LeapFrog LF2415 User manual

LF2415
LF2415-2
5“ Video Baby Monitor with
Night Light
User Guide
This guide contains important information.
Please keep it for future reference.

2
Contents
Important Safety Instructions�������������������������������������������������������������������������������3
Setup�����������������������������������������������������������������������������������������������������������������������4
What’s Included? .....................................................................................................................4
Overview..................................................................................................................................5
Parent Unit Icons..........................................................................................................9
Connect the Baby Monitor .....................................................................................................12
Charge the Parent Unit Battery..............................................................................................13
Power On or O󰀨 the Baby Monitor.........................................................................................14
Position the Baby Monitor......................................................................................................15
Basic Operation���������������������������������������������������������������������������������������������������16
Talk to Your Baby via the Baby Unit.......................................................................................16
Use the Menu ........................................................................................................................17
Adjust Speaker Volume .........................................................................................................18
Zoom......................................................................................................................................19
Turn on/o󰀨 the Parent Unit Screen ........................................................................................20
Adjust Screen Brightness ......................................................................................................20
Advanced Operation �������������������������������������������������������������������������������������������21
Lullabies and Soothing Sounds .............................................................................................21
Adjust Baby Unit Speaker Volume.........................................................................................21
Night Light..............................................................................................................................22
Set Screen o󰀨 Timer ..............................................................................................................23
Adjust Sound Sensitivity Level...............................................................................................24
Turn on/o󰀨 Alert Tones...........................................................................................................25
Night Vision............................................................................................................................28
Dim Mode ..............................................................................................................................28
Monitoring Modes (LF2415-2 only)........................................................................................29
Additional Information ����������������������������������������������������������������������������������������27
Wall Mount (Optional) ............................................................................................................31
General Product Care............................................................................................................33
Storage ..................................................................................................................................33
Adult Supervision...................................................................................................................33
Technical Specications.........................................................................................................33
Disposal of Batteries and Product .........................................................................................34
Customer Service and Product Warranty ..............................................................................34

