LED Sens SR-2830-RF-IN Series User manual

RF Wall Mounted Touch Panel
Parameter
Wiring diagram
Product Size
29.1
86.0
86.0
Backlight
Glass interface(White & Black)
Touch sensitive
Adjust brightness and color
1)Sender DiagramConnection
LN
SR-2830RGB-AC
110V-230VAC
N
L
VinGND
LN
110V-230VAC
Power Supply
12-24VDC
Feature
Sens SR-2830-RF-IN
Part No. Iuput Voltage Remarks
Current
SR-1009FA 12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
SR-1009EA 12-36VDC Constant voltage
4x(96-288)W4x8A
Remote
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
Operation
Frequency
SR-2830-RF-IN-AC 100-240VAC 86x86x29.1
434MHz/868MHz
SR-2830-RF-IN-DC
Receiver
SR-1009FA3 12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
SR-1009FA7 12-36VDC Constant current
4x(8.4-25.2)W4x700mA
Remarks
Touch Sensor
12-24VDC 86x86x29.1
434MHz/868MHz Touch Sensor
SR-2830RGB-DC
Note:
One receiver can work with 1-8pcs SR-2830RGB
One SR-2830RGB control multiple receivers
The power supply chosen must be 20% higher than the actual load
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
LN
110V-230VAC
whi te
SR-1009FA
LED CONTROLLER
1234
Lea rni ng Ke y
whi te
SR-1009FA
LED CONTROLLER
1234
Lea rni ng Ke y
whi te
SR-1009FA
LED CONTROLLER
1234
Lea rni ng Ke y
Installation
12-2 4VD C
Powe r Sup ply
SR-2830-RF-IN-AC SR-2830-RF-IN-DC

Operation
Description of buttons
Turn ON/OFF
4 zones control seperately or
syhchronously, each zone could
control multiple receivers.
1. Learning ID with SR-1009 series:
Click learning button on RF receiver (SR-1009XX)→
Short Touch a zone button Z1,Z2,Z3 or Z4 (sender 2830RGB)→Touch dimming slider
The light flick means ID learnt successfully.
Touch zone button Z1/Z2/Z3/Z4 separately over 2 seconds, which will turn ON/OFF separately.
The backlight blue is ON for the zone, yellow is OFF for the zone.
Short press is choose the zone.
Long press can turn off/on each zone.
Notice : Each sender can control 4 different zones separately,each zone can be learned endless
receivers,so one sender can control as many receivers as you can.
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Saving color or mode
Play&pause button,10 build-in
mode
Brightness button
long press dim up,
long press again,dim dowm.
a.Save color :choose a zone or multiple zones from(Z1,Z2,Z3,Z4)
Touch dimming slider to get a favorite color →
Hold button over 2 seconds →
The light flicking means successfully saved.
b.Save mode:choose a zone or multiple zones from(Z1,Z2,Z3,Z4) →
press button,10 build-in modes inside, choose the favorite mode →
Hold button over 2 seconds-The light flicking means successfully saved.
c.Reply:Short touch button to replay the color or mode just saved.
→
Press Button, mode will run.Press it once,it runs one mode.Press button again,it stops,then press one more time,
it will enter next mode.There are total 10 build-ion modes.
Long press dim up,Long press again,dim down.
