Lelit Pro Line MaraX User manual

English
EN
User manual
PL62X
MaraX
Pro Line

PRO Line - MaraX - PL62X
2
THANK YOU FOR CHOOSING
A LELIT PRO LINE PRODUCT
Register your product on
care.lelit.com
Download the complete guide to get the most of
your coffee machine PL62X and visit our Lelit Espresso
YouTube channel for insights, tutorials, tips and tricks.
Save the box and all
the packing material!
LELIT has studied the external and internal pack-
ing of your coffee machine to help you re-use it in
case of maintenance or repair need.

Lelit Espresso - English
3
EN
Index
1. Daily cleaning 4
2. Weekly cleaning 4
3. Annual cleaning 5
4. Product overview 7
5. Factory settings 7
6. Equipment box 8
7. Packing 9
8. First start-up 9
9. How to install the water resin lter 10
10. Espresso and coffee 11
11. Steam and hot water 12
12. Stand-by mode 12
13. Limestone prevention 13
14. Lights and states of the machine 14
15. Warranty terms 15
ATTENTION:
Read the safety notes carefully before using this
product.

PRO Line - MaraX - PL62X
4
1. Daily cleaning
1.1 1.2 1.3
Note. For an optimal result we suggest you use our kit PLA9101 (not included) that
contains a microber cloth with embroidered LELIT logo, a paintbrush with bristles in nat-
ural bres and a brush with nylon bristles.
General cleaning. Use a soft cloth, preferably in microber, and moisten it with
tap water to clean the stainless-steel appliance body of the machine (Pic 1.1).
Group cleaning. After each extraction empty the coffee lter, wash the portal-
ter (G) and the relative lter with tap water and use the brush (I) to eliminate the
coffee residues from the group gasket (Pic 1.2).
Steam wand cleaning. After frothing the milk, clean the nozzle of the steam
wand (7) using a soft cloth and dispense a small quantity of steam to eliminate
every possible milk rest in the holes (Pic 1.3).
2. Weekly cleaning
Note. In the equipment box you’ll nd the detergents (F) for the rst cleaning cycle
of the machine. Aerwards, we suggest you use our accessories PLA9201 and PLA9203
(not included).
Filters and portalter cleaning. It’s necessary to clean the portalter to elim-
inate the coffee oils that affect the taste of your drinks negatively. Place a jug
under the hot water wand (15), turn the knob (12) anti-clockwise and take out
about 1 l of water.
Insert the portalter (G) and the used lters into the jug but pay attention not to
immerse the portalter handle (Pic. 2.1). Add 2 bags of detergent powder (F or
PLA9201). After 15 minutes, empty the jug and rinse the portalter (G) and the
lters with plenty of tap water.

Lelit Espresso - English
5
EN
2.1 2.2 2.3
10x10”
min
15
Backushing. Insert the blind lter (C) into the portalter and pour 1 bag of
detergent powder (F or PLA9201) into the lter. Insert the portalter (G) in the
group (13) and lift the lever (14) for 10 seconds. Stop the function and wait for
10 seconds. Repeat the procedure 10 times (Pic 2.2).
Remove the portalter (G) from the group and rinse it with hot water from the
brewing group (Pic 2.3).
Re-insert the portalter (G) in the group and repeat the previous operation 5
times for 10 seconds each time, without detergent powder.
Remove the portalter (G) and take out the blind lter (C). Empty the drainage tray
(17) and rinse the portalter (G), the lters and the tray (17) with plenty of tap water.
2.4
10x5”
Steam wand cleaning. Fill a jug with 500 ml of
cold water, add the content of 1 bottle of detergent
liquid (F or PLA9203) and immerse the steam wand
(7) in this solution.
Open the knob (3) and dispense steam for 5 sec-
onds. Stop the function and wait for 5 seconds. Re-
peat the operation 10 times (Pic 2.4).
Repeat the entire procedure using 1 l of fresh water
to rinse the steam wand (7) properly.
3. Annual cleaning
The descaling of the hydraulic circuit of the machine must be done every year to
ensure longevity and constant performances. This operation must be done by a
specialized technician. You can see the centres authorized to run this procedure
on our website: care.lelit.com.

PRO Line - MaraX - PL62X
6
1 11 17
in the equipment
box
Pic 4
1
12
10
15
2
6
8
9
3
4
5
14
13
16
7
17
11

Lelit Espresso - English
7
EN
4. Product overview
5. Factory settings
1. Mobile water tank cover
2. Heated surface for cup grate
3. Steam dispensing knob
4. Pilot light machine ready
5. Pilot light water tank full of water
6. Manometer for steam and pump
pressure during extraction
7. Multi-directional, anti-burn steam
wand
8. ON/OFF main switch (with lighted
frame)
9. Temperature mode switch
10. Water tank (2,6L)
11. Grate for heated surface
12. Hot water dispensing knob
13. Brewing group
14. Coffee group lever
15. Multi-directional, anti-burn hot
water wand
16. Use mode switch
17. Removable water drainage tray,
complete with grate
Use mode (16)
ModeX (pre-set value)
Temperature mode (9)
Warm (pre-set value)
Stand by:
ON
Resin lter:
Not inserted
To use the machine with different settings, download the complete guide. The
complete guide contains the instructions on how to set other functioning pro-
les.

