Ledi RGB-DMX-CONT-STICK3 User manual

Installation
Instructions
for the RGB DMX Stick 3 Controller
#RGB-DMX-CONT-STICK3

Version 05122017
2
POWER
DC +
POWER
Ground
DMX
Ground
DMX -
DMX +
P
OWER
DC
+
POWER
Ground
O
D
MX
Groun
d
DMX -
DMX
+
1 DMX +
2 DMX -
3 DMX2 +
4 POWER
5 DC +
6 DMX2 -
7 POWER
8 GROUND
POWER
+DMX
1.......8
(
(
1
DMX
+
2
DMX -
3
DMX
2
+
4 P
O
WE
R
5
D
C
+
6
DMX
2
-
7 P
O
WE
R
8
G
R
O
UND
P
OWE
R
+DMX
1.......8
(
(
Ref: SP485ECN-L
MAX485 CSA
DMX universe #1
DMX universe #2
20
18
16
14
12
10
8
6
4
2
19
17
15
13
11
9
7
5
3
1
VIN
GND
IR_RX
3.3V
Relay
DMX2+
DMX2-
DMX1+
DMX1-
GND_DMX
PORT1
PORT2
PORT3
PORT4
PORT5
PORT6
PORT7
PORT8
RS232 RX
RS232 TX
2. Connect the wires
POWER: Connect a 5.5V or 6V DC 0.6A ACDC supply.
Be sure to not invert the + and the ground.
DMX: Connect the DMX cable to the lighting
receivers (Leds, Dimmers, Fixtures..)
(for XLR: 1=ground 2=dmx- 3=dmx+)
3. Mount the interface on the wall
First, mount the back side of the interface on the wall with 2 or
more screws
Secondly, plug the connectors :
- DMX and power (connector block or RJ45)
- Ethernet cable
The front panel is mounted by pressing it against the back
plate and then sliding down. 2 screws should then be attached
underneith to hold the controller in place.
**CHECK PIN CONFIGURATIONS. APPLYING POWER TO THE DMX INPUT WILL DAMAGE THE CONTROLLER**
**MAKE SURE THE CONTROLLER IS MOUNTED WITHOUT TOO MUCH FORCE BEHIND AS THIS CAN PUSH APART THE GLASS**
POWER+DMX
WITH THE
CONNECTOR BLOCK
1. Mount an electrical box inside the wall
The controller can be installed in any standard electrical
backbox. If you use a double size box, you can insert
the power supply inside.
POWER+DMX
WITH THE
RJ45 CABLE
Compatible header connectors:
WURTH ELEKTRONIK ref: 61301021121
MOLEX ref: 10-89-7202
TE Connectivity ref: 1-87227-0
FCI ref: 77313-101-20LF
HARWIN ref: M20-9981046
SAMTEC ref: TSW-110-xx-T-D
FARNELL ref: 1841232
RS ref: 763-6754 673-7534 251-8165
MOUSER ref: 538-10-89-7202
DIGIKEY ref: WM26820-ND
2x10 pins EXTENSION socket
DMX CHIP replacement
EXTENSION socket
Installing the Controller

