Leica Zeno GG04 plus User manual
Leica Zeno GG04 plus
User Manual
Version 1.3
English
Introduction
Congratulations on the purchase of the Leica Zeno GG04 plus.
This manual contains important safety directions as well as instructions for
setting up the product and operating it. Refer to "1 Safety Directions" for fur-
ther information.
Read carefully through the User Manual before you switch on the product.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
•Windows is a registered trademark of Microsoft Corporation in the United
States and other countries
•Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
•Android™ is a trademark of Google Inc.
•Apple, iPad, iPad Air, iPad Pro, and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries.
•Use of the Made for Apple badge means that an accessory has been
designed to connect specically to the Apple product(s) identied in the
badge, and has been certied by the developer to meet Apple perform-
ance standards. Apple is not responsible for the operation of this device
or its compliance with safety and regulatory standards.
•iOS is a trademark or registered trademark of Cisco in the U.S. and other
countries and is used under license.
All other trademarks are the property of their respective owners.
This manual applies to all models of the Leica GG04 plus GNSS instrument.
Where there are differences between the various instruments they are clearly
described.
Name Description/Format
Leica
GG04 plus
Quick Guide
Provides an overview of the product together with
technical data and safety directions. Intended as a
quick reference guide.
ü ü
Leica
GG04 plus
User Manual
All instructions required in order to operate the
product to a basic level are contained in the User
Manual. Provides an overview of the product
together with technical data and safety directions.
-ü
Refer to the myWorld web page for all GG04 plus documentation/soft-
ware:
•https://myworld.leica-geosystems.com
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com)
offers a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
Purchase
Product identication
Trademarks
Validity of this
manual
Available
documentation
2
Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
ticates and service reports.
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myTraining Enhance your product knowledge with Leica Geosys-
tems Campus - Information, Knowledge, Training.
Study the latest online training material on your
products and register for seminars or courses in
your country.
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workow
and increase your efciency.
3
Table of Contents
1 Safety Directions 5
1.1 General Introduction 5
1.2 Denition of Use 6
1.3 Limits of Use 6
1.4 Responsibilities 6
1.5 Hazards of Use 7
1.6 Electromagnetic Compatibility (EMC) 11
1.7 FCC Statement, Applicable in U.S. 13
1.8 ISED Statements (EN/FR), Applicable in Canada 14
2 Description of the System 15
2.1 General Information 15
2.2 System Components 15
2.3 Data Collection 17
2.4 Power Concept 17
2.5 Leica Zeno GIS Software 17
2.6 Accessories 18
3 Operation 19
3.1 Guidelines for Correct Results with GNSS Surveys 19
3.2 Batteries 19
3.2.1 Operating Principles 19
3.2.2 Battery for GG04 plus 19
3.3 Equipment Setup as a Real-Time Rover 20
3.3.1 Setup with Leica Zeno GIS Hardware and Software 20
3.3.2 Setup with Third-Party Mobile Devices 21
3.4 Connection with Leica Zeno GIS Software 22
3.5 Correction Service Spot Lite and Spot Prime (PPP) 25
4 Care and Transport 27
4.1 Transport 27
4.2 Storage 27
4.3 Cleaning and Drying 27
5 Technical Data 29
5.1 Tracking Characteristics GG04 plus 29
5.2 Accuracy 29
5.3 Technical Data 30
5.4 Conformity to National Regulations 31
5.4.1 Dangerous Goods Regulations 32
6 Software Licence Agreement 33
Appendix A Firmware Upgrade 34
Appendix B Pin Assignments and Sockets 35
4 Table of Contents
1 Safety Directions
1.1 General Introduction
The following directions enable the person responsible for the product, and
the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the fol-
lowing table with the different signal words and their denitions! Supplemen-
tary safety information symbols may be placed within a warning message as
well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in appreciable material, nancial
and environmental damage.
☞Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efcient manner.
Description
About warning
messages
Safety Directions 5
1.2 Denition of Use
•Measuring raw data using carrier phase and code signal from GNSS satel-
lites.
•Computing with software.
•Recording measurements.
•Recording GNSS and point related data.
•Carrying out measurement tasks using various GNSS measuring techni-
ques.
•Data communication with external appliances.
•Use of the product without instruction.
•Use outside of the intended use and limits.
•Disabling safety systems.
