LENCO SCD-26 User manual

Instruction manual
Bedienungsanleitung
Manuel d utilisation
Manual de Instruccion es
Gebruiksaanwijzing
Model: SCD - 26USB
Portable Radio CD/MP3 Player with USB Flash Disk
Device
Tragbarer Radio - CD/MP3 - Spieler Mit
USB - Flash - Disk - Vorrich tung
Radio/Lecteur CD/MP3 Portatif Avec Interface USB Flash
Disk

Radio Rep r oductor CD/MP3 Port átil C on USB Flash
Disk
Draagbare Radio CD/MP3 Speler Met USB Flash Disk
Device

IMPORTANT SAFETY INSTRUCTIONS
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This lightning flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user to
the presence of insulated
dangerous voltage within
the products enclosure that
may be of sufficient
magnitude to constitute a
risk of electric shock
presents.
Warning: to reduce the risk
of electric shock, do not
remove
cover (or back ) no user -
serviceable part inside.
Refer servicing to qualified
service personnel.
The exclamation point
within an equilateral
triangle is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus n ear water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufactures
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polariz ed
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where it exits from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug the apparatus during lightening sorts or when unused for long periods of time.
13. Refer all servicing to qualified personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
14. This appliance should not be exposed to dripping or splashing water and no objects
filled with liquids such as vases should be placed on apparatus.
ENGLIS

Dripping warning: The products should not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the product.
Ventilation warning: The normal ventilation of the product should not be impeded for
intended use. E-1
NAMES OF CONTROLS
1. BATTERY COMPARTMENT
2. LCD TRACK DISPLAY
3. USB PORT
4. POWER IND ICATOR
5. CD PLAY/PAUSE BUTTON
6. CD PROGRAM/REPEAT BUTTON
7. +10 MP3 BUTTON
8. BASS BOOST BUTTON
9. CD COMPARTMENT
10. FOLDING HANDLE
11. CD DOOR OPEN/CLOSE
12. CD SKIP FORWARD BUTTON
13. CD SKIP BACKWARD BUTTON
14. CD PLAY MODE BUTTON
15. CD STOP BUTTON
16. FM STEREO INDICATOR
17. DIAL SCALE
18. BAND SE LECTOR
19. TUNING CONTROL
20. AC SOCKET
21. FM TELESCOPIC ANTENNA
22. FUNCTION SWITCH
23. VOLUME CONTROL
24. PHONES JACK
25. SPEAKER
INTRODUCTION
Thank you for purchasing this product.
Please read through these operating instructions, so you will know how to operate your
equipment properly. After you finished reading the instructions manual, put it away in a
safe place for future reference.
CAUTION:
Do not block the ventilation openings or holes.
Do not place any naked flame sources, such as lighted candles, on the apparatus.
When discarding batteries, environmental problems must be considered and local rules
or laws governing the disposal of these batteries must be followed strictly.
Invisible laser radiation when open and interlock failed or defeated. Avoid direct
exposure to bea m.
To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
NOTE:
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications could void the user's authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
REPRODUCTION OF LABELS
1. CLASSIFICATION LABEL, PLACED ON REAR ENCLOSURE .
2. WARNING LABEL, PLACED INSIDE THE UNIT .
CAUTION: Do not open the unit. There are no user serviceable parts inside the unit;
consult all servicing to qualified service personnel.

N
-
1
Discs for Playback
This system can playback all digital audio CD, finali z ed digital audio CD - Recordable (CD - R)
discs , finali zed digital audio CD-Rewritable (CD-RW) discs and CD-DA format digital audio
CD / CD -R/ CD - RW discs. E-2
POWER SOURCE
This unit is designed to be operated on AC/DC.
AC OPERATION
Plug the smaller end of AC power cord into AC jack on unit and the other bigger end into
AC wall outlet. The batteries will be automatically disconnected. For dual voltage version,
make sure that the AC voltage selector (located inside battery compartment) is switched to
your local voltage. (optional)
DC OPERATION
Open the BATTERY COMPARTMENT DOOR. Install 6 pcs UM-2/ C size batteries (not
included) into compartment. Please follow corre ct polarities as indicated.
CAUTION
Remove batteries if they are flat or not being used for a long period of time.
Batteries contain chemical substances, so they should be disposed of properly.
BASIC FUNCTION
SWITCHING ON THE UNIT
Set the FUNCTION swit ch to CD /MP3 or RADIO. The POWER indicator will be on.
TO ADJUST VOLUME
Rotate the VOLUME CONTROL back and forth to increase and decrease volume.
BASS BOOST SYSTEM
For more extra bass, press the BASS BOOST button to turn on the bass. Press the button
again to turn off.
HEADPHONES
For private listening, plug the headphones/earphones (not included) into PHONES jack(3.5
mm diameter).
CAUTION: Long time listening with headphones/ earphones at high volumes may cause
harmful damage to users ears.
USING THE RADIO
TUNING IN RADIO STATIONS
1. Move the FUNCTION switch to RADIO position, the POWER indicator will illuminate.
2. Slide the BAND switch to select the desired wave band: FM / FM ST..
3. Tune to required station by rotating the TUNING KNOB.
4. Adjust the VOLUME CONTROL t o desired volume level.
5. Extend the TELESCOPIC ANTENNA to its full length if you are listening to FM
broadcasting.
Note: If the broadcasting program is too noisy when you are listening to FM stereo

