Intelligent Controller LNL-X2220 Quick Reference
General
The LNL-X2220 intelligent controller provides decision making, event reporting, and database storage for the Lenel
hardware platform. Two reader interfaces provide control for two physical barriers.
The LNL-X2220 communicates with the host via on-board 10-BaseT/100Base-TX Ethernet port or the Micro USB
port (2.0) with an optional Micro USB to Ethernet adapter.
Each reader port can accommodate a reader that utilizes TTL (D1/D0, Clock/Data), F/2F (standard or supervised) or
2-wire RS-485 device signaling (OSDP reader for example) and also provides tri-state LED control, and buzzer
control (one wire LED mode only). Four Form-C relay outputs may be used for door strike control or alarm signaling.
Eight inputs are provided that may be used for monitoring the door contacts, exit push buttons, and alarm contacts.
Input circuits may be configured as unsupervised or supervised. The LNL-X2220 requires 12 to 24 VDC for power.
LNL-X2220 Hardware
VIN
TMP
GND
FLT
GND
TB1
GND
J2
D16
J6
GND_C
J5
GND
D0
CLK
LED
VO
BZR
DAT
D1
READER 1
GND
D0
CLK
LED
VO
BZR
DAT
D1
READER 2
TB9
TB8
NO
NO
C
NC
C
NC
OUT 1
OUT 2
PASS
NO
NO
C
NC
C
NC
OUT 3
OUT 4
12V
1
4
3
2
S1
ON
V
| | | | | |
1
2
3
4
5
R1
R2
J8
TR+
TR-
GND
IN1
IN2
TB3
TB4
TB5
TB6
IN3
IN4
IN5
IN6
IN7
IN8
TB7
K
1
K
2
K
3
K
4
J7 TB10 TB11
3V BR/CR2330
RESET
S2
BT1
.50 [12.70]
2.00 [50.80]
3.00 [76.20]
2.00 [50.80]
.50 [12.70]
8.00 [203.20]
5.50 [139.70].25 [6.35]
6.00 [152.40]
Ø.156 [3.96]
8 places
J2: Ethernet
jack
Earth
ground
S1 : DIP
switches
J6: Micro
USB jack
J8: microSD
card
Input
status LEDs
Relay
status LEDs
Status
LEDs
Battery: BR/CR2330
(replace annually)
S2: Reset switch
J7: Reader
power
select
J5: RS-485
terminator
J19
J19: Battery backup
+1
3
2
4
J10
-
J10: Remote
status LED
connection

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 2 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
LNL-X2220 Wiring
*Terms A & B are from the RS-485 standard.
Terminal Blocks 1-7 Connections Terminal Blocks 8-11 Connections
TB1-1 Power Fault
Input GND TB8-1 Reader 1 GND: Ground
TB1-2 FLT TB8-2 DAT/D0: Data/Data 0/
TR- (A) *
TB1-3 Cabinet
Tamper Input GND TB8-3 CLK/D1: Clock/Data 1/ TR+ (B) *
TB1-4 TMP TB8-4 BZR: Reader Buzzer
TB1-5 Power Input GND TB8-5 LED: Reader LED
TB1-6 VIN: 12 to 24 VDC TB8-6 VO: Reader Power
TB2 N/A Not Used TB9-1 Reader 2 GND: Ground
TB3-1 SIO Port
(2-wire
RS-485)
GND TB9-2 DAT/D0: Data/Data 0/
TR- (A) *
TB3-2 TR- (B) * TB9-3 CLK/D1: Clock/Data 1/
TR+ (B) *
TB3-3 TR+ (A) * TB9-4 BZR: Reader Buzzer
TB4-1 Input 2 IN2 TB9-5 LED: Reader LED
TB4-2 IN2 TB9-6 VO: Reader Power
TB4-3 Input 1 IN1 TB10-1 Out 1 NO: Normally Open Contact
TB4-4 IN1 TB10-2 C: Common
TB5-1 Input 4 IN4 TB10-3 NC: Normally Closed Contact
TB5-2 IN4 TB10-4 Out 2 NO: Normally Open Contact
TB5-3 Input 3 IN3 TB10-5 C: Common
TB5-4 IN3 TB10-6 NC: Normally Closed Contact
TB6-1 Input 6 IN6 TB11-1 Out 3 NO: Normally Open Contact
TB6-2 IN6 TB11-2 C: Common
TB6-3 Input 5 IN5 TB11-3 NC: Normally Closed Contact
TB6-4 IN5 TB11-4 Out 4 NO: Normally Open Contact
TB7-1 Input 8 IN8 TB11-5 C: Common
TB7-2 IN8 TB11-6 NC: Normally Closed Contact
TB7-3 Input 7 IN7
TB7-4 IN7