•Removal of hazard notices.
•Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions.
•Modication or conversion of the product.
•Use after misappropriation.
•Use of products with recognisable damage or defects.
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
•Inadequate safeguards at the working site.
•Controlling of machines, moving objects or similar monitoring application
without additional control and safety installations.
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion: not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or simi-
lar situations
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the per-
son responsible for the product before working in such conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the User Man-
ual and original accessories, in a safe condition.
Intended use
Reasonably
foreseeable misuse
Environment
Manufacturer of the
product
6 Safety Directions
The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the User Manual.
•To ensure that it is used in accordance with the instructions.
•To be familiar with local regulations relating to safety and accident pre-
vention.
•To inform Leica Geosystems immediately if the product and the applica-
tion becomes unsafe.
•To ensure that the national laws, regulations and conditions for the oper-
ation of the product are respected.
1.5 Hazards of Use
DANGER
Risk of electrocution
Because of the risk of electrocution, it is dangerous to use poles, levelling
staffs and extensions in the vicinity of electrical installations such as power
cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, rst contact the safety authorities responsible
for the electrical installations and follow their instructions.
Person responsible
for the product
Safety Directions 7
DANGER
Risk of being struck by lightning
If the product is used with accessories, for example on masts, staffs, poles,
you may increase the risk of being struck by lightning. Danger from high vol-
tages also exists near power lines. Lightning, voltage peaks, or the touching of
power lines can cause damage, injury and death.
Precautions:
▶Do not use the product in a thunderstorm as you can increase the risk of
being struck by lightning.
▶Be sure to remain at a safe distance from electrical installations. Do not
use the product directly under or close to power lines. If it is essential to
work in such an environment contact the safety authorities responsible
for electrical installations and follow their instructions.
▶If the product has to be permanently mounted in an exposed location, it is
advisable to provide a lightning conductor system. A suggestion on how to
design a lightning conductor for the product is given below. Always follow
the regulations in force in your country regarding grounding antennas and
masts. These installations must be carried out by an authorised specialist.
▶To prevent damages due to indirect lightning strikes (voltage spikes)
cables, for example for antenna, power source or modem should be pro-
tected with appropriate protection elements, like a lightning arrester.
These installations must be carried out by an authorised specialist.
▶If there is a risk of a thunderstorm, or if the equipment is to remain
unused and unattended for a long period, protect your product addition-
ally by unplugging all systems components and disconnecting all connect-
ing cables and supply cables, for example, instrument - antenna.
WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a dan-
ger of accidents occurring if the user does not pay attention to the environ-
mental conditions around, for example obstacles, excavations or trafc.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
WARNING
Inadequate securing of the working site
This can lead to dangerous situations, for example in trafc, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
trafc.
8 Safety Directions
WARNING
Lightning strike
If the product is used with accessories, for example masts, staffs, poles, you
may increase the risk of being struck by lightning.
Precautions:
▶Do not use the product in a thunderstorm.
WARNING
Exposure of batteries to high mechanical stress, high ambient tempera-
tures or immersion into uids
This can cause leakage, re or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical inuences and high ambient tem-
peratures. Do not drop or immerse batteries into uids.
WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or re, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with met-
allic objects.
WARNING
Incorrect fastening of the external antenna
Incorrect fastening of the external antenna to vehicles or transporters poses
the risk of the equipment being broken by mechanical inuence, vibration or
airstream. This may result in accident and physical injury.
Precautions:
▶Attach the external antenna professionally. The external antenna must be
secured additionally, for example by use of a safety cord. Ensure that the
mounting device is correctly mounted and able to carry the weight of the
external antenna (>1 kg) safely.
Safety Directions 9
WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environ-
ment liable to contamination.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specic treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair
knowledge.
Precautions:
▶Only authorised Leica Geosystems Service Centres are entitled to repair
these products.
CAUTION
Not properly secured accessories
If the accessories used with the product are not properly secured and the
product is subjected to mechanical shock, for example blows or falling, the
product may be damaged or people can sustain injury.
Precautions:
▶When setting up the product, make sure that the accessories are correctly
adapted, tted, secured, and locked in position.
▶Avoid subjecting the product to mechanical stress.
