Legacy PL-1145 User manual

PL1145
Operating Instructions
ProLine Series

About Topaz3
Topaz3 is the exclusive supplier of Maxon®, Legacy
and TruTalk brand communication products.
ur product line ranges from FCC licensed two-way
radios suitable for Business and Industry (B&I) markets
like farm, government, law enforcement, utility, etc. to
consumer recreational and light-duty business markets.
Product offerings include a variety of UHF and VHF
handheld and mobile radios, repeaters and RF link
modules as well as FRS (Family Radio Service), GMRS
(General Mobile Radio Service) radios, Citizens Band
radios and weather monitors.
Available accessory items include: a variety of carrying
cases, spare batteries, desktop and mobile chargers,
ear bud speaker microphones, and more for each radio
model.
For additional information on our product line, visit our
website: www.topaz3.com

Table of Contents / Contenido
I. FCC RF Exposure Compliance Requirements -
for ccupational Use nly.............. .1
I. Requerimientos de Obediencia a la
Exposición de RF del FCC - para uso
Ocupacional Solamente
............................2
II. Unpacking and Checking Equipment.....3
II. Desempaque y Verificación del Equipo...........29
III. Getting Started.......................................4
III.
Preparación.....................................................30
Charging the NiMH Battery Pack............4
Cargador de la Batería de NiMH.....................30
Attaching and Removing the Battery Pack.6
Instalación y Retiro de la Batería.....................32
Installing the Antenna...........................7
Instalación de la
Antena................................33
Installing the Belt Clip...........................7
Instalación del Clip de Cinturón.....................33
Installing the Speaker Mic. Jack Cover......7
Instalación de la Cubierta de la Clavija
de Conexión de Micrófono del Altavoz...........34
Attaching the ptional Speaker Mic........8
Agregando el Micrófono de Altavoz Opcional ...34
IV. Control Buttons / peration Features.....9
IV. Botones de Control del Radio / Rasgos
de
Funcionamiento....................................35
V. Radio peration....................................10
V. Funcionamiento del Ra-

VII. CTCSS Tone Signaling..............................13
VII. Señal de Tonos de
CTCSS.................................40
VIII. CTCSS Tone Setup....................................14
VIII. Arreglo de Tonos de
CTCSS..............................41
IX. Channel Setting Confirmation..................17
IX. Confirmación de la Configuración
de Ca-
nal.....................................................45
Frequency Confirmation..........................17
Confirmación de la
Frecuencia........................45
CTCSS Tone Confirmation.......................18
Confirmación de Tonos de
CTCSS.....................45
X. Radio Functions.......................................19
X. Funciones del Ra-
dio........................................46
Time- ut-Timer (T- -T)..........................19
Temporizador de Tiempo Límite (T-O-
T)...........46
Battery Save...........................................19
Preservación de
Batería..................................4
Low Battery Warning..............................19
Aviso de Batería
Baja.....................................4 XI. Licensing,
Safety and Service Information.20
XI. Información de Autorización y Servicio...........48
FCC Licensing.......................................20
Licencia de la
FCC........................................48

I. CC R Exposure Compliance Requirements -
for Occupational Use Only
The Federal Communications Commission (FCC), with
its action in General Docket 93-62, November 7, 1997,
has adopted a safety standard for human exposure to
Radio Frequency (RF) electromagnetic energy emitted
by FCC regulated equipment. Topaz3 / Legacy subscribes
to the same safety standard for the use of its products.
Proper operation of this radio will result in user
exposure far below the ccupational Safety and Health
Act ( SHA) and Federal Communications Commission
limits.
CAUTION - D N T transmit for more than 50% of total
radio use time (50% duty cycle). Transmitting
more than 50% of the time can cause FCC
RF exposure compliance requirements to be
exceeded.
•This radio is N T approved for use by the general
population in an uncontrolled environment. This radio
is restricted to occupational use, work related operations
only where radio operator must have the knowledge to
control the users exposure conditions for satisfying the
higher exposure limit allowed for occupational use.
•When transmitting, hold the radio in a vertical position
with its microphone 2 inches (5 cm) away from your
mouth. Keep the antenna at least 2 inches (5 cm) from
your head and body.
•This device has been approved for use, at a maximum
duty factor of 50%, using the specific belt clip tested for
body-worn SAR compliance. ther belt clips or body-
1

