leadsun AE2 User manual

Made in China AE2.166-B
All-In-One Solar Street Light
User Manual
AE2
LEADSUN INC.
Address: 1920 S. Archibald Ave. Suite I, Ontario, CA 91761
Phone: [phone] Fax: [phone]
Email: [email protected]
LEADSUN Australia PTY LTD
Address: 42 Greens Road, Dandenong South, Victoria 3175
Phone: [phone] Fax: [phone]
Email: [email protected]
LEADSUN Global Limited
Address: NO.1 Pingdong 1st Rd, Nanping Science & Technology
Industrial Park, Zhuhai, China 519060.
Phone: + Fax: + 86-756-2289712 86-756-8682090
Email: [e-mail]
www.leadsunglobal.com

2
1
Thank you for choosing LEADSUN's solar street light.
If you have any question, please consult our customer services [email protected].
LEADSUN reserves the right to update product appearance, function and construction without notice.
For any discrepancies in illustration or description, please refer to individual/real objects.
LEADSUN assures the accuracy and reliability of this manual, but is not responsible for any loss or
damage related to any operation of the products.
· Do not drop or apply excessive force to the unit.
· Recharge batteries every six months to maintain optimal battery life.
· Do not install directly under trees, buildings or other obstacles that may damage
the unit.
· Do not use detergent containing ammonia, benzene or abrasives to clean solar
panel.
· Modifying or refitting this light in a manner not authorized by LEADSUN may
cause the unit to stop working and may void the warranty.
Please have a licensed electrician install this unit to avoid risk of shock damage to
luminaries. Pay close attention to the cable polarity (L: RED; N: BLUE; PE:
YELLOW/GREEN). Tie up with waterproof rubberized fabric after completing
wiring.
A licensed electrician is required to install the unit with AC power supply.
Warning and Caution
Disposal
This product is made of recyclable high-performance materials and components
in accordance with ROHS. Do not dispose with normal household waste. To
preserve our environment, please bring used unit to an official collection point for
recycling.
Please refer to your local laws and regulations regarding the collection of
electrical products. Proper disposal can help prevent negative impacts to
our environment.
Operating Temperature
· The discharge temperature ranges from -4℉ to 140℉(-20℃~60℃). ·
· Recharge at a temperature between 32℉ to 140℉ (0℃~60℃).
· The controller will automatically stop charging in order to protect the battery if the
temperature drops below 32℉ (0℃) or rises above 140℉ (60℃).
· Do not install this unit in an area where the temperature exceeds these limits.
· For lighting solutions for cold environments, please contact your local LEADSUN
distributor/dealer.
Important Safety Information
WARNING:
Warnings must be followed
carefully to avoid serious
bodily injury.
CAUTIONS:
Cautions must be observed
to avoid minor injury to
yourself or damage to your
equipment.
This section presents important information intended to ensure safe and effective use of this product.
Read this section carefully and store it in an accessible location.
Key to Symbols
The symbols in this manual are identified by their level of importance, as defined below. Read the
following carefully before handling the product.
EN

Dim mode
(30% brightness)
Bright mode
(100% brightness)
34
1.1 Features
1. Introduction
4. At factory setting, AE2 units turn on at dusk and off at dawn automatically (light photosensitivity is
around 30lx). In the evening, AE2 units operate at dim mode when no one is not around, and
increase light output immediately when motion is detected.
To avoid incorrect operation that may damage the unit, please read the following instructions
carefully before installing your AE2 solar lights.
1. AE2 units will not work without sunlight. Please choose the appropriate model according to
radiance or peak sun hours for the desired installation location. For areas with low sunlight or
prone to consecutive overcast days, AE2 units may not operate at their optimal levels or may not
turn on at all.
2. AE2 units should be installed with the solar panel facing the Equator for optimal performance and
durability.
5. All internal parts of AE2 are waterproof and rated IP65. Holes and slits on the luminaires are
designed for heat dissipation and drainage. Metal parts are made of anodized rustproof aluminum,
which withstands high temperatures and humid weather. However, it is recommended that you
avoid areas with heavy acid mist or salt influx. The strong structural design can withstand the wind
speed up to 180km/hr.
1.2 Safety and Usage precautions
EarthEquator
3. Make sure to clear trees, buildings and other shadows, or the internal battery will not charge
properly, causing low efficiency and short working time.
AE2 Series is the world’s first ‘All-In-One’ solar powered LED light. Fully integrated all of its
components and motion sensor within an attractive and compact design, AE2 not only saves more
energy but also improved light effeciency. By critically choosing advanced Li-ion battery and
corrosion resistant material, we created at least three times longer lifespan and extremely simple
way for installation solar street light compare with traditional one that equiped with lead acid
battery. AE2 redefined solar street light in both intension and extension.
EN