10 Safety Directions
WARNING
Inappropriate mechanical inuences to batteries
During the transport, shipping or disposal of batteries it is possible for inap-
propriate mechanical inuences to constitute a re hazard.
Precautions:
▶Before shipping the product or disposing it, discharge the batteries by the
product until they are at.
▶When transporting or shipping batteries, the person in charge of the
product must ensure that the applicable national and international rules
and regulations are observed.
▶Before transportation or shipping, contact your local passenger or freight
transport company.
For the AC/DC power supply and the battery charger:
WARNING
Electric shock due to use under wet and severe conditions
If unit becomes wet it may cause you to receive an electric shock.
Precautions:
▶If the product becomes humid, it must not be used!
▶Use the product only in dry environments, for example in buildings or
vehicles.
▶Protect the product against humidity.
For the AC/DC power supply and the battery charger:
WARNING
Unauthorised opening of the product
Either of the following actions may cause you to receive an electric shock:
•Touching live components
•Using the product after incorrect attempts were made to carry out repairs.
Precautions:
▶Do not open the product!
▶Only Leica Geosystems authorised service centres are entitled to repair
these products.
1.6 Electromagnetic Compatibility (EMC)
The term Electromagnetic Compatibility is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radia-
tion and electrostatic discharges are present, and without causing electromag-
netic disturbances to other equipment.
Description
Safety Directions 11
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely
exclude the possibility that other equipment may be disturbed.
CAUTION
Use of the product with accessories from other manufacturers. For
example eld computers, personal computers or other electronic equip-
ment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, they meet the strict requirements
stipulated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment,
pay attention to the information about electromagnetic compatibility pro-
vided by the manufacturer.
CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possi-
bility that function of the product may be disturbed in such an electromag-
netic environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables attached at only one of their
two ends, for example external supply cables, interface cables, the permitted
level of electromagnetic radiation may be exceeded and the correct function-
ing of other products may be impaired.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery, product to computer, must be connected at both ends.
12 Safety Directions
WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic elds can cause disturbances in other equipment, in installa-
tions, in medical devices, for example pacemakers or hearing aids and in air-
crafts. Electromagnetic elds can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems AG cannot completely
exclude the possibility that other equipment can be disturbed or that
humans or animals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of lling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near to medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircrafts.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
☞This warning also applies when using products with Bluetooth.
1.7 FCC Statement, Applicable in U.S.
WARNING
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modications not expressly approved by Leica Geosystems for
compliance could void the user's authority to operate the equipment.
Radios, digital cellular
phones or products
with Bluetooth
Safety Directions 13
FCC ID: RFD-SAGG04P
IC: 3177A-SAGG04P
R 202-SMF096
IP66
IP68
Model: GG04 plus Art.No.: 123456
Equip. No.: XXXXXX S.No.: XXXXXX
Power: 7.4V --- nominal / 0.5 A max.
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured: 20XX
Made in Switzerland
0015185_003
005044_002
005044
_002
Made in China
Type: GEB212
2ICR19/66
Art. No.: 772806
7.4V /2.6 Ah
10A 19Wh XXXXXXXX-XXXXXX
A/S:+82 31 620 6252
Leica Geosystems AG, CH-9435 Heerbrugg
Li-Ion Battery
5A/130 C
S. No.:10412 전지
Manufactured by Huizhou Longji Electronics Co., Ltd.
1.8 ISED Statements (EN/FR), Applicable in Canada
WARNING
This Class (B) digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe (B) est conforme à la norme NMB-003
du Canada.
Canada Compliance Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions:
1.This device may not cause interference.
2.This device must accept any interference, including interference that
may cause undesired operation of the device.
Canada Déclaration de Conformité
L’émetteur/récepteur exempt de licence contenu dans le présent appareil
est conforme aux CNR d’Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes:
1.L’appareil ne doit pas produire de brouillage;
2.L’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
Labelling GG04 plus
Labelling internal
battery GEB212
14 Safety Directions
2 Description of the System
2.1 General Information
The instrument
•Is designed to be used on a pole. It calculates a position from the compu-
ted ranges to all visible and activated GNSS (Global Navigation Satellite
System) satellites.
