Lenovo V530S-07ICR
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo V530s-07ICR
11BM002MIX o cerca il tuo prodotto tra le migliori offerte di PC Desktop e Workstation

Read this first
Before using this documentation and the roduct it su orts, ensure that you read and understand the
following:
• A endix A “Im ortant safety information” on age 65
• Safety and Warranty Guide
• Setup Guide
First Edition (September 2019)
© Copyright Lenovo 2019
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered ursuant to a General Services
Administration “GSA” contract, use, re roduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
About this documentation iii
Chapter 1 Meet your computer 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 3
System board . . . . . . . . . . . . . . . . 5
Features and s ecifications . . . . . . . . . . . 6
Statement on USB transfer rate . . . . . . . . 7
Chapter 2 Get started with your
computer 9
Get started with Windows 10 . . . . . . . . . . 9
Windows account . . . . . . . . . . . . . 9
Windows user interface . . . . . . . . . . 10
Connect to networks . . . . . . . . . . . . . 11
Connect to the wired Ethernet . . . . . . . 11
Connect to Wi-Fi networks (for selected
models) . . . . . . . . . . . . . . . . 11
Use Lenovo Vantage . . . . . . . . . . . . . 11
Use multimedia . . . . . . . . . . . . . . . 12
Use audio . . . . . . . . . . . . . . . 12
Chapter 3 Explore your computer 13
Manage ower . . . . . . . . . . . . . . . 13
Set ower button behaviors . . . . . . . . 13
Set the ower lan . . . . . . . . . . . . 13
Transfer data . . . . . . . . . . . . . . . . 13
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . 13
Use the o tical drive (for selected models) . . 14
Use a media card (for selected models). . . . 14
Use a smart cable cli . . . . . . . . . . . . 15
Purchase accessories . . . . . . . . . . . . 15
Chapter 4 Secure your computer
and information 17
Lock the com uter . . . . . . . . . . . . . 17
Log in to your com uter securely . . . . . . . . 17
Use asswords . . . . . . . . . . . . . 18
Use the finger rint reader . . . . . . . . . 18
Use software security solutions. . . . . . . . . 19
Use firewalls . . . . . . . . . . . . . . 19
Use antivirus rograms . . . . . . . . . . 20
Use com utrace Agent software embedded in
firmware (for selected models) . . . . . . . 20
Use BIOS security solutions . . . . . . . . . . 20
Erase all storage drive data . . . . . . . . 20
Use the cover resence switch . . . . . . . 21
Use Smart USB Protection. . . . . . . . . 21
Chapter 5 UEFI BIOS 23
What is UEFI BIOS. . . . . . . . . . . . . . 23
Enter the BIOS menu. . . . . . . . . . . . . 23
Navigate in the BIOS interface . . . . . . . . . 23
Set the system date and time . . . . . . . . . 23
Change the startu sequence . . . . . . . . . 24
Enable or disable the configuration change
detection feature . . . . . . . . . . . . . . 24
Enable or disable the automatic ower-on
feature . . . . . . . . . . . . . . . . . . 25
Enable or disable the ErP LPS com liance mode . . 25
Change BIOS settings before installing a new
o erating system . . . . . . . . . . . . . . 25
U date UEFI BIOS. . . . . . . . . . . . . . 26
Recover from a BIOS u date failure . . . . . . . 26
Clear CMOS . . . . . . . . . . . . . . . . 27
Chapter 6 Troubleshooting,
diagnostics, and recovery 29
Basic rocedure for resolving com uter
roblems . . . . . . . . . . . . . . . . . 29
Troubleshooting . . . . . . . . . . . . . . 29
Startu roblems . . . . . . . . . . . . 30
Audio roblems . . . . . . . . . . . . . 31
Network roblems . . . . . . . . . . . . 32
Performance roblems . . . . . . . . . . 34
Storage drive roblems . . . . . . . . . . 35
CD or DVD roblems . . . . . . . . . . . 35
Serial connector roblems . . . . . . . . . 36
USB device roblems . . . . . . . . . . 36
Software roblems. . . . . . . . . . . . 37
Diagnostics . . . . . . . . . . . . . . . . 37
Lenovo diagnostic tools . . . . . . . . . . 37
Lenovo Vantage . . . . . . . . . . . . . 37
Recovery . . . . . . . . . . . . . . . . . 37
Restore system files and settings to an earlier
oint . . . . . . . . . . . . . . . . . 37
Restore your files from a backu . . . . . . 38
Reset your com uter . . . . . . . . . . . 38
Use advanced o tions . . . . . . . . . . 38
Windows automatic recovery. . . . . . . . 38
Create and use a recovery USB device . . . . 38
U date the device driver . . . . . . . . . 39
Chapter 7 CRU replacement 41
What are CRUs . . . . . . . . . . . . . . . 41
© Co yright Lenovo 2019 i