I. CC R Exposure Compliance Requirements -
for Occupational Use Only, continued
worn accessories may not comply and should be
avoided. ALWAYS use Maxon, Legacy and TruTalk
authorized accessories: antennas, batteries, belt clips,
speaker mics, etc.
•The radio is transmitting when the red LED on the
front of the radio is illuminated. You can cause the radio
to transmit by pressing the P-T-T bar on the radio.
•These are required operating configurations for meeting
FCC RF exposure compliance. Failure to observe these
restrictions mean violation.
2

II. Unpacking and Checking Equipment
Carefully unpack the radio and its accessories. Use
the item list below to identify the components included
in the product packaging, to ensure that no items are
discarded in the packing materials.
Radio Body
Antenna
Battery Charger (with plastic spacer
stored in charger base)
AC Adapter
NiMH Battery Pack
Speaker Microphone Jack Cover
Belt Clip
Screw Set
perating Instructions
If any items are missing or damaged, you should
contact the Topaz3 Customer Service Department.
Dial 1-800-821-7848, Ext. 499 for assistance.
3

III. Getting Started
Charging the NiMH Battery Pack
You will need to charge the battery pack fully before
initial use. For best results from your charging cycle,
follow these tips:
• Ensure the ambient temperature is between 41 and
104 °F (5 and 40°C) while charging. Temperatures
outside this range may not fully charge the battery.
• Always switch FF the transceiver equipped with
a NiMH battery pack before charging. Using the
radio during the charging cycle will hinder correct
charging.
• Do not recharge the battery pack if it is already
fully charged. Doing so may cause the life of the
battery pack to shorten or the battery pack may
be damaged.
• If the battery is stored for 2 months or more, it is a
good idea to complete the charge / discharge cycle
two or three times to allow the battery capacity
to return to normal.
• Never dispose of the battery in fire - it can explode
causing personal injury.
• Never attempt to disassemble the battery or remove
its case material or charging contacts. Do not short
the battery terminals.
4

III. Getting Started, continued
Charging the NiMH Battery Pack, continued
N TE: The first few uses from the battery will not be
at normal capacity. After repeating the charge / dis-
charge cycle two or three times, the battery capacity
will increase to provide full capacity.
1. Plug the AC adapter cable in the adapter jack
located on the rear of the charger, then into
an AC outlet.
2. Slide the NiMH battery pack (or the radio equipped
with a NiMH battery pack) into the charging slot.
3. Ensure that the metal contacts on the battery pack
come in contact with the charging terminals.
4. When charging the NiMH battery pack alone, insert
the provided plastic spacer (stored in charger base)
into the charging well, then insert the battery pack.
5. The charger LED will light to advise that charging
has begun. Charge the standard battery pack for
9 hours. REM VE THE PACK R RADI
FR M THE CHARGER.
IMPORTANT NOTE: The charger DOES NOT
TURN O AUTOMATICALLY after the charging
cycle has been completed. Damage to the battery
or reduced battery life may result if charged in
excess of the recommended charging time.
5

III. Getting Started, continued
Attaching and Removing the Battery Pack
After recharging the battery pack, REM VE IT FR M
THE CHARGER.
The battery pack life is over when its operating time
decreases even though it is fully and correctly charged.
Replace the pack with the manufacturers recommended
model.
Average battery pack life from the supplied 750 mAh
battery is 11+ hours; the optional 1350 mAh battery,
19+ hours. This service time is calculated using 90%
standby, 5% transmit and 5% receive time.
After charging the battery pack as described, you are
ready to install it to the radio body. Simply;
1. Match the four grooves of the battery pack with the
guides on the back of the radio.
2. Slide the battery pack up along the back of the radio
until the release latch locks.
To remove the battery pack, push down on the release
latch and slide the pack downward, and away from the
radio.
6