•Can be used with any existing Leica Zeno GIS hardware, like the
Zeno Tab 1, Zeno Tab 2, CS25, CS25 plus, CS25 GNSS, CS25 LRBT, Zeno 5,
Zeno 10, Zeno 15 or with the following third-party hardware in combina-
tion with Zeno Connect and Zeno Mobile:
•Selected Android phones with Android version > 4.1,
•Selected Android tablets with Android version > 4.1,
•Windows 7/8/10 PC/Laptop,
•Compatible with iPhone, and iPad.
•Can communicate with Leica Zeno GIS software:
•Zeno Mobile,
•Zeno Connect (compatible with Windows 7/8/10, Android version
> 4.1 or iPhone, and iPad), or
•Zeno Field
•With the help of Zeno Connect can be used with third-party applications.
•Can be congured to track all currently available satellite systems with all
included signals (multi-frequency and multi-satellite system).
•Can increase positioning accuracy through various correction services, like
SBAS, RTCM corrections or Spot options (Precise Point Positioning - PPP -
coming by L-band satellites).
•Can provide NMEA messages output on different Bluetooth ports to allow
reviewing and storing of GNSS metadata information.
The instrument contains several special features:
•Robust instrument with integrated antenna and built-in ground plane.
•Low power consumption.
•Simple mounting.
•Seamless integration with all available Leica Zeno GIS software.
•LED indicators for power, Bluetooth and signal reception.
•Multiple upgrade options.
The instrument is delivered with the latest rmware version installed. If a new
rmware version is released at a later point in time, use the Leica Zeno GIS
software on Windows to upload this version by a Bluetooth connection.
Refer to "A Firmware Upgrade" for rmware upgrade of the instrument.
☞To ensure best tracking performance, verify to have the most recent
Leica Zeno GIS rmware installed on the instrument.
2.2 System Components
The GG04 plus represents the so called instrument.
Component Description
Integrated antenna Receiving signals from a GNSS (Global Navigation
Satellite System).
Design
Special features
Firmware concept
Main components
Description of the System 15
Component Description
Bluetooth To wireless pair with Leica Zeno GIS or third-party
hardware.
Battery The battery compartment holds the GEB212 battery
for power supply.
LEDs Indication of power, Bluetooth and signal reception.
LEMO-1 connector Serial by RS232 or USB communication.
5/8" Whitworth
thread
Mounting the instrument for observation.
012209_001
c
d
a
b
e
f
g
a LEMO-1 connector,
RS232 and USB port
b Whitworth thread, for
instrument mounting
c Tracking LED
d Bluetooth LED
e Power LED
f ON/OFF key
g Battery compartment
Do not open the instrument or remove any connector as this action impairs
the protection against water, dust and sand. Open the instrument for battery
handling without exception in dry and clean conditions only.
The GG04 plus has Light Emitting Diode indicators. They indicate the basic
instrument status.
abc
012264_002
a Tracking LED
b Bluetooth LED
c Power LED
Description of the LEDs
LED LED Status Status of the Instrument
Tracking Green Enough satellites tracked to compute posi-
tion.
Dark No position computed.
Bluetooth Green The antenna is ready to be connected to.
Blue Connection established to a Bluetooth device.
Power Off Power is off.
Green Power level is good.
Red Power level is low.
Interface
☞
LED Indicators
16 Description of the System
LED LED Status Status of the Instrument
Flashing red Power level is critical.
2.3 Data Collection
The instrument can be connected with Leica Zeno GIS software and Leica Zeno
hardware or selected Android, iOS or Windows software and devices to collect
or verify assets in the eld and to collect raw data. Our software and ofce
software fully supports the collected GG04 plus data either to review and
adapt or to post-process collected raw data. The setting for the GG04 plus
Smart Antenna can be adjusted with different provided tools.
2.4 Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosys-
tems to ensure the correct functionality of the instrument.
Power for the instrument can be supplied internally only.
Internal power supply: One battery (GEB212) ts into the instrument.
•On: The instrument turns on as soon as the power supply is connected
and the power key is pressed.
•Off: To turn off the instrument push either the power key or disconnect
the power supply.
If an instrument connected to a low powered external battery continues to
operate, total discharge of the battery can occur.
2.5 Leica Zeno GIS Software
All Leica Zeno GIS hardware and software can utilise the GG04 plus with a sur-
vey pole. The compatible hardware includes the Zeno 5, Zeno 10, Zeno 15,
Zeno Tab 1, Zeno Tab 2, CS25, CS25 plus, CS25 GNSS, CS25 LRBT and selected
Android, iOS or Windows devices.