Version 05122017
3
Example of relay :
FINDER Ref.
22.23.9.012.4000
Rechargeable
battery*
11 mm
106 mm
146
mm
Rechargeable
b
atter
y*
P1 P2 P3 P4 ... GND
Make a cable using the 3 pins : TX, RX and G (GND)
Set the RS232 parameters to : 9600bds 8 bits, no Parity, 2 Stop bits
- To play a scene, send 3 bytes : 1 x y 255
- To stop a scene, send 3 bytes : 2 x y 255
- To pause a scene, send 3 bytes : 3 x y 255
- To release a pause, send 3 bytes : 4 x y 255
- To reset a scene, send 3 bytes : 5 x y 255
When (y)=0, (x) can be set between 0 and 255
-to stop scene 145, send the command: 2 145 0 255
When (y)=1, (x) can be set between 0 and 243 to trigger scenes 256-499
-to play scene 300, send the command: 1 255 45 255
Prev
Scene
mini
usb reset button micro SD dmx led
data
led
Touch-sensitive
user interface
Screw-terminal
rear connector
(5 pins)
Extension socket
rear connectors
(2x10 pins)
Power+DMX
socket
(RJ45)
Ethernet socket
(RJ45)
Front access
connections
Next
Scene
Dimmer Scene
Color Speed
Undo
Prev Area
Standby
Next Area
The controller can be connected to a local network, allowing it to be
controlled from a smartphone or tablet over WiFi.
࠮Connect the controller to a router or switch with an RJ45 cable
࠮The controller is set by default to get an IP address from the
router via DHCP. If the network is not working with DHCP, a
manual IP address and subnet mask can be set using the
Hardware Manager
࠮
The controller can be connected to an existing automation system
over a network and triggered via TCP package on port 2431 or UDP
packets on 2430. Refer to the remote protocol document for more
information.
BLACKOUT Relay (energy saving)
Dry Contact Port Triggering
Network Control TCP Triggering
is no receiver. A 36khz infra red receiver can be connected, such as
the TSOP34836 by Vishay Semiconductors. Farnell ref: 4913127. This
can be attached to the 20 pin connector. It’s a good idea to add a
resistor and capacitor to surpress power supply disturbance.
A relay can be connected between the RELAY and GND sockets
equipment such as lighting drivers. The signal is connected when
the controller is in standby.
Infra Red
RS232 Triggering
It is possible to start scenes using the input ports (contact closure).
To activate a port, a brief contact of atleast 1/25 second must be
established between the ports (1...8) and the ground (GND). Note:
.
Connections & Triggering
NOTE: Surface color not available in black.

Version 05122017
4
Settings Menu
To access the settings menu, hold the standby button for 3 seconds.
࠮Use the arrow buttons or palette to scrol through the menus
࠮Use the area buttons to navigate forwards and backwards
࠮The ‘undo’ button can also be used to navigate forwards
Mode (M): Manages the on/off button and the 4 modes (dimmer, speed, color, scene)
Arrows (A): Allows you to adjust which modes can be controlled by the arrows
Pallet (P): Allows you to adjust which modes can be controlled by the palette wheel
Scene (S): Scene management
First Start (F)
Trigger (T): Manages the controllers external triggering properties
Ethernet (E): Enables the Ethernet socket on the controller
Date/Time (D): Manages the date and time stored inside the controller
Graphics (G): Screen management
DMX Output (X): Manage the timings of the DMX output messages and the page priorities (advanced function!)
Sensitive (S): Manage the touch sensitivity settings
Language (L): change the language of the text which appears on the screen
About
iti
iti
es
es
(ad
(ad
van
van
ced
ced
fu
fu
nct
nct
ion
ion
!)
!)
S
etting up the Controller
The controller can be used with one of two different smartphone apps, each available on the App Store and Google Play
Store. These apps provide limited programming capabilities (see below for details), but are very easy to use and great for
simple customization. If full customization is needed, please refer to the ESA Pro Software (details below).
The controller can be fully programmed from a PC or Mac using the inlcuded ESA Pro software. The ESA Pro
software provides in-depth programming, from scene creating and editing, to dening and labeling multi-zoned
xtures. A software CD is included with your controller. The software may also be dowloaded at https://www.
nicolaudie.com/en/esapro.htm. Video tutorials for the ESA Pro software are also available at https://www.youtube.
com/user/Nicolaudie.
The controller’s rmware can be updated using the Hardware Manager, which is included with the ESA Pro software.
To view your controller’s rmware version, go to the settings menu and scroll to “About” (see the section “Settings
Menu” below for further details).
Lightpad
Designed to work seemlessly with the controller, Lightpad provides an easy way to contol your lights
over a local WiFi network. Use the color wheel to change the color, brightness, or speed of an effect.
Use the arrows to cycle through scenes and effects, just like the wall panel. Swipe down to reveal
quick scene selection buttons.
Easy Remote
Create an entirely customized remote control for your tablet or smartphone. Easy Remote is
a powerful and intuitive app allowing you to easily add buttons, faders, color wheels and more.
Connect to a WiFi network and the app will nd all compatible devices.
iPhone/iPad/Android Apps - Limited Programming Capabilities
ESA Pro Software - Full Programming Capabilities
Firmware Updates