III. Getting Started, continued
Installing the Antenna
Screw the antenna into the connector on the top of the
radio by holding the antenna at its base and turning
it clockwise until seated. Do not overtighten.
The antenna should never be used to carry your radio, or
as a base to clip radio accessories. Misuse of the antenna
can cause damage, and reduce your radios performance.
Installing the Belt Clip
We recommend that the belt clip is installed on the
radio. It keeps the radio from coming in contact with
hot surfaces, and away from your body if heat build-up
occurs with excess transmissions.
Use the two supplied screws to install the belt clip. If
a replacement is needed, use a screw designed to the
exact specifications as the original, to prevent acciden-
tal contact with internal circuitry, or possible personal
injury. Never use glue in conjunction with the provided
screws. Some of the glues components may crack the
radio back panel, causing radio damage and possible
personal injury.
Installing the Speaker Microphone Jack Cover
If you are not using an accessory, install the provided
cover over the speaker microphone jack using the screw
supplied. This will keep the radio water resistant.
7

III. Getting Started, continued
Attaching the Optional Speaker Microphone
1. Insert the speaker microphone jack into the radio.
2. Use the thumbscrew attachment on the speaker
microphone to make connection to the radio.
N TE: The radio is not fully water resistant while the
speaker microphone is attached.
8

IV. Radio Control Buttons / Operation eatures
A) Push-To-Talk (P-T-T) button (left side of radio)
Press and hold while speaking into the radio mic-
rophone, release to listen to incoming messages
B) Monitor button (left side of radio)
Press and hold to turn radio squelch off. Release
to turn squelch back on.
C) Microphone (front of radio)
D) Speaker (front of radio)
E) LED Indicator (top panel of radio)
Identifies transmit (red), receive (signal only) orange,
(signal + CTCSS) green, setup mode (orange), battery
low (flashing red)
) Power / volume control (top panel of radio)
Powers radio on and adjusts radio volume
G) Speaker microphone jack (right side of radio)
9
A
B
C
D
EF
G

V. Radio Operation
Power On / Transmit
Power on the radio by turning the power / volume
control clockwise out of detent. You will hear a
confirmation tone on power-up. To adjust radio
volume, press and hold the monitor button then
rotate the control further clockwise.
To transmit, place the radio microphone approximately
2 (5 cm) from your mouth then press and hold the
P-T-T bar while speaking in a normal tone. Release the
P-T-T bar when you are finished speaking; the radio
will be placed into receive mode.
If the battery pack voltage becomes too low for operation
to continue, transmission will stop and the top-panel
LED will blink red. Change or charge your battery to
continue radio operation. Refer to Low Battery Warning
on page 19.
10

V. Radio Operation, continued
N TE: The channel in use may have been programmed
with a signaling code. Refer to CTCSS Tone Signaling
on page 13.
Channels are pre-programmed with frequencies and
CTCSS tones. Refer to Factory Default Channel Settings
on page 18.
VI. Channel requency Selection
N TE: Read all steps before attempting this process,
as the radio will exit the setup mode if keypresses are
not performed within 5 seconds.
Change the channel frequency by using these steps:
1. Press and hold the P-T-T bar and monitor bar simul-
taneously, then turn the power N. Continue
to press both bars until the top-panel LED lights
orange. Release the P-T-T and monitor bars.
2. Press the P-T-T bar again. The LED now changes
from orange to red, and a beep sounds. The radio
is now in frequency setup mode.
3. You will press the P-T-T bar once for each frequency
selection. The P-T-T press will be accompanied
with a confirmation beep. There are a total of
8 different frequencies for the PL1145 radio,
defined on the next page.
11