Re lace a CRU . . . . . . . . . . . . . . . 41
Com uter cover . . . . . . . . . . . . . 42
Front bezel . . . . . . . . . . . . . . . 42
O tical drive . . . . . . . . . . . . . . 43
Storage drive . . . . . . . . . . . . . . 45
M.2 solid-state drive . . . . . . . . . . . 49
Coin-cell battery. . . . . . . . . . . . . 51
Memory module . . . . . . . . . . . . . 53
PCI Ex ress card . . . . . . . . . . . . 55
Power su ly assembly . . . . . . . . . . 57
Com lete the arts re lacement . . . . . . 58
Chapter 8 Help and support 61
Self-hel resources . . . . . . . . . . . . . 61
Call Lenovo . . . . . . . . . . . . . . . . 62
Before you contact Lenovo . . . . . . . . 62
Lenovo Customer Su ort Center . . . . . . 62
Purchase additional services. . . . . . . . . . 63
Appendix A Important safety
information 65
Appendix B Accessibility and
ergonomic information 79
Appendix C Supplemental
information about the Ubuntu operating
system 83
Appendix D Compliance
information 85
Appendix E Notices and
trademarks 97
ii Lenovo V530S-07ICR User Guide

About this documentation
• Illustrations in this documentation might look different from your roduct.
• De ending on the model, some o tional accessories, features, and software rograms might not be
available on your com uter.
• De ending on the version of o erating systems, some user interface instructions might not be a licable
to your com uter.
• Documentation content is subject to change without notice. Lenovo makes constant im rovements on the
documentation of your com uter, including this User Guide. To get the latest documentation, go to:
htt s://su ort.lenovo.com
• Microsoft® makes eriodic feature changes to the Windows® o erating system through Windows U date.
As a result, some information in this documentation might become outdated. Refer to Microsoft resources
for the latest information.
© Co yright Lenovo 2019 iii

iv Lenovo V530S-07ICR User Guide

Chapter 1 Meet your computer
Front
1. O tical drive eject/close button Eject or close the o tical drive tray.
2. O tical drive activity indicator This indicator is on when the o tical drive is in use.
3. SD-card slot*
Su orted cards:
• Secure Digital (SD) card
• Secure Digital eXtended-Ca acity (SDXC) USH-1 card
• Secure Digital High-Ca acity (SDHC) USH-1 card
Note: Your com uter does not su ort the content rotection for recordable
media (CPRM) feature for the SD card.
See “Use a media card (for selected models)” on age 14.
4. Storage drive activity indicator This indicator is on when the storage drive is in use.
© Co yright Lenovo 2019 1

5. Power button
Press to turn on the com uter.
To turn off the com uter, o en the Start menu, click Power, and then select
Shut down.
The indicator in the ower button shows the system status of your com uter.
• On: The com uter is on.
• Off: The com uter is off or in hibernation mode.
• Blinking: The com uter is in slee mode.
6. Micro hone connector Connect a micro hone.
7. Headset connector Connect a headset or head hones to your com uter.
8. USB 3.1 connectors Gen 1 (4) Connect USB-com atible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB rinter.
* for selected models
2Lenovo V530S-07ICR User Guide

Rear
1. Audio line-out connector
Send audio signals from the com uter to external devices, such as owered
stereo s eakers, head hones, or multimedia keyboards. To connect a stereo
system or other external recording device, connect a cable between the audio
line-in connector of the device and the audio line-out connector of the com uter.
Note: If your com uter has both an audio line-out connector and a headset or
head hone connector, always use the headset or head hone connector for
ear hones, head hones, or a headset. The head hone connector does not
su ort headset micro hones.
2. HDMI™ 1.4 out connector
Send audio and video signals from the com uter to another audio or video device,
such as a high- erformance monitor. For more information, see htt s://
www.hdmi.org/manufacturer/hdmi_1_4/index.as x.
3. Dis layPort 1.2 out connector
Send audio and video signals from the com uter to another audio or video device,
such as a high- erformance monitor. For more information, see htt s://
www.vesa.org/w -content/u loads/2010/12/Dis layPort-DevCon-Presentation-DP-
1.2-Dec-2010-rev-2b. df.
4. VGA-out connector Send video signals from the com uter to another video device, such as a monitor.
5. USB 2.0 connectors (2) Connect USB-com atible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB rinter.
6. USB 3.1 connectors Gen 1 (2) Connect USB-com atible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB rinter.
7. Power cord connector Connect the ower cord to your com uter for ower su ly.
Cha ter 1.Meet your com uter 3

