NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
VENTED GAS FIREPLACE HEATERS - DIRECT VENT MODELS
P/N 875,021M REV. G 03/2007
MODELS
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
Follow your gas suppliers instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
POURVOTRE SÉCURITÉ: Nepas entreposerni utiliser
d'essencenid'autrevapeursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Netouchezàaucuninterrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installeur,agencede service ou lefournisseurde gaz.
DIRECT VENT
ELITE®SERIES
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
OTL Report No. 116-F-05-5
sledoMtlovilliMsledoMcinortcelE
MNC0353VDEENC0353VDE
MNC5304VDEENC5304VDE
MNC0454VDEENC0454VDE
MPC0353VDEB-ENC0353VDE
MPC5304VDEB-ENC5304VDE
MPC0454VDEB-ENC0454VDE
B-MNC0353VDE B-MNC5304VDE B-MNC0454VDE B-MPC0353VDE B-MPC5304VDE B-MPC0454VDE
A French manual is available upon request. Order Form Number
875,021CF.
Ce manuel d’installation est disponible en francais, simplement
en faire la demande. Numéro de la pièce 875,021CF.
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE. AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
WARNINGS
• Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. Severe burns may result.
• Carefully supervise children in the
same room as appliance.
• If small children are present in the home, it is
recommended that this appliance be fitted with
a screen door or screen panel kit. See
Page 8
for ordering information.

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CONGRATULATIONS!
InselectingthisLENNOXDirect-VentGasApplianceyouhavechosenthefinestandmost
dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a
woodburningfireplace. WelcometoaFamilyoftensofthousandsofsatisfiedLENNOX
Fireplace Owners.
Please read and carefully follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The Homeowner's
Care and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your LENNOX product.
GENERAL INFORMATION
Note:Installationandrepairshouldbeperformed
by a qualified service person. The appliance
shouldbe inspected annuallyby a qualifiedpro-
fessional service technician. More frequent in-
spectionsand cleaningsmay berequired dueto
excessive lint from carpeting, bedding material,
etc. It is imperative that the control compart-
ment, burners and circulating air passage ways
of the appliance be kept clean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les in-
structions d'installation et d'utilisation qui
accompagnent l'appareil.
Provideadequateclearancesaroundairopen-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
Duetohightemperaturestheapplianceshould
be located out of traffic and away from furni-
ture and draperies. Locate furniture and win-
dow coverings accordingly.
Direct-Vent appliances operate with the com-
bustionchambercompletelyisolatedfromthe
inside atmosphere. All air for combustion is
broughtinfromtheoutsideand exhaustgases
are vented through the same direct vent, vent
system.
The millivolt appliances are designed to oper-
ateoneithernaturalorpropanegas.Amillivolt
gas control valve with piezo ignition system
provides safe, efficient operation. External
electrical power is required to operate the
optional electrically powered components if
installed. Electricalpowermustbewireddur-
ing appliance installation.
The electronic appliances are designed to op-
erate on either natural or propane gas. An
electronic intermittent pilot system provides
safe, efficient operation. External electrical
power is required to operate these units.
Theseappliancescomplywith National Safety
Standards and are tested and listed by Omni-
Test Laboratories (Report No. 116-F-05-5) to
ANSI Z21.88-2002 (in Canada, CSA-2.33-
2002), and CAN/CGA-2.17-M91 in both USA
and Canada, as vented gas fireplace heaters.
TheInstallation must conform to localcodes
or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA
54 , or the Natural Gas and Propane Installa-
tionCode,CSAB149.1 . Theappliance,when
installed, must be electrically grounded in
accordance with local codes or, in the ab-
sence of local codes, with the National Elec-
trical Code, ANSI/NFPA 70 , or the Canadian
Electrical Code, CSA C22.1 .
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONANDLISTINGSOFTHISUNIT.
TABLE OF CONTENTS
Introduction............................................ page 2
General Information................................ page 2
Operation/Care of Your Appliance .......... page 3
Variable Flame Adjustment ..................... page 4
Glass Cleaning........................................ page 5
Maintenance ........................................... page 5
Front Glass Enclosure Panel,
Removal and Installation ...................... page 5
Maintenance Schedule............................ page 6
Burner Adjustments................................ page 7
Flame Appearance and Sooting .............. page 7
Adjustment ............................................. page 7
Log Placement........................................ page 8
Decorative Volcanic Stone Placement .... page 9
Millivolt Appliance Checkout................... page 9
Electronic Appliance Checkout ............... page 9
Accessory Components.......................... page 9
Wiring Diagrams .................................... page 14
Warranty................................................. page 14
Replacement Parts ................................. page 14
Product Reference Information .............. page 14
Lighting Instructions –Millivolt.............. page 16
Lighting Instructions –Electronic........... page 18
Troubleshooting Guide –Millivolt ............ page 20
Troubleshooting Guide –Electronic ......... page 21
Replacement Parts List ........................... page 22
WARNING: THESE FIREPLACES ARE
VENTED HEATERS. DO NOT BURN
WOOD OR OTHER MATERIAL IN THESE
APPLIANCES.
WARNING:IMPROPERINSTALLATION,
ADJUSTMENT,ALTERATION, SERVICE
ORMAINTENANCECANCAUSEINJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT
A QUALIFIED INSTALLER, SERVICE
AGENCY OR THE GAS SUPPLIER.
WARNING: ELECTRONIC MODELS OF
THESE APPLIANCES ARE EQUIPPED
WITH A THREE-PRONG (GROUNDING)
PLUG UTILIZED IN CONNECTING THE
ELECTRONIC COMPONENTS TO THE
JUNCTION BOX IN THE LOWER COM-
PARTMENT. THIS GROUNDING PLUG
PROVIDES PROTECTION AGAINST
SHOCK HAZARD AND SHOULD BE
PLUGGED DIRECTLY INTO THE PROP-
ERLY GROUNDED THREE-PRONG RE-
CEPTACLE. DO NOT CUT OR REMOVE
THE GROUNDING PRONG FROM THE
PLUG.
INTRODUCTION
The Fireplace models covered in this manual
are Direct-Vent sealed combustion gas fire-
placeheatersdesignedforresidentialapplica-
tion.

