Lenel DirecDoor User manual

7.4
DirecDoor Installation Guide

Lenel®OnGuard®7.4 DirecDoor Installation Guide
This guide is item number 461018001, revision G,August 2017.
© 2017 United Technologies Corporation. All rights reserved.
Lenel®, OnGuard®, Prism®, BlueDiamond™, and UltraView®are registered trademarks or trademarks of UTC Fire &
Security Americas Corporation, Inc. Lenel is a part of UTC Climate, Controls & Security, a unit of United Technologies
Corporation.
All trademarks are the property of their respective owners.
Information in this document is subject to change without notice. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior express written
permission of UTC Fire & Security Americas Corporation, Inc., which such permission may have been granted in a
separate agreement (i.e., end user license agreement or software license agreement for the particular application).
Non-English versions of Lenel documents are offered as a service to our global audiences. We have attempted to provide
an accurate translation of the text, but the official text is the English text, and any differences in the translation are not
binding and have no legal effect.
The software described in this document is furnished under a license agreement and may only be used in accordance with
the terms of that agreement.
Crystal Reports for Windows is a trademark of Business Objects, S.A.
OnGuard includes ImageStream® Graphic Filters. © 2002 eBT International, Inc. (f/k/a Inso Corporation). All rights
reserved. ImageStream Graphic Filters and ImageStream are registered trademarks of eBT International, Inc. (f/k/a Inso
Corporation).
Integral and FlashPoint are trademarks of Integral Technologies, Inc.
Portions of this product were created using LEADTOOLS ©1991-2011, LEAD Technologies, Inc. ALL RIGHTS
RESERVED.
Active Directory, Microsoft, SQL Server,Windows, and Windows Server are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
Oracle is a registered trademark of Oracle International Corporation.
Other product names mentioned may be trademarks or registered trademarks of their respective companies and are hereby
acknowledged.
Warranty
UTC Fire & Security Americas Corporation, Inc. (“Lenel”) warrants that the product is free from defects in material and
workmanship under normal use and service with proper maintenance for one year from the date of factory shipment. Lenel
assumes no responsibility for products damaged by improper handling, misuse, neglect, improper installation, over-
voltages, repair, alteration, or accident. This warranty is limited to the repair or replacement of the defective unit. In no
event shall Lenel be liable for loss of use or consequential damages of any kind, however occasioned. There are no
expressed warranties other than those set forth herein. Warranty expressly excludes third party additions, deletions and/or
upgrades to this product, including those contained herein. Lenel does not make, nor intends, nor does it authorize any
agent or representative to make any other warranties or implied warranties, and expressly excludes and disclaims all
implied warranties of merchantability or fitness for a particular purpose.
Returned units are repaired or replaced from a stock of reconditioned units. All returns must be accompanied by a return
authorization number (RMA) obtained from the Lenel customer service department prior to returning or exchanging any
product. The RMA number must appear on the outside of the shipping box and on the packing slip.Any items returned
without an RMA number will not be accepted and will be returned at the customer's expense. All returns must have
transportation, insurance, and custom brokers’ fees prepaid.

