Lean Kiosk Systems LKS8500 Series User manual

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
1/8
Specification for Tigapo Cards vending machine self-service terminal

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
2/8
This product is a multifunctional self-service terminal for self-service payment and self-service card. This paper
expounds the specifications and instructions of this equipment in detail.
Version
number
Revision time
Version content
Author
Confirmator
December 11, 2021
Initial revision
Huang Wuhui
1. Product
Overview………………………………………………………………………………………………………3
1.1 Product introduction………………………………………………………………………….............…...…3
1.2 Features………………………………………………………………………………………….............……3
2. Technical parameter………………………………………………………………………………………….....4
2.1. System Design……………………………………………………………………………....………..4
2.2. Product configuration module parameters……………. ……………………….................………..4
2.3. Electrical properties…………………………………………………...................................……..5
2.4. Working environment……………………………... ……………………...................................5
2.5. Usage scenarios................................................ ………………...............................…………..5
2.6. Product description………………………………………………….........................…………..6
2.7. Dimensions of the machine……………………………… .… .… ........…….7
1. Product overview
1.1 Product Profile
This product is a self-service payment and settlement multifunctional card issuing self-service terminal, which is a new
type of human-computer interaction equipment with convenient use. The terminal equipment integrates the advantages
of touch control, industrial computer, multimedia advertisement design, network, industrial design, structural
innovation, etc. It can quickly complete information inquiry and video playing, and truly achieve simple human-
computer interaction.

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
3/8
1.2 Functional characteristics
A: The front user interface of 32-inch HD display screen, capacitive touch screen supports 10-point touch technology, 5
milliseconds fast response, accuracy and stability.
B: Support Android multimedia advertisement display on the same screen.
C: Multi-system compatibility of products: Android operating system of industrial computer, touch display screen, code
scanning payment, network information inquiry, receipt printing, face brushing payment, credit card and bank card
payment, etc.
D: Brand-new sheet metal structure design, corrosion-resistant and oxidation-resistant painting process, with good
dustproof effect.
E: Each machine has been tested by aging, static electricity, vibration, touch and click, etc., to ensure more stable
quality.
2. Technical parameters
3. 2.1 System Design
Touch display advertisement screen
Man-machine interaction displays the operation interface.
Industrial control integrated
machine
Main control computer, information input and output, information
exchange main control computer.
Camera
There are two cameras, one for taking pictures of operators and the other
for taking pictures of team operation platform.
All-in-one self-service credit card
payment module
Support users to pay by credit card and UnionPay card.
NFC card reader
Support non-credit card and membership card payment.

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
4/8
Power supply module
AC110-240V DC 12V DC 24V Switching Power Supply Module.
Banknote receiving module
Support users to pay in cash.
Card issuing machine
Users handle consumption cards and membership cards by themselves.
Structural design
Humanized anti-corrosion sheet metal painting design of appearance
structure.
2.2 Parameters of product electrical module
32-inch LCD panel module
Resolution: 1920*1080, 16: 9, operating temperature 0 ℃ ~ 60 ℃, wide
viewing angle, low power consumption: 20W backlight MTBF: 100,000
hours.
32-inch custom capacitive screen
32 inches, surface hardness 6h, 500G steel ball 2m unbreakable, haze
below 5%, transmittance above 90%.
Industrial control host
RK3399 quad-core, maximum frequency 1.8 GHz.
Flash memory: PDDR4 4GB.
Storage: 16GB EMMC NAND chip.
LVDS and HDMI dual-screen display.
Android 7.1 system.
Camera
C930C/camera can be fine-tuned up, down, left and right 20 degrees
All-in-one self-service credit card
payment module
UnionPay payment card reader.
NFC card reader
RFID reader.
Power supply module
Ming Wei Switching Power Supply Module AC 100-240V DC12V
DC24V
Banknote receiving module
Banknote recognizer, MEI SCNL 8328R (support US $, denominations
1.5. 10.20, 50, 100, 200,)
Card issuing machine
Creating spontaneous card device CRT-571
Wireless communication
Wireless WIFI Bluetooth 4G communication (domain LTE module).
Mingwei switching power supply
AC220V, DC12V 24V. 3C certification.
2.3 Electrical Performance
Input voltage
AC 100-240V 50/60 Hz 5A
2.4 Working Environment
Operating temperature
-30 ℃-50 ℃

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
5/8
Working humidity
0%-90%
Storage temperature
-10 ℃-60 ℃
Storage humidity
0%-65%
2.5 Usage Scenarios
A. Playground
B. Large shopping malls
C. Supermarkets
2.6 Product Description
32Inch touch
display screen
Card issuing
ddddidispenserma
Camera1
Camera2
Banknote receiver
Card issuing
machine2
All-in-one self-
service credit card
payment module
NFCCard reader

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
6/8
Rear door lock
Fan cooling
window
Wireless signal
window
ACPower socket
Network port
Cabinet base

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
7/8
2.7 Dimension drawing of the whole machine
2.8 Dimension Line Drawing of the Whole Machine

ShenZhen Lean Kiosk Systems Co.,Ltd
Version/Edition
DOC
NO.
LKS-SC-QWI-012
Model
LKS8500
Series
Version/
Edition
A/3
Date
2021-12-11
Tigapo Cards vending machine
page
8/8

FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
RF Exposure Information
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
