leadsun FREEDOM PLUS Technical manual

Made in China RUP.064-A
FREEDOM PLUS
Operation Instruction
Solar Street Light
www.leadsunglobal.com
FREEDOM PLUS
Operation Instruction
Solar Street Light
LEADSUN Australia PTY LTD
Address: 42 Greens Road, Dandenong South, Victoria 3175
Phone: [phone] Fax: [phone]
Email: [email protected]
LEADSUN Global Limited
Address: NO.1 Pingdong 1st Rd, Nanping Science & Technology
Industrial Park, Zhuhai, China 519060.
Phone: + Fax: + 86-756-2289712 86-756-8682090
Email: [e-mail]
LEADSUN INC.
th
Address: 10134 6 Street, Ste. M, Rancho Cucamonga, CA 91730
Phone: [phone] Fax: [phone]
Email: [email protected]

Accessories
2
1
Product Components
Solar Panel Parts List
Lighting part list
Parts
50W
80W
110W
130W/180W
Quantity
Solar panel
1
1
1
1
U-type bracket
1
1
1
1
Bushings
1
1
1
1
2M waterproof wire
1
1
1
1
M8×40
4
M8×25
4
4
4
10
M8×16
14
14
14
8
M8 Plain Washer
10
10
10
14
M8 Spring Washer
10
10
10
14
M8 Screw Nut
6
6
6
Bird Spike A
1
1
2
1
Bird Spike B
1
Bird Spike C
1
Self-tapping Screws
4
6
8
6
C-type Frame
2
C-Type Screw Nut
10
Blank holder
4
Part List
Parts
UP15/UP20
UP30/UP40
UP50/UP60
Quantity
M8×16
6
6
6
Solar panel U-type bracket Bushings C-type Frame
Bird Spike A
Bird Spike B
Bird Spike C
Solar Panel Components
Self-tapping
Screws
M8×16 M8×25 M8×40
Bird Spike Component
M8
Screw Nut
M8
Spring Washer
M8
Plain Washer
2M
waterproof wire
C-Type Screw Nut Blank holder
UP15/UP20 UP30/UP40
Lighting
UP50/UP60
Check if all the components are complete before installation, the components and quantity of
each set as follows:

34
Product maintenance
Product recycling
In order to assure that the solar panel receive the light efficiently, please use clear water
to clean the dirty mark on the surface of the panel regularly and prohibit the use of
chemical or abradant which includes chlorobenzene.
Only manufacturer, service agent or qualified personnel can replace the light source or
other circuit components of the lighting device. Without authorization, using the third
party component to replace is prohibited or it would cause serious damage to the
product. if the user disassembles the product without authorization, warranty becomes
void.
If you need to replace the components /accessories, please go to
www.leadsun.globalcom, or contact the local distributor.
The product is made of recyclable high-performance materials and components, please
don't dispose with other household garbage.
Please understand the local rules about the separate collection of electronics and
electrical products, dispose the waste products in the right way that avoids potential
negative effects of environment and human health.
Cautions
Transportation and storage
Working condition
Attention to the electric shock
To avoid electric shock, street light with AC adapter must be installed by the construction
qualified specialist.
The street light with AC adapter is customized product, please confirm the street light AC
adapter is in accord with the local electric supply standard.
Make sure the electric supply power is cut off during the installation and implement
waterproof and insulation protection.
Please read the below cautions carefully before using the PLUS series solar
street light to avoid physical injury and product failure caused by improper use.
Product protection grade IP65.
High tensile structure design can withstand level 3 typhoon (58m/s), beyond this level
might cause damage to the street light.
Working temperature range from -20℃ to 60℃ (charging temperature is limited within
0℃ to 60℃). The product with heating function can work under -40℃ to 60℃.
The product includes high capacity lithium-ion battery components, please follow the
aviation transport law. Please regard the product as the flammable and explosive
hazardous substance and store it separately from other goods.
The solar panel of the product is fragile, tier limitation is two layers. No stacking out of
limits and No press with heavy stuff.
Store the product under the temperature from 0℃to45℃
It should be charged every six months if the product is stored for long time. please use
the special charger to charge the product (the charger needs additional purchase) in
order to avoid battery or device damage.