Liability
It is expressly understood and agreed that the interface should only be used to control exits from areas where
an alternative method for exit is available. This product is not intended for, nor is rated for operation in life-
critical control applications. Lenel is not liable under any circumstances for loss or damage caused by or
partially caused by the misapplication or malfunction of the product. Lenel's liability does not extend beyond
the purchase price of the product.
LENEL DOES NOT REPRESENT THAT SOFTWARE, HARDWARE OR RELATED SERVICES MAY NOT BE
HACKED, COMPROMISED AND/OR CIRCUMVENTED. LENEL DOES NOT WARRANT THAT SOFTWARE,
HARDWARE OR RELATED SERVICES WILL WORK PROPERLY IN ALL ENVIRONMENTS AND
APPLICATIONS AND DOES NOT WARRANT ANY SOFTWARE, HARDWARE OR RELATED SERVICES
AGAINST HARMFUL ELECTROMAGNETIC INTERFERENCE INDUCTION OR RADIATION (EMI, RFI, ETC.)
EMITTED FROM EXTERNAL SOURCES. THEABILITY OF SOFTWARE, HARDWARE AND RELATED
SERVICES TO WORK PROPERLY DEPENDS ON A NUMBER OF PRODUCTS AND SERVICES MADE
AVAILABLE BY THIRD PARTIES OVER WHICH LENEL HAS NO CONTROL INCLUDING, BUT NOT LIMITED
TO, INTERNET, CELLULARAND LANDLINE CONNECTIVITY; MOBILE DEVICE AND RELATED OPERATING
SYSTEM COMPATABILITY; OR PROPER INSTALLATION, CONFIGURATION AND MAINTENANCE OF
AUTHORIZED HARDWARE AND OTHER SOFTWARE.
LENEL MAY MAKE CERTAIN BIOMETRIC CAPABILITIES (E.G., FINGERPRINT, VOICE PRINT, FACIAL
RECOGNITION, ETC.), DATA RECORDING CAPABILITIES (E.G., VOICE RECORDING), AND/OR DATA/
INFORMATION RECOGNITION AND TRANSLATION CAPABILITIES AVAILABLE IN PRODUCTS LENEL
MANUFACTURES AND/OR RESELLS. LENEL DOES NOT CONTROL THE CONDITIONS AND METHODS OF
USE OF PRODUCTS IT MANUFACTURES AND/OR RESELLS. THE END-USER AND/OR INSTALLER AND/OR
RESELLER/DISTRIBUTORACTAS CONTROLLER OF THE DATA RESULTING FROM USE OF THESE
PRODUCTS, INCLUDING ANY RESULTING PERSONALLY IDENTIFIABLE INFORMATION OR PRIVATE
DATA, ANDARE SOLELY RESPONSIBLE TO ENSURE THATANY PARTICULAR INSTALLATIONAND USE OF
PRODUCTS COMPLY WITH ALL APPLICABLE PRIVACY AND OTHER LAWS, INCLUDING ANY
REQUIREMENT TO OBTAIN CONSENT. THE CAPABILITY OR USE OF ANY PRODUCTS MANUFACTURED
OR SOLD BY LENEL TO RECORD CONSENT SHALL NOT BE SUBSTITUTED FOR THE CONTROLLER’S
OBLIGATION TO INDEPENDENTLY DETERMINE WHETHER CONSENT IS REQUIRED, NOR SHALL SUCH
CAPABILITY OR USE SHIFT ANY OBLIGATION TO OBTAIN ANY REQUIRED CONSENT TO LENEL.

DirecDoor Installation Guide 5
Table of Contents
CHAPTER 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
CHAPTER 2 Installation, Planning, and Mounting . . . . . . . . . . . . . . . . . . . . . . . .15
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Radio Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Electrostatic Discharge (ESD) Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
General Installation Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Observing Noise Prevention Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Signal Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Mounting and Handling Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mounting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Determining Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
CHAPTER 3 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Connectors and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Power LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Installing the PoE (Power over Ethernet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing the Auxiliary Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Installing the Battery Backup, AC Fail, and Low Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Wiring the Tamper Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Table of Contents
6DirecDoor Installation Guide
CHAPTER 4 DirecDoor Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
DirecDoor Board Overview and Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Switches and Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
LED Indicators on the DirecDoor Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Input LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
UCSIMMPlus Board LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Safe Shutdown Procedure for the DirecDoor Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Important Information for Firewall Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring Upstream Communications with the Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
CHAPTER 5 Reader Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Setting the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Setting the Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Wiring the Readers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Wiring the Digital Inputs (DIs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Wiring the Door Strikes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Wiring the Fire Alarm Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
CHAPTER 6 DDIO Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
DirecDoor I/O Expansion Board Overview and Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setting the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Installing the DDIO in the Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Installing the DDIO in a Remote Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Power and RS485 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Input and Output Device Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Available Resistance Combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
CHAPTER 7 DO Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Wiring Digital Outputs (DOs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
CHAPTER 8 Dual Network Interface Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

