LENCO 123SC Operating instructions

If you have no lights,
proceed to
“System Inoperative”
Operate the system in TEST MODE.
• If the system works in the Test Mode there is a problem with the accessory signal.
Check for proper connection to the orange accessory wire of the control box.
• If the system does not work in Test Mode continue to Step 2.
Verify there is 12V or 24V at the Power Plug: Disconnect the Power Plug from the control box’s power
and measure voltage using a DC voltmeter.
• If 12V or 24V is not at the Power Plug across the two pins,
step 1: Check the fuse or circuit breaker (between
battery and control box)
step 2:
step 3:
step 4: Check battery switch.
• If 12V or 24V is at the Power Plug across the two pins,
Check the key pad connection.
Call Lenco Marine for further technical assistance.
SYSTEM INOPERATIVE (Power Fault)
NOTE:Under normal operation the control box’s orange accessory wire requires a 12V level
or a tachometer signal to turn the control box ON (top triangular LEDs on switch are lit)
Step 1:
Step 2:
Verify that the power connection is firmly
attached and that 12 or 24 volts is available.
Verify the Orange wire is connected to a 12
or 24V source or an Engine Tach Signal.
Step 3:
receptacle
GENERAL TROUBLESHOOTING
FOR 123SC TRIM TAB SYSTEM
FOR ADDITIONAL INFORMATION, CONTACT LENCO’S TECHNICAL SERVICE DEPARTMENT AT:
Lenco actuators come with 6FT actuator cables that feature Deutsch terminations.
Boat builders may use a separate wire harness connecting power and actuators to control box.
If you’re not certain if there is a separate connection in your boat, contact the boat manufacturer.
This guide is intended to provide basic functional diagnostics and will assist in determining
the source of the problem. Choose Power Fault or Actuator Fault and follow the steps.
If you have this reading
and are still experiencing
a problem, call Lenco.
If you have any of these readings,
proceed (on the next page)to
“Actuator Inoperative”
NO LIGHTS
Are any lights on the Digital Switch illuminated?
POWER FAULT STBD SIDE FAULTPORT SIDE FAULT BOTH SIDE FAULT GOOD READING
LIGHTS LIGHTS
TEST MODE
Press and hold all four keypad buttons down for approximately
three seconds. The LEDs on the keypad should track down than back up
and stop with the top triangular LED lit on each side.
Press the left side button on the keypad labeled “DOWN”. The
starboard actuator should extend and the left side indicating lights should
track.
Press the right side button on the keypad labeled “UP”. The port
actuator should extend and the right side indicating lights should track.
Momentarily press all four keypad buttons down simultaneously.
Both actuators should retract fully and keypad should have no indicating
lights on.
Step 1:
Step 2:
Step 3:
Step 4:
Press &
Hold 3 Sec.
Triangular
LEDs Should
Be Illuminated
Key Pad
Connection
20 Amp Fuse
1
Orange Wire Connection
2
Power Wire Connection
3
4Battery switch
(images would vary)
PG 1

If you have no lights,
proceed (other pg) to
“System Inoperative”
GENERAL TROUBLESHOOTING
FOR 123SC TRIM TAB SYSTEM
FOR ADDITIONAL INFORMATION, CONTACT LENCO’S TECHNICAL SERVICE DEPARTMENT AT:
This guide is intended to provide basic functional diagnostics and will assist in determining
the source of the problem. Choose Power Fault or Actuator Fault and follow the steps.
If you have this reading
and are still experiencing
a problem, call Lenco.
If you have any of these readings,
proceed to
“Actuator Inoperative”
NO LIGHTS
Are any lights on the Digital Switch illuminated?
POWER FAULT STBD SIDE FAULTPORT SIDE FAULT BOTH SIDE FAULT GOOD READING
LIGHTS LIGHTS
OPERATIONAL TEST
further technical assistance.
Step A:
Step B:
Press the left-side button on the switch labeled “DOWN”. The starboard actuator
should extend and the left-side indicator lights should track.
Press the right-side button on the switch labeled “UP”. The port actuator should
extend and the right-side indicator lights should track.
• If fault reading is present at the opposite side of the key pad, the actuator (or its
connections) may be defective. Proceed to Step 4.
• If fault reading is present at the same side of the key pad, the control box may be
defective. Call Lenco Marine for
Press & Hold
PG 2
Lights
should
track
STARBOARD
PORT
Perform the OPERATIONAL TEST.
ACTUATOR INOPERATIVE (Actuator Fault)
Step 1:
Step 2: If the fault continues, s
Check to make sure that the Deutsch Connectors are
firmly attached. If the connection is loose, firmly press
the two connectors together.
wap the connections to the
actuators. Disconnect actuators from control box and
reconnect actuators to opposite control box outputs.
Step 3:
White/Red Wire
& Black/Red Wire
Port Deutsch Connec.
White/Green Wire
& Black/Green Wire
Starboard Deutsch Connec.
1
Swap Connections
2
Remove the wire leads
from the connector by
depressing the small
latch inside the
connector housing.
Extend the Actuator:
White Terminal to Positive
(+) Battery Terminal.
Black Terminal to Negative
(-) Battery Terminal.
Remove the orange wedge
by lifting the wedge from the
connector with a small flat
head screwdriver or Deutsch
connector tool.
6
5
4
Step 4: If fault continues, disconnect the Deutsch Connectors and remove the
orange wedge.
Step 5: Remove the wire leads from the connector by depressing the small
latches inside the connector housing and pulling on the wire leads.
Step 6: Once the wires are removed from the housing, touch the white wire
leads to a Positive (+) 12V Battery Terminal and the black wire leads
to a Negative (-) 12V Battery Terminal. The actuator should extend
while connected to the battery. Reverse the polarity of the wire leads
to the battery terminals and the actuator should retract.
If the actuator does not extend and retract, replace the actuator.
If the actuator extends and retracts properly, re-assemble the
connector taking care to properly seat the wire leads into the
connector housing. Proceed to Step 7.
Step 7: Attach the port and starboard connectors to the system. If the fault reading continues,
contact Lenco’s Customer Service at: or 772-288-2662
•
•
Press & Hold
Lights
should
track
