Leicke DS36696 User manual

User's Manual
Retro Docking Station with Qi Inductive Power
Standard for Qi-compati le Smartphones
Product num er: DS36696

Thank you for purchasing the Retro Docking Station with Qi (Inductive Power
Standard) from LEICKE.
We hold several brands to produce and distribute our products: LEICKE (power
adapters, batteries, docking stations), KanaaN (adapters/converters, charging cables
etc.), Sharon (iPad cases with keyboard, fans etc.), He ron (protective cases, docking
stations, screen protectors etc.), Manna (notebook cases).
We continuously work on the development of our products, our customer support and
innovations. ur products have a long service life, are eco-friendly and high performing.
Furthermore, every day we do our very best to satisfy you as our customer. That is why
you, no matter if private or business customer, are in the focus of our company’s efforts.
We take your reviews and proposals seriously and evaluate them continuously. That way,
we get to know you and your demands on our products and services better and thus
allow for positive enhancements.
To discover more about LEICKE products, or if you have any questions about this
product, visit our website www.leicke.com (production & wholesale) or
www.leicke-distributor.de (distribution) and feel free to contact us.
PACKAGE CONTENTS
Before attempting to use this device, please check the packaging and make sure the
following items are contained in the package:
Num er of
Pieces
Name Note
1Retro Docking Station with Qi for
smartphones with Qi interface
Qi interface, ports to charge other
devices
1 Power Cord plug depending on target country
1 User's Manual Language depends on model

PRODUCT INFORMATION
The LEICKE Retro Docking Station for smartphones with Qi interface, e.g. the Nokia
Lumia 920 or 928, has a Qi compatible charging interface. Therewith you can charge
your smartphone without any annoying cables – just put it on the charging interface, a
few seconds later the charging symbol will appear on your smartphone's display. The Qi
interface is compatible with all smartphones having a Qi interface themselves. So with
this docking station you may also charge smartphones, like the Samsung S4 or the LG
Nexus 4.
Furthermore, the LEICKE Retro Docking Station has 4 USB ports to charge other
devices. We offer a wide range of matching Retro Handsets as an accessory, wireless as
well as with cable.
TECHNICAL DETAILS
Input voltage 230V AC
utput voltage USB 5V
utput current USB 2A maximum
Max. transmitted power 5W (5V max. 1A)
Distance between mobile phone and
charging circuit
5 ~ 8 mm
Alignment help by charging coil Magnetic feedback
Efficiency Max. 72%
Protection functions Temperature, excess current,
short circuit protection
Maximum temperature of the charging
interface
55 °C
Compatibility All smartphones with built-in Qi interface
perating Temperature 0°C~40°C
Allowed Relative Humidity 10 ~85 % relative
Storing temperature -20°C~60°C
* The mobile phone will be brought perceptible to the correct charging position

Charging the Smartphone
Step 1: Put your smartphone onto the docking station's charging interface. For an
efficient power supply via Qi, the optimal charging position will be indicated with the help
of a magnet. Like this, the smartphone will be drawn in a perceptible way to the right
position. Try to avoid charging processes outside this zone to save energy.
Step 2: Please wait a few seconds until your smartphone displays the charging
symbol. Charging will start automatically. Please note, that charging may take a while
longer compared to charging with a cable.
Step 3: If the charging process does not start, take the smartphone away and then
put it back on to the interface.
Note: You can also use a cable to charge your smartphone. For this purpose there are
ports at the front and the back of the docking station. This holds also true for
smartphones, tablets and accessories of other producers. Please charge your
smartphone or tablet before the capacity reaches less than 20% if possible, to ensure a
long life of your battery.
Energy Efficiency
As the needed power is transmitted without wire when using the Qi inductive power
standard, there will be a bit more power lost than with the use of a cable. Therefore,
charging the device completely will take more time in comparison to when a cable is
used.
SAFETY NOTES
Please avoid the following situations:
−High humidity and contact to liquids like water or oil
−Mechanical strains like impacts or drop downs
−Heat or operating temperatures above or below the proper range
−Connection of defective or faulty accessories or cables etc.

CLEANING
Please clean your docking station with a moist cloth only. Do not use alcohol or
aggressive cleaning solutions.
TROUBLE SHOOTING
Please check the connection carefully before turning on the device.
Pro lem Possi le Cause/Possi le Solution
Smartphone does not
load via Qi 1. Is your smartphone Qi compatible?
2. Is the docking station connected to a power source?
3. Is the smartphone on the right position on the charging
interface?
4. Is your smartphone maybe not able to charge? *
Accessories won't
charge
1. Is the docking station connected to a power source?
2. Is the cable used USB compatible?
3. Did you try another port?
Unable to charge
keyboard
1. Make sure the USB power cable is connected properly to
the keyboard and the power source.
2. Make sure the wall charger is plugged into the power
outlet.
3. Make sure, you have the right output voltage.
You will find the needed information in the manual of your smartphone.
If the problems cannot be solved, please don't hesitate to contact us.