Version 05122017
5
Internal Menu
MODE (M) :
M OFF enable :
M Dimm. enable : when enabled, scenes can be made brighter or darker
M Color. enable : when enabled, the color of a scene can be changed
M Speed. enable : when enabled, dynamic scenes can be made faster and slower
M Scene. enable : when enabled, the scene can be changed
M Auto mode :
M Auto time : the amount of time the controller will wait before reverting to the default mode
M Default : the default mode which the controller will revert to after a certain amount of time
M Dimmer 100% : when enabled, the dimmer mode will adjust between 0% and 100% without saturating to white between 100% and 200%
M Lock Control : Once this is enabled, you can hold the dimmer button for 5 seconds to enable/disable lock mode. It’s automatically activated
after 120 seconds. When lock is activated, you’ll see a red border around the screen
Arrows (A) : Allows you to adjust which modes can be controlled by the arrows
A Dimmer enable : allows for the Dimmer mode to be controlled by the arrows
A Color enable : allows for the Color mode to be controlled by the arrows
A Speed enable : allows for the Speed mode to be controlled by the arrows
A Scene enable : allows for the Scene mode to be controlled by the arrows
A Default : the mode to jump to when the arrows are pressed, if the arrows are not enabled on the selected mode
Pallet (P) : Allows you to adjust which modes can be controlled by the palette wheel
P Dimmer enable : allows for the Dimmer mode to be controlled by the palette wheel
P Color enable : allows for the Color mode to be controlled by the palette wheel
P Speed enable : allows for the Speed mode to be controlled by the palette wheel
P Scene enable : allows for the Scene mode to be controlled by the palette wheel
P Default : the mode to jump to when the palette is pressed, if the palette is not enabled on the selected mode
Scene (S) : Scene management
S
enable :
S Pause enable : allows a scene to be paused if the scene mode button is held for 1 second
S Stop enable : allows a scene to be stopped if the scene mode button is held for 4 seconds
S Fade
: manages the fading between scenes
Never : the controller will never fade between scenes
S Fade time : the time of the automatic fade between scenes
S Auto reset : when enabled, any color, dimmer or speed overrides will be reset each time the scene is changed
S Trigger : sets the scene triggering mode. Time Delay and Scene Butt allow for scenes to be scrolled through without playing
Auto : the scene will be triggered as soon as it’s selected
Time Delay : a short delay is added before a scene is triggered
Scene Butt. : the selected scene will not play until the scene button is pressed
First Start (F) :
F Scene Nr. : specify a default scene number
F Scene Scene Recover : activates the previously playing scene
F Display Time : when enabled, the time will be displayed on the screen at startup
F Scene Nr. : enables the triggering of a scene at startup. If disabled, no scene will be triggered
Trigger (T) : Manages the controllers external triggering properties
T Time enable : enables the clock triggering
T Ports enable : enables the 8 dry contact ports
T RS232 enable : enables scene triggering by RS232
T IR enable : enables the infra red port (disabled by default to prevent interference)
T UDP enable : allows the controller to send and receive UDP messages required for network control
T Blackout port : enables the blackout relay output which is triggered when the stanby putton is touched
Service *To replace the Li-Ion rechargeable battery on the DE3 :
1. You need a rechargeable 3.6v LIR 2032 replacement battery
2. Remove the back panel by pulling down and sliding it out.
3. Using a paper clip push the battery from the bottom so it slides out of
its cage.
4. Slide the replacement battery in from the top, making sure the positive
side is facing up.
5. Replace the back panel by pushing it up into place.
Servicable parts include:
࠮Memory card - used to store the scenes
࠮Battery - used to store the clock/calendar
࠮DMX Chips - used to drive the DMX (see p2.)

Version 05122017
6
Date/Time (D) : Manages the date and time stored inside the controller
Date : the controllers date
Time : the controllers clock time
G Bright normal : the % brightness when the controller is not sleeping G Bright sleep: the % brightness when the controller is sleeping
G Bright LED : the % brightness of the mode and reset LEDs
G
raphics (G) : Screen management
G Image enable : allows for images to be shown for each scene if they have been assigned in the programming software
G Image full : when enabled, the image will be displayed in full screen and the scene and area will not be visible
G Image time : the time it takes before the image is displayed in full screen
G Sleep enable : when enabled, the screen brightness will dim after a certain amount of time
G Sleep time : the amount of time to wait before sleeping
G Bright normal : the brightness of the screen’s backlight
G Bright sleep : the brightness of the screen’s backlight whilst the controller is sleeping
G Bright LED : the brightness of the scene, undo and standby LED’s
DMX Output (X) : Manage the timings of the DMX output messages and the page priorities (advanced function!)
X MBB : Mark Before Break- the time to wait between sending each 512 channel DMX message (or ‘packet’)
X Break : Break- the time to wait just before sending a new packet, resetting the DMX line
X MAB : Mark After Break- the message which tells your receiver to begin reading data
X MBS : Mark Between Slots- the delay time between sending each DMX channels data within the DMX packet
Univ-1/Univ-2 :
X Alphab Mode : if the same scene is triggered in the global area and a second area, the area with the highest letter will take priority
X LTP Mode : If the same scene is triggered in the global area and a second area, the latest scene triggered takes priority
S
ensitive (S) : Manage the touch sensitivity settings
S USB Init : reset the touch sensitivity when the USB is connected and disconnected
S Auto Time : the time to wait before automatically resetting the touch sensitivity
S High Sense : when enabled, the sensitivity will be increased
S See Values : see each touch sensitive button number and palette value
Language (L) : change the language of the text which appears on the screen
A
bout :
Reset : Reset all settings to the factory default
Ethernet (E) : Manages the controllers network settings
Ethernet : Enables the Ethernet socket on the controller
Dynamic IP Addr : enables dynamic IP addressing (DHCP) which allows the controller to obtain an IP address from a router
Sync Blackout: when this open is enabled, all other controllers on the network will go into standby when the standby button is pressed
Enable NTP : enables Network Time Protocol. The controller will synchornise the clock with the internet if a connection is evailable
NTP Server : the IP address of the server to synchronize the clock. The default is 005.135.141.108
Device’s IP Add : the controllers static IP address it will use if it does not receive an IP address via DHCP
Mask: the subnet mask of the controller if not set to DHCP. Generally this is 255.255.255.0
Default Gateway : the IP address of the router if not set to DHCP
MAC Address : a unique ID used to identify the controller on the network

Version 05122017
7
Troubleshooting
The controller is in bootloader mode. This is a special ‘startup mode’
-Check that there is nothing metallic touching the back of the controller
-Try formatting or replacing the SD card
-Try formatting the SD card in the computer
-Try replacing the SD memory card
There is no SD card detected.
-Check the SD card is properly connected
-Try formatting the SD card in the computer
-Try replacing the SD memory card
-Be sure that the latest software version is installed
-Connect by USB and open the Hardware Manager (found in the software
-Check the DMX +, - and GND are connected correctly
-Be sure that the DMX address has been set correctly
-Check there are no more than 32 devices in the chain
-Connect with the computer and open Hardware Manager (found in the
software directory). Open the DMX Input/Output tab and move the faders.
The 4 Mode LEDs on the controller are All LEDs on the controller are
All LEDs on the controller are
except the standby LED
The controller is not detected by the
computer
The lights are not responding
Instructions provided by Nicolaudie-Sunlite
For additional assistance, please contact LEDI’s Design Department at
[phone], or [e-mail].

Version 05122017
8
120-277V
AC Power
RGB Tape Light
RGB Tape Light
RGB Tape Light
RGB DMX Stick 3 Controller
CAT- 5 CAT- 5
CAT- 5
RGB Hardwire Connector
RGB Hardwire Connector
RGB Hardwire Connector
RGB DMX Decoder
RGB DMX Decoder
RGB DMX Decoder
RGB DMX
Terminator
120-277V
AC Power
120-277V
AC Power
Complete System Wiring Diagram