6
5
Operation instruction
FREEDOM PLUS series intelligent lithium battery solar led street light integrates LED street light, long
lifespan LiFePO4 lithium battery pack, high-efficiency smart controller, and Aluminum structure shell.
The product not only can apply to the traditional split type solar street light maintenance or replacement
but also a brand new cost-efficient solution for newly installed lithium battery solar street light.
FREEDOM PLUS intelligent lithium battery solar LED street light, with the advantages of longer lifespan,
simple installation, and less maintenance provides a perfect solution to the user.
Overview
1.Definition of the native mode
OFF mode: The system will not work, charge or
discharge.
Transport (idle) mode: the system will power off in
an hour and goes to the OFF mode.
ON mode: the system will work normally, charging in
the daytime and discharging at night.
*
*
*
2. Start up
Daytime start-up: when the lighting condition is
sufficient (>30lx),theproductconnectstothe
solarpanelifitlights20secondsthenoff,it
meanstheproducthasstartedupandgoesto
theONmode.Ifthelightingconditionisnot
good,itneedsNightstart-upmethod.
Night start-up: long press the button (5s), the light
is on and release the button, the light is off, it will go
to the OFF mode.
After the light went off, if it meets the normal lighting
condition (<30lx)thelightwillon,ifitdoesnot,
thentheproductwillgointotheOFFmode.
*
*
OFF
mode
ON
mode
Button Switch
Functional Specification
No.
Component
Brief description
1
Solar panel
Absorb Solar power and transform it into electric power,
control the light by light-operated switch
2
Bird spike
Avoiding birds dropping to cover the solar panel
3
Solar panel bracket
Use to fasten the solar power supply system
4
PIR Motion sensor
Adjust the brightness automatically by the motion sensor
5
LED
Lighting
6
LED street light switch
Switch on or off the LED street light at night
7
USA Type-A charging port
Charging for the battery ( Please use 14V, 1.5A dedicated
charger)
8
USB Type B port
Programming special port
9
Street light bracket
Use to fasten the LED street light
1
2
4
5
6
7
8
9
3
Long press till the
light is on or lighting
condition is sufficient
in daytime.
Long press 5 seconds
or if no operation
for more than an hour
Long press
5 seconds
Short press, the
light will switch
between on and off
Transport
mode
Short press, the
light will flash then
off
3. Button instructions
Short press the button, if the lighting status does not change, it is in the OFF mode.
Short press the button, if the light flash and then off, it is in transport (idle) mode;
Short press the button, if the light switch between ON and OFF directly, it is in ON mode, In
this mode, it can switch the light ON by short press the button.
Short press the button (1s) to find out the current product mode:
*
*
*

8
7
Please choose the appropriate model depending on the sunlight intensity of the place and
required working time.
If the installation site is on the northern hemisphere, the solar panel should face to the south as far
as possible and if it is on the southern hemisphere, the panel should face to the north as much as
possible. (see picture 1)
1. Installation conditions
Make sure the sunlight is not blocked by any constructions or trees during the installation or it will
affect the charging and discharging efficiency of the solar power system and the operation of the
street light. (see picture 2)
Picture 1
Product installation
1
2
4. The solar panel module of UP series solar
street light is optional, you can use either
your own existing solar panel or our standard
optional solar panel module and bracket.
5. The output voltage of the solar panel is 18V
DC, 50Wp~180Wp, the operation efficiency
will be affected if the voltage is beyond this
range.
7. It is suggested to choose cantilever light pole
for the UP series solar street light installation,
the diameter of the light pole top which uses
to install the solar panel bracket should no
more than 80mm.
Long press the button for (5s) to switch the working modes:
In the OFF mode, when connected to the solar panel, if the lighting condition is normal, it will
start up automatically; or long press the button 5s, if the light is ON and then OFF, the
product will go into the ON mode.
In the ON mode, long press the button 5s, the light flash 3 times then off, the product will go
into the transport (idle) mode; if disconnected from the solar panel, the product will go into
the OFF mode directly;
In the transport (Idle) mode, long press the button 5s, if the light flash one time and then off,
the product will go into the OFF mode; or without any operation after an hour, the product
will go into OFF mode automatically.
*
*
*
Operation instruction
Cantilever Top of the Light pole
80mm
60mm
8. The product default setting is using light-operated switch to control the light through the solar
panel (light-operated control threshold is 30lx). It means light up automatically when dark and light
off when dawn. The street light will go into the dim mode when no one around at night and it will
full brightness when someone around.
6. If you choose your own solar panel, just
connect the solar panel output cable to the
UP series solar street light input terminal.
Dim mode
(30% Brightness)
Full Brightness
(100% brightness)
Equator
Picture 2