3
The applied name plate is located at the bottom of
the Baby Unit’s base. When using your equipment, basic
safety precautions should always be followed to reduce the
risk of re, electric shock and injury, including the following:
1. Follow all warnings and instructions marked on the
product.
2. Adult setup is required.
3� CAUTION: Do not install the Baby Unit at a height
above 2 metres.
4. This product is intended as an aid. It is not a substitute
for responsible and proper adult supervision and
should not be used as such.
5. This product is not intended for use as a medical
monitor.
6. Do not use this product near water, for example, near
to a bath, sink, swimming pool or shower.
7� CAUTION: Use only the battery provided. There may be
a risk of explosion if a wrong type of battery is used for
the Parent Unit. The battery cannot be subjected to high
or low extreme temperature and low air pressure at high
altitude during use, storage or transportation. Disposal
of battery in re or a hot oven, mechanically crushing or
cutting or the battery can result in an explosion. Leaving
the battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of
ammable liquid of gas. Battery subjected to extremely
low air pressure may result in an explosion or the leakage
of ammable liquid or gas. Dispose of used batteries
according to the instructions.
8. Use only the adaptors included with this product.
Incorrect adaptor polarity or voltage can seriously
damage the product. Use only the adaptors and
battery listed below.
Power adaptors information:
Baby Unit Output: 5V DC 600mA;
VTech Telecommunications Ltd�;
Model: VT05EAU05060
Parent Unit Output: 5V DC 1A;
VTech Telecommunications Ltd�;
Model: VT05EAU05100
Rechargeable battery information:
Zhuhai Great Power Energy Co�, Ltd�
Li-ion battery, 3�6V, 2600mAh, 9�36Wh;
Model: ICR18650-2�6Ah-3�6V-1S1P
9. The power adaptors are intended to be correctly oriented
in a vertical or oor mount position. The prongs are not
designed to hold the plug in place if it is plugged into a
ceiling, under-the-table or cabinet outlet.
10. For pluggable equipment, the socket-outlet should
be installed near the equipment and should be easily
accessible.
11. Unplug this product from the wall outlet before
cleaning.
12.Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning. Do not modify the power adaptors or
replace with other adaptors.
13.Do not allow anything to rest on the power cords. Do not
install this product where the cords may be walked on
or crimped.
14.This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or electricity supply provider.
15.Do not overload wall outlets or use an extension cord.
16.Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
17.This product should not be placed in any area where proper
ventilation is not provided. Slots and openings in the back or
bottom of this product are provided for ventilation. To protect
them from overheating, these openings must not be blocked
by placing the product on a soft surface such as a bed, sofa
or rug. This product should never be placed near or over a
radiator or heat source.
18.Never push objects of any kind into this product through
the slots because they may touch dangerous voltage points
or create a short circuit. Never spill liquid of any kind on the
product.
19.To reduce the risk of electric shock, do not disassemble
this product, but take it to an authorised service facility.
Disassembling or removing parts of the product other than via
the battery door may expose you to dangerous voltages or
other risks. Incorrect reassembling can cause electric shock
when the product is subsequently used.
20.You should test the sound reception every time you turn on the
units or move one of the components.
21.Periodically examine all components for damage.
22.There is a very low risk of privacy loss when using certain
electronic devices, such as baby monitors, cordless telephones,
etc. To protect your privacy, make sure the product has
never been used before purchase, reset the baby monitor
periodically by powering o󰀨 and then powering on the
units, and power o󰀨 the baby monitor if you are not
intending to use it for some time�
23.Children should be supervised to ensure that they do not play
with the product.
24.The small parts of this monitor can be swallowed by babies or
small children. Keep these parts out of reach of children.
25.The product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature between 0oC
and 40oC.
2. Mishandling batteries can cause burn, re or explosion
hazards.
3. Do not expose the product to extreme cold, heat or direct
sunlight. Do not put the product close to a heating source.
4. Batteries should not be exposed to excessive heat such as
bright sunshine or re.
5. Warning—Strangulation Hazard—
Children have STRANGLED in cords. Keep this
cord out of the reach of children. Do not remove
this Do not remove warning label on the adaptor
cord.
6. Never place the Baby Unit(s) inside the baby’s cot or playpen.
Never cover the Baby Unit(s) or Parent Unit with anything
such as a towel or a blanket.
7. Other electronic products may cause interference with your
baby monitor. Try installing your baby monitor as far away
from these electronic devices as possible: wireless routers,
radios, cellular telephones, intercoms, room monitors,
televisions, personal computers, kitchen appliances and
cordless telephones.
Important Safety Instructions

4
Setup
What’s Included?
Parent Unit Baby Unit
Parent Unit Adaptor Baby Unit Adaptor
Quick Start
Guide
Learn to set up your units and have all
detailed instructions on using your baby
monitor.

5
Overview
Baby Unit
1
2
3
4
6
7
8
10
9
5
1
2
3
4
6
7
8
10
9
5
1
2
3
4
6
7
8
10
9
5

6
1 Light Sensor
2 Camera lens
3 Infrared LEDs
• Allow you to see clearly in a dark environment.
4Night light
5 Microphone
6 Power jack
7 Speaker
8 PAIR key
• The Parent Unit and Baby Unit(s) provided are already paired
9Night light control key
• Press to turn the night light on or o󰀨.
10 Slots for wall mounting

7
Parent Unit
1
3
4
6
5
7
9
8
2
10
11
12

8
1 Antenna
2 3-level sound indicator light
3Battery LED light
• On when the Parent Unit is connected to AC power, and the battery is charging.
• Flashes when the Parent Unit battery is low and needs to be charged.
4 LINK LED light
• On when the Parent Unit is linked to the Baby Unit.
• Flashes when the link to the Baby Unit is lost.
5Arrow keys
• Navigate within the menus.
6MENU/SELECT
• Press to enter the main menu.
• While in a menu, press to choose an item, or save a setting.
7/ RETURN/TALK
• Press and hold to talk to the Baby Unit.
• While in a sub-menu, press to exit.
8/
LCD o󰀨/POWER key
• Press and hold to power on/o󰀨 the Parent Unit.
• Press to screen on/o󰀨.
9/ (VOL -/VOL +)
10 Power jack
11 RESET
• Force reboot the Parent Unit
12 Speaker