PRO Line - MaraX - PL62X
8
6. Equipment box
A. 1 dose (9-11g) coffee lter
B. 2 doses PLUS (18-21g) coffee lter
C. Blind lter for backushing
D. Tamper in stainless steel with red
wood handle (PLA481R)
E. Raiser for espresso cups
F. First cleaning kit (with 3 detergent
powder single-dose bags and 1 sin-
gle-dose bottle)
G. Filterholder complete with 2 doses
(14-18g) coffee lter
H. LELIT 35L water resin lter
I. Brush for group head cleaning
J. Plastic spoon for coffee powder
K. Power cord
h
i
k
a
b
cf
ej
g
d

Lelit Espresso - English
9
EN
7. Packing
The packaging of your coffee machine has been studied and produced to be
re-used. Use the original box and all the packaging elements in case you need
to send the machine back to your reseller or to an authorized service centre,
for ordinary or extraordinary maintenance. The complete guide contains the
instructions to help you pack the machine easily.
8. First start-up
8.1 8.2 8.3
FRONT
30
sec
Attention. Remove the machine from its packing and follow the instructions printed
on the box.
Place the machine on a solid, at and dry surface and make sure the appliance is
stable; if needed, screw/unscrew the feet to adjust the position of the machine.
From the equipment box, take out the water drainage tray (17), the grate (11),
the mobile cover (1) and position them as indicated in Pic. 4.
Fill the water tank (10) with room temperature water up to the indicated maxi-
mum level and insert it in its seating (Pic 8.1).
Use the power cord (K) to connect the machine to the electrical mains and turn
ON the machine by pressing the ON/OFF (8) switch. If the water tank (10) is full
of water and properly inserted in its seating, the pilot light (5) goes ON (Pic 8.2).
The hydraulic circuit will need maximum 4 minutes from the 1st turn on to get
lled with water. Once the waiting time is over, the pilot light (4) will start ash-
ing. Lift the group lever (14) completely. The brewing group (13) will start dis-

PRO Line - MaraX - PL62X
10
pensing water (within 30 seconds). Let the water come out for about 30 seconds
and then return the group lever to its initial position (Pic 8.3).
Now the hydraulic circuit is lled up. The machine will start heating the water to
reach the pre-set values. This operation requires maximum 24 minutes: the pilot
light (5) remains rmly on, while the pilot light (4) ashes.
The machine is ready for use when the 2 pilot lights (4 & 5) and the lighted
frame of the ON/OFF (8) switch are rmly on.
Attention. During the heating phase, a small quantity of water will drain in the
tray (17). is is normal and conrms the machine correct functioning (functions check).
9. How to install the water resin lter
9.1 9.2 9.3
1
2
min
3
Before installing the resin lter (H) in the water tank (10), immerse the resin lter
in a jug full of water for about 3 minutes, to eliminate the air inside the lter that
may cause a machine malfunction (Pic 9.1).
Take out the water tank (10) and remove the black rubber support placed on
the bottom of the tank. Insert the resin lter (H) in the bigger hole of the rubber
support, remove the charge tube from the small plastic lter and x it on the
nozzle of the resin lter (H) (Pic 9.2).
Re-place the support in its seating on the bottom of the tank (Pic 9.3), ll the
tank (10) with water and insert the tank (10) in its seating.

Lelit Espresso - English
11
EN
10. Espresso and coffee
10.1 10.2 10.3
1OK
2
Choose your coffee lter, insert it into the portalter (G) and ll it with the ade-
quate quantity of ground coffee. Use the tamper (D) to press the coffee powder
in the portalter (G). Fix the portalter (G) into the brewing group (13) and make
sure the handle is aligned with padlock symbol present on the group (Pic 10.1).
Place the cup/s under the portalter and lift the group lever (14) to start the
coffee extraction (Pic 10.2).
During the extraction phase, the lighted frame of the ON/OFF switch (8) ashes
to indicate that the pump works. Return the group lever (14) to its initial position
to stop the extraction (Pic 10.3).
Take out the portalter (G) and empty the lter after every coffee extraction.
Note. During the normal functioning the pilot lights of the machine may ash or go
o to indicate various states of the machine. See the chapter 14 “Pilot lights and states of
the machine” for more details.
Note. We suggest you leave the portalter (G) inserted into the brewing group (13)
to help harmonize the temperature between the group and the portalter complete of the
lter.
Attention. Do not remove or loosen the portalter (G) from the brewing group
(13) during the coee extraction to avoid burn risks caused by hot water leaks.

