Lenovo Gemplus 41N3005 User manual

GemplusGemPCSmartCardReader from
Lenovo
User’s Guide

GemplusGemPCSmartCardReader from
Lenovo
User’s Guide

Note: Before using this information and the product it supports, read the information in
“Service and Support” on page 9and “Lenovo Statement of Limited Warranty” on page
11
First Edition (December 2005)
©Copyright Lenovo 2005.
Portions ©Copyright International Business Machines Corporation 2003.
All rights reserved.
U.S. GOVERNMENT USERS –RESTRICTED RIGHTS: Our products and/or services are provided with
RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule
contract with Lenovo Group Limited, if any, or the standard terms of this commercial license, or if the agency is
unable to accept this Program under these terms, then we provide this Program under the provisions set forth in
Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in
Data-General, FAR 52.227.14 (Alternate III).

Contents
Preface ...............v
Registering your option ..........v
Chapter 1. Introduction ........1
Chapter 2. Installation.........3
Installing the Gemplus GemPC Smart Cardreader
writer.................3
Windows XP and Windows 2000.......3
Installing and using the Gemplus SmartDiag
diagnostic tool..............4
Chapter 3. Uninstalling the Gemplus
SmartDiag diagnostic tool .......5
Specifications ............7
Service and Support .........9
Online technical support ..........9
Telephone technical support .........9
Lenovo Statement of Limited Warranty 11
Part 1-General Terms...........11
Part 2-Country-unique Terms ........13
Part 3-Warranty Information ........23
Warranty Period ............23
Types of Warranty Service ........23
Worldwide telephone list .........24
Guarantee supplement for Mexico .......27
Notices ..............29
Trademarks ..............30
Electronic emission notices .........30
©Lenovo 2005. Portions ©IBM Corp. 2003. iii

iv Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Preface
This user’s guide provides information on the Gemplus GemPC Smart Card
Reader from Lenovo.
Your option package contains the following:
vGemplus GemPC Smart CardReader from Lenovo
vGemplus GemPC Smart Card Reader from Lenovo CD containing the device drivers,
the Gemplus SmartDiag diagnostic tool, and this user’s guide
vQuick Installation Guide
Contact your place of purchase if an item is missing or damaged. Be sure to retain
your proof of purchase and packing material. They might be required to receive
warranty service.
Registering your option
Thank you for purchasing this Lenovo
™ product. Please take afew moments to
register your product and provide us with information that will help Lenovo to
better serve you in the future. Your feedback is valuable to us in developing
products and services that are important to you, as well as in developing better
ways to communicate with you. Register your option on the following Web site:
http://www.lenovo.com/register
Lenovo will send you information and updates on your registered product unless
you indicate on the Web site questionnaire that you do not want to receive further
information.
©Lenovo 2005. Portions ©IBM Corp. 2003. v

vi Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Chapter 1. Introduction
The Gemplus GemPC Smart Card Reader from Lenovo incorporates smart cards
into IBM compatible PC’s equipped with aPC Card slot. The smart card reader
writer is ahigh-performance, compact and lightweight device that can handle a
wide range of functions for various applications, such as computer security,
network security, banking, and telecommunications.
The Gemplus GemPC Smart Card Reader from Lenovo supports most memory and
microprocessor cards currently on the market and because of its general-purpose
architecture, embossed cards can be used. The smart card reader writer is
compatible with all cards that meet ISO 7816-1, -2, -3, and 7811 standards
(embossed card) with T=0 and T=1 protocols. With its Plug and Play installation,
the smart card reader writer is ready for use with Microsoft
® Windows ® XP and
Windows 2000 Professional.
The device driver supports the following operating systems:
vWindows 2000 Professional
vWindows XP
©Lenovo 2005. Portions ©IBM Corp. 2003. 1

2Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Chapter 2. Installation
This chapter provides instructions for installing the Gemplus GemPC Smart Card
Reader from Lenovo and the Gemplus SmartDiag diagnostic tool. This chapter also
includes instructions on updating the device driver.
Installing the Gemplus GemPC Smart Card reader writer
This section contains instructions for installing the Gemplus GemPC smart card
reader writer for Microsoft Windows XP and Microsoft Windows 2000 Professional.
Note: To verify if newer versions of this installation software are available, visit
the Lenovo Web site at http://www.lenovo.com/think/support for the latest
software and documentation.
Windows XP and Windows 2000
To install the Gemplus GemPC smart cardreader writer for Windows XP or
Windows 2000, complete the following procedure:
1. Insert the CD for the Gemplus GemPC Smart CardReader from Lenovo that
comes with your option in the computer.
2. After inserting the CD, the User’s Guide Software CD screen automatically
opens. On the left side of the screen, click Software.
3. Click on Install Device Drivers. The Gemplus GemPC Smart CardReader
Installer Window will pop up.
4. Click Next.
5. Read through the End User Licensing Agreement and if you agree with the
terms and conditions of the agreement, select ″Iaccept the terms in the
agreement″,and click Next.
6. Choose an install directory and click Next.
7. Click Finish.
8. Insert the Gemplus GemPC Smart CardReader from Lenovo in your computer,
(As shown below).
Smart
Reader
Card
9. Your option is ready for use.
For information on the Gemplus SmartDiag diagnostic tool, see “Installing and
using the Gemplus SmartDiag diagnostic tool” on page 4.
©Lenovo 2005. Portions ©IBM Corp. 2003. 3