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
thefluwithheadaches,dizziness and/or nau-
sea. If you have these signs, obtain fresh air
immediately. Turn off the gas supply to the
appliance and have it serviced by a qualified
professional, as it may not be operating
correctly.
OPERATION AND CARE OF YOUR
APPLIANCE
Appliance operation may be controlled by the
followingmeans:thefactoryprovidedmodesty
panel-mounted ON-OFF control switch, a re-
motelylocatedoptional wall switchor optional
remote control. The modesty panel mounted
ON-OFF control switch is located behind the
hinged drop-down panel below the appliance
front glass enclosure panel. See Figure 1.
GasControls/ControlCompartmentAccess
The gas controls can be found behind the
hinged drop-down panel.
To open the hinged drop-down panel, actuate
the spring loaded magnetic catches securing
the door. First, gently depress the upper right
top corner of the panel until the magnet catch
"pops" the door free. Then, gently pulling the
panelforward,disengagetheleftmagnetcatch
and allow the panel to swing down to open.
On millivolt systems, the piezo ignitor, Hi/Lo
flameadjustmentknob,andpilotandmaingas
ON/OFF control knob are located on the mod-
esty panel. On both millivolt and electronic
systems the gas valve is located behind the
modesty panel. See
Figure 1.
These appliances are designed to operate
on natural or propane gas only.
Millivolt Models -
Input of millivolt models is shown in the fol-
lowing table:
Electronic Models -
Electronic models have a fixed rate gas valve.
Input of electronic models is shown in the
following table:
Table 1 shows the units' gas orifice size for
theelevationsindicated.
Maximum manifold pressure is 3.5 in. w.c.
(0.87 kPa) for natural gas and 10 in. w.c.
(2.49 kPa) for LP/Propane gas.
Do not use these appliances if any part has
beenunderwater.Immediatelycallaqualified,
professional service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a étéplongé
dansl'eau, complètementou en partie. Appeler
untechnicienqualifiépourinspecterl'appareilet
remplacertoutepartiedusystèmedecontrôleet
toutecommandequiontétéplongésdansl'leau.
Table 1
evlaVsaGetaR-dexiFhtiwsledoMcinortcelE
saGenaporPdnalarutaN
.oNledoM)H/UTB(etartupnI
E53VD03000,72
5304VDE000,03
0454VDE000,33
.oNledoM ezisecifirO noitavelE teeF )sretem(
.taN.porP
0353VDE 04#35# 0054-0 )2731-0(
5304VDE 63#25#
0454VDE 33#15#
WARNING: FAILURE TO COMPLY
WITHTHEINSTALLATION AND OPER-
ATING INSTRUCTIONS PROVIDED IN
THIS DOCUMENT WILL RESULT IN
ANIMPROPERLY INSTALLEDANDOP-
ERATING APPLIANCE, VOIDING ITS
WARRANTY. ANY CHANGE TO THIS
APPLIANCE AND/OR ITS OPERATING
CONTROLS IS DANGEROUS. IM-
PROPER INSTALLATION OR USE OF
THIS APPLIANCE CAN CAUSE SERI-
OUS INJURY OR DEATH FROM FIRE,
BURNS, EXPLOSION OR CARBON
MONOXIDE POISONING.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZ-
ARDS OF HIGH SURFACE TEMPERA-
TURES. USE CAUTION AROUND THE
APPLIANCE TO AVOID BURNS OR
CLOTHING IGNITION. YOUNG CHIL-
DRENSHOULDBECAREFULLYSUPER-
VISED WHEN THEY ARE IN THE SAME
ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTH-
ING OR OTHER FLAMMABLE MATE-
RIALSONOR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LES MEUBLES, L'ESSENCE OU AUTRES
LIQUIDES À VAPEUR INFLAMMABLES
LOIN DE L'APPAREIL.
htiwsledoMtlovilliM evlaVsaGdetaludoM-yllaunaM saGlarutaNsaGenaporP
.oNledoM tupnI etar )H/UTB( .oNledoM tupnI etar )H/UTB(
DEV 0353 000,12 ot 000,72 DEV 0353 007,02 ot 000,72
DEV 5304 005,32 ot 000,03 DEV 5304 002,42 ot 000,03
DEV 0454 000,62 ot 000,33 DEV 0454 005,62 ot 000,33
Test gage connections are provided on the
front of the millivolt gas control valve (identi-
fied OUT for the manifold side and IN for inlet
pressure. A ¹⁄₈" NPT test gage connection is
provided on the electronic gas control valve
adjacent to the outlet to the main burner.
Minimuminletgaspressuretotheseappliances
is5.0 incheswatercolumn(1.24kPa)fornatural
gas and 11 inches water column (2.74 kPa) for
propane for the purpose of input adjustment.
Maximum inlet gas supply pressure to these
appliances is 10.5 inches water column (2.61
kPa) for natural gas and 13.0 inches water col-
umn (3.23 kPa) for propane.
The appliance must be isolated from the gas
supply piping system (by closing its individual
manualshut-offvalve)duringanypressuretest-
ing of the gas supply piping system at test
pressuresequaltoorlessthan¹⁄₂ psig(3.5kPa).
Theapplianceanditsindividualshut-offvalvemust
bedisconnectedfromthegassupplypipingsystem
duringany pressure testing of thatsystem atpres-
sures in excess of ¹⁄₂ psig(3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
Any safety guard or screen removed for ser-
vicing the appliance must be replaced prior
to operating the appliance.

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 3
Honeywell Electronic
Gas Valve
Figure 2
Note: The piezo ignitor is located on the modesty panel - refer to Figure 1.
Variable Flame Height Adjustment
( Millivolt Appliances only)
1. All Millivolt appliances are equipped with a
variable gas control valve. Flame height for
thesemodelsmaybeadjustedthrougharange
between fixed low and high settings, alter-
nately, while the appliance is in operation.
Adjusttheflameheightasdesiredafterlight-
ing the appliance by rotating the variable
adjustmentcontrolknoblocatedonthefront
ofthevalve (refer to Figure 2) .(Anextension
isprovided tothis knobso thatthe adjustment
may be made at the modesty panel.)
2. Whenlitforthefirsttime,thisappliancewill
emit a slight odor for an hour or two. This is
due to the “burn-in”of internal paints and
lubricantsusedinthemanufacturingprocess.
H
I
LO
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
Variable Flame Height Adjustment
Manifold Pressure Port
Inlet Pressure Port
Main Gas
Control Knob
IN OUT
SIT Millivolt Gas Valve
ON/OFF Switch
Electronic
Gas Control
Valve
Inlet
Pressure
Port
Manifold Pressure Port
OFF
IN
PSI
ON
CONTROL
IGNITER
Millivolt Appliances -
To light millivolt appliances refer to the de-
tailed lighting instructions found on page 11
(English) and page 12 (French). Millivolt ap-
pliance lighting instructions may also be
found on the pull out lighting instruction
labels attached to the gas control valve.
Millivoltappliancesarefittedwithan ON/OFF
RockerSwitchfor applianceON/OFF control.
See
Figure 1 for its location. Once the pilot is
lighted,theON/OFFrockerswitchwillcontrol
theapplianceON/OFF operation. Tooperate:
Toggle the switch between its ON and OFF
positions.
If your millivolt appliance is equipped with an
optionalremote wallswitch or remote control
kit and the pilot is lit, the appliance main
burner may be turned on and off with the wall
switch or remote control.
Electronic Appliances -
To light electronic appliances refer to the
detailed lighting instructions found in both
English and French on
pages 13 and 14 of
these instructions respectively. Electronic
appliance lighting instructions may also
be found on the pull out lighting instruction
labels attached to the gas control valve.
Electronic appliances are fitted with an ON/
OFF Rocker Switch for appliance ON/OFF
control. See Figure 1 for its location.
Once the pilot is lighted, the ON/OFF rocker
switch will control the appliance ON/OFF op-
eration. To operate: Toggle the switch be-
tween its ON and OFF positions.
Remove the bottom compartment door by
sliding the hinge pin, located at the door’s left
side, to the right until it disengages from the
left corner post hole. Pull the door diagonally
to the left, away from the fireplace.
Once the control compartment door has been
removed, the modesty panel can be removed
as follows: slide the modesty panel forward
untilitcontactsthecabinetbottompanel,then
lift straight up and tilt forward. Remove the
modesty panel carefully, so that none of the
wires become loose or disconnected. Now
complete access to the gas control valve and
its related controls is attainable.
To ease door closure, depress the catches to
placethemintheirretractedpositionuntilthey
stay there, then close the door.
Operationofmillivoltandelectronicgascon-
trolsystemsaredifferent.Beforelightingand
operating your appliance determine if you
have a millivolt or electronic appliance.
RefertoFigure 1 foraccesstothegascontrol
valve.Millivoltapplianceswillbefittedwiththe
gas control valve shown in Figure 2 .
Appliances with electronic systems will be
fittedwiththeelectronicvalveshownin Figure
3 .Familiarize yourself with the gas control
valve that your appliance uses.
Figure 1
Control Compartment Access -
Millivolt Control Valve Shown
Piezo Ignitor
Gas
Valve
Modesty Panel
Control
Compartment
Access Panel
ON/OFF
Switch
Hinge Pin
If your electronic appliance is equipped with
anoptionalremotewallswitchorremotecon-
trol kit the appliance main burner may be
turned on and off with the wall switch or
remote control.