N
-
2
station, please slide the BAND switch from FM ST. to FM. The FM STEREO indicator
will be on when you are receiving FM stereo program.
6. Turn off the radio by switching the FUNCTION switch to "OFF" position
E-3
USING THE CD /MP3
LOADING A DISC
1. Set the FUNCTION switch to CD /MP3 position.
2. Open the CD door.
3. Place an au dio CD /MP3 into the tray with the label side facing up.
4. Close the CD door.
The total number of tracks will appear o n the display after several seconds.
5. To remove the CD, press CD DOOR OPEN /CLOSE to open CD compartment lid, grasp
the CD by its edges, and c arefully take it out.
Note:
To ensure good system performance; wait until the disc tray completely reads the disc
before proceeding.
If no disc is loaded into the compartment, or the disc is placed upside down, the display
will show 00 .
PLAYING A DISC
1. Press the PLAY/PAUSE button to start playback.
The playback starts from track 1, will appear on the display
To interrupt playback, press the PLAY/ PAUSE button, will disappear and the
track number will flash on and off on the display.
T o resume playback, press the PLAY/PAUSE button again .
2. To stop playback, press the STOP button, the total number of tracks appears in the
display.
SELECTING A DESIRED TRACK/PASSAGE
To select a desired track
Press the CD SKIP FORWARD/ BACKWARD button repeatedly in stop mode or during
play until the desired track appears on the display.
Press the PLAY/PAUSE button to start play.
P ROGRAM TRACKS
You may play the tracks (songs) on the disc in the order as you like. Program tracks of disc
are possible when playback is stopped. Up to 20 tracks for CD or 60 tracks for MP3/ USB
can be stored in the memory in any order.
1. In stop mode, press the PROG RAM button to enter program setting, the
flashes on and off o n the display.
2. Press the CD SKIP FORWARD button to select the first desired track to be programmed.
3. Press the PROGRAM button to enter. The display shows flashing.
4. Repeat steps 2 & 3 to store other desired tracks until all tracks programmed.

N
-
3
5. Press the PLAY/PAUSE button to start playback from the first programmed track. The
display will show . (The first programmed track)
6. Press the STOP button to stop program playback.
E-4
To Erase the Memory(Program)
To clear the program, you have two option s:
1. Press STOP button when the disc stopped, or
2. Open the CD compart ment lid, program will be erased.
REPEAT
You can play one track or all tracks on the disc repeatedly.
To Repeat a Single Track
1. Press the REPEAT button once in play, " " shows flashing on the display. The
current track will be played over and over a gain till you press the STOP button.
2. To cancel repeat play, press REPEAT button twice. " " disappear s from display.
To repeat all the Tracks
1. Press REPEAT button twice in play, " " shows steady o n the display, all tracks on
the disc will be p layed over and over again till you press the STOP button.
2. To cancel repeat play, press the REPEAT button once more. " " disappears from
the display.
INTROSCAN PLAY
Press the CD PLAY MODE button once in stop mode, then press the CD PLAY/ PAUSE
butto n. The unit will start to play the first 10 seconds of music of each track until all tracks
are played . It will then stop. Press the CD PLAY MODE button three times to cancel.
RANDOM PLAY
Press the CD PLAY MODE button twice in stop mode, RDM appears on the display. P ress
the CD PLAY/ PAUSE button to start play ing tracks in a random order until all tracks are
played . It will then stop. Press the CD PLAY MODE button twice to cancel.
DIRECTORY SEARCHING (for MP3 only)
Press the CD PLAY MODE button three times and/ or hold in stop mode or during play .
Press the CD PLAY/ PAUSE button to start play ing the tracks located in the root of the next
directory. Press the CD PLAY MODE button once to cancel.
To select a song which track num ber exceeds 10 (for MP3
only)
Us e the +10 MP3 button and the CD SKIP FORWARD button to select a song which track
number exceeds 10, press this button to skip 10 tracks each time. For example, to select
track 45, press +10 button 4 times, then press the CD SKIP FORWARD button five times,
the display will show the track number 45 .

N
-
4
LISTEN ING TO USB FLASH DISK DEVICE
1. Set the FUNCTION switch to CD /MP3 position.
2. Connect the USB Flash Disk Device into the USB PORT.
3. If the USB is readable, the display will show USB, and then start to playback
a utomatically from the first track. E-5
4. Press the STOP button to stop playing. The display will show total number of tracks.
You may proceed repeat play (repeat1- repeat -- all)/ program/ program play/ random
play/ skip up and down operation as the same described in above USING THE
CD/ MP3 .
SPECIFICATIONS
CD SECTION
Channels: 2 channels
Optical pick - up: 3 beams laser
Frequency Response: 100Hz - 16KHz
RADIO SECTION
Receiving Band: FM/FM ST.
Tuning Range: F M: 87.5 - 108 MHz
FM ST. : 87.5 - 1 08 MHz
Antenna: FM rod antenna
USB SECTION
Full Speed : 12Mb/s, Version 1.1
USB Flash Disk Version: 1.1 or 2.0
File System: FAT12, FAT16, FAT32
Auto Search: Whole Disk (MP3 File)
GENERAL
Output Power: 1.2 W x 2 (RMS)
Phones ja ck: 3.5mm
Power Source: AC 230V/50Hz
DC 9V 1.5V UM - 2/C x 6pcs
Power Consumption: 13.5W
Note: Specifications are subject to change for continuous improvement without prior
notice.
Do not use any USB extension cable for connecting the USB stick which may cause harmful
interference
In case of m al function due to electrostatic discharge, just reset the product (reconnect of
power source may be required) to resume normal operation
If at any time in the future you should need to dispose of this pro duct

N
-
5
please note that Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice. (Waste Electrical and
Electronic Equipment Directive).
