LENCO BH-100 User manual

INSTRUCTION MANUAL
Headset with Bluetooth
MODEL: BH-100
www.lenco.com

HEADSET OVERVIEW
OPENNING INSTRUCTIONS
Charging the headset
1.Your headset uses a rechargeable built-in battery,make sure the headset is fully charged before using it
for the first time.
2.Connect the USB cable to the charging socket,the headset can be charged.
3.During charging,the LED indicator light remains red,when charging completed,it turns to blue.
Turning the headset on
1.Press the power switch button for 3 seconds in shutdown mode,the blue indicator light flashes 5 times
and you will hear prompt tone.
Turning the headset off
1.Press the power switch button for 5seconds in standby mode,the blue indicator light flashes 5 times
rapidly and you will hear prompt tone.
①Power switch
②Volume up & Next song
③Volume down & Previous song
④Microphone
⑤LED Indicator Light
⑥Charging socket

Pairing and Connecting the headset with a phone
1. Press and hold the power switch button about 7-9 seconds until you see the blue and red indicator light
flashes rapidly and continually by turns,then release the button.
2. Activate the Bluetooth feature on your phone and search for the headset.
3. Select the headset (Lenco BH-100 ) from the list of devices found by your phone.
4. When pairing successfully,the indicator light will stop flashing,the blue indicator light flashes once
every 3 seconds in standby mode.
Reconnecting the headset with a phone
1.Your headset will attempt to reconnect automatically each time you turn it on,but this feature may be
unavailable on some devices,you can try to reconnect from paired devices on phone.
Answering a call
1.Short press the power switch button to answer a call when you hear incoming call tones.
2.When you are listening to music,the music stops during a call.
Ending a call
1.Short press the power switch button to end a call.
Rejecting a call
1.Press the power switch button for 2 seconds to reject a call when a call comes in.
Redialing the latest call
1.Short press the power switch button for 2 times continually, and then it will make a call to the latest
number you dialed.
Volume Control
1.Long press the volume up or down button to adjust the volume.
2.You will hear a beep when volume level of the headset reaches its’ highest level.
Play or Pause music
1.Press the power switch button to select play/pause the song
Previous or Next song
1.Short press and then release the previous/next song button to select previous/next song.
2.While playing the song, 'Short press and release' the previous song button only go to the beginning of the
current song, then 'Short press and release' button again to go to the previous song.

TECHNISCHE DATEN
ITEM
SPECIFICATIONS
Driver Unit
10 mm
Impedance
16 Ohms
Frequency Response
20 Hz to 20KHz
S/N
88±5dB
Rated Power
3 mW
Max. output Power
30 mW
Max.Input Power
30 mW
Operating voltage range
3.0V-4.2V
Battery
Lithium 3.7V, 100mAh
Bluetooth-Version
Bluetooth v4.0
Mic Sensitivity
-42 ±3dB
Operating range
up to 33 feet(10 meters)
Standby time
up to 160hours
Talk/Play time
about 4 hours
Charging time
1.5 hours
* Depending on the phone type and usage, the actual time may vary.
WARNING: When participating in the traffic listening to a personal music
player can make the listener less aware of potential dangers such as
approaching cars.
WARNING: To prevent possible hearing damage, do not listen at high
volume levels for long periods.
This product operates at 2400 - 2483.5 MHz and is designated only to be used inside a normal household
environment. This product is suited for this purpose within all EU counties.
Hereby, STL Group BV, Ankerkade 20 NL 5928 PL Venlo, declares that this product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.

The declaration of conformity may be consulted at
https://lencosupport.zendesk.com/forums/22413161-CE-Documents
Service and support
For information: www.lenco.com
Lenco offers service and warranty in accordance to European law, which means that in case of repairs
(both during and after the warranty period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs to Lenco directly.
Important note: If this unit is opened or accessed by a non-official service center in any way, the
warranty expires.
This device is not suitable for professional use. In case of professional use, all warranty obligations of the
manufacturer will be voided.
Products with the CE marking comply with the EMC Directive (2004/108/EC) and the
Low Voltage Directive (2006/95/EC) issued by the Commission of the European
Community.
The declaration of conformity may be consulted at
https://lencosupport.zendesk.com/forums/22413161-CE-Documents
This symbol indicates that the relevant electrical product or battery should not be
disposed of as general household waste in Europe. To ensure the correct waste treatment
of the product and battery, please dispose them in accordance to any applicable local
laws of requirement for disposal of electrical equipment or batteries. In so doing, you
will help to conserve natural resources and improve standards of environmental
protection in treatment and disposal of electrical waste (Waste Electrical and Electronic
Equipment Directive).
® All rights reserved