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Maintenance
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service techni-
cian.However,morefrequentperiodicinspec-
tions and cleanings should be performed by
the homeowner. Homeowner must contact a
qualified service technician at once if any
abnormal condition is observed.
Refer to the maintenance schedule for mainte-
nancetasks,procedures,periodicityandbywhom
theyshouldbeperformed. Alwaysverifyproper
operation of the appliance after servicing.
IMPORTANT: TURN OFF GAS AND ANY
ELECTRICAL POWER BEFORE SERVICING
THE APPLIANCE.
3. Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
Morefrequentcleaningmayberequireddueto
excessivelintfromcarpeting,beddingmateri-
als, etc. It is important that control compart-
ments, burners and circulating air passage-
ways of the appliance be kept clean and clear
of obstruction of venting and combustion air.
4. Always turn off gas to the pilot (millivolt
appliances) before cleaning. Before re-light-
ing, refer to the lighting instructions in this
manual.Instructions are also found on a pull-
outpanellocatedontheflooroftheappliance.
5. Always keep the appliance area clear and
freefromcombustiblematerials,gasolineand
other flammable liquids.
6. Remember,Millivolt applianceshave a con-
tinuous burning pilot flame. Exercise caution
whenusingproductswithcombustiblevapors.
Glass Cleaning
It will be necessary to clean the glass periodi-
cally. Duringstart-upit is normalforconden-
sationto form on the inside of the glass. This
can cause lint, dust and other airborne par-
ticles to cling to the glass surface. Also initial
paint curing may deposit a slight film on the
glass. It is therefore recommended that the
glassbecleanedtwoorthreetimeswithanon-
ammonia household cleaner and warm water
(agasfireplaceglasscleanerisrecommended).
After that the glass should be cleaned two or
three times during each heating season, de-
pending on the circumstances present.
Note: Clean glass after first two weeks of
operation.
WARNING: DO NOT USE ABRASIVE
CLEANERS. NEVER CLEAN THE GLASS
WHEN IT IS HOT.
Front Glass Enclosure Panel, Removal
and Installation
These are direct-vent appliances. They are de-
signed to operate only when the front glass
enclosurepanel is installed. Generallythe front
glass enclosure panel should not be removed
excepttogain accesstothe componentswithin
thefirebox,andtheappliancemayonlybeoper-
ated without the front glass enclosure panel in
placeforverybriefperiodsoftimeduring appli-
ance checkout and adjustment.
During this appliance checkout and adjust-
ment period, a potential safety hazard exists
- EXERCISE EXTREME CAUTION to prevent
the occurrence of any burn injuries from the
exposed flames or hot surfaces.
Alsonote, thatwhile thefront glass enclosure
panel is removed, the flame appearance will
appear to be smaller than normal.
Refer to
Figure 4 and remove the front glass
enclosure panel as follows:
1. Remove the top bustle, and the top louver
assembly or radiant panel.
3. Remove the bottom compartment door by
sliding the hinge pin, located at the door’s left
side,totherightuntilitdisengagesfromtheleft
cornerposthole.Pullthedoordiagonallytothe
left, away from the fireplace.
4. Locate the two (2) latches at the top of the
controlcompartmentanddisengagethemfrom
the floor frame bottom Vee-flange, pulling
down on their handles to open them.
5. Swingthebottomofthedooroutandraise
itslightlytoliftthetopflangeofthedoorframe
away from the appliance.
2. Remove the bottom bustle, and open the
hingeddrop-downcontrolcompartmentpanel.
WARNING: DO NOT OPERATE APPLI-
ANCE WITH THE GLASS FRONT RE-
MOVED, CRACKED OR BROKEN. RE-
PLACEMENT OF THE GLASS SHOULD
BEDONE BYALICENSEDOR QUALIFIED
SERVICE TECHNICIAN.
WARNING: HANDLE THIS GLASS WITH
EXTREMECARE! DONOTSTRIKEDOOR.
TEMPERED GLASS IS SUSCEPTIBLE TO
DAMAGE– DONOTSCRATCHORHANDLE
ROUGHLY WHILE REINSTALLING THE
GLASS DOOR FRAME.
WARNING: NO NOT ATTEMPT TO SUB-
STITUTETHEMATERIALSUSEDONTHIS
DOOR,ORREPLACECRACKEDORBRO-
KEN GLASS WITH ANY MATERIALS
OTHERTHANTHOSEPROVIDED BY THE
APPLIANCE MANUFACTURER.
THEGLASSDOOROFTHISAPPLIANCEMUST
ONLY BE REPLACED AS A COMPLETE UNIT
ASPROVIDED BY THE MANUFACTURER. DO
NOT ATTEMPT TO REPLACE BROKEN,
CRACKEDORCHIPPEDGLASSSEPARATELY.
CAUTION: DO NOT ATTEMPT TO TOUCH THE
FRONT ENCLOSURE GLASS WITH YOUR
HANDS WHILE THE FIREPLACE IS IN USE.

