Leicke LH67301 User manual

User's Manual
LEICKE Sharon Body Fat Analyser
Product number: LH 7301

Thank you for purchasing the Body Fat Analyser from LEICKE Sharon.
We continuously work on the development of our products, our customer support and
innovations. Our products have a long service life, are eco-friendly and high performing.
Furthermore, every day we do our very best to satisfy you as our customer. That is why
you, no matter if private or business customer, are in the focus of our company’s efforts.
We take your reviews and proposals seriously and evaluate them continuously. That way,
we get to know you and your demands on our products and services better and thus
allow for positive enhancements.
To discover more about EICKE products, or if you have any questions about this
product, visit our website www.leicke.com.
PACKAGE CONTENTS
Before attempting to use this device, please check the packaging and make sure the
following items are contained in the package:
Number of
Pieces
Name Note
1 Body Fat Analyser Bluetooth 4.0
3 Three AAA-size Batteries (1.5V each)
1 User's Manual -

TECHNICAL DETAILS
Power Source 4.5V (Three AAA-size Batteries)
Measurement Unit Kilogram / Stone / Pound
Measurement Range 5kg to 180kg / 0st: 11lb to 28st: 5lb /
11lb to 397lb
Accuracy 5-50kg: ±0.3kg; 50-100kg: ±0.4kg;
100-150kg: ±0.5kg; 150-180kg: ±0.7kg
Normal working condition Temperature: 5°C to 40°C
Relative humidity: ≤ 85%RH
Atmospheric pressure: 86kPa to 106kPa
Storage & transportation
condition
Temperature: -20°C to 60°C
Relative humidity: 10%RH to 93%RH
Atmospheric pressure: 50kPa to 106kPa
Turn on Method SENSE ON technology
Division 0.1kg / 0.2lb
Auto-OFF The scale will turn off after about 15 seconds
if there is no operation
Display Digital CD
Weight 1.6 kg
Dimensions Size: 300 x 300 x 24 mm
About the Accuracy of This Product
This product passes strict inspection before delivery and therefore its accuracy
is guaranteed by the manufacturer.
Please refer to the above table for the descriptions on accuracy.
This product is specially designed for body fat analysis as well as weight
measurement. It should NOT be used by anyone during the process of
transaction for verification of goods’ weight.

PRODUCT INFORMATION
The Sharon Body Fat Analyser applies BIA (Bio-impedance Analysis) technology. A small
amount of weak current flows through the human body so as to detect the bio-impedance
and estimate calorie, BMI, body fat, body water, muscle mass and bone mass. The
electrical current is small and may not be felt.
This BIA technology is cheap, safe, non-invasive, toxic-free and harmless. It also
possesses the characteristics of simple operation and abundant information.
The current mentioned above is less than 0.5mA. However, please be aware that anyone
with a wearable or implantable medical electronic instrument, such as a pacemaker, must
avoid using this device.
The intended use of this device is for healthy children 10-17 years old and healthy adults.
Device Components
LCD Display
Down Key Up Key
Set Key
UNIT Button
Battery
Compartment

SAFETY INFORMATION
The warning signs and symbols are essential to ensure correct and safe use of this
product and protect you and others from injury. Please kindly find the meanings of the
warning signs and symbols, which you may encounter in the label and user manual, as
follows:
Symbol for “THE OPERATION
GUIDE MUST BE READ” Symbol for “MANUFACTURER”
The Bluetooth Combination
Mark
Symbol for “DIRECT
CURRENT”
Symbol for “COMP IES WITH
EU REQUIREMENTS”
Symbol for “ENVIRONMENT
PROTECTION - Electrical
waste products
should not be disposed of with
household waste. Please
recycle where
facilities exist. Check with your
local
authority or retailer for recycling
advice”
Symbol for “MANUFACTURE
DATE”
Symbol for “SERIA NUMBER”
CAUTION:
* Sharon EICKE Body Fat Analyser offers you a seamless way to manage your health.
Please be aware that this device is designed for healthy population over 10 years old
self-measuring and self-monitoring body compositions. Any information provided by this
device is in no way meant to treat, cure or prevent any disease or illness from
happening. If in doubt, contact your physician.
* This device is contraindicated for any female subject who may be suspected of, or is
pregnant. Otherwise, the effects of this device on the fetus are unknown.
* This device is contraindicated for any person who is connected to a wearable or
implantable electronic device or instrument such as a pacemaker or defibrillator.
* This device should not be used for anyone who is acutely or chronically ill because of
suffering from a disease or taking medications that affect your water levels. The
accuracy of readings for these patients has not been verified. Specific medical advice
should be obtained from a physician.
* H67301 is equipped with data transmission function. It may emit electromagnetic
energy so as to perform its intended function. Nearby portable and mobile RF