Product Installation
10
9
25°
55°
40°
15°
If you choose LEADSUN solar panel module and bracket, please follow the below
installations. If you use your own solar panel module, it can be used for reference.
Fasten the U-type bracket to the solar panel
frame, see figure 1, the accessories are
M8*16 screw, M8 screw nut, M8 plain
washer, M8 spring washer.
2. Solar Panel Bracket Module Installation
50~110W Bracket Module Installation
1
2
Embed 5pcs C-type screw nuts into the cross-bar. As shown in figure 3.
130~180W bracket module installation
2Using 4pcs blank-holders, M8*40 screw, M8 spring washer, M8 plain washer, C-type screw
nut to fasten the solar panel frame by the two cross-bars, adjusting the two cross-bars
center distance to 640mm and mediate the solar panel. as shown in figure 4.
1
M8 screw nut
M8 spring washer
M8 plain washer
Blank holde
M8 spring washer
M8 plain washer
M8*45 screw
M8*16 screw
M8 spring washer
M8 plain washer
M8*25 screw
Figure 1
640mm
Choose an appropriate angle to fasten the bushings, the accessories are M8*25 screw,
M8 spring washer, M8 plain washer. See figure 2.
Figure 2
Figure 3
Figure 4

4. light pole cantilever wire threading
Thread the waterproof wire into the cantilever of the light pole and lead out from the top of the
light pole. (see figure 8)
Attention to the direction of the waterproof wire.
Using the self-tapping screw in the accessory to fasten the
bird spike on the top frame of the solar power system. (see
figure 7)
3. Install the bird spike
2m waterproof wire is the standard accessory of the
solar panel module, You will not have this, if you have
chosen your existing solar panel for the street light.
PS:
2m
12
11
3As shown in figure 5, use the accessories M8*25 screw,
M8 spring washer, M8 plain washer, C-type screw nut to
fasten the U-type bracket on the cross-bar.
4
25°
55°
40°
15°
C-type screw nut
M8 spring washer
M8 plain washer
M8*25 Screw
M8 spring washer
M8 plain washer
M8*25 Screw
Self-tapping
screw
Product Installation
Figure 5
Choose a proper angle to fasten the bushings, the accessories are M8*25 screw, M8 spring
washer, M8 plain washer. as shown in figure 6.
Figure 6
Figure 7
Figure 8

Troubleshooting
No.
Negative
Phenomenon
Inspection Process
Approach
1
No lighting at the
night
Check if the light is in ON mode or not.
Test according to the “Button Instructions'
from the chapter “Operation instruction" in
this manual.
Check if the solar panel is blocked by
any buildings or trees during daytime,
which will influence the sunlight.
Clear away the blockade or change the street
light installation site.
Check if the solar panel is illuminated by
any other artificial light source at night.
Move the artificial light source away or
change the light installation site.
2
Lighting time is
seriously
inadequate
Check if the solar panel is blocked by
any building or trees during the daytime,
which might influence the sunlight.
Clear away any blockades or change the
street light installation site.
Check if the solar panel has dirt or any
blocks covering on the surface which
might influence the sunlight.
Clean the solar panel surface.
3
Abnormal motion
detection
Check if the lighting environment
temperature is same as that of human
bodytemperature.
If the external temperature is same as of the
human body temperature, the sensitivity of
PIR motion sensor will reduce. It will return
back to normal when the external
temperature decreases.
Check if the lighting is installed too high.
When the lighting installation is higher than 8
meters, the sensitivity of the motion detection
function will drop and it is suggested to lower
the height or use other working mode.
Change the broken PIR motion sensor or
controller.
13
Connect the waterproof wire from the cantilever part with wire of the LED street light part and
lock the connectors in turns; Embed the LED street light bracket into the cantilever and fasten it
by the M8*16 screw, make sure the LED street light has installed stably on the light pole then the
installation is finished.
Connect the solar power system with the waterproof wire in the light pole and lock the
connectors in turns; embed the light pole into the X bracket and use the special tool to fasten the
M8*16mm screw. (if using the electric wrench, torsion should set to 14N.m) (see figure 9).
5. Solar Power System Installation
6. LED Street Light Installation
14
Product Installation
Figure 9