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior
Check Flame Patterns and Flame Height
Checking Vent System
Cleaning Front Glass Enclosure Panel
Homeowner
Homeowner
Homeowner
Homeowner
Carefullyremovelogs,rockwoolanddecora-
tivevolcanicstone and vermiculite. Vacuum
outinteriorofthefirebox. Cleanfireboxwalls
and log grate. Replace logs, Rockwool and
volcanic stone as detailed in this manual.
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Check Flame Patterns and Flame Height
Inspecting/Cleaning Pilot and Burner
Checking Vent System
Appliance Checkout
Replacing Rockwool Ember Materials
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Homeowner/Qualified Services Technician
Inspectvalve andensure itis properlyoperat-
ing. Check piping for leaks. Vacuum the
controlcompartment,fireplacelogsandburner
area.
Referto
Figures 6 (EDV3530), 7 (EDV4035)
or 8 (EDV4540) on page 7 and verify the
flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the logs.
Referto Figure9(SIT)orFigure10(Honeywell)
on page 8 . Remove any surface build-up on
pilotandburnerassembly.Wipethepilotnozzles,
ignitor/flame rod and hood. Ensure the pilot
flame engulfs the flame sensor as shown.
Inspect the vent system at the top and at the
base(withinthe firebox) forsignsofblockage
orobstruction. Look for any signs of disloca-
tion of the vent components.
Perform the appropriate appliance checkout
procedure detailed in this manual.
Remove old ember materials and vacuum the
rockwoolplacementarea. Placenewrockwool
as described in this document.
Maintenance Schedule
Annually (Before the onset of the Burning Season)
Clean as necessary following the directions
providedinthismanual. DO NOT TOUCH OR
ATTEMPT TO CLEAN GLASS WHILE HOT.
Inspect the vent system at the top and at the
base (within the firebox) for signs of block-
age or obstruction. Look for any signs of
dislocation of the vent components.
Refer to Refer to Figures 6 (EDV3530), 7
(EDV4035) or 8 (EDV4540) on page 7 and
verifythe flame patternand height displayed
by the appliance conforms to the picture.
Flames must not impinge on the logs.

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ENSURE THAT THE FRONT GLASS PANEL IS IN
PLACE AND SEALED DURING ADJUSTMENT.
Figure 4
Burner Adjustments
The following paragraphs address burner ad-
justment concerns and procedures.
Flame Appearance and Sooting
Proper flame appearance is a matter of taste.
Generallymostpeoplepreferthewarmglowof
a yellow to orange flame. Appliances operated
withair shutteropenings thatare toolarge will
exhibit flames that are blue and transparent.
These weak, blue and transparent flames are
termedanemic.Iftheairshutteropeningistoo
small sooting may develop.
Sooting is indicated by black puffs developing
at the tips of very long orange flames. Sooting
results in black deposits forming on the logs,
appliance inside surfaces and on exterior sur-
faces adjacent to the vent termination.
Sootingiscaused by incompletecombustionin
theflamesandalackofcombustionairentering
the air shutter opening. To achieve a warm
yellowtoorangeflamewithanorangebodythat
does not soot, the shutter opening must be
adjustedbetweenthesetwoextremes. Nosmoke
orsootshouldbepresent.Repositionthelogsif
the flames impinge on any of them.
If the logs are properly positioned and sooting
conditions exist, the air shutter opening on the
mainburnertubeshouldbeadjusted.Normally,
the more offsets in the vent system, the greater
theneedfortheairshuttertobeopenedfurther.
Glass Door Latch
Lower Compartment Door and Hinge
Glass Door
Firebox Floor
Bottom Vee-flange
Glass Door Frame
Top Flange
Glass Door Frame
Modesty Panel
Adjustment
CAUTION: THE ADJUSTMENT ROD AND
NEARBY APPLIANCE SURFACES ARE HOT.
EXERCISECAUTIONTOAVOIDINJURYWHILE
ADJUSTING FLAME APPEARANCE.
To adjust the flame, move the adjustment rod
(located in the lower control area) back or
forward to increase or reduce the air shutter
opening,respectively.Positionthe air shutter
to the factory setting as shown in
Figure5 on
page7 .Allowtheburnertooperateforatleast
15 minutes. Observe the flame continuously.
If it appears weak or sooty as previously de-
scribed, adjust the air shutter by pushing or
pulling on the adjustment rod until the flame
appearance is as desired.
Theadjustmentrodandassociatedadjustableair
shutter is patented technology. Flame adjust-
ments can be made quickly and accurately to
taste without the need of disassembling the
appliance and waiting for 30 minutes after each
adjustment.
Propane models may exhibit a flame pattern
that may candle or appear stringy. If this is
problematic or persists as the appliance is
continually operated, adjust the air shutter
closed as described in the previous para-
graphs. Operate the appliance for a period of
timeastheeffectdiminishes,ensuringthatthe
appliance does not develop sooty flames.
When satisfied that the appliance operates
properly, proceed to finish the installation.
Leave the control knob in “ON”position and
turnthe remote switch “OFF.”Close the lower
control compartment door.
1. Retrieve the glass door frame. Visually
inspectthegasketonthebacksideofthepanel.
The gasket surface must be clean, free of ir-
regularities and seated firmly.
2. Position the door frame in front of the
firebox opening and engage the top flange
over the lip at the top of the firebox opening.
3. Swing the door down and back. Ensure the
gasketseatsevenlyasthedoordrawsshut. Engage
the Vee-flange at the bottom of the door with the
latches and close the latches to secure the door.
4. Reinstall the bottom compartment door by
insertingtherightsidelocatingpinintotheright
cabinetcornerpostandthentheleftsidespring-
loaded pin into the left cabinet corner post.
5. Reinstallthetopandbottombustle,andthe
top louver assembly or radiant panel.
To install the front glass enclosure panel,
proceed as follows:
WARNING:AIRSHUTTERADJUSTMENT
SHOULD ONLY BE PERFORMED BY A
QUALIFIED PROFESSIONAL SERVICE
TECHNICIAN.

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Log Placement
Carefully position the ceramic fiber logs and twigs over the burner as shown in Figures 6
(EDV3530), 7 (EDV4035) or 8 (EDV4540) on this page. Refer to the detailed log placement
instructions provided in the LOG PLACEMENT GUIDE accompanying this document.
Figure 8
Propertwigplacementiscritical to preventsooting. Twigsshouldbeplacedin the gapsbetween
the flame peaks and should be positioned so that at no time they impinge the flames.
Figure 6
Figure 7
EDV3530
EDV4035
EDV4540
Figure 5
RENRUBNIAM GNITTESGNINEPORETTUHSYROTCAF
sledoM saGlarutaN )mm(sehcni saGenaporP )mm(sehcni
0353VDE
8/1)2.3(
8/3)5.9(
5304VDE)5.9(8/3
0454VDE)5.9(8/3
Air Shutter
Opening
Burner
Venturi
Tube
Air
Shutter
Door
Orifice
Increase
Air Shutter
Opening
Decrease
Air Shutter
Opening
Air Shutter
Adjusting
Arm
WARNING: LOGS GET VERY HOT AND
WILL REMAIN HOT UP TO ONE HOUR
AFTER GAS SUPPLY IS TURNED OFF.
HANDLEONLY WHEN LOGS ARE COOL.
TURN OFF ALL ELECTRICITY TO THE
APPLIANCE BEFORE YOU INSTALL
GRATE AND LOGS.
WARNING: THIS APPLIANCE IS NOT
MEANTTOBURN WOOD. ANY ATTEMPT
TO DO SO COULD CAUSE IRREPARABLE
DAMAGE TO YOUR APPLIANCE AND
PROVE HAZARDOUS TO YOUR SAFETY.
WARNING: THE SIZE AND POSITION OF
THE LOG SET WAS ENGINEERED TO
GIVE YOUR APPLIANCE A SAFE, RELI-
ABLE AND ATTRACTIVE FLAME PAT-
TERN. ANYATTEMPTTOUSEADIFFER-
ENT LOG SET IN THE FIREPLACE WILL
VOID THE WARRANTY AND WILL RE-
SULT IN INCOMPLETE COMBUSTION,
SOOTING, AND POOR FLAME QUALITY.