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 3 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
Jumpers and Jacks
The LNL-X2220 processor hardware interface is configured using jumpers to setup the reader port power and end of
line termination.
* Install jumper J7 in the 12V position ONLY if the input voltage (VIN) is greater than 20 VDC.
Failure to do so may damage the reader or LNL-X2220.
**Observe polarity connection to LED. External current limiting is not required.
DIP Switches
The four switches on S1 DIP switch configure the operating mode of the LNL-X2220 processor. DIP switches are
read on power-up except where noted.
Pressing reset switch S2 causes the LNL-X2220 to reboot.
Jumpers Set at Description
J1 N/A Factory Use Only
J2 N/A 10-Base-T/100Base-Tx Ethernet Connection (Port 0)
J3 N/A Factory Use Only
J4 N/A N/A
J5 OFF RS-485 EOL Terminator is Off
ON RS-485 EOL Terminator is On
J6 N/A Micro USB Port (2.0)
J7 Reader Power Select *
12V 12 VDC at Reader Ports
PASS VIN "Pass Through" to Reader Ports
J8 N/A microSD Card
J10-1 N/A Remote Status LED #1 **
J10-2 N/A Remote Status LED #2 **
J10-3 N/A Remote Status LED #3 **
J10-4 N/A Remote Status LED #4 **
J19 OFF Backup battery is OFF
ON Backup battery is ON. Refer to Memory and Real Time
Clock Backup Battery on page 7.

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 4 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
X = ON or OFF. All other switch settings are unassigned and reserved for future use.
* In the factory or Lenel default modes, downloaded configuration/database is not saved to flash memory.
FactoryDefaultCommunicationParameters
Interface 1 (NIC1)
• Network: static IP address: 192.168.0.251
• Subnet Mask: 255.255.0.0
• Default Gateway: 192.168.0.1
• DNS Server: 192.168.0.1
• Primary Host port: IP server, Data Security: TLS if Available, port 3001, communication address: 0
• Alternate Host Port: Disabled
Bulk Erase Configuration Memory
The bulk erase function can be used for the following purposes:
• Erase all configuration and cardholder database (sanitize board, less third party applications)
• Update OEM default parameters after OEM code has been changed
• Recover from database corruption causing LNL-X2220 board to continuously reboot
If clearing the memory does not correct the initialization problem, contact LenelS2 OnGuard Technical Support.
Bulk Erase Steps
Important: Do not remove power during steps 1-6.
1. Set S1 DIP switches to: 1 & 2 "ON," 3 & 4 "OFF."
2. Apply power to the LNL-X2220 board. LED 1 on for about 15 seconds while LNL-X2220 boots up.
3. After the LNL-X2220 boots up, watch for LEDs 1 & 2 and 3 & 4 to alternately flash at a 0.5 second rate.
4. Within 10 seconds after the above pattern starts, change switches 1 or 2 to "OFF." If these switches are not
changed, the LNL-X2220 board will power up using the OEM default communication parameters.
5. LED 2 will flash indicating that the configuration memory is being erased. Full memory erase takes up to 60
seconds, usually a lot less.
When complete, only LEDs 1 & 4 will flash for about 3 seconds.
6. The LNL-X2220 board will complete its initialization in 2 seconds after LEDs 1 & 4 stop flashing.
1 2 3 4 Definition
OFF OFF OFF OFF Normal operating mode.
ON X OFF OFF After initialization, enable default User Name (admin) and
Password
(password). The switch is read on the fly, no need to re-boot. For more
information refer to IT Security on page 8.
OFF ON OFF OFF Use factory default communication parameters. *
ON ON OFF OFF Use Leneldefault communication parameters. *
Contactsystem
manufacturerfordetails. See Bulk Erase Configuration
Memory on page 4.
ON ON OFF OFF Bulk Erase prompt mode at power up. See Bulk Erase Configuration
Memory on page 4.
X X X ON Makes the LNL-X2220 report and function like an LNL-2220. To be
used in situations where the host software has not been updated to
support the LNL-X series product line.