9
Parent Unit Icons
Main
Menu
Sub-
menu
Options
Brightness
Adjust the parent unit LCD screen brightness.
Lullaby
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
Play/Stop
60min
45min
30min
15min
OFF
Select to play one of the four soothing sounds.
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
Select to play one of the ve melodies or play all.
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
Set a timer to stop the lullaby, or play non-stop.
Night light
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
Turn on/o󰀨 night light.
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
Select from 7 night light colors or auto-color change.
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
Night light timer
• Set a timer to turn off the night light or auto-on when sound
detected.
• If timer is set to OFF, and the night light is turned on, then
the night light remains on always.
• If this is set to AUTO, the night light will remain on for 15
minutes. If you manually switch off the night light, while
AUTO is selected, the night light will turn on when the
detected sound exceeds the selected Sound Sensitivity
Level and last for 15 minutes.
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
• Turn on/off auto adaptive night light.

10
Screen o󰀨 Timer
60min
45min
30min
15min
OFF 60min
45min
30min
15min
OFF
60min
45min
30min
15min
OFF
5min
• Select a screen o󰀨 time, or always remain on.
60min
AUTO
30min
15min
ON
OFF
ON
OFF
OFF
VOX level
• Set the Sound Sensitivity Level for auto screen on.
Alert settings
• Sound Alert in Split-view (For LF2415-2 only).
• Turn on/o󰀨 Low battery alert tone.
• Turn on/o󰀨 Link lost alert tone.
• Turn on/o󰀨 Conrmation alert tone.
Temperature
Turn on/o󰀨 temperature Alert.
Select the minimum and maximum temperature range.
Temperature display format.
Camera settings
Adjust the Baby Unit’s speaker volume.
Zoom
Monitoring mode (For LF2415-2 only)
Select a camera to view.
View in Patrol mode.
View in Split mode.

11
Status icon
Connection status
Baby Unit 1 and 2 are being viewed in Patrol mode (For LF2415-2
only).
Baby Unit 1 and 2 are being viewed in Split mode (For LF2415-2
only).
Current view status
• The Baby Unit number that is being viewed.
Night light is turned on.
Auto-on night light is turned on.
Zoom is turned on.
Night vision is turned on.
Melodies and soothing sounds are playing.
Talkback is on.
Sound level indicator
Parent unit is muted.
Temperature alert is turned on.
Temperature
Battery indicator
Low battery indicator

12
Connect the Baby Monitor
Connect the Parent Unit and Baby Unit to a power supply with the included power
adapters.
Notes:
• Baby Unit turns on automatically after it connects to the power socket.
• The rechargeable battery in the Parent Unit is built-in.
• Use only the power adaptors supplied with this product.
• Make sure the Parent Unit and the Baby Unit are not connected to an electronically controlled
electric outlet.
• Connect the power adaptors in a vertical or oor mount position only. The adaptor prongs are
not designed to hold the weight of the Parent Unit and the Baby Unit, so do not connect them
to any ceiling, under-the-table, or cabinet outlets. Otherwise, the adaptors may not properly
connect to the outlets.
• Make sure the Parent Unit, the Baby Unit and the power adaptor cords are out of reach of
children.