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 9
Electronic Appliance Checkout
To light the burner, refer to the lighting instruc-
tionson
page13and14 . Ensuretheignitorlights
thepilot.Thepilotflameshouldengulftheflame
sensor as shown in
Figure 10 .
Figure 10
With proper care and maintenance, your appli-
ancewillprovidemanyyearsofenjoyment.Ifyou
shouldexperienceanyproblem,firstrefertothe
troubleshootingguideinthismanual.Ifproblem
persists, contact your Lennox distributor.
Glowing Embers (Rockwool) Placement
Refer to the detailed glowing embers place-
mentinstructionsprovidedintheLOGPLACE-
MENT GUIDE accompanying this document.
Ceramic Panel Placement
Referto thedetailed ceramicpanel placement
instructionsprovidedintheLOG PLACEMENT
GUIDE accompanying this document.
Millivolt Appliance Checkout
Thepilotflameshould besteady,notlifting or
floating. Flame should be blue in color with
traces of orange at the outer edge.
Thetop³⁄₈" (10mm)at thepilotgenerator (ther-
mopile)andthetop¹⁄₈"min(tip)ofthequickdrop
outthermocoupleshouldbeengulfedinthepilot
flame. The flame should project 1" (25 mm)
beyondthehoodatallthreeports.See
Figure 9.
To light the burner, refer to the lighting instruc-
tions on
pages 11 and 12.
ACCESSORY COMPONENTS
Remote Control System (Standard) H0249 RCL
Standard Remote Control System
The Model RCL (Standard) Remote Control
System,featuresasimpleOn/Offcontrolfunc-
tion for the fireplace. This model includes a
hand-held transmitter, a remote receiver with
wall-mount coverplate and all hardware re-
quired to install the unit. The remote receiver
can be wall or hearth mounted.
Deluxe Remote Control System
The Model RCL-T (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screen which presents access to many en-
hancements, including; battery power level in-
dicator,timer,modeofoperation,thermostatic
display including room temperature in either
metric of English units, flame indicator and
clock. Fully programmable, the Model RCL-T
allowsforcommandovernearlyalloperational
andtemperaturevariables,usingthehandheld
remote control transmitter.
Remote Control System (Deluxe) H0251 RCL-T
The kits attach to the glass enclosure panel
without the use of hardware. The decorative
arch kits can not be used in conjunction with
the screen panel kit.
MILLIVOLT
Thermocouple
Hood Ignitor Rod
³⁄₈" Min
(9 mm)
Thermopile
Pilot
Nozzels
ELECTRONIC
Proper Flame
Adjustment
Pilot
Nozzle
3/8 To 1/2 Inch
(9 mm to 13 mm)
Ground
Electrode
Flame Rod
Hot Surface
Igniter
stiKrooDhcrA
.oNledoM
.oNgolataC .oNledoM
dehsiloP ssarB dehsurB sselniatS
0353VDE 43L18 BPC53KDA 86L89 SBC53KDA
5304VDE 53L18 BPC04KDA 96L89 SBC04KDA
0454VDE 63L18 BPC54KDA 07L89 SBC54KDA
Flame Modulating Remote Control
FlameModulatingRemoteControlswerede-
veloped to provide a safe, reliable and user-
friendly remote control system for appli-
ancesequippedwith a MillivoltGasValve. A
detailedsetofinstructionsareincludedwith
each remote.
Flame Modulating Remote Control
– Natural Gas H0301 RCL-MN
Flame Modulating Remote Control
– LP/Propane Gas H0302 RCL-ML

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
These louvers are designed to replace the
standard charcoal louvers that are provided
with the appliance. The brass and brushed
stainless louver kits include six (6) louvers.
Forced Air Blower Kits
-Single Speed 80L84 FBK-100
-Variable Speed with
wall-mountable switch 80L85 FBK-200
-Variable Speed with
unit-mountable switch 80L86 FBK-250
ACCESSORY COMPONENTS CONTINUED
Clean faced panel kits are available to convert
thestandardlouveredfireplacestoradiantmod-
els which are more suited for finishing around
the firebox opening with non-combustible
materials, such as tile.
Thesehoodkitsreplacethestandardhoodthat
comes with these fireplaces.
Thesekitsaredesignedtoattachdirectlytothe
front face of the fireplace at the four edges of
the glass enclosure panel.
Forced Air Kit
TheFBK-100blowerprovidesconstantvelocity
forced air circulation. The FBK-200 assembly
with variable speed, wall-mountable switch
provides variable speed forced air circulation.
The FBK-250 assembly with variable speed
unit-mountable switch, also provides variable
speed forced air circulation.
These kits are easy to install and do not
requirehardware toattach themto thestan-
dard glass door frame.They can not be used
in conjunction with the screen panel kit.
(FBK-200 Models Only)
stiKlenaPecaFnaelC
.oNledoM .oNgolataC .oNledoM
0353VDE 63L88 2-C53DAR
5304VDE 73L88 2-C04DAR
0454VDE 83L88 2-C54DAR
stiKrevuoLdelbmessA
.oNledoM
.oNgolataC .oNledoMdehsiloP ssarB dehsurB sselniatS
0353VDE 82L88 2-BP53RVL 23L88 SB53RVL
5304VDE 92L88 2-BP04RVL 33L88 SB04RVL
0454VDE 03L88 2-BP54RVL 43L88 SB54RVL
stiKdooH
.oNledoM
.oNgolataC .oNledoMdehsiloP ssarB dehsurB sselniatS
0353VDE 76K69 BP53BE 94L88 SB53BE
5304VDE 86K69 BP04BE 05L88 SB04BE
0454VDE 96K69 BP54BE 15L88 SB54BE
stiKemarFrooDeceiP-4
.oNledoM
.oNgolataC .oNledoM
dehsiloP ssarB dehsurB sselniatS
0353VDE 44L88 BP53EKTD 07L09 SB53EKTD
5304VDE 54L88 2-BP04KTD 17L09 SB04KTD
0454VDE 64L88 2-BP54KTD 27L09 SB54KTD
stiKmirTrooDenaP-niwT
.oNledoM
.oNgolataC .oNledoM
dehsiloP ssarB dehsurB sselniatS
0353VDE 28M02 BP53-KDPT 58M02 SB53-KDPT
5304VDE 38M02 BP04-KDPT 68M02 SB04-KDPT
0454VDE 48M02 BP54-KDPT 78M02 SB54-KDPT

