le-idea IDEA 37 User manual

Red LED FLASH
好is
1) Download the APP
Quick Start Guide
(FOR REMOTE CONTROL)
14+ EN
IDEA 37
Scan QR code below using your device camera ,corresponding to APP Store or Google Play Store and
download the “VS GPS PRO” application for free .
2) Unfold the arms
3) Power aircraft
Press the aircraft’s power button and hold for 3 seconds until all 4 LED lights begin to flash, when
the lights change from flashing quickly to flash slowly, the aircraft is turned on successfully.
4) Pair remote with the aircraft
Press the power switch of the remote control and hold for 3 seconds to turn it on, the remote control
will sounds “beep...beep” and indicator light display red light.
During this process, pairing the remote with the drone automatically, and the blue indicator lights of
the drone stay on, pairing remote with the aircraft successfully.
IOS Device
Android Device
Switch
Red LED FLASH
Blue LED ON
Instruction
Video( GPS mode)

WIFI NAME: Eis-Wif-xxxxxx
5) WIFI connection
During search satellites ,
Step 1: Open WIFI setting ,and search the WIFI name start at Eis*****, and connect it.
Step 2: Launch the APP until you can view the application's real time video.
Tips: You may connect to the drone's WIFI at any step.
6) Compass calibration
Step1 : Put the aircraft on a horizontal place, short press the Compass calibration button, and all
the indicator lights of the drone will flash slowly.
Step2 : Hold the aircraft horizontally and rotate it 360 degrees, and loop about 3 times until the
rear lights are ON, the horizontal calibration is completed. At this time, the vertical direction
can be performed.
Step3 : Hold the aircraft vertically and rotate it 360 degrees around a vertical axis,and loop 3 times,you
will hear "DI" during this process .When the front lights are ON ,this confirms calibrating the compass
successfully.
Attention :
1) lt is not necessary to calibrate the compass at NO GPS MODE.
2) When taking off from the same location, it is not necessary to calibrate the compass every time
the drone is powered on. But we recommend that it is better to calibrate the compass.
3) You can calibrate the compass with the remote control or APP.
ALWAYS REFER TO INSTRUCTION MANUAL FOR COMPLETE DETAILS
7) Gyroscope calibration
At the same time, pull Left and Right Joystick of the remote inwards to 5 o’clock position and
hold for 3-5 seconds, the aircraft’s lights will flash quickly during the process , once the lights
change back to the previous lights ,gyroscope calibration is completed.
8) GPS Switch(DEFAULTS GPS MODE )
GPS mode=Outdoor mode ; NO GPS mode=Indoor mode
1. Press the GPS mode button and hold for 3 seconds until you hear one sound "DI" beep , switch
to NO GPS MODE successfully;
2. Press the switch mode button and hold for 3 seconds, and hear two sounds of "DI DI"beeps,
switch to GPS MODE successfully;
Gyroscope calibration

GPS switch
Start engine
Attention :Switch the GPS SWITCH after pairing the remote or after searching satellites.
1) It can be switched between GPS / NO GPS mode on the remote controller, but can’t be switched
on the APP.
2) When the satellite searching is successful, the app will display "device connected (GPS mode)";
when the satellite searching is unsuccessful, the app will display "device connected (Indoor
mode)".
3) When taking off the drone indoors, please manually switch to NO GPS mode to take off.
4) After taking off, the GPS SWITCH button is disabled.
9) Search satellites
The aircraft must be placed on the a flat level surface after the calibrations were completed,if its’ rear
lights change to solid on and the remote control sounds “DI” , it means that the satellite searching
is successful and the aircraft can be taken off.
Attention:
1. Please make sure that the drone is operated in wide-open space.
2. If the GPS receives a signal from 7 or more satellites show in the app, the rear LED of the
drone will stay on.
10) Start engine
Step 1 :At the same time, pull Left and Right Joystick of the remote inwards to 7 and 5 o’clock
position and hold for 3-5 seconds, and 4 rotors will begin spinning.
Attention :
1. If you want to stop the engines while the rotors are spinning, please repeat unlock ,the engines
will stop immediately .
2. When satellite searching is unsuccessful, the motor can be unlocked but cannot be taken off;
after the satellite searching successfully, the motor can be unlocked and the drone can be also
taken off.
Step 2 : When the left joystick is pushed upward, the aircraft rises. (Default left-hand throttle)
Step 3 : When the left joystick is pushed downward, the aircraft descends. (Default left-hand throttle)
11) One key return
During the flight process , short press the "one key return "button , the aircraft will return to the take
off point . Short press this button one more time, cancel returning.
Attention: Be sure the drone searches satellites successfully before take-off , as once meet emergency
accident, you may turn off the remote’s switch and WIFI signal at the same time, the drone will auto
return immediately
One key return

Step 9: Unlock with APP's joystick
Step 3: Open the APP "VS GPS PRO "
Step 1: Power aircraft
Step 2: WIFI connection
Quick Start Guide
(FOR MOBILE CONTROL)
Step 5: Compass calibration
Step 6: Gyroscope calibration(Horizontal calibration)
1. After calibrating compass, please click ;2.Please select the icon ;
3.To do a Horizontal calibration, and the 4 LED of aircraft will flash quickly until the app prompts that
“ level calibration finished”.
Step 7: Search satellites(Refer to 8) on the page 3)
Step 8: One key take-off(Disable this function in Indoor mode)
1.After the satellite searching successfully, click ; 2.Find out to unlock the drone;
3.Click and APP will prompt to slide to confirm automatic take-off; 4.Slide button to fly the aircraft.
Attention: The cancel function is disabled; If you do not slide the button, the rotors will stop after 10 seconds.
Tap "one key return" to auto landing for safety. As "one key to land" function was canceled.
http://www.le-idearc.com/category/downloads/18
Do not recommend beginners to control the aircraft with the APP
Instruction
Video

Open the app, click "Enter Device" on the homepage,
then you will see the prompt "Please conduct
geomagnetic calibration for the aircraft".
Select"Confirm" , follow the prompts to calibrate the
compass until the app prompts the calibration is
completed.




Step 4: Pair APP with the aircraft
After opening the APP, the APP will automatically link to the aircraft within 10-30 seconds. For detailed
lighting changes, please refer to 4) on the page 1.
Note: Even APP shows enough satellites, you must calibrate the compass.
Rocker button can be found in .
At the same time ,touch and pull screen's left and
right joystick outward to 7 and 5 o'clock to unlock
the aircraft, repeat it to stop unlock.