communications equipment can affect the performance. And the device can interfere
vicinity electrical equipment.
* WARNING: No modifications of this equipment are allowed. This may result in
increased EMISSIONS or decreased IMMUNITY.
* Please use the device according to the user manual. Any misuse can cause electric
shock, burns, fire and other unexpected hazards.
* Please use and storage the device under the environment which was provided in the
user manual.
* Don’t expose the device to extreme temperatures, direct sunlight, moist or corrosive
environment.
* Do not step on the scale when your body or feet are wet, especially after bathing or
showering to prevent slipping.
* Please keep the device out of reach of infants, children or pets, since inhalation or
swallowing of small parts is dangerous or even fatal.
* Please don't use the device out of lifetime any more because degraded sensors and
electrodes, or loosened electrodes can degrade performance or cause other problems.
* If you have an allergy to stainless steel, please avoid contact to the electrodes of the
device.
* The patient is an intended operator. The patient can measure, transmit data and
charge battery under normal circumstances and maintain the device and its accessories
according to the user manual.
* The device is not AP/APG equipment. It is not suitable for use in the presence of a
flammable anaesthetic mixture with air (or oxygen, nitrous oxide).
* Please use ACCESSORIES and detachable parts specified / authorised by
MANUFACTURER. Otherwise, it may cause damage to the unit or danger to the user /
patient.

MEASUREMENT PRINCIPLE
To ensure the accuracy of measurement, please follow the instructions below
when you start measurement.
Place the scale on a flat, hard surface. Soft surface such as carpet will affect the
performance of the scale. Step onto the platform with bare feet. Stand still and keep full
contact with the electrodes until the measurement is complete.
Start measurement at least two hours after getting up or dining.
Avoid measurement immediately after strenuous exercise, sauna or bath, drinking, and
dining. For maximum accuracy and repeatability, it is recommended that you should use
the device in the same time of the day and on the same location.
The condition of the skin on the bottom of your feet can affect the reading. Take the
reading with clean, slightly damp feet for best accuracy. If you are having a problem on
operating this scale please contact customer service.
Body fat percentage estimates will vary with the amount of water in the body, and can be
affected by dehydration or over-hydration due to such factors as alcohol consumption,
menstruation, illness, intense exercise, etc.
LCD DISPLAY SIGNAL
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
Body Fat Analysis Result Percentage
Total Body Water Analysis
Result
Male
Muscle Mass Analysis
Result
Male Athlete
Bone Mass Analysis Result Female
Age Female Athlete
ft Foot User ID (P1-P8)
st lb Stone Calorie Analysis Result

Pound Body Mass Index
CM Centimetre ow Battery
kg Kilogram Goal Weight
Difference Compared with
Goal Weight
More than the Goal Weight
ess than Goal Weight Successful Bluetooth Connection
Data transmitting / pending
to transmit to wireless
wellness system
INSERT THE BATTERIES
1. Open the battery door at the back of the scale.
2. Insert the batteries (3x1.5V AAA) into the battery
compartment according to the polarity indications marked
inside the compartment. (The digits “8888”
will be shown on the CD.)
3. Close the battery door and wait until the digits “0.0” are
shown on the CD.
4.
CAUTION:
* When the symbol appears, the device will power off in about 3s. Then you shall replace with a
new set of batteries. Please replace all three batteries at the same time. Do NOT mix old batteries with
new ones.
* Worn batteries are hazardous waste. Do NOT dispose of them together with the household garbage.
* Please refer to the local ordinances and recycling instructions regarding disposal of the worn batteries
and scrapped device.
* If you do not intend to use this unit for a prolonged period of time, it is advisable to remove the batteries
before storing.

SET UP YOUR PROFILE
The body fat analyser supports multiple users (up to 8). You may follow below
instructions to assign a User ID and set up your own profile, including Gender, Stature,
Age and Goal Weight.
1. Assigning User ID
With batteries correctly installed, press “SET” key to enter
setting.
The system will request User ID selection first. As pictured
below, “P1” blinks. The operator may press the function
key “up” or “down” to select User ID among P1 to P8.
Press “SET” key to confirm User ID.
2. Setting Gender
After confirming User ID, the system will divert to Gender
setting automatically.
As pictured below, the portrait “ “ blinks. The operator
may press the function keys to select Gender.
(Male/Female/Male Athlete/ Female Athlete).
Press “SET” key to confirm Gender.
Athlete Mode:
An athlete is defined as an adult who is involved in intense physical activity of
approximate 12 hours per week and who has a resting heart rate of
approximately 60 beats per minute or less.
3. Setting Stature
After confirming Gender, the system will divert to
Stature setting automatically.
As pictured below, the digit “160” blinks.
The operator may press the function keys again to
increase or decrease the numeral.
(Range: 100 cm to 220 cm/ 3’3.5”~7’2.5” ft)
You may press and hold the function key “Up” or

“Down” for fast changing the numeral.
Press UNIT Button to select between ft (Foot) and cm (Centimetre).
Press “SET” key to confirm Stature.
4. Setting Age
After confirming Stature, the system will
divert to Age setting.
As pictured below, the digit “30” blinks. The operator
may press the function keys to increase or decrease
the numeral.
(Age Setting Range for Normal Mode:
10 to 85 years old)
5. Setting Goal
After confirming Age, the system will
divert to Goal setting.
As pictured below, the digits “50.0” blink. The
operator may press the function key ”Up” or “Down”
to increase or decrease the numeral.
You may press and hold the function key or for fast
changing the numeral.
Press “SET” key to confirm Goal.
When the CD displays “0.0kg”, you may start measuring.