DirecDoor Installation Guide 7
Table of Contents
CHAPTER 9 Pre-Power Up Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Testing the DirecDoor Controller Before Powering Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
CHAPTER 10 Controller Firmware Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Integrated Configuration Tool (ICT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Software and Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Connecting and Starting the Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Controller Setup Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Controller Information Menu > Parameters Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Controller Information Menu > Information Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Controller Parameters Menu > Primary Network Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Controller Parameters Menu > Secondary Network Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Controller Parameters Menu > Other Parameters Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Disable/Enable the Integrated Configuration Tool (ICT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Upgrading the Controller Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Configuration Checklist for the Integrated Configuration Tool . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Configuring the Host Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Configuring the DirecDoor Controller in the Host Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Configuring the Dual NIC in the Host Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
CHAPTER 11 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
CE (European) and FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
CE Regulatory Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
WEEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
UL Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
CHAPTER 12 Troubleshooting and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . .83
Power Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Reader Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Door Strike Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
DirecDoor Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Diagnostic LED Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Inserting and Removing the UCSIMMPlus Board on the DirecDoor Board . . . . . . . . . . . . . . . . . . . . . . 86
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Table of Contents
8DirecDoor Installation Guide

DirecDoor Installation Guide 9
CHAPTER 1 Introduction
Notes: This manual covers all versions of the DirecDoor Controller, including the DirecDoor
Single Door Controller (DDSDC). The DDSDC has fewer hardware components and
features than other DirecDoor models.
The following components have been removed from the DDSDC:
Connector J4: The DDSDC only supports one door that can support up to two (2)
readers.
Connector J5 and Switch SW3: The DDSDC does not support the DirecDoor I/O
Expansion Board (DDIO). The DDSDC does not support RS-485 communication.
Connector J7: The DDSDC does not support the NX bus.
Connector J11: The DDSDC does not support a dial-up modem.
The DDSDC also does not support a Dual Network Interface Card (NIC).
When working with the DDSDC and this manual, ignore references to the above-
mentioned hardware components and features, and any references about the host
application and/or the ICT and these components/features.
The DirecDoor controller provides distributed processing for the interface of access control readers,
keypads, alarm inputs and outputs back to a host system computer. This distributed processing allows
each DirecDoor controller to operate independent of the host system computer with the majority of
access control and alarm monitoring decisions made locally at the controller. DirecDoor provides
instant response for door control and alarm sensing in the field, while leaving the host system
computer with more processing power for quickly executing daily operations such as alarm response,
database updates and reporting.
DirecDoor incorporates flash memory technology that provides the ability to receive its operating
system and application remotely from the host system over the already established communications
path. This allows future firmware upgrades centrally from the host system without requiring costly
service trips to each location for firmware replacement. Both, the modular design and the flash
memory technology, provide a simple migration path when considering future host system upgrades.
The DirecDoor controller consists of the following:
•Enclosure with DirecDoor PCA mounted
•Hardware kit

Introduction
10 DirecDoor Installation Guide
–Ground terminal lug
–SEMS screws
–Protection diodes
–Metal Oxide Varistors (MOVs) surge absorbers
–Network cable ferrite
–1K end-of-line resistors
•Mounting hole template
•Installation screwdriver
•DirecDoor Quick Installation Instructions
•DirecDoor Integrated Configuration Tool Quick Guide
The items received in your shipment depend on the items ordered. Inspect the package and contents
for visible damage. If any components are damaged or missing, do not use the unit; contact the
supplier immediately. If you need to return the unit, you must ship it in the original box.
Specifications
For UL-compliant installations, refer to UL Compliance on page 80.
Enclosure Specifications
Physical dimensions 10.15 inches high x 9.15 inches wide x 3.04 inches deep
(258 mm high x 232 mm wide x 77 mm deep)
Operating environment +35°F to +122°F (+2°C to +50°C)
Humidity range 5% to 95% non-condensing
Thermal air cooling At least 6 inches (15.2 cm) of clearance is required on all four sides of
the controller.
Power
Controller power input
requirements •IEEE802.3af 16 watt Class 0 Mode A or B Power over Ethernet Power Sourcing Equipment (PoE/PSE) on Standard Category 5
Ethernet Cable
Note: By Ethernet standards, the maximum cable length is limited to
328 ft. (100 m) between the PoE source and the DirecDoor
controller.
-Or-
•Auxiliary 24 VDC 1 A local supply (24 watts)
Cabling
Host to controller •Network: Cat 5 Type A or B