11
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Touch-Up Paint (Charcoal) Kit 90L74 TPK-C
Touch-Up Paint (Tan) Kit 98K67 TPK-T
Touch-Up Paint Kit
Repairofminor scratchesanddiscoloration of
theappliancecharcoalpaintedsurfacesmaybe
accomplished with the touch-up paint kit.
Bag of Glowing Embers 88L53 FGE
Bag of Glowing Embers
Replacementember materials are available for
use with these appliances. Order a bag of
Glowing Embers, Model FGE to replace ember
materialsaspartoftheperiodicmaintenanceof
the appliance.
ACCESSORYCOMPONENTSCONTINUED
The2-piecepolishedbrassorbrushedstain-
lesslouverkitsmaybeusedtoreplaceeither
the middle charcoal louver of each louver
set,orthecharcoallouverineachlouverset
closest to the glass door.
stiKrevuoLeceiP-2
.oNledoM
.oNgolataC .oNledoM
dehsiloP ssarB dehsurB sselniatS
0353VDE 50L69 BP53RVL2 90L69 SB53RVL2
5304VDE 60L69 BP04RVL2 01L69 SB04RVL2
0454VDE 70L69 BP54RVL2 11L69 SB54RVL2
This kit contains brass trim pieces used to
finish the gaps between the wall board and
thefireplace,providingtheapplianceabrass
perimeter highlight.
stiKmirThsiniF
.oNledoM
.oNgolataC .oNledoM dehsiloP ssarB
0353VDE 4540H 3BPE53KT
5304VDE 22K69 3BP04KT
0454VDE 32K69 3BP54KT
Thebrickaded panel liner kits includeceramic
panelsofthesidewalls,therearandthebaffle
of the firebox. The panels have brick-like
features in relief.
Thesescreenpanelscanbeinstalledontheglass
enclosure panel to provided protection from
the hot glass surface. The screen panel kits
cannot be used in conjunction with either of the
arch door kits or door frame kits.
stiKlenaPneercS
.oNledoM .oNgolataC .oNledoM
0353VDE 25L88 E53GH
5304VDE 23K69 04GH
0454VDE 33K69 54GH
stiKreniLlenaPdedakcirB
.oNledoM .oNgolataC .oNledoM
0353VDE 5770H 53-KLBE
5304VDE 6770H 04-KLBE
0454VDE 7770H 54-KLBE
ON/OFF Wall Switch Kit 85L87 FWSK
ON/OFF Wall Switch Kit
The ON/OFF wall switch kit may be used to
controlthe operation ofthe fireplaceburner as
an alternative to the modesty panel mounted
ON-OFF switch. Install the ON/OFF wall switch
in a convenient location near the fireplace.

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Style View Doors -
Style View Doors come in 4 beautiful styles. They are easy to install and will not require hardware to attach them to the standard
glass door frame. The door includes heavy duty magnet door latches and functional twin-pane doors.
Arch Design
Arch Pane Design Square Pane Design
Square Design
ARCH DESIGN KITS
Cat. No. Model Description Model Series
H0862 AD40C 40” Arch Doors, Charcoal
EDV4035
H0863 AD40TI 40” Arch Doors, Textured Iron
H0864 AD40SP 40” Arch Doors, Satin Pewter
H0865 AD40AB 40” Arch Doors, Antique Brass
H0866 AD45C 45” Arch Doors, Charcoal
EDV4540
H0867 AD45TI 45” Arch Doors, Textured Iron
H0868 AD45SP 45” Arch Doors, Satin Pewter
H0869 AD45AB 45” Arch Doors, Antique Brass
H0870 AD35EC 35” Elite Arch Doors, Charcoal
EDV3530
H0871 AD35ETI 35” Elite Arch Doors, Textured Iron
H0872 AD35ESP 35” Elite Arch Doors, Satin Pewter
H0873 AD35EAB 35” Elite Arch Doors, Antique Brass
ARCH PANE DESIGN KITS
H0934 APD40C 40” Arch Pane Doors, Charcoal
H0935 APD40TI 40” Arch Pane Doors, Textured Iron
H0936 APD40SP 40” Arch Pane Doors, Satin Pewter
H0937 APD40AB 40” Arch Pane Doors, Antique Brass
H0938 APD45C 45” Arch Pane Doors, Charcoal
H0939 APD45TI 45” Arch Pane Doors, Textured Iron
H0940 APD45SP 45” Arch Pane Doors, Satin Pewter
H0941 APD45AB 45” Arch Pane Doors, Antique Brass
H0942 APD35EC 35” Elite Arch Pane Doors, Charcoal
H0943 APD35ETI 35” Elite Arch Pane Doors, Textured Iron
H0944 APD35ESP 35” Elite Arch Pane Doors, Satin Pewter
H0945 APD35EAB 35” Elite Arch Pane Doors, Antique Brass
EDV4035
EDV4540
EDV3530
SQUARE DESIGN KITS
Cat. No. Model Description Model Series
H0950 SD40C 40” Sq. Doors, Charcoal
H0951 SD40TI 40” Sq. Doors, Textured Iron
H0952 SD40SP 40” Sq. Doors, Satin Pewter
H0953 SD40AB 40” Sq. Doors, Antique Brass
H0954 SD45C 45” Sq. Doors, Charcoal
H0955 SD45TI 45” Sq. Doors, Textured Iron
H0956 SD45SP 45” Sq. Doors, Satin Pewter
H0957 SD45AB 45” Sq. Doors, Antique Brass
H0958 SD35EC 35” Elite Sq. Doors, Charcoal
H0959 SD35ETI 35” Elite Sq. Doors, Textured Iron
H0960 SD35ESP 35” Elite Sq. Doors, Satin Pewter
H0961 SD35EAB 35” Elite Sq. Doors, Antique Brass
SQUARE PANE DESIGN KITS
H0966 SPD40C 40” Sq. Pane Doors, Charcoal
H0967 SPD40TI 40” Sq. Pane Doors, Textured Iron
H0968 SPD40SP 40” Sq. Pane Doors, Satin Pewter
H0969 SPD40AB 40” Sq. Pane Doors, Antique Brass
H0970 SPD45C 45” Sq. Pane Doors, Charcoal
H0971 SPD45TI 45” Sq. Pane Doors, Textured Iron
H0972 SPD45SP 45” Sq. Pane Doors, Satin Pewter
H0973 SPD45AB 45” Sq. Pane Doors, Antique Brass
H0974 SPD35EC 35” Elite Sq. Pane Doors, Charcoal
H0975 SPD35ETI 35î Elite Sq. Pane Doors, Textured Iron
H0976 SPD35ESP 35” Elite Sq. Pane Doors, Satin Pewt.
H0977 SPD35EAB 35” Elite Sq. Pane Doors, Ant. Brass
EDV4035
EDV4540
EDV3530
EDV4035
EDV4540
EDV3530
ACCESSORY COMPONENTS CONTINUED