8. Serial connector Connect an external modem, a serial rinter, or other devices that use a serial
connector.
9. Ethernet connector
Connect to a local area network (LAN). When the green indicator is on, the
com uter is connected to a LAN. When the yellow indicator blinks, data is being
transmitted.
10. Smart cable cli slots (3) Lock devices (such as the keyboard and the mouse) to your com uter through a
smart cable cli .
11. Padlock loo Lock the com uter cover through a adlock.
12. Security-lock slot Lock your com uter to a desk, table, or other fixtures through a Kensington-style
cable lock.
13. Serial connector* Connect an external modem, a serial rinter, or other devices that use a serial
connector.
14. PCI-Ex ress card area
Install PCI-Ex ress cards into this area to im rove the o erating erformance of
the com uter. De ending on the com uter model, the connectors in this area
vary.
* for selected models
4Lenovo V530S-07ICR User Guide

System board
1 4- in ower connector 2 Micro rocessor socket
3 Micro rocessor fan connector 4 Coin-cell battery
5 Buzzer 6 Memory slot (DIMM1)
7 Memory slot (DIMM2) 8 6- in ower connector
9 Internal s eaker connector 10 Clear CMOS (Com lementary Metal Oxide
Semiconductor) / Recovery jum er
11 Storage drive activity indicator connector 12 Thermal sensor connector
13 M.2 solid-state drive slot 14 M.2 Wi-Fi card slot
15 SATA connector (connecting to the storage drive) 16 SATA ower connector
17 SATA connector (connecting to the o tical drive) 18 Card reader connector
19 Serial (COM2) connector 20 PCI Ex ress x16 gra hics card slot
21 PCI Ex ress x1 card slot 22 Parallel connector
Cha ter 1.Meet your com uter 5

Features and specifications
Dimensions
• Width: 100.0 mm (3.9 inches)
• Height: 274.8 mm (10.8 inches)
• De th: 304.4 mm (12.0 inches)
Weight (without the package) Maximum configuration as shi ed: 4.2 kg (9.3 lb)
Hardware configuration
1. Right-click the Start button to o en the Start context menu.
2. Click Device Manager. Ty e the administrator assword or rovide
confirmation if rom ted.
Power supply • 180-watt automatic voltage-sensing ower su ly
Electrical input • In ut voltage: From 100 V ac to 240 V ac
• In ut frequency: 50/60 Hz
Microprocessor To view the micro rocessor information of your com uter, right-click the Start
button and then click System.
Storage device
• 3.5-inch storage drive*
• 2.5-inch storage drive*
• M.2 solid-state drive*
To know the storage drive ca acity:
1. Right-click the Start button to o en the Start context menu.
2. Click Disk Management.
Note: The storage drive ca acity indicated by the system is less than the nominal
ca acity.
Video features
• The integrated gra hics card su orts the following:
– Dis layPort 1.2 out connector
– HDMI 1.4 out connector
– VGA-out connector
• The o tional discrete gra hics card rovides an enhanced video ex erience
and extended ca abilities.
Audio features
• The integrated audio card su orts the following:
– Audio line-out connector
– Headset connector
– Internal s eaker*
– Micro hone connector
• The o tional discrete audio card rovides an enhanced audio ex erience and
extended ca abilities.
6Lenovo V530S-07ICR User Guide

Expansion
• Card reader*
• M.2 solid-state drive slot
• Memory slots
• O tical drive*
• PCI Ex ress x1 card slot
• PCI Ex ress x16 gra hics card slot
• Storage drive bay
Network features
• Bluetooth*
• Ethernet LAN
• Wireless LAN*
* for selected models
Statement on USB transfer rate
De ending on many factors such as the rocessing ca ability of the host and eri heral devices, file
attributes, and other factors related to system configuration and o erating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corres onding device.
USB device Data rate (Gbit/s)
3.1 Gen 1 5
3.1 Gen 2 10
3.2 20
Cha ter 1.Meet your com uter 7