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 5 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
Input Power, Cabinet Tamper, and UPS Fault Input Wiring
The LNL-X2220 requires 12 to 24 VDC power. Locate power source as close
to the unit as possible. Connect power with minimum of 18 AWG wire.
Connect the GND signal to earth ground in ONE LOCATION within the
system. Multiple earth ground connections may cause ground loop
problems and is not advised.
Observe POLARITY on 12 to 24 VDC input.
There are two dedicated inputs for cabinet tamper and UPS fault monitoring.
Normal (safe) condition is a closed contact. If these inputs are not used, install
a jumper wire.
Communication Wiring
The LNL-X2220 controller communicates to the host via the on-board Ethernet 10-
BaseT/100Base-TX port and/or the USB port (2.0) with an optional USB to Ethernet
adapter.
The serial I/O device communication port (TB3) is a 2-wire RS-485 interface which can
be used to connect additional I/O panels. The interface allows multi-drop
communication on a single bus of up to 4,000 feet (1,219 m). Use 1-twisted pair with
drain wire and shield, 120 ohm impedance, 24 AWG, 4,000 ft. (1,219 m) maximum for
communication.
Important: Install the termination jumper ONLY on the panel at each
end of the RS-485 bus. Failure to do so will compromise the
proper operation of the communication channel.
Reader Wiring
Each reader port supports a reader with TTL (D1/D0, Clock/Data), F/2F (standard or supervised) or 2-wire RS-485
signaling (OSDP reader for example). Power to the readers is selectable: 12 VDC (VIN must be greater than 20
VDC), or power is passed-through (PASS) from the input voltage of the LNL-X2220 (TB1-VIN), 300 mA maximum
per reader port. Readers that require different voltage or have high current requirements must be powered separately.
Refer to the reader manufacturer’s specifications for cabling requirements. In the 2-wire LED mode, the buzzer
output is used to drive the second LED. Reader port configuration is set via the host software.
To fully utilize each reader port:
• TTL signaling requires a 6-conductor cable (18 AWG)
• F/2F signaling requires a 4-conductor cable
• RS-485 signaling requires two 2-conductor cables. Use one cable for power (18 AWG) and one cable for
communication (24 AWG, with drain wire and shield)
Notes: For OSDP cable lengths greater than 200 ft (61 m) or EMF interference, install 120Ω+/- 2Ωresistor
across RS-485 termination ends.
Data 0 and Data 1 wires for Wiegand may be reused for OSDP. However, standard Wiegand cable may
not meet RS-485 twisted pair recommendations. The reuse of cable works best on shorter cable lengths
at lower data rates.
12 TO 24 VDC
VIN
+
-
CABINET
TAMPER
POWER
FAULT
TB1
TMP
GND
FLT
GND
GND
TR-
TR+
GND
To serial I/O Devices
TB3
1

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 6 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
Note: If the input voltage to the LNL-X2220 is 12 VDC, jumper J7 MUST be in the PASS position.
Typical D1/D0 or Clock/Data Reader Typical 2-wire RS-485 Device (such as OSDP Reader)
Typical Unsupervised F/2F Reader Typical Supervised F/2F Reader
Input Circuit Wiring
There are 8 inputs that are typically used to monitor door position, request to exit, or alarm contacts. Input circuits can
be configured as unsupervised or supervised. When unsupervised, reporting consists of only the open or closed states.
When configured as supervised, the input circuit will report not only open and closed, but also open circuit, shorted,
grounded,* and foreign voltage.* A supervised input circuit requires two resistors be added to the circuit to facilitate
proper reporting. The standard supervised circuit requires 1k ohm, 1% resistors and should be located as close to the
sensor as possible. Custom end of line (EOL) resistances may be configured via the host software.
* Grounded and foreign voltage states are not a requirement of UL 294 and therefore not verified by UL.
12V PASS J7 Reader Power Select
12 VDC is available on reader ports (VIN is greater than or equal to 20 VDC).
VIN power is “passed through” (PASS) to reader ports.
TB8 OR TB9
POWER
TR+ (B)
TR- (A)
GND GND
DAT/D0
CLK/D1
VO
TB8 OR TB9
GND
DAT/D0
CLK/D1
BZR
LED
VO
GND
DAT/D0
CLK/D1
BUZZER
LED
POWER
VO
LED
BZR
D1/CLK/TR+
D0/DAT/TR-
GND
+12 VDC
D1
GROUND
DO (GREEN LED)
1
TB8 or TB9
1
VO
LED
BZR
D1/CLK/TR+
D0/DAT/TR-
GND
+12 VDC
D1
GROUND
DO (GREEN LED)
NORMALLY CLOSED CONTACT *
DOOR MONITOR SWITCH
REQUEST TO EXIT SWITCH
NORMALLY OPEN CONTACT *
1K,1%
1K,1%
1K,1%
1K,1%
TB8 or TB9
* Jumper: Connect D1 and LED on supervised F/2F readers.

