LEDISONS LDS15-WPF-ZWA User manual

LDS15-WPF-ZWA
Rendementstraat 5
8094 RA Hattemerbroek
Thank you for purchasing the solar up down light. We are committed to oering the
most eective home and garden solar lighting solution.
PARTS CONTAINED
1) 1X Aluminum Solar Lamp
2) 1X ST64 Filament bulb
3) 1X Dry-anchors and Screws
4) 1X Instruction
FEATURES
1) Solar panel: 5V,200mA
2) Lithium battery: LI-ION 3.7V 2000mAh
3) Filament Bulb:3V,2W
4) Lamp luminous: Full mode with 60 lumen and half mode with 30 lumen
5) Material:Aluminum lamp body and Glass
OPERATION
Select the required brightness by covering the solar panel and pushing the ON/OFF
switch.
Full brightness (first push)- Half brightness (second push)-OFF(third push).
INSTALLATION
• Choose place where needs light at night and select a location where the unit will
receive abundant sunlight during the day.
• Any cover or awning that shades the panel will aect the charging of the battery
resulting in a shorter run time at night.
• Drill 2 holes on the wall according to the hole location from the wall mount and
insert the dry anchors.
• Fix the screws in place and slide the lamp down onto the screws.
• The light will turn on automatically after dusk. The light should not be placed clo-
se to other bright lighting such as streetlights as the the solarlight may not turn
on at night
SOLAR LIGHT PIANO
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
MANUAL

LDS15-WPF-ZWA
MANUAL
Rendementstraat 5
8094 RA Hattemerbroek
BATTERY REPLACEMENT
The battery is 3.7V 2000mAh Li-ion rechargeable battery which is easily replaceable.
If the battery begins to illuminate dimly or for short durations of time and you know
that it has had suicient sunlight on the panel,you should replace the battery in fol-
lowing way:
1. Take o the lamp from the wall
2. Unscrew the two screws which connect the solar battery box with metal
frame.
3. Pull out the solar battery box carefully.
4. Remove the 8 screws on the plate without damaging cables.
5. Disjoin the old battery and replace a new battery.
WARNING – Polarity is important. Wrong polarity is dangerous and will destroy the
unit.