DirecDoor Installation Guide 11
Specifications
Note: For output load capacity (watts) available for readers and strikes, refer to Determining
Power Requirements on page 20.
Controller to readers Reader voltage: 12 VDC
If the cable distance is:
•Greater than 500 feet (152.4 m), but not greater/longer than
2000 feet (609.6 m), and/or current per reader greater than150 mA:
use 20-AWG shielded cable, refer to Reader Interface on page 37.
•Less than 500 feet (152.4 m): use 22-AWG shielded cable.
We recommend using 20-AWG shielded cable to wire readers, DOs, and
DIs. Use plenum-rated cable for applications where cable is to be run
above the false (suspended) ceiling in the air circulation space.
Recommended:
•Alpha Xtra Guard1® foil shield cable, non-plenum-rated
•Belden series security and alarm cable (commercial applications
shielded), plenum-rated
Controller to DIs or
DOs Use any cable with the desired number of individually shielded pairs.
Devices
Readers •Number supported: maximum of two (2) readers
•Reader technology supported: Wiegand, F/2F, and Supervised F/2F
•Supports keypad only and keypad/reader technology
•Output devices maximum ratings:
•Door DO (Reader LED) = 20 mA @ 12 VDC maximum
•Door strike (DO) relay = 2 A @ 28 VDC or 30 VAC maximum
Strikes Maximum current: 390 mA per strike output.
Refer to table Device Current on page 12 for recommended strike
models and associated power requirements.
DOs •Number supported: maximum six (6) DOs
•Output devices maximum ratings: six (6) DO outputs: 20 mA @ 7.5
to 12 VDC
Regulatory information
Listings •FCC Class A
•UL 1076
•UL 294
•CE
Refer to Regulatory Information on page 77 for more information.
Maximum Peripheral Loads
Reader/Strike PoE Auxiliary Power Supply
Voltage DC 12 24 12 24
Enclosure Specifications (Continued)

Introduction
12 DirecDoor Installation Guide
For readers not listed in the table below, refer to the applicable reader installation manual.
Total watts available 8 10 12 20
Device Current
Device Operating Voltage Avg. Measured Current (mA) Watts
Model T100 reader 12 55 0.66
Model T200 reader 12 55 0.66
Model T500 reader 12 95 1.14
Model T520 reader 12 105 1.26
Model T525 reader 12 140 1.68
Model T700 reader 12 75 0.90
Model T720 reader 12 75 0.90
Model T725 reader 12 110 1.32
Securitron M62 Magnalock
strikea12 240 2.88
Securitron M62 Magnalock
strikea
a. When using magnetic strikes with auto-voltage select, additional power allowances must be considered
due to auto-voltage circuitry operation.
24 140 3.36
HES, Inc 5000-12/24D strike 12 230 2.76
HES, Inc 5000-12/24D strike 24 115 2.76
Rutherford 4114x05x32D strike 12 190 2.28
Von Duprin 5100 3FP695
24 VDC 12 390 4.68
Von Duprin 5100 3FP695
24 VDC 24 195 4.68
RCR-REX 12 28 0.336
RCR-REX 24 17 0.408
Maximum Peripheral Loads (Continued)
Reader/Strike PoE Auxiliary Power Supply

