Leguan 135 NEO Operating manual

Operator and Service manual
Version 7/2020
July 2020

2
TABLE OF CONTENTS
INTRODUCTION AND WARRANTY CONDITIONS...........................................................4
INTRODUCTION .................................................................................................................... 4
WARRANTY CONDITIONS ........................................................................................................ 4
GENERAL INFORMATION..............................................................................................7
TECHNICAL SPECIFICATIONS..................................................................................................... 8
MAIN DIMENSIONS ............................................................................................................... 9
REACH DIAGRAM AND SUPPORT DIMENSIONS............................................................................ 10
SIGNS AND MARKINGS ......................................................................................................... 11
SAFETY INSTRUCTIONS...............................................................................................12
BEFORE USING THE MACHINE ................................................................................................ 12
RISK OF TIPPING OVER.......................................................................................................... 13
RISK OF FALLING................................................................................................................. 13
RISK OF COLLISION .............................................................................................................. 13
RISK OF ELECTRIC SHOCK....................................................................................................... 14
RISK OF FIRE /EXPLOSION..................................................................................................... 14
DAILY INSPECTIONS BEFORE STARTING WORK ............................................................................ 15
CONTROLS AND SWITCHES.........................................................................................16
CONTROL DEVICES ON THE PLATFORM ..................................................................................... 16
Platform overload indicator light................................................................................. 17
Dynamic outreach control signal light ......................................................................... 17
Fault light ................................................................................................................... 17
Inclination sensor indicator light ................................................................................. 18
Boom centre position indicator (slewing)..................................................................... 19
Boom transport support indicator light ....................................................................... 19
Low fuel level indicator ............................................................................................... 19
LOWER CONTROLS PANEL ..................................................................................................... 20
230 VCONNECTIONS AND SWITCHES ...................................................................................... 21
OPERATION ................................................................................................................22
STARTING THE COMBUSTION ENGINE /ELECTRIC MOTOR ............................................................. 22
Start-stop function...................................................................................................... 22
DRIVE .............................................................................................................................. 23
Determining the gradient of the slope......................................................................... 24
General information: tracks and their service life ........................................................ 24
Guidelines: Operating environment of an access platform with tracks ......................... 25
Guidelines: Operating an access platform with tracks.................................................. 25
USE OF OUTRIGGERS............................................................................................................ 26
Automatic levelling ..................................................................................................... 26
Manual levelling ......................................................................................................... 26
Setting the outriggers to transport position................................................................. 27
USE OF BOOMS .................................................................................................................. 28
Home-Function ........................................................................................................... 28
Back to work position.................................................................................................. 29
Boom Lift & Platform Tilt Without Outriggers.............................................................. 29
ENDING OPERATION ............................................................................................................ 29
ADDITIONAL INSTRUCTIONS FOR WINTER USE............................................................................ 30
BACK-UP LOWERING AND EMERGENCY USE ..............................................................31
BACK-UP LOWERING PROCEDURE ........................................................................................... 31
BACK-UP OPERATION OF OUTRIGGERS ..................................................................................... 31
OVERRIDE OF BOOM SAFETY FUNCTIONS WHEN MOTOR IS RUNNING .............................................. 32
Override of boom safety functions using the hand pump ............................................. 32
OVERRIDE OF DRIVE AND OUTRIGGER SAFETY FUNCTIONS ............................................................ 32

