Ledix ZAMEL ZSL Series User manual

MESH LED POWER SUPPLY ZSL-25-12, ZSL-35-12, ZSL-60-12, ZSL-100-12, ZSL-150-12
MANUAL INSTRUCTION
ZAMEL Sp. z o.o.
ul. Zielona 27, 43-200 Pszczyna, Poland
Tel. [phone], Fax [phone]
www.zamel.com, e-mail: [email protected]
plik: Instrukcja ZSL-25_35_60_100_150 EN | modykacja: 21.03.2017
FEATURES
DESCRIPTION
● For use in household LED installa-
tions.
● 12 V DC output voltage of high
stability.
● Wide range of output power.
● Overvoltage and short-circuit protec-
tions.
● No-load operation resistance.
● Free mounting indoor only.
● Output voltage adjustment by means
of a potentiometer within a minimum
range of 10% nominal voltage.
ZSL series switched-mode power sup-
plies are designed for a direct use in
home LED lighting installations. Their
modular construction allows for an easy
and comfortable mounting indoor to hor-
izontal and vertical surfaces. The 12 V
DC output voltage power supplies are
available in a wide range of output power
(25÷150 W). The built-in protections guar-
antee a continuous and undisturbed oper-
ation of all connected LED elements. The
power supplies are equipped with output
voltage adjustment within the minimum
range of ±10% by means of a potentiom-
eter. Metal casing ensures proper power
supply cooling and prolongs its life.
The device is designed for a sin-
gle-phase installation and must be
installed in accordance with stan-
dards valid in a particular country.
The device should be connected
according to the details included in this operat-
ing manual. Installation, connection and control
should be carried out by a qualied electrician
staff, who act in accordance with the service
manual and the device functions.
In case of casing dismantling an electric shock
may occur, and the guarantee is lost then. Be-
fore installation make sure the connection ca-
bles are not under voltage. The cruciform head
screwdriver 3,5 mm should be used to instal the
device. Improper transport, storage, and use
of the device inuence its wrong functioning.
It is not advisable to instal the device in the fol-
lowing cases: if any device part is missing or
the device is damaged or deformed. In case of
improper functioning of the device contact the
producer.
CAUTION
TECHNICAL DATA
The symbol means selective
collecting of electrical and
electronic equipment.
ZSL-25-12 ZSL-35-12 ZSL-60-12 ZSL-100-12 ZSL-150-12
Input parameters
Input voltage range: 110÷260 V AC
Input frequency range: 50 / 60 Hz
Input current: 0,3 A 0,38 A 0,65 A 0,85 A 1,05 A
Power supply cons-
umption during no load: ~0,5 W ~0,6 W ~1,5 W ~0,9 W ~3,9 W
Efciency: 85 % 75 % 80 % 83 % 83 %
Power factor: 0,5
Output parameters
Nominal output voltage: 12 V DC
Nominal output current: 2,5 A 3 A 5 A 8,5 A 12,5 A
Output current range: 0÷2,5 A 0÷3 A 0÷5 A 0÷8,5 A 0÷12,5 A
Nominal output power: 25 W 35 W 60 W 100 W 150 W
Ripples and noises
(max): 200 mVpp
U adjustment range: 10,5÷13,5 V 8,5÷13 V 11,3÷13,2 V 11,5÷12,8 V 10,8÷15 V
Voltage tolerance: 1 %
Output voltage time
increase (max): ~15 ms
Output backup time
(max): ~80 ms
Other parameters
Overload protection: Yes – returnable (app. 180÷200% Pn)
Output short-circuit
protection: Yes – returnable
Thermal protection: No
Resistance to idle
state: Yes
Operating temperature: -20÷60°C
Protection class: I
Overvoltage category: II
Casing protection
degree: IP20
Mounting: free
Operating position: Free (horizontal or vertical plane)
Dimensions (mm): 87x59x32,5 87x59x32,5 110x78x36,5 162x99x42 200x98x42,5
Weight: 100 g 115 g 195 g 340 g 385 g
Reference standard: PN-EN 55015, PN-EN 61547, PN-EN 6100-3-2,
PN-EN 6100-3-3, PN-EN 61347-1

WARRANTY CARD
There is 24 months guarantee on the product.
Salesman stamp and signature, date of sale.
1. ZAMEL Sp. z o.o. assures 24 months guarantee for the product.
2. The manufacturer’s guarantee does not cover any of the following actions:
a) mechanical damage during transport, loading / unloading or under other circumstances,
b) damage caused by incorrect product mounting or misuse,
c) damage caused by unauthorised modications made by the PURCHASER or any third parties to the
product or any other devices needed for the product functioning,
d) damage caused by Act of God or any other incidents independent of the manufacturer - ZAMEL Sp z o.o.
e) supply sources (batteries) included in the device during selling (if they are included).
3. The PURCHASER shall lay any claims in writing to the dealer or ZAMEL Sp. z o.o.
4. ZAMEL Sp. z o.o. is liable for processing any claim according to current Polish legislation.
5. ZAMEL Sp. z o.o. shall process the claim at its own discretion: product repair, replacement or money return.
6. The manufacturer’s guarantee is valid in the Republic of Poland.
7. The PURCHASER’s statutory rights in any applicable legislation whether against the retailer arising from the purchase contract or other-
wise are not affected by this warranty.
MOUNTING PRODUCT FAMILY
1. Disconnect power supply by the
phase fuse, the circuit-breaker or the
switch-disconnector combined to the
proper circuit.
2. Check if there is no voltage on con-
nection cables by means of a special
measure equipment.
3. Connect the cables with the termi-
nals of ZSL-XX-12 power supply in ac-
cordance with the installing diagram.
4. After connecting the cables protect
the terminals with a cover (refers to
ZSL-60-12, ZSL-100-12, ZSL-150-12).
5. Sw itch on the power supply from the
mains.
6. If required adjust the appropriate
Uout value by means of a potentiome-
ter.
DIAGRAM
LEGEND OF SYMBOLS
Output voltage adjustment.
Device made in protection
class I.
The ZSL power supplies belong to the
product family:
ZSL - XX - 12
Output power
Device symbol
Output voltage adjustment.
25 – 25 W / 2,1 A
35 – 35 W / 3 A
60 – 60 W / 5 A
100 – 100 W / 8,5 A
150 – 150 W / 12,5 A
ZSL-25-12
ZSL-35-12
ZSL-60-12
IN OUT IN OUT
Uout
adjustment
PE
N
L
Uout
adjustment
Uout
signalling
Uout
signalling
ZSL-100-12
ZSL-150-12