13
Charge the Parent Unit Battery
The Parent Unit runs on an internal rechargeable battery or AC power. To
continuously monitor your baby, keep the Parent Unit connected to AC power.
The Parent Unit turns on automatically after it connects to the power socket, and
its battery will charge at the same time.
Notes:
• Before using the baby monitor for the rst time, charge the Parent Unit battery for 12 hours.
When the Parent Unit battery is fully charged, the battery icon becomes solid .
• The standby time varies depending on your actual use.
The battery icon on the screen indicates the battery status (see the following
table).
Battery Indicators Battery Status Action
The screen displays .
The LED light ashes.
The battery power is very low
and may only be used for aused for a
short time.short time.
Charge without interruption
(about 30 minutes).
The battery icon becomes
solid .
The battery is fully charged. To keep the battery charged,
connect it to AC power when in
use.

14
Power On or O󰀨 the Baby Monitor
1� Connect the power adaptor to the Baby Unit and a power supply to power on
the unit.
Disconnect from the power supply to power o󰀨.
2� Press and hold to turn on the Parent Unit, the welcome screen appears and
the green LINK LED ashes.

3� Once your Baby Unit and Parent Unit are powered on, the Parent Unit and Baby
Unit will pair each other automatically. When they are connected successfully, the
LINK LED lights steadily. And your Parent Unit streams live video from the
Baby Unit.

15
Positioning the Baby Monitor
Caution: Keep the Baby Unit out of the reach of your baby. Never place or mount the Baby
Unit inside the baby’s cot or playpen.
Place the Baby Unit more than 1m away from your baby.
Cautions:
• The default volume of your Parent Unit is level 3, and the maximum volume is level 5.
If you experience feedback noise from your baby monitor while positioning:
- Make sure your Baby Unit and Parent Unit are more than 1 metre apart; OR
- Lower the volume of your Parent Unit.
• To avoid interference from other electronic devices, place your baby monitor at least 1 metre
away from devices such as wireless routers, microwaves, mobile phones and computers.
≥
<
1m
1m
﹏﹏﹏
﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏
﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
﹏﹏﹏﹏﹏
Manual
Tilt
12
3
4

16
Basic Operation
Talk to Your Baby via the Baby Unit
You can use the Talk function on the Parent Unit to comfort your baby from
the other room.
1� Press and hold the key. The status icon appears on the screen.
2� Speak towards the microphone on the Parent Unit. Your voice is transmitted to
the Baby Unit.
3. When nished talking, release the key to hear your baby again.
Notes:
• The Parent Unit speaker is muted during voice broadcast. Sound transmission from the Baby
Unit resumes after is released.
• After around 20 seconds of sound re-transmission, the speaker returns to mute if you had
set it to mute before pressing .
Press and hold

17
Use the Menu
Press on the Parent Unit to enter the main menu, choose a menu item, or save
a setting. You can use the Parent Unit menu for advanced settings or operations,
such as to play or stop the Baby Unit lullaby, or to adjust the Baby Unit sound
sensitivity.
While in the menu:
• Press or to scroll among the menu options.
• Press to select an item, or to save a setting.
• Press or to scroll among the sub-menus, or to adjust a setting.
• Press to return to the previous menu options without changing the current setting.
• Press / to return to the live video.

18
Adjust Speaker Volume
Press | to adjust the speaker volume level on the parent unit, received
from the Baby Unit.

19
Zoom
1� Press to enter the main menu.
2� Press or to go to (Camera Settings) menu , then press to conrm.
3� Press or to select (zoom).
4� Press or to select and press to conrm.
You can zoom in or out your image between 1x and 2x�

20
Turn on/o󰀨 the Parent Unit Screen
You can turn on or turn o󰀨 the Parent Unit screen without powering o󰀨 the unit.
When the screen is turned o󰀨, you can still hear from the Baby Unit.
• Press / on the Parent Unit to turn o󰀨 the screen.
• Press any key on the Parent Unit to turn the screen on again.
Adjust Screen Brightness
You can change the brightness of the Parent Unit screen from Level 1 to Level 5.
The LCD screen brightness is preset to Level 3.
To adjust LCD brightness:
1� Press to enter the main menu, press
again to select (Brightness) when
the Parent Unit is idle.
2� Press to increase or press to
decrease the brightness, then press to
conrm your setting.