With the Leica Zeno GIS software you can do different things:
•Seamlessly connect to the GG04 plus Smart Antenna through Bluetooth.
•Compute positions.
•Congure the Smart Antenna.
•Collect raw data from the Smart Antenna.
•Collect live data.
•Congure RTK connections to improve positioning accuracy.
•Export collected data in different formats.
Refer to the respective software documentation for further information.
A Leica Zeno Connect license for third-party Android or iOS devices is already
included with the purchase of the instrument. Leica Zeno Connect for third-
party devices can be found in the corresponding App Stores.
All further available and supported software can be purchased from Leica Geo-
systems AG.
Live and raw data
collection
General
Power options
On/Off behaviour
Total discharge
Description
Software to utilise
the instrument
Description of the System 17
2.6 Accessories
Extra equipment such as cables and universal pole holders are listed in the
setup sections. Any further description of accessories is not part of this man-
ual. Refer to the LeicaZeno GIS Equipment List.
Description
18 Description of the System
3 Operation
3.1 Guidelines for Correct Results with GNSS Surveys
Successful GNSS measurements require undisturbed satellite signal reception.
For kinematic use, be sure to select measurement positions with best satellite
reception possible. Use the instrument in location which is free of obstruc-
tions such as trees, buildings or mountains for best measurement results.
Centre the instrument precisely over the target positions.
3.2 Batteries
3.2.1 Operating Principles
•The battery must be charged before using it for the rst time because it is
delivered with an energy content as low as possible.
•The permissible temperature range for charging is from 0 °C to
+40 °C/+32 °F to +104 °F. For optimal charging, we recommend charging
the batteries at a low ambient temperature of +10 °C to +20 °C/+50 °F to
+68 °F if possible.
•It is normal for the battery to become warm during charging. Using the
chargers recommended by Leica Geosystems, it is not possible to charge
the battery once the temperature is too high.
•For new batteries or batteries that have been stored for a long time
(> three months), it is effectual to make only one charge/discharge cycle.
•For Li-Ion batteries, a single discharging and charging cycle is sufcient.
We recommend carrying out the process when the battery capacity indica-
ted on the charger or on a Leica Geosystems product deviates signicantly
from the actual battery capacity available.
•The batteries can be operated from −20 °C to +55 °C/−4 °F to +131 °F.
•Low operating temperatures reduce the capacity that can be drawn; high
operating temperatures reduce the service life of the battery.
3.2.2 Battery for GG04 plus
012536_00101253
6_
001
12
4
3
5
76
☞Turn the GG04 plus over to gain access to the battery compartment.
1. Push the slide fastener in the direction of the arrow with the open-
lock symbol.
2. Open the battery compartment.
3. Pull the battery from the battery compartment.
Undisturbed satellite
signal reception
Centred instrument
First-time use/
charging batteries
Operation/
discharging
Change battery step-
by-step
Operation 19
4. A pictogram of the battery is displayed inside the battery compart-
ment. It is a visual aid to help in placing the battery correctly.
5. Place the battery into the battery compartment, ensuring that the
contacts are facing outward. Click the battery into position.
6. Close the battery compartment.
7. Lock the battery compartment by pushing the slide fastener in the
direction of the arrow with the close-lock symbol.
3.3 Equipment Setup as a Real-Time Rover
3.3.1 Setup with Leica Zeno GIS Hardware and Software
The equipment setup is used for real-time rover with extended periods of use
in the eld.
This chapter shows a possible pole setup with Leica Zeno GIS hardware and
software.
Connection between the GG04 plus instrument and the eld controller is made
through Bluetooth. All hardware is xed on a Leica carbon pole in this exam-
ple.
•The antenna is mounted directly using screw tting.
•Carbon bre poles are used. They can be replaced with their aluminium
equivalent without any change to these instructions.
a
b
c
d
e
f
012566_001
a GG04 plus
b GEB212 battery
c Pole
d CS25 plus or Zeno 5 eld
controller
e AZ204, GHT55 or GHT72
pole holder
f GHT63 pole clamp
1. Attach the GHT63 pole clamp to the pole.
Use
Description
☞
Equipment setup
Equipment setup
step-by-step
20 Operation