PRO Line - MaraX - PL62X
12
11. Steam and hot water
To obtain an optimal performance of the machine, lift the group lever (14) com-
pletely and return it to its initial position about 30 seconds before using the
steam wand or the hot water wand (7 or 15).
11.1 Turn the knobs (3 or 12) anticlockwise to dispense
steam or hot water (Pic 11.1).
Vary the rotation of the knob to adjust the steam or
hot water quantity/intensity.
Turn the knobs (3 or 12) clockwise to stop the func-
tion.
12. Stand-by mode
12.1 12.2 12.3
30
min
After 30 minutes of inactivity, the machine will go automatically in stand-by
mode (Pic 12.1).
The lighted frame of the ON/OFF switch (8) ashes while the pilot lights (4 and
5) remain rmly off (Pic 12.2).
To re-start the machine, you must lift the group lever (14) completely and return
it to its initial position (Pic 12.3).
Wait until all the pilot lights are rmly on before using the machine.

Lelit Espresso - English
13
EN
Note. e Stand-by function can be disabled. For more details download the com-
plete guide.
13. Limestone prevention
13.1 To prevent limestone deposits and grant a better
result in the cup, use the water resin lter (H). The
lter found in the equipment box has an autonomy
tested for 35 litres of water.
Use the slides put on the handles of the water tank
(10) to remember the complete llings of the tank
and replace the resin lter once exhausted (Pic
13.1).
Note. e resin lter must be replaced every 14 complete llings, or aer 4 months
of use. If the machine remains unused for 1 month, the resin lter must be replaced with a
new one.
Note. Sea chapter 6 “How to install the water resin lter” to replace the lter cor-
rectly.

PRO Line - MaraX - PL62X
14
14. Lights and states of the machine
State of the machine
Machine in heating phase
Wait until the machine is ready for use
Water tank is missing or water tank
is empty
Fill the water tank (10) with water and insert it in
its seating
Machine ready for use
You can start using the machine
Machine in Stand-by mode
Lift the group lever (14) completely and return it
in its initial position to activate the machine. Wait
until all the pilot lights are rmly on before using
the machine.
Temperature sensor NTC1
disconnected or damaged
Contact the service centre
Temperature sensor NTC2
disconnected or damaged
Contact the service centre
Boiler lling phase has exceeded the
maximum time
Check the correct position of the water tank (10)
and remove eventual blockages. Re-start the
machine with the main switch. If the problem
persists, contact the service centre.
Pilot light is on Pilot light ashes Pilot light is off

Lelit Espresso - English
15
EN
15. Warranty terms
Legal warranty
This product is covered by the warran-
ty laws valid in the country where the
product has been sold; specic infor-
mation about the warranty terms can
be given by the seller or by the im-
porter in the country where the prod-
uct has been purchased. The seller or
importer is completely responsible for
the product.
The importer is completely responsi-
ble also for the fullment of the laws in
force in the country where the import-
er distributes the product, including
the correct disposal of the product at
the end of its working life.
Inside the European countries the
laws in force are the national laws im-
plementing the EC Directive 44/99/
CE.

PRO Line - MaraX - PL62X
16
IMPORTANT INFORMATION
For the correct disposal of the product in accordance with EU DI-
RECTIVE 2002/96/EC and with Legislative Decree no. 151 of 25 July
2005. At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special authorised dierential
waste collection centre or to a dealer providing this service. Disposing
of a household appliance separately avoids possible negative conse-
quences for the environment and health caused by improper disposal
and enables recovery of the materials it contains, with signicant sav-
ings in energy and resources. e product is marked with a crossed-
out wheelie bin as a reminder of the need to dispose of household
appliances separately.
EC DECLARATION OF CONFORMITY
Gemme Italian Producers srl declares under its own responsibility
that the product:
Coee machine type: PL62X
to which this declaration relates conforms to the following standards:
EN 60335/1 - EN 60335/2/15 - EN 61000/3/2 - EN 55014
pursuant to directives:
2014/35/EU - 2014/30/EU
NB: is declaration is null and void should the machine be modied
without our specic authorisation.
Castegnato, 20/02/2020 - Managing Director
Gemme Italian Producers srl
25045 Castegnato (Bs)

Lelit Espresso - English
17
EN
Notes

espresso.lelit.com
EN/7800052, REV 01, dated 01/07/20
Art. PL62X
©2020 Gemme Italian Producers Srl.
All Rights Reserved