13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS CONTINUED
Tall Arch Pane Door
Style View Doors Continued -
Style View Doors also come in a Tall Arch Pane Design. Two distinctive grille kits, the “Crescents”and “Sunrise”design, are
also offered seperately. They are easy to install and will not require hardware to attach them to the standard glass door frame.
The door includes heavy duty magnet door latches and functional twin-pane doors.
“Crescents” Grille Kits “Sunrise” Grille Kits
TALL ARCH PANE DOORS
Cat. No. Model Description Model Series
H3537 TAPD35EC 35” Elite Arch Pane Doors, Charcoal EDV3530
H3539 35” Elite Arch Pane Doors, Satin Pewter
40” Arch Pane Doors, Charcoal EDV4035
40” Arch Pane Doors, Satin Pewter
45” Arch Pane Doors, Charcoal EDV4540
45” Arch Pane Doors, Satin Pewter
TAPD35ESP
H3529 TAPD40C
H3531 TAPD40SP
H3533 TAPD45C
H3535 TAPD45SP
“Crescents” Grille Kits
Cat. No. Model Description Model Series
H3541 CUGK35C 35” Crescents Upper Grille Kit, Charcoal
EDV3530
H3543 35” Crescents Upper Grille Kit, Satin Pewter
CUGK35SP
H3545 CLGK35C 35” Crescents Lower Grille Kit, Charcoal
H3547 35” Crescents Lower Grille Kit, Satin Pewter
CLGK35SP
H3549 CUGK40C 40” Crescents Upper Grille Kit, Charcoal
EDV4035
H3551 40” Crescents Upper Grille Kit, Satin Pewter
CUGK40SP
H3553 CLGK40C 40” Crescents Lower Grille Kit, Charcoal
H3555 40” Crescents Lower Grille Kit, Satin Pewter
CLGK40SP
H3557 CUGK45C 45” Crescents Upper Grille Kit, Charcoal
EDV4540
H3559 45” Crescents Upper Grille Kit, Satin Pewter
CUGK45SP
H3561 CLGK45C 45” Crescents Lower Grille Kit, Charcoal
H3563 45” Crescents Lower Grille Kit, Satin Pewter
CLGK45SP
“Sunrise” Grille Kits
Cat. No. Model Description Model Series
H3565 SUGK35C 35” Sunrise Upper Grille Kit, Charcoal
EDV3530
H3567 35” Sunrise Upper Grille Kit, Satin Pewter
SUGK35SP
H3569 SLGK35C 35” Sunrise Lower Grille Kit, Charcoal
H3571 35” Sunrise Lower Grille Kit, Satin Pewter
SLGK35SP
H3573 SUGK40C 40” Sunrise Upper Grille Kit, Charcoal
EDV4035
H3575 40” Sunrise Upper Grille Kit, Satin Pewter
SUGK40SP
H3577 SLGK40C 40” Sunrise Lower Grille Kit, Charcoal
H3579 40” Sunrise Lower Grille Kit, Satin Pewter
SLGK40SP
H3581 SUGK45C 45” Sunrise Upper Grille Kit, Charcoal
EDV4540
H3583 45” Sunrise Upper Grille Kit, Satin Pewter
SUGK45SP
H3585 SLGK45C 45” Sunrise Lower Grille Kit, Charcoal
H3587 45” Sunrise Lower Grille Kit, Satin Pewter
SLGK45SP
Thisscreen panel kitcan beinstalled on the glass enclosure panel to prevent direct contact with the
hot glass surface. The panel kit adds a new design choice with a handsome textured iron finish. The
screen panel kit cannot be used in conjunction with either of the arch door kits or door frame kits.
Arch Screen Panel Kit Model No. Catalog No.
40" Decorative Arch Screen Panel Kit - Textured Iron DASPK40TI H3594

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARRANTY
Your gas appliance is covered by a limited
twenty year warranty. You will find a copy of
the warranty accompanying this manual.
Pleasereadthewarrantytobefamiliarwithits
coverage.
Retain this manual. File it with your other
documents for future reference.
REPLACEMENT PARTS
Acompletepartslistisfoundattheendofthis
manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
yourLennoxdistributor or dealer.Parts will be
shipped at prevailing prices at time of order.
If you encounter any problems or have any
questions concerning the installation or appli-
cation of this system, please contact your dis-
tributor, or Lennox directly:
LENNOX HEARTH PRODUCTS
1110 West Taft Avenue
Orange, CA 92865
PRODUCT REFERENCE INFORMATION
Werecommend that you record thefollowingimportantinformationaboutyourfireplace. Please
contactyourLennoxdealerforanyquestionsorconcerns. ForthenumberofyournearestLennox
dealer, please call 1-800-9-LENNOX.
Your Fireplace's Model Number _______________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed __________________________
The Type of Gas Your Fireplace Uses ___________________________________
Your Dealer's Name_________________________________________________
When ordering repair parts, always give the
following information:
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
WIRING DIAGRAMS
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
provided on schematics attached directly to
theapplianceonapulloutpanellocatedwithin
the control compartment.
CAUTION: LABEL ALL WIRES PRIOR TO DIS-
CONNECTION WHEN SERVICING CONTROLS.
WIRINGERRORSCANCAUSEIMPROPERAND
DANGEROUS APPLIANCE OPERATION.
Thermopile
TH
TP TH
TP
Millivolt Wiring Diagram
If any of the original wire as supplied must be replaced,
it must be replaced with Type AWM 105°C – 18 GA. wire.
*OR OPTIONAL WALL-MOUNTED ON/OFF SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE CONTROL RECEIVER
Factory Wired
Field Wired
Schematic Representation Only
APPLIANCE-MOUNTED ON/OFF SWITCH
*Turn the appliance-mounted ON/OFF burner control switch
to the OFF position if an optional
control switch is installed.
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
BK
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-250 Kits
R
WH
BL
W
Gas Valve
B
R
IGNITER
BK
Schematic Representation Only
*ON/OFF Switch (Integral
with Gas Valve)
Optional
FBK-250
Module
*Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
G
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
OR OPTIONAL WALL SWITCH OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
PILOT
ASSEMBLY
OPT
BLOWER
Junction Box
White
Green
Red
Black
Neutral
Side of
Receptacle
Tab Intact
Green
Ground
Screw
Hot
Side of
Receptacle
Ta b
Broken
Optional
Accessory
Switch
120 VAC - Black
n
e
e
r
G-dn
u
o
r
Ge
ti
h
W
-
lar
t
u
e
N
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C – 18 GA. wire.
2. 120V, 60Hz – Less than 3 amps.
BK
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-100 and FBK-200 Kits
R
W
BL
W
Gas Valve
B
R
IGNITER
BK
*Blower speed control switch is provided in FBK200 blower kit.
Schematic Representation Only
**ON/OFF Switch (Integral
with Gas Valve) **Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
OR OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
G
OPT
BLOWER
PILOT
ASSEMBLY
Junction Box
White
Green
Red
Black
Neutral
Side of
Receptacle
Tab Intact
Green
Ground
Screw
Hot
Side of
Receptacle
Ta b
Broken
120 VAC - Black
n
e
e
r
G-dn
u
o
r
G
Optional
Accessory
Switch
e
ti
h
W
-
lar
t
u
e
N

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
NOTES:

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
LIGHTING INSTRUCTIONS – MILLIVOLT GAS VALVE
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a piezo
ignitor. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.”The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.”Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B”in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark ignitor (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 ¹⁄₂ minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released,
stop and immediately call your service
technician or gas supplier.
•If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or
gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician.
Force or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT”to “OFF”
unless the knob is pushed in slightly. Do not force.
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY
RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT
INSTRUCTIONS D'ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez aucune
odeur de gaz autour de l’apareil ainsi que près du sol; certains gaz,
étant plus lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez àaucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelez immédiatement votre compagnie de gaz en utilisant le
téléphone du voisin.
•S’ilvousestimpossibledecontactervotrecompagniedegaz,appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de
bouger, n’essayez pas de le réparer. Communiquez immédiatement
avec un technicien de service qualifié. Toute tentative pour le forcer
ou le réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergédans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a étésous l’eau.
1. Tournez l’interrupteur mural àla position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural àla
position d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz à
étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à8
inclusivement.
• Si le bouton ne sort pas automatiquement après avoir été
relâché, arrêtez immédiatement et
téléphonez àvotre technicien de
service ou àvotre fournisseur de gaz.
• Si la veilleuse refuse de rester
allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à
sa position d’arrêt “OFF”et
téléphonez àvotre technicien de
service ou àvotre fournisseur de gaz.
9. Tournez le bouton de réglage du gaz en sens inverse des aiguilles
d’une montre jusqu’à sa position de marche “ON”.
10. Fermez le compartiment de contrôle du bas.
11. Au besoin, rebrancher l’appareil au courant électrique et remettre
l’interrupteur du brûleur principal àla position “ON”ou régler le
thermostat àla température désirée.
12. Si l’appareil ne fonctionne pas, suivre les instructions intitulées
“Pour fermer le gaz qui alimente l’appareil”et appeler un
technicien ou le fournisseur de gaz.
Remarque: Il est impossible de tourner le bouton de “PILOT”à“OFF”à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B”des
consignes de sécuritéau verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez àl’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de
veilleuse “PILOT”.
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
1. ARRÊTEZ! Lisez les consignes de sécuritéau verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural àla position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale
est ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
•Do not use any phone in your building.
FOR YOUR SAFETY READ BEFORE LIGHTING
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try to
repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
LIGHTING INSTRUCTIONS — ELECTRONIC
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
3. Turn the ON/OFF switch to “OFF”. Do not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
TO TURN OFF GAS TO APPLIANCE
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
5. Turn the ON/OFF switch to “OFF”. Do not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B”in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Turn the ON/OFF switch to “ON”. Do not force.
8. Turn “ON”all electrical power to appliance (remote wall
switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
ON/OFF Switch
OFF
IN
PSI
ON
CONTROL
IGNITER
Front View
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE — ELECTRONIC
INSTRUCTIONS D’ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Lorsquevousallumezl’appareil,suivezexactementcesinstruc-
tions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez
aucune odeur de gaz autour de l’apareil ainsi que près du sol;
certainsgaz,étantpluslourdsquel’air,descendentauniveaudu
sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE
ODEUR DE GAZ
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez àaucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelezimmédiatementvotrecompagniedegazenutilisant
le téléphone du voisin.
•S’il vous est impossible de contacter votre compagnie de
gaz, appelez le service des incendies.
C. N’utilisez que votre main pour manipuler linterrupteur “ON/
OFF”de la valve àgaz. N’utilisez jamais d’outils. Si
l’interrupteur ne bouge pas manuellement, n’essayez pas de le
réparer. Communiquez immèdiatement avec un technicien de
service qualifié. Toute tentative pour forcer l’interrupteur ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Nevousservezpas decet appareilsi l’unde seséléments aété
immergédans l’eau. Appelez immédiatement un technicien
compétent pour faire inspecter l’appareil et remplacer toute
piècedusystèmederéglageoucommandedugazquiaétésous
l’eau.
1. ARRÊTEZ ! Lisez les consignes de sécuritéau verso de cette
plaque.
2. Tournez l’interrupteur mural àla position d’arrêt “OFF”.
3. Ouvrez la porte du compartiment de contrôle du bas.
4. Assurez-vousquelasoupaped’arrêtdelacanalisationprincipale
est ouverte.
5. Tournezlamanettederéglagedugazàlapositiond’arrêt“OFF”.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous
décelezuneodeurdegaz ARRÊTEZ! Retournezaupoint“B”des
consignes de sécuritéau verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez àl’étape suivante.
7. Tournezlamanettederéglagedugazjusqu’àlapositiondemarche
“ON”. Ne la forcez pas.
8. Ouvrez le courant électrique (“ON”) qui alimente l’appareil
(interrupteurmural).
9. Fermez la porte du compartiment de contrôle du bas.
10. Au besoin, rebrancher l’apareil au courant électrique et
remettre l’interrupteur principal du brûleur àla position “ON”
ou régler le thermostat àla température désirée.
11. Si l’appareil ne se met pas en marche, suivre les instructions
intitulées “Pour fermer le gaz qui alimente l’appareil”et appeler
un technicien ou le fournisseur de gaz.
POUR ÉTEINDRE L’APPAREIL
1. Coupeztoutlecourantélectriquequialimentel’appareil(interrupteur
mural).
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
3. Tournezlamanettederéglagedugazàlapositiond’arrêt“OFF”.
Ne la forcez pas.
4. Fermez la soupape d’arrêt de la canalisation principale.
5. Fermez la porte du compartiment de contrôle du bas.
1. Pourunefermeturecomplète,tournezl’interrupteur mural àla
position d’arrêt “OFF”.
2. Ouvrez la porte du compartiment de contrôle du bas.
Interrupteur
ON/OFF
OFF
IN
PSI
ON
CONTROL
IGNITER
Vue de face
AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
1. Spark ignitor will not light
pilot after repeated
triggering of ignitor button.
2. Pilot will not stay lit after
carefully following the
lighting instructions.
3. Pilot burning, no gas to
burner, Valve knob “ON,”
Wall Switch “ON.”
4. Frequent pilot/burner outage
problem.
CORRECTIVE ACTIONSYMPTOM
A. Defective ignitor
(no spark at electrode).
B. Defective or misaligned electrode
at pilot (spark at electrode).
C. Gas supply pressure errant.
D. Pilot orifice plugged.
A. Defective pilot generator
(thermocouple).
A. Wall switch or wires defective.
B. Thermopile may not be generating
sufficient millivoltage.
C. Plugged burner orifice.
A. Pilot flame may be too low or
blowing (high) causing the pilot/
valve safety to drop out.
Check for spark at electrode and pilot; if no spark and
electrode wire is properly connected, replace ignitor.
POSSIBLE CAUSES
Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in
the “ON”position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
Clean and/or adjust pilot flame for maximum flame impinge-
ment on thermocouple
(Figure 9 on page 8) .
Check burner orifice for stoppage and remove.
Checkthermopilewithmillivoltmeter.Takereadingatthermo-
pile terminals of gas valve. Should read 325 millivolts mini-
mum with optional wall switch “OFF.”Replace faulty thermo-
pile if reading is below specified minimum.
Check wall switch and wires for proper connections. Jumper
wire across terminals at wall switch, if burner comes on,
replacedefectivewallswitch.Ifokay,jumperwiresacrosswall
switch wires at valve, if burner comes on, wires are faulty or
connections are bad.
Check pilot flame, it must impinge on thermocouple
(Figure
9 on page 8)
Clean and/or adjust pilot for maximum flame
impingement on thermocouple. Ensure that the connection
between the valve and thermocouple are tight and secure.
Clean or replace pilot orifice.
Check inlet gas pressure. It should be within the limits as
marked on the rating plate.
Using a match, light pilot. If pilot lights, turn off pilot and
triggertheignitorbuttonagain.Ifpilotlights,animpropergas
mixture caused the bad lighting and a longer purge period is
recommended. If pilot will not light –check gap at electrode
and pilot –should be ¹⁄₈" to have a strong spark. If gap
measures ¹⁄₈", replace pilot
(Figure 9 on page 8) .