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 7 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
The input circuit wiring configurations shown are supported but may not be typical:
Relay Circuit Wiring
Four relays with Form-C contacts (dry) are provided for controlling door lock mechanisms or alarm signaling. Each
relay has a Common pole (C), a Normally Open pole (NO) and a Normally Closed pole (NC). When controlling the
delivery of power to the door strike, the Normally Open and Common poles are typically used. When momentarily
removing power to unlock the door, as with a magnetic lock, the Normally Closed and Common poles are typically
used. Check with local building codes for proper egress door installation.
Door lock mechanisms can generate feedback to the relay circuit that can cause damage and premature failure of the
relay plus affect the operation of the LNL-X2220. For this reason, it is recommended that a diode be used to protect
the relay. Wire should be of sufficient gauge to avoid voltage loss.
Diode Selection
Diode current rating: 1x strike current. Diode breakdown voltage: 4x strike voltage. For 12 VDC or 24 VDC strike,
diode 1N4002 (100V/1A) typical.
Memory and Real Time Clock Backup Battery
The static RAM and the real time clock are backed up by a lithium battery when input power is removed. This
battery should be replaced annually. If data in the static RAM is determined to be corrupt after power up, all data,
including flash memory, is considered invalid and is erased. All configuration data must be re-downloaded.
During installation and while the unit is not powered, change the jumper (J19) position from OFF to ON to enable
the battery backup.
Battery type: BR2330 or CR2330.
1K,1%
1K,1%
1K,1%
1K,1%
IN4 IN3 IN2 IN1
Standard Supervised Circuit,
Normally Closed Contact
Standard Supervised Circuit,
Normally Open Contact
Unsupervised Circuit,
Normally Open Contact
Unsupervised Circuit,
Normally Closed Contact
Terminal Blocks
TB4 through TB7

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 8 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
IT Security
When installing the LNL-X2220, it is important to ensure that it is done in a secure manner.
Upon installation, the user accounts to the web configuration page should be created with secure passwords, and that
all DIP switches are in the off position for the normal operating mode. The LNL-X2220 is shipped from the factory
with a default login account, which is enabled when DIP 1 is moved from OFF to ON. The default login user name
and password will be available for five minutes once enabled. Therefore, it is important that at least one user account
is defined, and the DIP switches are set to OFF before the LNL-X2220 is commissioned. It is also highly
recommended not to configure the LNL-X2220 with an IP address that is accessible from the public Internet.
To further enhance network security, options are available to disable SNMP, Zeroconf discovery, as well as the web
configuration module itself. Additionally, data encryption can be enabled over the host communication port.
Status LEDs
Power-up: All LEDs OFF.
Initialization: After power is applied or the reset switch is pressed, LED 1 is ON for about 15 seconds, then LEDs 2
through 6, R1, R2, and IN1 through IN8 are flashed once at the beginning of initialization.
LEDs 3 and 4 turn ON for approximately 1 second after the hardware initialization has completed, then the
application code is initialized. The amount of time the application takes to initialize depends on the size of the
database, about 1 second without a card database. Each 10,000 cards adds about 2 seconds to the application
initialization.
When LEDs 1 through 4 flash at the same time, data is being read from or written to flash memory; do not cycle
power when in this state.
If the sequence stops or repeats, perform “Bulk Erase Steps” on page 4.

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 9 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
Running: After initialization is complete, the LEDs have the following meanings:
* If this input is defined, every three seconds the LED is pulsed to its opposite state for 0.1 seconds,
otherwise, the LED is off.
Specifications
The interface is for use in low voltage, Class 2 circuits only.
The installation of this device must comply with all local fire and electrical codes.
LED Description
1 Off-line / On-line and battery status
Off-line = 20% ON, On-line = 80% ON
Double flash if battery is low
2 Host communication activity (Ethernet or Micro USB port)
3 Internal SIO communication activity
4 External SIO communication activity
5 Unassigned
R1 Reader 1
Clock/Data or D1/D0 mode: Flashes when Data is Received, either input
F/2F mode: Flashes when Data/Acknowledgment is Received
RS-485 mode: Flashes when Transmitting Data
R2 Reader 2
Clock/Data or D1/D0 mode: Flashes when Data is Received, either input
F/2F mode: Flashes when Data/Acknowledgment is Received
RS-485 mode: Flashes when Transmitting Data
D16 Flashes with Ethernet traffic
YEL Ethernet Speed: OFF = 10Mb/S, ON = 100Mb/S
GRN OFF= No link, ON = Good link, Flashing = Ethernet activity
IN1 - IN8 OFF = Inactive, ON = Active, Flash = Fault *
K1 - K4 ON = Energized
Primary Power: 12 to 24 VDC ± 10%, 500 mA maximum (reader and USB ports not
included)
Reader Ports: 600 mA maximum (add 600 mA to primary power current)
Micro USB Port: 5 VDC, 500 mA maximum (add 270 mA to primary power current)
Memory and Clock
Backup Battery: 3 Volt Lithium, type BR2330 or CR2330
microSD Card Format: microSD or microSDHC; 2GB to 8GB
Host Communication: Ethernet: 10-BaseT/100Base-TX and Micro USB port (2.0) with optional
adapter: pluggable model USB2-OTGE100
Serial I/O Device One each: 2-wire RS-485, 2,400 to 115,200 bps, asynchronous, half-
duplex, 1 start bit, 8 data bits, and 1 stop bit