3
Override of transport position monitoring ................................................................... 33
OVERRIDE OF LOAD CONTROL AND PLATFORM EMERGENCY STOP SWITCH........................................ 33
EMERGENCY LOWERING WITHOUT POWER TO LOGIC CONTROLLER ................................................. 33
TRANSPORTATION......................................................................................................35
INSTRUCTIONS: SERVICE, MAINTENANCE AND INSPECTION......................................36
GENERAL INSTRUCTIONS....................................................................................................... 36
Battery handling ......................................................................................................... 36
Handling of fuel and oil products................................................................................. 37
SERVICE INSTRUCTIONS..............................................................................................38
MAINTENANCE AND INSPECTIONS,SERVICE SCHEDULE ................................................................ 38
Crawler track and 4WD wheel nuts ............................................................................. 39
GREASING......................................................................................................................... 40
Greasing diagram ....................................................................................................... 40
Greasing of the slew ring............................................................................................. 41
Greasing the telescopic boom chain pulley and inspection of the chain........................ 41
Greasing of Telescoping Booms................................................................................... 42
Greasing of the Position Sensor Pins on the Outriggers................................................ 42
HANDLING OF FUEL AND REFUELLING ...................................................................................... 43
HYDRAULIC OIL AND HYDRAULIC OIL FILTER REPLACEMENT ........................................................... 43
HYDRAULIC OIL LEVEL .......................................................................................................... 44
BATTERY CHECK.................................................................................................................. 44
FUNCTIONING OF SET UP SYSTEM ........................................................................................... 45
HYDRAULIC SYSTEM SETTINGS................................................................................................ 46
OVERLOAD PROTECTION COMPONENTS................................................................................... 47
ELECTRIC SENSORS .............................................................................................................. 48
Transport position monitoring................................................................................... 48
Levelling monitoring.................................................................................................. 49
INSPECTION OF THE TRACK TIGHTNESS AND ADJUSTMENT............................................................. 49
Adjustment of the tightness of the track.................................................................... 50
REPAIR INSTRUCTIONS...............................................................................................51
WELDING.......................................................................................................................... 51
INSTRUCTIONS FOR TEMPORARY STORAGE...............................................................52
INSTRUCTIONS FOR DISPOSING THE ACCESS PLATFORM...........................................53
TROUBLESHOOTING ...................................................................................................54
BLOCK DIAGRAMS FOR LEGUAN 135 NEO SAFETY FUNCTIONS..................................57
PERFORMED SERVICE .................................................................................................65
Appendices:
Hydraulic diagram
Electrical diagram
Owner’s Manual (Combustion engine)

4
INTRODUCTION AND WARRANTY CONDITIONS
Introduction
LEGUAN LIFTS wants to thank you for purchasing this LEGUAN access platform. It is the result of
Leguan’s long experience in design and manufacturing of access equipment.
We ask you to read and understand the contents of this manual completely before operating
the access platform. This will improve your operating and maintenance efficiency, help avoid
breakdowns and damage and extend the life of your machine.
Pay special attention to this symbol. It indicates important safety factors that
require special attention. Every operator must read and understand this
manual before commencing operation, and the instructions in this manual must
be followed. If you lend the access platform out to others, make sure that they
familiarise themselves with and understand these instructions. If there is
anything unclear with the operation, please contact your Leguan dealer.
If spare parts are needed, use only original LEGUAN parts. The strain that these parts are
subjected to is taken into account in their manufacture. They will provide your machine with
maximum life expectancy and ensure optimum safety.
It is not possible to give explicit operating instructions to all operating conditions of the
machine. Therefore, the manufacturer is not responsible for any damage caused by eventual
faults in this Operators Manual.
The manufacturer does not accept any responsibility for consequential losses resulting from the
use of this self-propelled access platform.
The lifespan of the track system of an access platform on rubber tracks is heavily dependent on
the working environment and work methods. If the access platform is being used on terrain
with stones or gravel, on demolition sites with concrete, or in an environment with scrap metal,
the lifespan of the track system may be significantly reduced. Therefore, damage to the tracks,
track rollers or crawler track chassis, caused by operation in such environments, is not covered
by warranty.
The machine operator can influence the service life of the tracks by complying with instructions
for their use and maintenance.
Warranty conditions
This product is under warranty for a period of twenty-four (24) months without restrictions on
operating hours. For battery products (e.g. starter battery, remote control battery) warranty is
twelve (12) months without restrictions on operating hours.
The warranty covers manufacturing and material defects. All warranty obligations end when
the warranty period ends. Warranty repair that has been started will be completed regardless
of the expiry date of the warranty period.

5
A condition for the warranty is that both the buyer and the seller have accepted the delivery. If
the buyer is not present when the delivery takes place and does not make a complaint within
14 days of delivery of this access platform, the sale is deemed closed and the warranty period is
then officially underway.
This warranty does not restrict the buyer’s legal right to submit a complaint about a flaw in the
purchased product.
Warranty is limited to the repair of a faulty access platform without cost at an authorised
Leguan service workshop. The warranty period for parts that are changed in connection with
the repair will end when the warranty period for the access platform ends. Parts that have been
changed in the warranty repair will remain Leguan Lifts’ property without compensation.
The warranty does not cover the following situations:
-inappropriate use of the product
-changes and repair work performed without consent from the manufacturer
-insufficient or flawed maintenance
-machine breakdowns due to causes other than a manufacturing error
-acts of vandalism
-adjustments, repair and the replacement of parts due to normal wear and tear, negligent use
or non-compliance with the instructions for use
-exceptional strain placed on the access platform, sudden and unforeseeable events, natural
disasters
-external, mechanical or chemical causes (damage to the paintwork, such as scratches and
abrasions caused by flying stones, pollution and environmental impurities, strong detergents,
or by lifting operations or lifting equipment)
-alterations, repair or reinstallation performed without consent from the manufacturer or
dealer
-any patterns or uneven patches on the paintwork
-if the warranty claim is not submitted within reasonable time of the buyer observing the flaw
or when the flaw should have been noticed. Notification must always be submitted within two
(2) weeks of the buyer noticing the defect. - under all circumstances, the buyer must act so
that his action does not make the defect(s) worse
-the manufacturer does not accept any responsibility for consequential losses resulting from
the use of this access platform
In the event a fault occurs that is attributable to manufacturing or assembly defect, contact the
dealer without delay.

6
ALKUPERÄINEN EY-VAATIMUSTENMUKAISUUSVAKUUTUS
ORIGINAL EC DECLARATION OF CONFORMITY FOR MACHINERY
TÄTEN VAKUUTAMME, ETTÄ
HEREWITH DECLARES THAT
HENKILÖNOSTIN NIMELLISKUORMA
AERIAL PLATFORM NOMINAL LOAD
MALLI NOSTOKORKEUS
MODEL PLATFORM HEIGHT
SARJANUMERO VALMISTUSVUOSI
SERIAL NR YEAR OF CONSTRUCTION
ON KONEDIREKTIIVIN 2006/42/EY ASIAAN KUUULUVIEN SÄÄNNÖSTEN MUKAINEN
IS IN ACCORDANCE WITH THE REGULATIONS LAID OUT IN THE MACHINERY DIRECTIVE:
2006/42/EC
KONE TÄYTTÄÄ LISÄKSI MUIDEN EY-DIREKTIIVIN VAATIMUKSET: 2004/108/EY
THE MACHINE ALSO FULFILLS THE REQUIREMENTS LAID OUT IN THE DIRECTIVES:
2004/108/EC
SEURAAVIA EUROOPPALAISIA YHDENMUKAISIA STANDARDEJA ON SOVELLETTU
SUUNNITTELUSSA: EN280:2013+A1:2015
FOLLOWING EUROPEAN HARMONIZED STANDARDS ARE USED WHEN THE MACHINERY WAS
DESIGNED: EN280:2013+A1:2015
Teknisen tiedoston on valtuutettu kokoamaan: LEGUAN LIFTS OY
Storage address of original documents: Ylötie 1, FI-33470 Ylöjärvi,
Finland
Ilmoitettu laitos / Notified Body INSPECTA TARKASTUS OY,
NB0424
Hyväksyntätodistus / Certificate 19074-2019
Paikka / Place Ylöjärvi, FINLAND
Päiväys / Date dd.mm.20yy
Valmistaja / Manufacturer:
Ylötie 10, FI-33470 Ylöjärvi, Finland
____________________________________
xxxx
Toimitusjohtaja / Managing Director
LEGUAN
135 NEO
250 kg
11,4 m
007xxxx
20xx

7
GENERAL INFORMATION
LEGUAN 135 NEO is a self-propelled Mobile Elevating Work Platform –commonly called an
‘access platform’, designed for indoor and outdoor use. Access platforms are designed for the
lifting of persons and their equipment only. Using an access platform as a crane is prohibited.
LEGUAN 135 NEO is designed and built in accordance with the international safety standards
and MEWP (Mobile Elevating Work Platform) standards.
The figure below shows the machine’s main parts. Except for its track system, the track-
equipped machine is similar in structure to a device with wheels.
1. Chassis
a. Extra side weight (4WD) or
Track frame (TRD)
2. Transmission, with wheels or crawler
tracks
3. Outrigger
4. Outrigger cylinder
5. Combustion engine
6. Lower boom
7. Boom lift cylinder
8. Upper boom
9. Telescope cylinder
10. Push lever
11. Upper rod
b. Tool box
12. Control valve box
13. Transport support
14. Lower control panel, control box
15. Electric motor
16. Middle boom
17. Extension
18. Platform control box
19. Platform
20. Levelling cylinder
21. JIB-boom
22. JIB push rod
Figure 1 Leguan 135 NEO main parts

8
Technical specifications
Working height
13.4 m
Max. platform height
11.4 m
Max. outreach @ 120 kg
7.1 m
Max. outreach @ 250 kg
6.6 m
Safe working load
250 kg
Transport length
4.55 m
Transport length without platform
3.85 m
Transport height
1.93 m
Width, without platform and outrigger plates
0.89 m
with platform
1.33 m
Platform dimensions, W x L, 2 persons
1.33 x 0.75 m
Max. allowed levelling inaccuracy
1.0º
Platform rotation
± 40º
Slewing
360º
Gradeability
50 % (27º)
Gradeability sideways
28 % (16º)
Support dimensions
3.07 x 3.14 m
Max. gradient of slope for set up
22 % (12º)
Weight, depending on equipment
1650 kg
Drive system, hydraulic
4WD or tracks
Drive speed
max. 2.5 km/h
Lowest operating temperature
-20 °C (storage -40 °C)
Starter battery / electric system
60 Ah / 12V
Sound power level at control position, LWA
92.5 dB (A)
Max. outrigger force
12,5 kN
Max. load under wheels
0.3 N/mm2 (3 bar)
Vibration emission, awmax
(uncertainty K=0.3 m/s2)
0.6 m/s2

9
Main dimensions
Figure 2 135 NEO Main dimensions, side
Figure 3 135 NEO main dimensions, rear

10
Reach diagram and support dimensions
Figure 4 Reach diagram
Figure 5 Support dimensions

11
Signs and markings
1. Type plate and CE-marking
2. Safe working load (SWL)
3. Control symbols decal
4. Max. horizontal force and wind
speed
5. Max. outrigger force
6. Distance from energized electric
wires
7. General user instructions
8. Daily inspection
9. Emergency lowering (2)
10. Residual current device
11. Electric motor voltage
12. Tie down points (4)
13. Tyre pressure
14. Leguan 135 decal
15. Lower controls’ decal
16. Lift points (4)
Figure 6 Signs and decals

12
SAFETY INSTRUCTIONS
The operator must know and follow all safety instructions. The operator must receive sufficient
instructions in order to be able to use the lift correctly and safely. This Operator’s Manual must
always be kept in the machine.
To prevent unauthorised use of the access platform, take the main switch key with you after
concluding operation if the machine is left unsupervised.
NOTE! DANGER!
When working with the access platform, it is recommended that the
operator(s) always wear a certified safety harness that is properly
connected to the attachment points. Always follow local rules and
regulations regarding workplace safety and use of access platforms!
This access platform is not electrically insulated. Never use it near any live
parts or wires.
Before using the machine
-read the instructions for use carefully before operating the machine.
-only persons aged 18 or older who have received sufficient training may use the access
platform.
-the operator must know all the functions of this access platform as well as its Rated Load,
loading instructions and safety instructions.
-if there is heavy traffic in the working area, it must be fenced off and marked with a fence or
line. Road traffic regulations must be followed as well.
-make sure that there are no bystanders in the working area.
-do not use a faulty access platform. Submit notifications about all faults and defects and make
sure that they are repaired before commencing operation.
-follow inspection and service instructions and intervals.
-the operator must check the access platform visually at the beginning of each work shift. This
check is necessary to make sure that the machine is in working order before making the daily
inspection prior to commencing operation.
-if a combustion engine is used indoors, make sure that the space is appropriately ventilated

13
Risk of tipping over
-Exceeding the access platform’s maximum load or additional load or the maximum number of
people permitted on the platform is strictly prohibited.
-When wind speed is equal to or greater than 12.5 m/s (28 mph), the use of the access platform
must be discontinued immediately, and the platform must be lowered down to the transport
position.
-Ensure that the access platform is used on dry, solid, level ground only. The ground is solid
enough if it can carry min. 3 kg/cm2. On softer ground, use extra support plates under the
outriggers.
-Do not use a ladder, chair, stool, scaffolding or any other means to increase the reach
capability of this access platform.
-If the platform gets stuck or jammed, or it is too close to a building or a wall to be moved, do
not try to release the platform by operating the controls. All persons must leave the platform
first (with the help of a rescue service or fire brigade if necessary), only after that one can try
to lower the platform by using the emergency lowering.
-Do not increase the area of the platform or the load. Increasing the area exposed to wind
weakens the stability of the access platform.
-Weight must be equally distributed across the platform. Make sure that additional weight
cannot shift on the platform.
-Do not drive on gradients that are steeper than the max. values given for this access platform
and for the slope.
-Never use this access platform as a crane. This access platform is intended for lifting the max.
allowed number of persons and additional load only.
-Check and make sure that all tyres are in good condition. If the tyres are full of air, make sure
that there is correct pressure in the tyres.
-To ensure the safe operation of this access platform the manufacturer has conducted
approved tests for the LEGUAN 135 NEO in accordance with the standard EN
280:2013+A1:2015 static stability test in accordance with paragraph 6.1.4.2.1 and dynamic
overload test in accordance with paragraph 6.1.4.3 of the EN 280:2013+A1:2015.
Risk of falling
-When working with the access platform, the operator(s) should always wear a certified safety
harness which is properly connected to the platform.
-Do not stretch or reach out over the handrails. Stand steadily on the platform floor.
-It is not allowed to go to or step out from the platform when the booms are lifted.
-Keep the platform floor clean.
-Always close the platform gate before commencing operation.
Risk of collision
-Adjust the drive speed so that it is safe with regard to the ground conditions.
-When operating the lift, take into account that visibility may be limited
-The operator must follow all regulations concerning the use of safety equipment on the work
site

14
-Make sure that there are no overhead obstacles on the work site that could prohibit lifting of
the platform, or objects that might cause a collision
-Do not operate this access platform in the working area of another overhead lifting device or
similar equipment that is moving, unless this lifting device is secured so that there is no risk of
collision
-Beware of crushing hazard when holding the handrail of the platform in a potential collision
situation
-When operating the lift, beware of limited visibility and trapping hazard.
Risk of electric shock
-This machine is not insulated from voltage or protected against contact with live parts
-Do not touch the machine if it comes in contact with a live electric line
-Persons on the platform or at ground level must not touch or operate the machine before
power has been cut off from the electric line
-During welding repairs, using any part of this access platform as an earth conductor is
prohibited
-Do not use this access platform during a thunderstorm or in high winds
-Leave clearance for electric lines, taking into account movements of the platform, movements
of electric lines, and high winds and gusts.
The minimum safety clearances for overhead cables are shown in the following table. The
clearances for the most commonly used voltages in overhead lines are as follows, use these
safety clearances if national or local regulations are not available:
VOLTAGE MIN. DISTANCE
0 –1,000 V 2 m
1 –45 kV 3 m
110 kV 5 m
220 kV 5 m
400 kV 5 m
Risk of fire / explosion
-The machine must not be started in a place where one can smell LPG, petrol, solvent or other
flammable substance
-Do not add fuel when the engine is running or hot
-Charge the battery only in places with sufficient ventilation, where there is no open fire and
no activity which could cause spark emissions (such as welding).

15
Daily inspections before starting work
-ground
-supports
-horizontal position
-emergency stop button
-emergency lowering
-control devices
-access routes
-platform
-oil leakage
-work area
NOTE!
If you notice faults or missing equipment on this access platform, do not
use the machine before the faults have been corrected. Never set the
access platform up in a place where the ground may be too soft. Beware of
soft ground and potholes.

16
CONTROLS AND SWITCHES
Control devices on the platform
The platform’s controls and indicators on the control panel may be slightly different in different
models. Indicators and switches that are marked as optional are not installed on all models.
Figure 7 Platform control panel
1. Lowering button
2. Emergency stop switch
3. Horn / platform work lights (option)
4. Back to work position / Home -
Switch
5. Platform tilt enabler button
6. Platform rotation
7. Telescope in/out buttons
8. Joystick
9. Platform overload indicator
10. Outreach control indicator
11. Fault light
12. Boom centre position indicator
13. Boom transport position indicator
14. Low fuel indicator
15. Inclination sensor indicator
16. Outrigger switches (manual)
17. Automatic levelling switches
18. Automatic levelling indication light
(light blinks) / boom use allowed
(light on)
19. Combustion engine / electric motor
start/stop switch
20. Automatic start / stop function
indicator light
21. Speed selection / manual choke
switch

17
Platform overload indicator light
This access platform is equipped with automatic platform overload
system which prevents all boom movements in case the 250 kg rated load
is exceeded. Should this happen, there is an audible warning signal and an
indicator light up at the control panel (Figure 7 (10)).The booms can be
operated again after the overload has been removed from the platform.
If platform overload goes on while platform is moving then lift down, telescope in and slewing
functions are enabled to release the overload situation. If platform overload goes on while
platform is stationary, all movements are disabled until overload is removed.
NEVER OVERLOAD THE PLATFORM!
Dynamic outreach control signal light
This access platform is equipped with dynamic outreach control.
Outreach depends on the actual load on the platform.
-Red dynamic outreach control signal light (Figure 7 (11)) will blink and
an audible sound alarm can be heard when the telescope boom is
about to reach the current maximum outreach.
-The frequency of the blinking light as well as the audible sound will increase as the telescopic
boom closes the maximum outreach.
-When the maximum outreach is achieved red dynamic outreach control signal light will stay
continuously on and:
-Telescope boom movement out is prevented.
-Continuous audible sound will signal that the maximum outreach is achieved.
-If boom is moved while dynamic outreach light is on then telescope reverses automatically if
current outreach is above limits.
Move telescope in to decrease outreach.
Fault light
The fault light will signal errors and faults on the equipment. Possible
faults are divided into two categories based on their severity.
When an ERROR occurs, the red fault light will BLINK.
-Equipment can be used with extreme caution.
-Some features are prevented.
-If the red fault light blinks, return booms onto their transport positions, perform daily
inspection and remove possible cause of the error.
-If the problem persists, contact your Leguan dealer.
When a FAULT occurs, the red fault light will stay ON continuously.
-Ensure neither emergency stop button is pushed down.

18
-If the emergency buttons are not active, one of the safety components has failed and
prevented the use of the equipment.
-Return booms on their transport supports, stop working with the equipment and contact
your local Leguan dealer.
Possible errors and faults can be diagnosed with a separate service display (option).
Fault light BLINKS_INTERMITTENT (option).
-Hydraulic oil overheats
-Stop using the machine and let it cool down
-Audible signal is given only when machine is running
Inclination sensor indicator light
This access platform is equipped with inclination sensor which alerts when
the inclination of the chassis exceeds the given limits.
If the limits are exceeded while driving an orange indicator light will blink
and give an audible alert can be heard. Drive the machine to more even
surface.
While using booms:
If the ALARM limit is exceeded:
-Orange indicator light will blink, and an audible alert can be heard.
-Return all booms CAREFULLY on to their transport support
-Check that the ground is solid enough
-Re-level
Do not reach, slew or lift the booms when the inclination alert light is on!
RISK OF TIPPING OVER!

19
Boom centre position indicator (slewing)
The slew ring of the access platform is equipped with inductive sensor which
lights the green boom centre position indicator light whenever the 1st boom
is above the transport support. Indicator light is only an aid and does not
guarantee that booms will lower straight to transport supports.
Boom centre position light is blinking when boom is nearby its centre
position. Automatic levelling up is disabled to prevent collisions on outriggers up position.
Use outriggers only when boom center position light is on!
Always visually ensure that the booms are properly placed on their
transport supports!
Boom transport support indicator light
Boom transport support indicator light will stay continuously green when all
booms are properly placed on their transport supports.
Boom transport position light is in blinking when boom is on raised transport
position. This situation is used to cross high obstacles. Driving is possible on
lowered speed. Automatic levelling is disabled but manual levelling is
allowed. Return booms back to transport position when raised position is not required.
Low fuel level indicator
Low fuel level indicator lights up when the fuel level is low (approx. 1.5 l).
When the low fuel indicator light is lit refuel as soon as possible.
Fuel tank capacity is 6,1 l.

20
Lower controls panel
Figure 8 Lower controls panel
1. Hour meter
2. Safety functions override switch
3. Emergency stop switch
4. Indicator lights
-Inclination sensor
-Platform overload
-Dynamic outreach control
5. Remote control selection switch
6. Combustion engine / electric
motor start switch
7. Ignition key / upper/lower
controls selector switch
8. Boom raise switch / choke
9. Telescope in/out switch
10. Boom rotation switch
11. Platform tilt switch
12. Home switch / lowering
13. Speed selector switch (dead
man’s switch)
Functioning of the lower control:
1. The ignition key (figure 8, switch 7) must be turned to lower control position
2. Turn on combustion engine or electric motor with the start switch (figure 8, switch 6)
3. To use the booms (figure 8, switches 8-11), you must also select movement speed with the
speed selector switch (switch 13).
-The speed selector also works as a dead man’s switch, so it must be kept turned to the
desired speed ( or ) when using the booms.
When the work takes place in an area that is open to the public, the ignition key should be
removed to prevent unauthorised use and the machine can only be used from the platform.
NOTE! The emergency stop buttons of the lower control and platform
panels function regardless of which control mode is selected.