VI. Channel requency Selection, continued
Action Channel No. Color
Beep Pattern Frequency ( Hz)
Press P-T-T 1 time (single beep) 1 464.5000 Brown
Press P-T-T 2 times (two beeps) 2 464.5500 Yellow
Press P-T-T 3 times (three beeps) 3 467.7625 J
Press P-T-T 4 times (four beeps) 4 467.8125 K
Press P-T-T 5 times (five beeps) 5 467.8500 Silver Star
Press P-T-T 6 times (long then short beep) 6 467.8750 Gold Star
Press P-T-T 7 times (long then 2 short beeps) 7 467.9000 Red Star
Press P-T-T 8 times (long then 3 short beeps) 8 467.9250 Blue Star
N TE: Pressing the P-T-T bar more than 8 times will
cause an error tone to sound, and no value will be
selected.
If you are a new licensee, please do not use frequencies
3 (Color J) and 4 (Color K). These two channels are
reserved for special and industrial use only, unless your
FCC license provides clearance for use of these channels.
4. Listen for the beep pattern of the selected frequency
number. This takes approximately 2 seconds.
5. Press the monitor bar to confirm the frequency
selection. The LED will show red, and blink twice.
6. Press the monitor bar again to confirm the beep
pattern of the selected frequency number.
12

VI. Channel requency Selection, continued
Example of setting a channel to frequency no. 5: After
entering frequency setup mode, press the P-T-T bar 5
times to select frequency 5 (Silver Star). A beep sounds
with each P-T-T press. Wait for 2 seconds to hear the
beep pattern of the frequency number. Five short beeps
sound. Press the monitor bar. The LED will show red
and blink twice. Press the monitor bar again. Five short
beeps sound to confirm that frequency 5 has been
selected.
VII. CTCSS Tone Signaling
CTCSS Tones prevent the radio from hearing signals
unless they match coded tones in your radio. When
a received signal has a code that matches your code,
squelch will open and you will hear the signal. When
a received signal has a code different from the
one set up in your radio, squelch will not open and
you will not hear the signal.
When you transmit on a channel set up with CTCSS,
the receiving station must have a matching code in
order to hear your signal.
CTCSS Tones are selected from 38 standard signaling
codes and 11 non-standard tones. Refer to the table
at top of next page.
13

VII. CTCSS Tone Signaling, continued
No. Freq. No. Freq. No. Freq. No. Freq.
01 67.0Hz 14 107.2Hz 27 167.9Hz 40 159. Hz
02 71.9 15 110.9 2 173. 41 171.3
03 74.4 16 114. 29 179.9 42 177.3
04 77.0 17 11 . 30 1 6.2 43 1 3.5
05 79.7 1 123.0 31 192. 44 1 9.9
06 2.5 19 127.3 32 203.5 45 196.6
07 5.4 20 131. 33 210.7 46 199.5
0 .5 21 136.5 34 21 .1 47 206.5
09 91.5 22 141.3 35 225.7 4 229.1
10 94. 23 146.2 36 233.6 49 254.1
11 97.4 24 151.4 37 241. 00 OFF
12 100.0 25 156.7 3 250.3
13 103.5 26 162.2 39 69.3
N TE: Selecting 00 will turn signaling FF.
VIII. CTCSS Tone Setup
Refer to the codes listed above, and remember:
1. When selecting a single digit number (0 - 9),
always use 2 digits (00 - 09).
2. When you are confirming the selected signaling
number, there will be a short pause between
the 10s digit and the 1s digit.
14

VIII. CTCSS Tone Setup, continued
N TE: Read all steps before attempting this process,
as the radio will exit the setup mode if keypresses are
not performed within 5 seconds.
1. Press and hold the P-T-T bar and monitor bar, then
turn the radio power N. Continue to press
both bars until the top-panel LED lights orange.
Release the P-T-T and monitor bars.
2. Press the monitor bar again. The LED will change
from orange to green and a beep sounds. The
radio is now in CTCSS tone set up mode.
3. Press the P-T-T bar to select the 10s digit of the
desired signaling number. Each time you press
the P-T-T bar, a beep sounds and the 10s digit
of the signaling number changes. There are a
total of 5 different numbers (0 - 4).
Action Value Beep Pattern
Press and hold P-T-T for 2-3 seconds 0 x 1-second tone
Press P-T-T 1 time 1 x single beep
Press P-T-T 2 times 2 x 2 single beeps
Press P-T-T 3 times 3 x 3 single beeps
Press P-T-T 4 times 4 x 4 single beeps
N TE: Pressing the P-T-T bar more than 5 times will
cause an error tone to sound, and no value will be
selected.
15
