LEGENDEX ROGUE M.O.L.L.E MR-MP-COL-1 User manual

LEGENDEX ROGUE M.O.L.L.E
PRODUCT CODE: MR-MP-COL-1
Holden Colorado Dash Panel Kit
LEGENDEX.COM.AU [phone]
PRODUCT CODE: MR-MP-COL-1

NUT M4 Hex Nut (1 spare) 5
WASHER M4 SS Washer (1 spare) 5
SPACER 6mm Nylon Spacer 4
TOOLS REQUIRED
Wear protective clothing including eye wear.
Clean Hands work best.
Disconnect the Battery to ensure you don’t earth out. Or Use an Auto-
electrician.
BOLT M4 X 30mm PH2 Button Head Screw 4
Phillips Head screwdriver
Small Spanner
Drill and Bits
Once you have unpacked the system from the box make sure you have all parts that are
listed on the packing list below.
MR-MP-COL-1 Dash Panel 1
CHECK YOUR PACK LIST
COMPONENTS
LEGENDEX.COM.AU [phone]
IMPORTANT
PRODUCT CODE: MR-MP-COL-1

STEP 1
STEP 2
Start with double-checking all the correct components and gathering the tools required.
Place MOLLE panel on top of lid in
desired location and mark mounting
holes with a felt tip pen
LEGENDEX.COM.AU [phone]
INSTALLING YOUR NEW ROGUE M.O.L.L.E
STEP 3
Open lid and remove front screws
shown in image
STEP 4
Remove front dash facia
PRODUCT CODE: MR-MP-COL-1

STEP 5
Remove Lid and hinge assembly from
the dash
LEGENDEX.COM.AU [phone]
INSTALLING YOUR NEW ROGUE M.O.L.L.E
STEP 6
Check the MOLLE panel against your
previously marked holes and drill
through with a 4.5mm drill bit.
Assemble the MOLLE panel with
provided spacers to your preferred
height
STEP 7
Fit and tighten the supplied nuts to
the back of the Dash lid
PRODUCT CODE: MR-MP-COL-1

STEP 8
Re-install hinge plate and lid to the
dash
LEGENDEX.COM.AU [phone]
INSTALLING YOUR NEW ROGUE M.O.L.L.E
STEP 9
Re-Assemble the facia and fit you
favourite accessories
STEP 10
Fit and tighten the supplied buts to
the back of the Dash lid
PRODUCT CODE: MR-MP-COL-1