8Lenovo V530S-07ICR User Guide

Chapter 2 Get started with your computer
Get started with Windows 10
Learn the basics of Windows 10 and start working with it right away. For more information about Windows
10, see the Windows hel information.
Windows account
To use the Windows o erating system, a user account is required. It can either be a Windows user account
or a Microsoft account.
Windows user account
When you start Windows for the first time, you are rom ted to create a Windows user account. This first
account you created is of the “Administrator” ty e. With an Administrator account, you can create additional
user accounts or change account ty es by doing the following:
1. O en the Start menu and select Settings ➙ Accounts ➙ Family & other users.
2. Follow the on-screen instructions.
Microsoft account
You can also log in to the Windows o erating system with a Microsoft account.
To create a Microsoft account, go to the Microsoft sign-u age at htt s://signu .live.com and follow the on-
screen instructions.
With a Microsoft account, you can:
• Enjoy one-time signing in if you are using other Microsoft services, such as OneDrive, Sky e, and Outlook.
com.
• Sync ersonalized settings across other Windows-based devices.
© Co yright Lenovo 2019 9

Windows user interface
1. Account Change account settings, lock the com uter, or sign out from the current account.
2. Documents O en the Documents folder, a default folder to save your received files.
3. Pictures O en the Pictures folder, a default folder to save your received ictures.
4. Settings Launch Settings.
5. Power Shut down, restart, or ut the com uter into slee mode.
6. Start button O en the Start menu.
7. Windows Search Ty e what you are looking for in the search box and get search results from your
com uter and the Web.
8. Task View Dis lay all o ened a s and switch among them.
9. Windows notification area Dis lay notifications and status of some features.
10. Battery status icon Dis lay ower status and change battery or ower settings. When your com uter
is not connected to ac ower, the icon changes to .
11. Network icon Connect to an available wireless network and dis lay the network status. When
connected to a wired network, the icon changes to .
12. Action center Dis lay the latest notifications from a s and rovide quick access to some
features.
Open the Start menu
• Click the Start button.
• Press the Windows logo key on the keyboard.
Open the Start context menu
Right-click the Start button.
10 Lenovo V530S-07ICR User Guide

Access Control Panel
• O en the Start menu and click Windows System ➙ Control Panel.
• Use Windows Search.
Launch an app
• O en the Start menu and select the a you want to launch.
• Use Windows Search.
Connect to networks
Your com uter hel s you connect to the world through a wired or wireless network.
Connect to the wired Ethernet
Connect your com uter to a local network through the Ethernet connector on your com uter with an
Ethernet cable.
Connect to Wi-Fi networks (for selected models)
1. Click the network icon in the Windows notification area. A list of available wireless networks is dis layed.
2. Select a network to connect. Provide required information if needed.
Use Lenovo Vantage
The reinstalled Lenovo Vantage is a customized one-sto solution to hel you maintain your com uter with
automated u dates and fixes, configure hardware settings, and get ersonalized su ort.
Access Lenovo Vantage
O en the Start menu and click Lenovo Vantage. You also can ty e Lenovo Vantage in the search box.
To download the latest version of Lenovo Vantage, go to Microsoft Store and search by the a name.
Key features
Lenovo Vantage makes eriodic u dates of the features to kee im roving your ex erience with your
com uter.
Note: The available features vary de ending on the com uter model.
• System Update
Download and install firmware and driver u dates to kee your com uter u -to-date. You can configure
the o tions to install u dates automatically when available.
• Hardware Settings
Configure intelligent settings of the following hardware to make your com uter smarter to use:
– Camera
– Com uter dis lay
Cha ter 2.Get started with your com uter 11