DirecDoor Installation Guide 13
Specifications
CPU Specifications
Communications Interfaces
Network 10/100 MB Ethernet, on-board Ethernet RJ-45
connection, Supports Static IP, UDP, and DHCP
CPU Specifications Type 2 SIMMaType 3 SIMMb
Operating system uClinux 2.6 uClinux 2.6
Processor Xilinx MicroBlaze Xilinx MicroBlaze
RAM 32 MB 64 MB
Flash memory 32 MB 32 MB
Host Application and Capacities
All currently supported versions of OnGuard
Badge capacity 28,000
Offline transaction capacity (number of logs) 50,000
a. The Type 2 SIMM supports only Mode B Power over Ethernet.
b. The Type 3 SIMM supports Mode A and Mode B Power over Ethernet.

Introduction
14 DirecDoor Installation Guide

DirecDoor Installation Guide 15
CHAPTER 2 Installation, Planning, and Mounting
Read these instructions and all supporting documentation entirely before installing or operating this
product. A qualified service person, complying with all applicable codes, should perform the
hardware installation.
Note: We recommend that you configure DirecDoor controllers before field deployment.This
means you should define your network addressing scheme prior to installation, bench
configure your DirecDoor controllers following the networking scheme, and identify
the DirecDoor controller externally, then proceed with on-site installation.
The following is a basic outline for installing and setting up your DirecDoor system. Some steps may
have been done for you depending on what you ordered. Some steps are optional, depending on the
additional equipment you plan to use. These steps are noted.
• WARNING! • Do not apply power to any component until the installation is complete.
Damage to components may occur if power is incorrectly applied.
1. Determine the cable clamps needed and obtain them before starting the installation.
During the installation, remember to:
•Label all connections/cables for ease of maintenance.
•Leave enough slack in the wiring so the cables can be “dressed.” This minimizes
interference during board removal or replacement.
2. Unpack your system. Refer to Introduction on page 9.
3. Mount the enclosure. Refer to Mounting on page 17.
4. If required, mount and install one of the following:
•PoE power supply. Refer to Installing the PoE (Power over Ethernet) on page 24.
•Auxiliary power supply with battery backup. Refer to Installing theAuxiliary Power Supply
on page 25.
5. Verify that your network is up and running.
6. Install and wire up the DirecDoor board. Be sure to configure and verify the jumpers. Plug in the
network cable. Refer to DirecDoor Board on page 27.
7. Wire the readers to the controller. Be sure to configure and verify the switch settings and
jumpers. Refer to Reader Interface on page 37.

Installation, Planning, and Mounting
16 DirecDoor Installation Guide
8. If using digital outputs, wire the digital outputs to the board. Refer to DO Interface on page 57.
9. Test the wiring before you apply power. Refer to Pre-Power Up Testing on page 61.
10. Configure your controller. Configure the controller using the Integrated Configuration Tool.
Refer to Controller Firmware Tools on page 63.
Safety
Radio Interference
Note: This is an FCC Class A product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate measures.
Electrostatic Discharge (ESD) Precaution
• WARNING! • Circuit board components are vulnerable to damage by electrostatic discharge
(ESD). ESD can cause immediate or subtle damage to sensitive electronic
parts. An electrostatic charge can build up on the human body and then
discharge when you touch a board.A discharge can be produced when walking
across a carpet and touching a board, for example. Before handling any board,
make sure you dissipate your body’s charge by touching ground. This
discharges any static electricity build-up.
General Installation Rules
• WARNING! • This equipment is to be installed, maintained and serviced by authorized
service persons only.
The authorized installation contractor should comply with the following rules:
•Neatly label cables at both ends.
(For example, labels should include: controller address number/device or reader number)
•Use individually shielded pairs of cables only. All wiring must comply with local, state, and
federal electrical codes and fire codes.
•Obey all national, state, and local electrical and safety codes.
•Obtain any required permits and/or inspections. Contact the local fire marshal for assistance if
necessary.
•Safety of customer personnel is the primary consideration of the installation.
•Neatly dress and tie or lace all wiring in a professional manner.
•Gather together and tape all unused conductors in multiple conductor cables.
•Shield all cabling and terminate properly.