Installing and using the Gemplus SmartDiag diagnostic tool
The Gemplus SmartDiag diagnostic tool reports softwareor hardwareproblems
and provide troubleshooting information. If the displayed information does not
solve the problem, you can generate adiagnostic report for technical support.
The diagnostic tool verifies the availability of the following:
vOperating system services that support smart cards
vGemplus GemPC Smart cardreaders
vGemplus GemPC Smart cards
To install the Gemplus SmartDiag diagnostic tool, complete the following
procedure:
1. Insert the Lenovo Smart Card Reader Writer CD into the CD-ROM drive.
2. From the computer desktop, click Start →Run.
3. In the Open: field, type d:\smartdiag\setup,where dis the CD-ROM drive.
4. Click OK.
5. Follow the instructions on the screen to continue the installation.
To start the diagnostic tool, click Start →Programs →Gemplus →SmartDiag →
SmartDiag .
Note: To view the Help documentation for the diagnostic tool, click Start →
Programs →Gemplus →SmartDiag →SmartDiag →Help.
4Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Chapter 3. Uninstalling the Gemplus SmartDiag diagnostic
tool
This chapter provides instructions for uninstalling the Gemplus SmartDiag
diagnostic tool.
To remove the Gemplus SmartDiag diagnostic tool, complete the following
procedures:
1. From the computer desktop, click Start →Settings →Control Panel.
2. Double-click Add/Remove Programs.
3. Select Lenovo Smart Card Reader Tools.
4. Click Add/Remove or Change/Remove.
©Lenovo 2005. Portions ©IBM Corp. 2003. 5

6Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Specifications
Following arespecifications for the Gemplus GemPC Smart Card Reader from
Lenovo.
Table 1. Physical specifications
Form factor PC Card Type II
Dimensions 3.4″x2.16″x0.2″(85 mm x54 mm x5mm)
Weight 29 g
Table 2. Electrical specifications
Operating voltage 5.0 V+/ -10 %
Power consumption Idle: 4mA (average value)
Operating mode: 25 mA max (average value)
Standby mode: 150uA
Communication speed with card 9600bps -3445 bps
Table 3. Compatibility
Operating system Windows 2000 Professional
Windows XP
Smart card All cards that meet ISO 7816-1, -2, -3, -4 with T=0 and
T=1 protocols.
Table 4. Certifications and standards
Microsoft PC/SC
Microsoft hardware compatibility list
Table 5. Regulatory and safety
Safety USA/Canada UL, cUL
Europe EN 60950
EMI USA FCC part 15 Class B
Canada CSA950
Europe EN 55022, 50082-1
EN 50081-1
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
Japan VCCI
Taiwan BSMI
©Lenovo 2005. Portions ©IBM Corp. 2003. 7

8Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Service and Support
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of the product. Refer to
your Lenovo Statement of Limited Warranty for afull explanation of Lenovo
warranty terms.
Online technical support
Online technical support is available during the life of your product through the
Lenovo Support Web site at http://www.lenovo.com/think/support.
During the warranty period, assistance for replacement or exchange of defective
components is available. In addition, if your option is installed in aLenovo
computer, you might be entitled to service at your location. Your technical support
representative can help you determine the best alternative.
Telephone technical support
Installation and configuration support through the Customer Support Center will
be withdrawn or made available for afee, at Lenovo’s discretion, 90 days after the
option has been withdrawn from marketing. Additional support offerings,
including step-by-step installation assistance, are available for anominal fee.
To assist the technical support representative, have available as much of the
following information as possible:
vOption name
vOption number
vProof of purchase
vComputer manufacturer, model, serial number, and manual
vExact wording of the error message (if any)
vDescription of the problem
vHardware and software configuration information for your system
If possible, be at your computer. Your technical support representative might want
to walk you through the problem during the call.
For alist of Service and Support phone numbers, see “Worldwide telephone list”
on page 24. Phone numbers are subject to change without notice. For the most
current phone numbers, go to http://www.lenovo.com/think/support and click
Support phone list.If the number for your country or region is not listed, contact
your reseller or Lenovo marketing representative.
©Lenovo 2005. Portions ©IBM Corp. 2003. 9