1 3 Part Description.
10
6
2
3
1
56
11 12
14
13
14
No.
Name
Brief Function
1
Solar Panel
To absorb solar energy and convert into electricity
2
PIR Sensor
Motion detection
3
LED Module
Illumination
4
铝合金边框
保护太阳能板
5
Heat-sink Hole
Heat dissipation
6
Controller
Charging and discharging control
7
Type B USB Connector Female
For program input
8
Switch button
ON/OFF or Turn ON/OFF the light
9
Type A USB Connector Female
For battery charging via 14VDC 1.5A power supply
10
Anti-thief Bracket
Mount solar engine and lamp head on a pole
11
Reset button
Restart the gateway
12
SIM card slot
Insert 2G/4G card
13
2G/4G Antenna
Wireless network communication
14
LORA Antenna
Network group communication
7
8
9
Standard
Gateway type
LORA terminal
EN
4
5

1.4 Parts List
Before you begin installation, please make sure all parts are received. Below are the
parts for each model:
Bracket
M8 Screws
M8 Nuts
Spring Washers Spanner
Solar Engine
AST30XX:
AST45XX:
Antenna (optional)
Solar Engine Anti-thief Bracket
M8 Screws
M8 Nuts
Spring Washers Spanner Antenna (optional)
2. Activation
Definition of the native mode
OFF mode: The system will not work, charge or
discharge.
Transport (idle) mode: the system will power off in
an hour and goes to the OFF mode.
ON mode: the system will work normally, charging
in the daytime and discharging at night.
*
*
*
Start up
*
*
OFF
mode
ON
mode
Button Switch
Long press till the
light is on or lighting
condition is sufficient
in daytime.
Long press 5 seconds
or if no operation
for more than an hour
Long press
5 seconds
Short press, the
light will switch
between on and off
Transport
mode
Short press, the
light will flash then
off
Button instructions
Short press the button, if the lighting status does not change, it is in the OFF mode.
Short press the button, if the light flash and then off, it is in transport (idle) mode;
Short press the button, if the light switch between ON and OFF directly, it is in ON mode, In this mode, it
can switch the light ON by short press the button.
Short press the button (1s) to find out the current product mode:
*
*
*
Long press the button for (5s) to switch the working modes:
*
*
*
In the OFF mode, when connected to the solar panel, if the lighting condition is normal, it will start up
automatically; or long press the button 5s, if the light is ON and then OFF, the product will go into the ON
mode.
In the ON mode, long press the button 5s, the light flash 3 times then off, the product will go into the
transport (idle) mode; if disconnected from the solar panel, the product will go into the OFF mode
directly;
In the transport (Idle) mode, long press the button 5s, if the light flash one time and then off, the product
will go into the OFF mode; or without any operation after an hour, the product will go into OFF mode
automatically.
1
2
3
Daytime start-up: when the lighting condition is
sufficient (>30lx), the product connects to the
solar panel if it lights 20 seconds then off, it
means the product has started up and goes
to the ON mode. If the lighting condition is
not good, it needs Night start-up method.
Night start-up: long press the button (5s), the light
is on and release the button, the light is off, it will go
to the OFF mode.
After the light went off, if it meets the normal lighting
condition (<30lx) the light will on, if it does not, then
the product will go into the OFF mode.
EN
78

Determine the pole’s position according to the max radiation and road condition. Confirm
installation height and distance by referring to AE2 specifications. LEADSUN recommends using a
steel pole with a diameter of 60-90mm and a thickness of more than 2mm.
Joint the bracket to the solar engine with 2pcs of M8×55 bolts by attached tools. (This step is only
needed for the models of AST45XX).
Joint the rear cover and bracket with 4pcs of M8×90 bolts, leaving space to easily mount the unit
onto the pole (Figure 2).
Mount the unit on the pole by fastening the M8 bolts. The torque wrench is 14N.m (Figure 3).
Figure 2
Figure 3
3. Installation
1. Please confirm if the 2G/4G module in the gateway is support the data network covered by the
local carrier before installation.
2. When using the inbuilt 2G/4G module gateway, you need to insert a SIM card which has the
data service. The data service will cause the service fee, and you need to pay the relevant
service fee to the local carrier.
Cautions:
4. Wireless system installation (Suitable for wireless type)
Connect the antenna to the corresponding position according to the picture below, (Please pay
attention to the difference of 2G/4G antenna and LORA antenna.)
Antenna installation
1
LORA Terminal antenna installation
LORA Antenna
Gateway antenna intallation
2G/4G Antenna LORA Antenna
EN
9 10
1
2
3
4