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 10 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
UL 294, 7th edition Performance Levels:
Note: Outputs are Power limited/class 2 when powered by external power limited/class 2 power supply model
LNL-AL400ULX or LNL-AL600ULX-4CB6.
These specifications are subject to change without notice.
Inputs: Eight unsupervised/supervised, standard EOL: 1k/1k ohm, 1%, ¼ watt
Two unsupervised dedicated for cabinet tamper and UPS fault monitoring
Outputs: Four relays, Form-C with dry contacts
Normally open contact (NO) contact: 5 A @ 30 VDC resistive
Normally closed contact (NC) contact: 3 A @ 30 VDC resistive
Reader Interface:
Power:
(jumper selectable) 12 VDC ± 10% regulated, 300 mA maximum each reader (input voltage (VIN) must be greater than 20 VDC)
or
12 to 24 VDC ± 10% (input voltage (VIN) passed through), 300 mA
maximum each reader
Data Inputs: TTL compatible, F/2F or 2-wire RS-485
RS-485 Mode: 9,600 to 115,200 bps, asynchronous, half-duplex, 1 start bit, 8 data bits,
and 1 stop bit. Maximum cable length: 2000 ft. (609.6 m)
LED Output: TTL levels, high>3 V, low<0.5 V, 5 mA source/sink maximum
Buzzer Output: Open collector, 12 VDC open circuit maximum, 40 mA sink maximum
Cable Requirements:
Power: 1 twisted pair, 18 to 16 AWG
Ethernet: CAT-5, minimum
RS-485:
I/O Device Port:
Reader Port:
1 twisted pair, shielded, 120 ohm impedance, 24AWG, 4,000 ft. (1,219 m)
max.
1 twisted pair, shielded, 120 ohm impedance, 24 AWG, 2,000 ft. (610 m)
max.
Alarm Input: 1 twisted pair, 30 ohm maximum
Environmental:
Temperature: Storage: -55 to +85 °C (-67° to 185° F)
Operating: 0 to +70 °C (32° to 158° F)
Humidity: 5 to 95% RHNC
Mechanical:
Dimension: 8 in. (203.2 mm) W x 6 in. (152.4 mm) L x 1 in. (25 mm) H
Weight: 9 oz. (255 g) nominal, board only
Feature Level
Standby Power I
Endurance IV
Line Security I
Destructive Attack I

© 2021 Carrier. All Rights Reserved. LenelS2 is a part of Carrier. 11 QR50L-1037E — revision 4.004
Intelligent Controller LNL-X2220 Quick Reference
UL Listed Installations
• For access control-only installations using DC power, power shall be provided by a UL 294 or UL 603, class 2
power supply with appropriate ratings.
• For burglar alarm installations, backup power is not provided. A UL 603 listed, class 2 power supply with
appropriate ratings shall be used that provides a minimum four hours of standby power after notification of loss
of AC power.
• Locations and wiring methods shall be in accordance with the National Electrical Code, ANSI/NFPA 70.
Regulatory Information
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Liability
It is expressly understood and agreed that the interface should only be used to control exits from areas where an
alternative method for exit is available. This product is not intended for, nor is rated for operation in life-critical
control applications. LenelS2 is not liable under any circumstances for loss or damage caused by or partially caused
by the misapplication or malfunction of the product.LenelS2’s liability does not extend beyond the purchase price of
the product.
Certifications
For certification information, refer to the hardware documentation for the host application.
Product Warnings and Disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO, AND INSTALLATION BY, AN EXPERIENCED
SECURITY PROFESSIONAL. LENELS2 CANNOT PROVIDE ANYASSURANCE THAT ANY PERSON OR
ENTITY BUYING ITS PRODUCTS, INCLUDING ANY “AUTHORIZED DEALER”, IS PROPERLY TRAINED
OR EXPERIENCED TO CORRECTLY INSTALL SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and product safety information, please check https://
firesecurityproducts.com/en/policy/product-warning or scan the following code:
