 1 193404
Left Leg 1 193002
Right Leg 1 193003
Screw 8 193024
Shelf: 1930 1 193005
1931 1 193105
1934 1 193405
Top Panel: 1930 1 193001
1931 1 193101
1934 1 193401
Carriage Bolt 4 193022
Barrel Nut 4 193023
Glide 4 193027








A
B
C
D
E
F
G
H
I
PART NO.
CODE DESCRIPTION QTY.
PARTS LIST
100193037: 1 of 2; Rev A: Rev Date
28-JUN-2016
For questions or concerns, please call the Safco Consumer Hot Line 1-800-664-0042
available Monday-Friday 7:30 AM to 5:00 PM (Central Time) (English-speaking operators)
TOOLS REQUIRED: Phillips Screwdriver
PRODUCT WARRANTY REGISTRATION is available online at: www.safcoproducts.com
1930
1931
1934
Computer Desk (or Fax/Printer Stand)
ASSEMBLY INSTRUCTIONS
A
1
F
G
E
C
H
B
D
I
Attach the A Modesty Panel to the B
Left Leg and the C Right Leg with two
D Screws per side.
A
D
C
B
ASSEMBLED UNIT
Screw
D
HARDWARE PACK: 193019
Carriage Bolt
G
Barrel Nut
H
Glide
I
Minneapolis, MN 55428
www.safcoproducts.com
an LDI Spaces Company

Safco Products Company, New Hope, MN 55428
100193037: 2 of 2; Rev A: Rev Date 28-JUN-2016
Carefully lay the unit on its back. Screw
a I Glide into the front and back hole
of each Leg. Set the unit upright. Adjust
Glides to make unit level.
Insert a D Screw in the hole at the inside
front of each Leg, but do not tighten com-
pletely; leave about 1/16” gap. Place the
E Shelf between the Legs, with the back
flange resting in the bottom flange of the
Modesty Panel, and guide the slots at the
sides of the Shelf behind the Screws. Fas-
ten Shelf to lower corners of the Modesty
Panel with two additional Screws. Now
tighten the front Screws.
The F Top Panel can be mounted
with either side up; select the side
you prefer, and slide it into the top
channels of the Legs (the cord cutout
should be facing toward the back).
Insert a G Carriage Bolt (with the
square neck) into each square hole
in the Legs, through the Top Panel,
and fasten with a H Barrel Nut.
HANG BACK OF SHELF
ON MODESTY PANEL HANG FRONT OF
SHELF ON SCREW
ATTENTION:
Please CENTER load over Legs
at rear of unit. Do NOT place
heavy loads at front.
2
3
4
E
D
F
G
H
I