– Eye Care Mode
The Eye Care Mode tool reduces the blue light emitted from the dis lay and thus creates a less
stimulating image and more relaxing vision ex erience for your eyes. For details, go to:
htt s://www.lenovo.com/blue-light
– Keyboard
– Micro hone
– S eakers
• Health & Support
Monitor your com uter health and get ersonalized su ort of your com uter. You can:
– Scan the com uter hardware and diagnose hardware roblems.
– Look u com uter warranty status (online).
– Access User Guide.
– Read ti s and tricks articles customized for your com uter.
• Lenovo Wi-Fi Security
Protect your com uter from malicious Wi-Fi networks.
Use multimedia
Use your com uter for business or entertainment with the devices (such as a camera, a monitor, or
s eakers).
Use audio
To enhance the hearing enjoyment, connect s eakers, head hones, or a headset to the audio connector.
Adjust the volume
1. Click the volume icon in the Windows notification area on the taskbar.
2. Follow the on-screen instructions to adjust the volume. Click the s eaker icon to mute the audio.
Change the sound settings
1. Go to Control Panel and view by category.
2. Click Hardware and Sound ➙ Sound.
3. Change the settings as you refer.
12 Lenovo V530S-07ICR User Guide

Chapter 3 Explore your computer
Manage power
Use the information in this section to achieve the best balance between erformance and ower efficiency.
Set power button behaviors
You can define what the ower button does according to your reference. For exam le, by ressing the
ower button, you can turn off the com uter or ut the com uter to slee or hibernation mode.
To change what the ower button does:
1. Go to Control Panel and view by large icons or small icons.
2. Click Power Options ➙ Choose what the power buttons do.
3. Change the settings as you refer.
Set the power plan
For ENERGY STAR® com liant com uters, the following ower lan takes effect when your com uters have
been idle for a s ecified duration:
Table 1. Default power plan (when plugged into ac power)
• Turn off the dis lay: After 10 minutes
• Put the com uter to slee : After 25 minutes
To awaken the com uter from Slee mode, ress any key on your keyboard.
To reset the ower lan to achieve the best balance between erformance and ower saving:
1. Go to Control Panel and view by large icons or small icons.
2. Click Power Options, and then choose or customize a ower lan of your reference.
Transfer data
Quickly share your files using the built-in Bluetooth technology among devices with the same features. You
also can install a disc or media card to transfer data.
Connect to a Bluetooth-enabled device (for selected models)
You can connect all ty es of Bluetooth-enabled device to your com uter, such as a keyboard, a mouse, a
smart hone, or s eakers. The devices must be within a short distance, usually 10 meters (33 feet), from the
com uter.
1. Turn on Bluetooth on the com uter.
a. O en the Start menu, and then click Settings ➙ Devices ➙ Bluetooth & other devices.
b. Turn on the Bluetooth switch.
2. Click Add Bluetooth or other device ➙ Bluetooth.
3. Select a Bluetooth device, and then follow the on-screen instructions.
© Co yright Lenovo 2019 13

Your Bluetooth device and com uter will automatically connect the next time if the two devices are in range
of each other with Bluetooth turned on. You can use Bluetooth for data transfer or remote control and
communication.
Use the optical drive (for selected models)
If your com uter has an o tical drive, read the following information.
Know the type of your optical drive
1. Right-click the Start button to o en the Start context menu.
2. Click Device Manager. Ty e the administrator assword or rovide confirmation if rom ted.
Install or remove a disc
1. With the com uter on, ress the eject/close button on the o tical drive. The tray slides out of the drive.
2. Insert a disc into the tray or remove a disc from the tray, and then ress the eject/close button again to
close the tray.
Note: If the tray does not slide out of the drive when you ress the eject/close button, turn off the com uter.
Then, insert a straightened a er cli into the emergency-eject hole adjacent to the eject/close button. Use
the emergency eject only in an emergency.
Record a disc
1. Insert a recordable disc into the o tical drive that su orts recording.
2. Do one of the following:
• O en the Start menu, and then click Settings ➙ Devices ➙ AutoPlay. Select or turn on Use
AutoPlay for all media and devices.
• O en Windows Media Player.
• Double-click the ISO file.
3. Follow the on-screen instructions.
Use a media card (for selected models)
If your com uter has a SD-card slot, read the following information.
Install a media card
1. Locate the SD-card slot.
2. Ensure that the metal contacts on the card are facing that in the SD-card slot. Insert the card firmly into
the SD-card slot until it is secured in lace.
Remove a media card
Attention: Before removing a media card, eject the card from the Windows o erating system first.
Otherwise, data on the card might get corru ted or lost.
1. Click the triangular icon in the Windows notification area to show hidden icons. Then, right-click the
Safely Remove Hardware and Eject Media icon.
2. Select the corres onding item to eject the card from the Windows o erating system.
3. Press the card and remove it from your com uter. Store the card safely for future use.
14 Lenovo V530S-07ICR User Guide
