Ledj ALU ZOOM PAR 64 User manual

www.prolight.co.uk
Quad Par 64
(Order code: LEDJ46 - Black)
(Order code: LEDJ47 - Polished)
USER MANUAL

WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modifications to this equipment are not
subject to warranty.
LEDJ Quad Par 64 Safety

LEDJ Quad Par 64 Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modification to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the power-cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Only use the equipment indoors.
• Do not expose to flammable sources, liquids or gases.
• Always disconnect the power from the mains when equipment is not in use or before
cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the
power-cable.
• Make sure that the available voltage is between 220v/240v.
• Make sure that the power-cable is never crimped or damaged. Check the equipment and
the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply immediately.
Have a qualified engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature fluctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might damage
the equipment. Leave the equipment switched off until it has reached room temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualified
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.

You should find inside the LEDJ carton the following items:
1, Quad Par 64 Unit 2, Instruction manual, 3, Power cable
Technical Specifications:
DMX channels: 7
400Hz flicker free LEDs
Power supply: AC 240 ~ 50Hz
18 x 8W Quad colour LEDs
Power Consumption: 175W
Beam angle: 25 degrees
Dimensions: 310 x 230 x 220mm
Weight: 2.8Kgs
Operating modes: 1, Static Colour mode
2, Colour change mode
3, Colour Fade mode
4, Auto Run mode
5, Slave mode
6, LED mode
7, Sound active mode
8, DMX mode
LEDJ Quad Par 64 Technical specifications
Overview:
1, DMX output
2, DMX input
3, LED display
4, Fuse (2A)
5, Mode selection button
6, Up button
7, Down button
8, Enter button
1
2
3
4
5
6
7
8

1, RGBW colour mix mode
In this mode you can set the Quad Par 64 to any colour and any brightness.
Press the “MODE” button to show “C1” with two digits after it.
The “C1” represents Red, “C2” = Green, “C3” = Blue, “C4” = White and “CF” = strobe.
The two digits after it are the brightness 00 to 99 or in “CF” they are the strobe speed.
Examples: If you set C1, C2, C3 and C4 all to zero, your 229 will have no LEDs showing (blackout).
If you set C1 to 99 and C2, C3 and C4 to zero your 229 wil be 100% Red.
2, Colour change mode
Mode button - Press the “MODE” button until the LED display shows “JU00”, then press the
“ENTER” button to choose one of the colour changing modes using the “UP” and “DOWN” buttons.
1, “JU00” = RGBW (15 colours), 2, “JF00” = Strobe,
Now press the “ENTER” button again and you can then select the colour change speed using the
“UP” and “DOWN” buttons.
3, Colour fade mode
Mode button - Press the MODE button until the LED display shows “F000”, then press the
“ENTER” button to choose one of the colour fading modes using the “UP” and “DOWN” buttons.
1, “FA00” = RGBW (15 colours), 2, “FF00” = Strobe,
Now press the “ENTER” button again and you can then select the colour fade speed using the
“UP” and “DOWN” buttons.
4, Auto Run mode
Mode button - Press the “MODE” button until the LED display shows “AUTO”, the unit will now run
through it’s built-in programmes.
5, Slave mode
Link the units together using a 3-pin DMX cable, then press the MODE button to select one of the
above modes. On the Slave units press the mode button until the LED display shows “SLAV”. The
Slave units will then follow in sequence with the Master unit.
6, LED mode - Use this mode to switch the LED display On and Off
7, Sound active mode
Mode button - Press the “MODE” button until the LED display shows “SU00”, then press the
“ENTER” button to set the desired sensitivity level using the “UP” and “DOWN” buttons.
The sound sensitivity levels are from 00-99 (00 = low, 99 = high)
8), DMX Addressing mode
To access the DMX address mode, press the “MODE” button until the LED display shows “A001”,
then press the “ENTER” button and set the first digit in the DMX address using the “UP” and
“DOWN” buttons. Now repeat this step to set the second and third digits for the desired DMX
address setting. Follow the DMX channel assignment and function table overleaf.
Note: The speed settings for operation modes 2 and 3 are from 00-99 (00 = slow, 99 = fast)
The strobe speed settings for operation modes 1, 2 and 3 are from 00-99 (00 = slow, 99 = fast)
LEDJ Quad Par 64 Operation

7 Channel DMX chart
LEDJ Quad Par 64 Operation
Channel
1
2
3
4
5
6
7
Value
000-255
000-255
000-255
000-255
000-255
000-255
0-4
5-80
81-150
151-255
Function
Master dimmer
Strobe
Red (0 - 100%)
Green (0-100%)
Blue (0-100%)
White (0-100%)
No function
Colour Macro
Colour change
Colour fade

DMX-512:
• DMX (Digital Multiplex) is a universal protocol used as a form of communication between
intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the
controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the
DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have
a data “out” terminal).
DMX Linking:
• DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all fixtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX fixtures try to use the
shortest cable path possible. The order in which fixtures are connected in a DMX line does not
influence the DMX addressing. For example; a fixture assigned to a DMX address of 1 may be
placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a
fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to
address 1 to that unit, no matter where it is located in the DMX chain.
DATA Cable (DMX cable) requirements (for DMX operation):
• The Quad Par 64 can be controlled via DMX-512 protocol. The DMX address is set on the back
of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for data
input/output (figure 1).
Figure 1
Also remember that DMX cable must be daisy chained and cannot be split.
LEDJ Quad Par 64 DMX Setup
Further DMX cables can be purchased
from all good sound and lighting suppliers
or Prolight dealers.
Please quote:
CABL10 – 2M
CABL11 – 5M
CABL12 – 10M

Notice:
• Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer
casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special Note: Line termination:
• When longer runs of cable are used, you may need to use a terminator on the last unit to
avoid erratic behaviour.
Using a cable terminator (part number CABL90) will decrease the possibilities of erratic
behaviour.
5-Pin XLR DMX Connectors:
• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin
XLR fixtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin
XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the
correct cable conversion.
Termination reduces signal transmission problems
and interferance. it is always advisable to connect a
DMX terminal, (resistance 120 Ohm 1/4 W) between
pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.
LEDJ Quad Par 64 DMX Setup