10 Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide

Lenovo Statement of Limited Warranty
LSOLW-00 05/2005
Part 1-General Terms
This Statement of Limited Warranty includes Part 1-General Terms, Part 2-Country-unique Terms, and Part 3-
Warranty Information. The terms of Part 2replace or modify those of Part 1. The warranties provided by Lenovo
Group Limited or one of its subsidiaries (called ″Lenovo″)in this Statement of Limited Warranty apply only to
Machines you purchase for your use, and not for resale. The term “Machine” means aLenovo machine, its options,
features, conversions, upgrades or peripheral products, or any combination of them. The term “Machine” does not
include any software programs, whether pre-loaded with the Machine, installed subsequently or otherwise. Nothing
in this Statement of Limited Warranty affects any statutory rights of consumers that cannot be waived
or limited by contract.
What this Warranty Covers
Lenovo warrants that each Machine 1) is free from defects in materials and workmanship and 2)
conforms to Lenovo’s Official Published Specifications (“Specifications”) which are available on request.
The warranty period for the Machine starts on the original date of installation and is specified in Part 3-
Warranty Information. The date on your invoice or sales receipt is the date of installation unless Lenovo
or your reseller informs you otherwise. Unless Lenovo specifies otherwise, these warranties apply only in
the country or region in which you purchased the Machine.
THESE WARRANTIES ARE YOUR EXCLUSIVE WARRANTIES AND REPLACE ALL OTHER
WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OF EXPRESS OR IMPLIED WARRANTIES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO
YOU. IN THAT EVENT, SUCH WARRANTIES ARE LIMITED IN DURATION TO THE WARRANTY
PERIOD. NO WARRANTIES APPLY AFTER THAT PERIOD. SOME STATES OR JURISDICTIONS
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
What this Warranty Does not Cover
This warranty does not cover the following:
vany software programs, whether pre-loaded or shipped with the Machine, or installed subsequently;
vfailure resulting from misuse, accident, modification, unsuitable physical or operating environment, or
improper maintenance by you;
vfailure caused by aproduct for which Lenovo is not responsible; and
vany non-Lenovo products, including those that Lenovo may procure and provide with or integrate into
aLenovo Machine at your request.
The warranty is voided by removal or alteration of identification labels on the Machine or its parts.
Lenovo does not warrant uninterrupted or error-free operation of aMachine.
Any technical or other support provided for aMachine under warranty, such as assistance with "how-to"
questions and those regarding Machine set-up and installation, is provided WITHOUT WARRANTIES
OF ANY KIND.
How to Obtain Warranty Service
Warranty service may be provided by Lenovo, IBM, your reseller if authorized to perform warranty
service, or an authorized warranty service provider. Each of them is referred to as a“Service Provider.”
©Lenovo 2005. Portions ©IBM Corp. 2003. 11

If the Machine does not function as warranted during the warranty period, contact aService Provider. If
you do not register the Machine with Lenovo, you may be required to present proof of purchase as
evidence of your entitlement to warranty service.
What Lenovo Will Do to Correct Problems
When you contact aService Provider for service, you must follow the problem determination and
resolution procedures that we specify. An initial diagnosis of your problem can be made either by a
technician over the telephone or electronically by access to asupport website.
The type of warranty service applicable to your Machine is specified in Part 3-Warranty Information.
You are responsible for downloading and installing designated software updates from asupport web site
or from other electronic media, and following the instructions that your Service Provider provides.
Software updates may include basic input/output system code (called “BIOS”), utility programs, device
drivers, and other software updates.
If your problem can be resolved with aCustomer Replaceable Unit (“CRU”) (e.g., keyboard, mouse,
speaker, memory, hard disk drive), your Service Provider will ship the CRU to you for you to install.
If the Machine does not function as warranted during the warranty period and your problem cannot be
resolved over the telephone or electronically, through your application of software updates, or with a
CRU, your Service Provider, will either, at its discretion, 1) repair it to make it function as warranted, or
2) replace it with one that is at least functionally equivalent. If your Service Provider is unable to do
either, you may return the Machine to your place of purchase and your money will be refunded.
As part of the warranty service, your Service Provider may also install selected engineering changes that
apply to the Machine.
Exchange of aMachine or Part
When the warranty service involves the exchange of aMachine or part, the item your Service Provider
replaces becomes Lenovo’s property and the replacement becomes yours. You represent that all removed
items are genuine and unaltered. The replacement may not be new, but will be in good working order
and at least functionally equivalent to the item replaced. The replacement assumes the warranty service
status of the replaced item.
Your Additional Responsibilities
Before your Service Provider exchanges aMachine or part, you agree to remove all features, parts,
options, alterations, and attachments not under warranty service.
You also agree to:
1. ensure that the Machine is free of any legal obligations or restrictions that prevent its exchange;
2. obtain authorization from the owner to have your Service Provider service aMachine that you do not
own; and
3. where applicable, before service is provided:
a. follow the service request procedures that your Service Provider provides;
b. backup or secure all programs, data, and funds contained in the Machine; and
c. provide your Service Provider with sufficient, free, and safe access to your facilities to permit
Lenovo to fulfill its obligations.
4. (a) ensure all information about identified or identifiable individuals (Personal Data) is deleted from
the Machine (to the extent technically possible), (b) allow your Service Provider or asupplier to
process on your behalf any remaining Personal Data as your Service Provider considers necessary to
fulfill its obligations under this Statement of Limited Warranty (which may include shipping the
Machine for such processing to other service locations around the world), and (c) ensure that such
processing complies with any laws applicable to such Personal Data.
12 Gemplus GemPC Smart Card Reader from Lenovo:User’s Guide