DirecDoor Installation Guide 17
Observing Noise Prevention Procedures
Observing Noise Prevention Procedures
Signal Transmission
•Where practical, keep cables well separated from each other. Separate power cables from signal
cables.
•Keep the break-out at the ends of signal cables as short as possible.
•Ground all shield drain wire(s) at the DirecDoor controller using the grounding nuts provided
outside the cabinet enclosure.
• WARNING! • Do not ground both cable ends.
Cable Routing
Keep cabling at least 1 foot (30.5 cm) away from any power line or other AC voltage source.
Exercise caution when locating cables and DirecDoor components near any other equipment that may
cause electrical interference (noise). Examples of electrical and electro-magnetic noise sources are:
•Fluorescent lighting and neon fixtures.
•Power distribution panels, including wiring, transformers, generators, and alternators.
•Motors that drive machinery, such as air conditioners, elevators, escalators, large blowers, and
machine tools. Electromagnetic equipment such as degaussers, magnetic chucks, etc.
•Control equipment (relays) for machinery and other switching devices that carry or switch large
currents.
•Radio and television receivers and transmitters.
•Signal generators and intercom systems.
•Radar transmitting equipment.
•Arc welders, electrodischarge machinery, and related equipment.
•RF induction heaters.
Cable Length
•Minimize long parallel cable runs since they increase the likelihood of interference between
signal cables and electrical interference sources.
•Avoid excess cable length between the DirecDoor controller and the optional equipment, such as
readers and digital outputs, to reduce signal degradation due to external effects.
Mounting
Be sure to read the mounting and handling guidelines below before beginning to mount the controller.
Mounting and Handling Guidelines
Comply with the following guidelines:
•Locate the host computer and the DirecDoor controller in areas secure from any disruption to
data communications or tampering.

Installation, Planning, and Mounting
18 DirecDoor Installation Guide
•Clean and clear all mounting areas of corrosive gases and airborne metallic particles. Avoid
installing near photocopiers due to contamination from toner particles.
•Protect the DirecDoor from hazardous (high) voltages.
•Mount the DirecDoor on a vertical surface with at least 6 inches (15.2 cm) clearance on all four
sides to support thermal air cooling.
•Locate the DirecDoor in a place that provides dedicated AC earth ground. The DirecDoor must
be earth grounded.
•Keep interior and exterior housing of all DirecDoor cabinets and other components free of wire
remnants.
•Avoid temperatures outside range specified for DirecDoor operating environment (refer to
Specifications on page 10). Do not leave boards or other components in direct sunlight.
•To avoid mechanical damage, do not drop or stack boards.
•Do not subject printed circuit boards to electrostatic discharge.
Mounting Instructions
Mount the controller cabinet using the following steps, the DirecDoor Mounting Template on
page 19, and figure DirecDoor Controller and Components in Standard Enclosure on page 20.
• WARNING! • Do not apply power to any component during installation. Damage to
components may occur if power is incorrectly applied.
1. Remove enclosure from shipping container and remove any packing material.
2. Using the DirecDoor Mounting Template, mark and then drill the four (4) mounting holes.
3. Bolt the enclosure securely to the wall using four (4) #8 thread lag bolts or equivalent.
4. The DirecDoor has standard cable knockouts on the sides, bottom and back of enclosure. These
knockouts are to be used to install cabling. Use proper size and type of cable strain reliefs to
secure cables to enclosure.
• WARNING! • The DirecDoor controller must be earth grounded.

DirecDoor Installation Guide 19
Mounting
DirecDoor Mounting Template

Installation, Planning, and Mounting
20 DirecDoor Installation Guide
DirecDoor Controller and Components in Standard Enclosure
Determining Power Requirements
Use the DirecDoor Wattage Calculator worksheet below to help plan your installation. An Excel
(XLS) version of the DirecDoor Wattage Calculator is available at this link.