Insert SIM Card
Insert the 2G/4G SIM card into the slot according to the picture. Press the button next to it to
restart the gateway and cover the waterproof plug.
2
The SIM card cutting edge is face down and the magnetic
stripe is away to the indicator light.
Cautions:
Application scenarios
Road installation
Linear installation is adopted on the road. It is possible to consider installing multiply
street light with gateway, if it is far away; Packet access can make the installation
distance extend infinitely.
Decentralized installation in Village/Factory/Park
In the situation of decentralized installation, the solar street light with gateway is
recommended to install in the center of all the street lights.
3
Gateway street light
120 street lights 120 street lights
Each wireless street light communication distance range from 800 to 3000m. One gateway street
light can remote control 120 street lights.
Gateway street light
Gateway street light
Software operation instruction
4
With LEADSUN EDGE, you can do the following operation:
1. Register to become a member
2. lighting control
3. History data query
4. Working mode configuration
5. Real-time view.
For detail instructions, please see the "APP User Guide" under "More Functions" in the
software.
Please use LEDSUN EDGE to control the light, visit www.leadsunglobal.com and follow
the steps to Download the LEADSUN EDGE.
A. Apple cellphone please go to the App Store searching 'LEADSUN EDGE' then click
install.
B. Android cellphone please visit www.leadsunglobal.com or go to the software
platforms like Google Play to download and install 'LEADSUN EDGE'.
C. PC App please visit http://47.52.88.104:8083/Home/Login
EN
11 12

6. Troubleshooting
No.
Symptoms
Troubleshooting steps
Process
1
No light at night
Check that the lamp can be manually
activated.
Refer to “Activation and Installation” section
on this user guide and run activation tests.
Check if the solar panel is blocked
from the sunlight by houses, trees and
other obstacles.
Clear obstructions or change installation
location.
Check if there is any artificial light
source(s) shining on the solar panel
during the night.
Remove the artificial light source(s) of
interference or change the installation
location.
Examine status of each component
based on the repair guide.
Replace the damaged component(s).
2
A serious shortage
of working time
Check if the solar panel is blocked
from the sunlight by houses, trees and
other obstacles.
Clear obstructions or change installation
location.
Check if the surface of the solar panel
is dusty or covered.
Clean the surface of solar panels as
detailed above.
Examine if the battery pack is
damaged as per the repair guide
instructions.
Replace damaged battery.
3
Lighting does not
follow the normal
operating mode of
turning on and off
Reprogram.
4
Lights fail to turn
on properly when
humans approach
Check if the air temperature close to
human body temperature.
When the air temperature is close to human
temperature, motion detection may slow
down. It will return to normal after the air
temperature changes.
Check if the installation height is too
high.
It is out of motion detection range when
installation height exceeds 8m. It is
recommended to reduce the height or use
other operating modes.
Replace damaged motion sensor or
controllers.
5. Maintenance and Products Care
Transportation and Storage
· This product contains lithium batteries. Please follow air transport regulations when shipping. It
should be regarded as potentially flammable and explosive, and be isolated from other goods
when stored, so as to avoid any damage.
· The solar panels of this product should be considered as fragile. There should never be more
than 4 layers of boxes when stacked. To avoid damage to the panels, make sure no heavy
pressure is applied to the boxes.
· Please store the product in temperature between 0℃ to 45℃.
· If stored for a long period, the product should be recharged every 6 months. Please only use the
special charger (purchased from manufacturer) to avoid damage to the battery or device.
· When repackaging the product after inspection or charging, set the light into sleep mode by
holding the On/Off button for 5 sec. The light will flash three times to signal that it has properly
entered sleep mode. You may now repackage the product into its box. To exit sleep mode, either
press the On/Off button one more time, or wait an hour for the light to reboot automatically
through contact with sunlight.
Clean
To clean, apply mild detergent with a damp cloth and gently wipe the surface of the solar panel.
Replacement of Parts / Spare Parts:
Please contact LEADSUN or your local distributor/dealer.
EN
13 14
